Desa SPC-15R User manual

Infra-Red Heater Tank Top Heater
Owner’s Manual
MODELS
SPC-15R, HD15A, N15A, AND TT15A
10,000-15,000 BTU
SPC-30R, HD30, AND TT30
10,000-30,000 BTU
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to appli-
ance.
2. Extinguish any open
flame.
FOR YOUR SAFETY
Do not store or use gaso-
line or other flammable
vapors and liquids in the
vicinity of this or any other
appliance.
WARNING CARBON MONOXIDE HAZARD
This appliance can produce carbon mon-
oxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed
space such as a camper, tent, car, or home.
Save this manual for future reference.
For more information, visit www.desatech.com
klsuiejlb oeklhi kokle ,,;log;e ;;pdl;l klsuiejlb
kfds fgh fghfdg hlkrjty reti4m fifjeoc mazn
klsuiejlb oeklhi kokle ,,;log;e ;;pdl;l klsuiejl
b
kfdfgs dfgh yurrtllcvb j erg mazn bwsjdsg
g
;
e
klsu
iejlb oeklhi kokle ,,;log;e ;;pdl;l klsuiejlb
kfdsfgh hlkrjty reti4m fifjeoc mazn
klsuiejlb oeklhi kokle ,,;log;e ;;pdl;l klsuiejlb
kfdsfgh fghfdg hlkrjty reti4m fifjeoc mazn
kfdsfgh fghfdg hlkrjty reti4m fifjeoc mazn
klsuiejlb oeklh
i kokle ,,;log;e ;;pdl;l klsuiejlb
k
fdsfgh fghfdg hlkrjty reti4m fifjeoc mazn
klsuiejlb oeklhi kokle ,,;log;e ;;pdl;l klsuiejlb
kfdsfgh fghfdg hlkrjty reti4m fifjeoc mazn
klsuiejlb oeklhi kokfdfgs dfgh yurrtllcvb j erg
klsuiejlb oeklhi kokle ,,;log;e ;;pdl;l klsuiejlb
kfdsfgh fghfdg hlkrjty reti4m fifjeoc mazn
klsuiejlb oeklhi kokle ,,;log;e ;;pdl;l klsuiejlb
kfdsfgh fghfdg hlkrjty reti4m fifjeoc mazn
klsuiejlbkfdfgs dfgh yurrtllcvb j erg mazn
Two burner
Tank Top
shown

www.desatech.com 113973-01A
2
IMPORTANT: Read and understand this manual before
assembling, starting or servicing heater. Improper use
of heater can cause serious injury. Keep this manual for
future reference.
GENERAL HAZARD WARNING:
Failure to comply with the precautions and instructions
provided with this heater, can result in death, serious
bodily injury and property loss or damage from hazards
of fire, explosion, burn, asphyxiation, carbon monoxide
poisoning, and/or electrical shock.
Only persons who can understand and follow the instruc-
tions should use or service this heater.
If you need assistance or heater information such as an in-
structions manual, labels, etc. contact the manufacturer.
SPECIFICATIONS
15,000 Btu 30,000 Btu
Type of Gas: Propane/LP Only Propane/LP Only
Gas Supply Pressure to regulator
Maximum Bottle Pressure Bottle Pressure
Minimum 20 psi (1.37 bar) 20 psi (1.37 bar)
Gas Supply Pressure 10 - 18 psi 10 - 18 psi
Regulator out (.68 bar - 1.2 bar) (.68 bar - 1.2 bar)
Minimum Ambient Temp. Rating 0°F (-17.8°C) 0°F (-17.8°C)
Rating 10,000 - 15,000 Btu/hr 10,000 - 30,000 Btu/hr
(3.0 - 4.4 kW) (3.0 - 8.8 kW)
Ignition Match Light Piezo Ignition
Fuel Consumption per 20 lb. Cylinder 36 hours 18 hours
TABLE OF CONTENTS
Specifications ...................................................... 2
Safety Information ............................................... 3
Assembly Instructions ......................................... 4
Operating Instructions ......................................... 5
Maintenance and Storage ................................... 6
Servicing .............................................................. 7
Technical Service ................................................ 7
Replacement Parts .............................................. 7
Illustrated Parts Breakdown and Parts List ......... 8
Warranty and Repair Service ............................ 10

