Contec RT-U46C User manual

CheckMate TM III RT-U46C 2
1. Introduction
Your CheckMate™ III (Model RT-U46C) universal
remote control is simple to program, easy to use, and
can operate up to three (3) devices, which include:
2. Before Getting Started
Some of the special features and buttons on your
remote control are as follows:
Point and Press TM Programming
Let’s you program your TV and VCR devices without
codes. For more information, see sections 5 and 6.
[VCR / VOD] Toggle
“Toggles” the VCR buttons between cable Video-
On-Demand (VOD) and VCR / DVD functions. For
more information, see section 13.
Smartkeys TM
Program multiple button presses on the [CBL] and
[TV] buttons. For more information, see section 8.
Time Out
Shuts off remote if any button is pressed and held
for 45 seconds. This extends battery life in the event
the remote becomes lodges under or between
heavy objects
Reset
Lets you reset your remote to its original default
settings. For more information, see section 11.
[Movies], [Sports], [News]
Program your favorite channels on the "Movies",
"Sports" and "News" buttons. For more information
see section 9.
For Motorola DCT®or CFT2200 cable set-top
terminals, these buttons are pre-programmed and
labeled [PPV /LOCK], [*HELP], [MUSIC].
Install two (2) new “AA” batteries as indicated by the
diagram in the battery compartment.
When the indicator light becomes dim or no longer
illuminates during use, install two (2) new “AA” size
batteries.
Your remote control has Memory Guard™, which
eliminates reprogramming after battery changes.
Before you can use your remote control, it must be
programmed (set-up) to operate the above devices.
CABLE
TV
VIDEO
CheckMate TM III RT-U46C 5
5. Programming Your TV
CheckMate TM III RT-U46C 3
4. Programming Your Cable Set-Top Terminal
Model RT-U46C is pre-programmed to operate the
Scientific-Atlanta Explorer®, Pioneer Voyager®and
Pace 510 digital set-top terminals.
To operate a different cable set-top terminal, look up
the brand and model in the Cable Setup Code list. If
you are not sure of your brand and model, contact
your cable company.
To program your cable set-top terminal...
1. Turn on your cable set-top terminal.
2. Press [CBL], then [SELECT] together - hold both
buttons down until indicator light illuminates.
3. From the Cable Setup Code list, locate and enter
the 3-digit code for your brand and model.
4. Press [CBL] to lock in the code. The indicator light
will blink and go out.
Write your cable set-top terminal brand & setup
code .
CheckMate TM III RT-U46C 4
TV Setup Codes
CheckMate TM III RT-U46C 6
3. Installing / Replacing Batteries
CheckMate TM III RT-U46C 7
If you have a TV that’s operated by remote control,
it is recommended that you plug it directly into a
wall outlet instead of the cable set-top terminal.
To program your TV...
1. Turn on your TV.
2. Press [TV], then [SELECT] together - hold both
buttons down until the indicator light illuminates.
3. a.Press and hold [CH+] until your TV turns off. As
soon as your TV turns off, release [CH+]❶.
OR
b.From the TV Setup Code list, locate and enter
a 3-digit code for your brand. If multiple codes
are listed, you may have to enter several 3-
digit codes until your TV turns off.
4. Press [MUTE]. If your TV turns back on, press
[TV] to lock in the code. The indicator light will
blink and go out.
If your TV does not turn back on, repeat steps 3
and 4 until you can turn your TV off and on.
Write your TV brand & setup code_____________.
Refer to section 10 for code number readback.
❶Note when using the Point and Press™‚
Programming method (step 3a). If you find a code
that turns your TV off but not back on (step 4), you
may have gone past the correct matching code.
Try pressing [CH–] one step at a time until you find
a code that turns your TV back on.
To program your TV / VCR combination unit...
1. First, program your remote for the TV functions.
Following the steps in this section, find a TV Setup
Code that operates the TV functions of your
TV/VCR (power, vol+/–, mute, ch+/–, 0-9).
2. Then, program your remote for the VCR
functions.
Following the steps in Section 5 for code number
entry, enter, lock and test each 3-digit VCR
Setup Code until a code is found that operates
the VCR functions of your TV / VCR (play, stop,
fast-forward, rewind, pause, record).
Note: You can not use the Point and Press™
Programming method to program the VCR
functions of the TV / VCR.
CheckMateTM III
Model RT-U46C
Universal Remote Control
Programming And Operating
Instructions
To have a clearer idea of the features and capabilities of
your remote control, take a moment to read these
instructions. Save for future reference.