www.desatech.com
113973-01A 3
SAFETY INFORMATION
WARNING: This product con-
tains and/or generates chemicals
known to the State of California
to cause cancer or birth defects,
or other reproductive harm.
WARNING: Not for home or
recreational vehicle use.
WARNING: Fire, burn, inhala-
tion, and explosion hazard. Keep
solid combustibles, such as build-
ing materials, paper or cardboard,
a safe distance away from the
heater as recommended by the
instructions. Never use the heater
in spaces which do or may contain
volatile or airborne combustibles,
or products such as gasoline, sol-
vents, paint thinner, dust particles
or unknown chemicals.
ASPHYXIATION HAZARD
• Do not use this heater for heating human
living quarters.
• Do not use in unventilated areas.
• The flow of combustion and ventilation
air must not be obstructed.
• Proper ventilation air must be provided
to support the combustion air require-
ments of the heater being used.
• Refer to the specification section of
the heater’s manual, heater data plate,
or contact DESA Heating Products to
determine combustion air ventilation
requirements of the heater.
• Lack of proper ventilation air will lead
to improper combustion.
• Improper combustion can lead to car-
bon monoxide poisoning leading to
serious injury or death. Symptom of
carbon monoxide poisoning can include
headaches dizziness and difficulty in
breathing.
1. Keep children and animals away from heater.
2. Never operate heater while sleeping or unat-
tended.
3. Check the heater thoroughly for damage. Do
not operate a damaged heater.
4. Do not modify the heater or operate a heater
which has been modified from its original
condition.
5. Use only propane/LP gas.
6. Use only vapor withdrawal propane/LP
supply. If there is any question about vapor
withdrawal, ask your propane/LP dealer.
7. For outdoor use only. Area must be well ven-
tilated. Provide minimum openings of 1 sq ft
(.093m²) near the floor and 1 sq ft. (.093m²)
near the ceiling. Do not use inside house,
camper, tent, vehicle, or any type of unvented
or enclosed area.
8. Do not use heater in basement or below
ground level.
9. Before connecting heater to the propane/LP
tank, make sure the heater regulator knob is
in the "OFF" position. Always connect and
light heater in areas free of open flames.
10. Mount the propane/LP cylinders vertically
(shutoff valve up). Secure them from falling
or being knocked over and protect them from
damage.
11. IMPORTANT: Use only the hose and regulator
assembly provided with the dual burner tank
top heater. Inspect the hose assembly before
each use. If there is excessive abrasion or wear,
or hose is cut, replace with hose assembly listed
on parts list before using heater. The hose and
regulator must be protected from damage.
12. The heater burner must be at least 2 ft. (.61m)
above the floor. Always attach to propane/LP
tank in an upright position. Never operate
a heater on its side or attach to propane/LP
tank in a horizontal position. This could lead
to dangerous flare-ups or fire. Do not direct
heat toward propane/LP cylinders.
13. Maintain minimum clearance from nor-
mal combustible materials (like paper)
as follows: Sides - 3 ft. (.91m);
Top and
Front - 5 ft. (1.5m). Locate 10 ft. (3m) from
canvas or plastic tarpaulins or similar cover-
ings and secure them to prevent flapping or
movement due to wind action.
14. If at any time gas odor is detected, IMME-
DIATELY DISCONTINUE operation until
the source of gas has been located and cor-
rected.

www.desatech.com 113973-01A
4
Figure 3 - Attaching Burner Head
Assembly to Support Arm
15. Install the heater such that it is not directly
exposed to water spray, rain, dripping water
and/or wind.
16. Operate only on a stable, level surface.
17. Due to the high surface and exhaust tempera-
tures, adults and children must observe clear-
ances to avoid burns or clothing ignition.
18. Do not move, handle or service while hot or
burning. Do not attach or remove a hot or
operating heater from the propane/LP tank.
19. Before each use, check heater for leaks. Never
use an open flame to check for leaks. Apply a
mixture of liquid soap and water to all joints.
Bubbles forming show a leak. Correct all leaks.
20. Keep all connections and fittings clean. Make
sure propane/LP tank valve is clean. Check
"O" ring on heater inlet fuel valve connector
for damage before each use. Replace if worn
or damaged.
21. Use only in accordance with local codes or, in
the absence of local codes, with the Standard
for the Storage and Handling of Liquefied Pe-
troleum Gases ANSI/NFPA 58 and CSA B149.1,
Natural Gas and Propane Installation Code.
ASSEMBLY
INSTRUCTIONS
30,000 BTU MODELS ONLY
1. Inspect the heater components for possible
shipping damage. If any is found, immediately
notify the dealer. Check to make sure that all
components are included with your heater (see
pages 8 and 9).
2. Insert the piezo ignitor into the bracket on the
burner support bracket as shown in Figure 1.
Tighten the piezo mounting nut. Do not over
tighten the nut.
3. Connect the burner hoses together as shown in
Figure 2. Wrench tighten to insure leak tight
connection.
4. Mount the burner assembly onto the support arm
using the burner head mounting brackets and
brass screws as shown in Figure 3. Place side
of bracket into the slot on support arm. Secure
with screw. Make certain that the air holes on the
sides of the burner tube are not blocked. Securely
tighten the burners into place.
5. Attach the electrode wires to the piezo ignitor
as shown in Figure 4.
SAFETY INFORMATION
Continued
Figure 1 - Installing Piezo Ignitor
Piezo Ignitor
Piezo
Mounting
Nut
Burner
Support
Bracket
Figure 2 - Attaching Burner Hoses to
Regulator
Burner Head
Assembly
Support
Arm
Burner Head
Mounting Bracket
Brass Screw
Slot
Air Hole
Figure 4 - Attaching Electrode Wires to
Piezo Ignitor
Piezo Ignitor
Electrode Wires

www.desatech.com
113973-01A 5
OPERATING
INSTRUCTIONS
1. Check heater for damage. If heater is damaged,
promptly inform dealer where you bought
heater.
2. Follow all of the safety and operating pre-
cautions.
3. Check the "O" ring on the POL before each
use. Replace the "O" ring if there is any sign
of wear or damage.
4. Make sure heater regulator knob is in the
"OFF" position.
5. 30,000 Btu Models Only Attach the heater to
the guard on the propane/LP cylinder with the
support arm on the inside of the guard and bolts
through two holes in the guard (see Figure 5).
Tighten the support arm bracket into place us-
ing the wing nuts provided.
6. For All Models Connect the POL fitting
at regulator to the propane/LP cylinder by
rotating the POL nut counter clockwise into
the propane/LP cylinder's valve outlet and
securely tighten with a wrench.
WARNING: Attach heater in
upright position. Never attach
heater in a horizontal position.
This could lead to dangerous
flare-ups or fire.
7. Securely tighten all gas connections.
8. Open the cylinder's gas valve and check all
connections for leaks. Apply mixture of liquid
soap and water to gas joints. Bubbles forming
show a leak that must be corrected. DO NOT
USE A FLAME.
Figure 5 - Attaching Support Arm and
Regulator to Propane/LP Tank
Regulator
Support
Arm
Bolt
Support Arm
Bracket
Red Button
on Safety
Valve
TO START HEATER
WARNING: When lighting
the heater DO NOT look over
top of heater (reflector). Stand
to the side of the heater during
ignition. Do not stand or have
any part of your body in front
of the heater.
WARNING: MAKE SURE
THERE IS NO OPEN FLAME IN
THE AREA. Fully open the valve
on the propane/LP cylinder.
Read all lighting instructions before attempting
to ignite heater.
1. Turn the heater regulator knob counterclock-
wise to the "HI" position.
2. Repeatedly push and release the piezo ignitor
(dual burner), or place a lighted match near the
face of the heating element (mesh screen) of the
burner you are lighting, using the hole located
on the side of the reflector. See Figure 6.
CAUTION: Do not light at the
orifice.
3. Depress the red button on the safety valve
admitting gas to the burner (see Figure 6).
WARNING: Do not depress red
valve button before repeatedly
activating the piezo or inserting
match.
Figure 6 - Lighting Heater With a Match

www.desatech.com 113973-01A
6
4. When the gas on the face of the mesh screen
lights, continue to hold the valve button de-
pressed for 30 seconds, then release.
5. If flame goes out, wait 5 minutes and repeat
the lighting procedure.
6. If heater will not light after repeated tries, do
not attempt to repair heater. Return heater to
nearest authorized service center or to manu-
facturer of this product.
7. For dual burner models, repeat steps 1 through
4 to ignite the other burner.
8. After both burners or single burner, are lit,
turn the heater regulator knob to the desired
heat setting (LOW, MED, HI).
TO STOP HEATER
1. Securely close valve on the propane/LP
cylinder.
2. Turn the heater regulator knob to the "OFF"
position. Wait 15 minutes for the heater to cool
down before handling heater.
3. Always remove the heater from the propane/
LP tank after each use. Do not store the heater
while attached to propane/LP tank. Remove
the heater from the propane/LP tank by turn-
ing the fuel connector nut clockwise. Always
store propane/LP tank outdoors. Never store
propane/LP tank in an enclosed area.
TO RESTART HEATER
1. Securely close valve at propane/LP cylinder.
2. Wait 5 minutes.
3. Restart following To Start Heater procedure,
page 5.
OPERATING INSTRUCTIONS
Continued MAINTENANCE AND
STORAGE
1. Inspect heater before each use. Check connec-
tions for leaks. Apply mixture of liquid soap
and water to connections. Bubbles forming
show a leak that must be corrected. Correct
all leaks at once. Have heater inspected at least
annually by a qualified service person.
2. Before each use, check the soft "O" ring seat
at the bullnose of the POL fitting. If the "O"
ring is cut, scuffed, or otherwise damaged,
replace it with part number 6681.
3. Inspect hose/regulator assembly before each
use. If hose is highly worn or cut, replace.
3. Turn off the gas at the propane/LP gas supply
cylinder when the heater is not in use.
4. When the heater is to be stored, the connection
between the propane/LP gas supply cylinder
and the heater must be disconnected and the
cylinder removed from the heater and stored
out of doors and in accordance with Chapter
5 of the standard for Storage and Handling of
Liquefied Petroleum Gases ANSI/NFPA 58.

www.desatech.com
113973-01A 7
SERVICING
A hazardous condition may result if a heater is
used that has been modified or is not functioning
properly. When the heater is working properly:
• The emmitter screen is glowing bright orang-red.
• There are no flames above the burner.
• The flame is burning on the surface of the screen
and not inside the burner (flashback).
• There is no strong disagreeable odor, eye burn-
ing or other physical discomfort.
• There is no smoke or soot internal or external
to the heater.
• There are no unplanned or unexplained shut
downs of the heater.
The parts lists and exploded view show the heater
as it was constructed. Do not use a heater which is
different from that shown. In this regard, use only
the hose, regulator and cylinder connection fitting
(called a POL fitting) supplied with the heater.
IMPORTANT: For this heater, the regulator must
be set as shown in Specifications, page 2. If there
is any uncertainty about the regulator setting,
have it checked.
TECHNICAL SERVICE
A heater which is not working right must be re-
paired, but only by a trained, experienced service
person. To find the service center closest to you,
or if you have further questions about this heater,
contact DESA Heating Productsʼ Technical Service
Department at 1-866-672-6040. When calling,
please have your model and serial numbers of
your heater ready.
You can also visit DESA Heating Productsʼ Techni-
cal Service web site at www.desatech.com.
You may also obtain in-warranty or out-of-war-
ranty service by taking the product to your local
service center.
REPLACEMENT PARTS
WARNING: Use only original
replacement parts. This heater
must use design-specific parts.
Do not substitute or use generic
parts. Improper replacement
parts could cause serious or fa-
tal injuries. This will also protect
your warranty coverage for parts
replaced under warranty.
PARTS UNDER WARRANTY
Contact authorized dealers of this product. If they
canʼt supply original replacement part(s), either
contact your nearest Parts Central or call DESA
Heating Productsʼ Technical Service Department
at 1-866-672-6040.
When calling DESA Heating Products, have ready
• your name
• your address
• model number of your heater
• how heater was malfunctioning
• purchase date
PARTS NOT UNDER WARRANTY
Contact authorized dealers of this product. If
they canʼt supply original replacement part(s),
either contact your nearest Parts Central (listed in
Authorized Service Center booklet) or call DESA
Heating Products at 1-866-672-6040 for referral
information.
When calling DESA Heating Products, have ready
• model number of your heater
• the replacement part number

www.desatech.com 113973-01A
8
ILLUSTRATED PARTS BREAKDOWN
MODELS
SPC-30R, HD30, TT30
2
1
2
3
4
6
75
8
9
10
11
12
13
14
15
1

www.desatech.com
113973-01A 9
PARTS LIST
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 6 of this manual.
KEY PART NUMBER
NO. 15,000 Btu 30,000 Btu DESCRIPTION QTY.
1 114092-01 114092-01 Burner Head Assembly 1-2
2 100939-01 100939-01 Grille 1-2
3 _____ 097159-05 Piezo Ignitor 1
4 _____ 102334-01 Nut, Piezo 1
5 _____ 114095-01 Support Arm 1
6 _____ 114099-01 Burner Head Mounting Bracket 2
7 _____ 114145-01 Brass Screw 2
8 _____ 114093-01 Hose Assembly 2
9 _____ 114096-01 Support Arm Bracket 1
10 _____ 114098-01 Fitting 1
11 _____ 114097-01 Fitting 1
12 101822-01 101822-01 POL Excess Flow/Regulator 2-1
13 114100-01 114100-01 Thermocouple 1-2
14 100898-01 100898-01 Thermocouple Nut 2-4
15 _____ 114094-01 Electrode Assembly 2
PARTS AVAILABLE - NOT SHOWN
114091-01 114091-03 Instruction Hang Tag (English) 1
114091-02 114091-04 Instruction Hang Tag (Spanish) 1
114091-05 114091-06 Instruction Hang Tag (French) 1
2
12
13
14
1
MODELS
SPC-15R, HD15A, N15A, TT15A

Propane/LP Infra-Red Tank Top Heater
Limited Warranty
DESA Heating Products warrants this product and any parts thereof, to be free from defects in material and
workmanship for one year from the date of first purchase, provided that the product has been properly installed,
operated, and maintained in accordance with all applicable instructions. To make a claim under this warranty, the
bill of sale or proof of purchase must be presented.
This warranty is extended only to the original retail purchaser. This warranty covers only the cost of parts required
to restore this heater to proper operating condition. Warranty parts must be obtained through authorized dealers
of this product and/or DESA Heating Products who will provide original factory replacement parts. Failure to use
original factory replacement parts voids this warranty. The heater must be used in accordance with all local codes
and instructions furnished with the unit.
This warranty does not apply to parts that are not in original condition because of normal wear and tear, or parts
that fail or become damaged as a result of misuse, accidents, lack of proper maintenance, alteration, tampering,
contaminated fuels, or defects caused by improper installation. Travel, transportation and incidental costs associated
with warranty repair are not reimbursable under this warranty and are the responsibility of the owner.
To the full extent allowed by the law of the jurisdiction that governs the sale of the product: This express war-
ranty excludes any and all other expressed warranties of merchantability and fitness for a particular purpose to
ONE YEAR from the date of first purchase: and DESA HEATING PRODUCTSʼ liability is hereby limited to
the purchase price of the product and DESA HEATING PRODUCTS shall not be liable for any other damages
whatsoever including indirect, incidental or consequential damages.
Some states do not allow a limitation on how long an implied warranty lasts or an exclusion or limitation of
incidental or consequential damages, so the above limitation on implied warranties, or exclusion or limitation on
damages may not apply to you.
This warranty provides the original retail purchaser with specific legal rights. For specific information regarding
those rights, please consult the applicable state laws.
WARRANTY AND REPAIR SERVICE
KEEP THIS WARRANTY
Model
Serial No.
Date of Purchase
2701 Industrial Drive
P.O. Box 90004
Bowling Green, KY 42102-9004
ATTN: Customer Service Department