Rev. 12/2001
© 2001, CONTEC CORPORATION
VCR Setup Codes
Cable Setup Codes
Admiral 058 061 062 067
Adventura 004
Akai 065
Aiwa 135
Amark 007 086
Ampro 112
Amstrad 006
Anam 088 089 093 111 120 125 134
AOC 065
Audio Vox 111
Belcor 041
Bell & Howell 062
Broksonic 011 054
Brokwood 041
Candle 027 052
Centurion 044 051
Citizen 027 052 059 062
Concerto 041 051
Contec 020
Coronado 007
Craig 134
Crown 007
Curtis Mathes 044 061 062
Daewoo 027 039 040 041 042 051 090 091 092 094
101 102 108 114 118 121 123 130
Daytron 041 044 051
Dumont 041
Electro Home 041 051
Elektra 002
Emerson 007 008 011 012 017 054 065 079 108 110
131
Envision 041 051
Fisher 010 028
Funai 004
GE 005 019 027 031 037 041 046 051 053 055
061 070 131
Gibralta 007 025 027 031 041 044 051 059 060 065
Goldstar(LG) 007 027 031 041 044 059 060 065 124
Grundig 059
Hall Mark 041 051
Hitachi 007 027 049 051 083 085 098 100
Inkel 075
JC Penney 005 010 027 037 041 051 065 069 070
JVC 048 077 080 132
Kawasho 041 051
KMC 007
KTV 007 030 059 065
Kurazai 062
Lodgenet 062
Logik 062
Luxman 027 041 051
LXI 006 035 067
Magnavox(Philips) 001 005 007 014 026 027 041 052 068 081
Majestic 062
Marantz 003 065 076
Megatron 086
Memorex 010 031 062
MGA/Mitsubishi 003 027 031 041 044 051 065 076 084
Montgomery Ward 007 037 044 057 058 062 065 067 081
NEC 023 027 031 044 101
Orion 013 017 033 045 047 078
Panasonic 018 019 021 024 053 063
Philco 001 007 027 052 065 081
Philips(Magnavox) 001 005 007 014 026 027 041 052 068 081
Pilot 041 059 097
Pioneer 056 103
Portland 007 027
ProScan 055 061 073 082 112
Proton 031 126 128
Pulsar 041
Quasar 019
Radio Shack 041
Realistic 012 057 079
RCA 022 027 046 053 055 061 065 072 073 082
Sampo 031 044
Samsung 007 016 020 031 044 119 129
Sanyo 002 010 028 104 133
Scott 031 044 079
Sears 002 007 010 016 027 028 043 069
Sharp 007 009 023 035 057 064 067 096
Signature 2000 007 044 058 062 067
Sony 032 038 050 066
Soundesign 052
Squareview 006
Supre-Macy 071
Sylvania 001 005 006 026 027 031 044 052 081 108
Symphonic 004 006
Tatung 019
Techwood 027
Teknika 001 007 027 052 062 079
Telerent 007 062
TMK 027 031
Tera 127
Toshiba 016 029 043 069
Totevision 059
Universal 027 070
Vidtech 027
Wards 027 031
White Westinghouse 058
XR-1000 062
Yamaha 027
York 031 044
Zenith 004 015 025 034 036
Admiral 014 056
Adventura 025
Aiwa 025 106
Akai 011 021 051 092 098 103
Audio Dynamics 007 044
Bell & Howell 005 024
Broksonic 009 048 053 064
Canon 008 034 105
Citizen 002 006 028 060
Colortyme 044
Craig 028 030
Curtis Mathes 008 013 034 044 060
Daewoo 006 010 012 057 058 112 114 116
Daytron 055 058
DBX 007 044
Dynatech 025 106
Emerson 002 003 006 008 009 022 033 040 049 051
064 091 101 106 107 109
Fisher 005 015 024 030 052
Funai 025 106
GE 008 027 028 034 041
Go Video 019 043 063
Goldstar(LG) 002 060
Cable set-top terminals
Televisions
VCR, DVD
Motorola (General Instrument)
DCT, CFT 2200 001
CFT2100, CFT2000 002
Jerrold 003
DL4, DP(V), DQN(V), DPBB
Scientific Atlanta
Explorer 004
Explorer(#, *) 015
Explorer(Blue Ridge) 016
Explorer(WorldGate™) 018
8600X 005
8600 006
8540, 70, 90 007
Pace
510 digital 004
Philips
digital 017
Pioneer
Voyager 004
BC-4600, BA-6000 008
BA-9000 009
BA-V1000, BA-V2000 010
Tocom
5503VIP, 5507, 5508 011
Zenith
Z-Tac 012
MM2500 013
Oak
Sigma One, P1, P2, P3 014
Sigma 2000
To program your VCR or DVD...
1. Turn on your VCR or DVD.
2. Press [VIDEO], then [SELECT] together - hold both
buttons down until the indicator light illuminates.
3. a.Press and hold [CH+] until your VCR or DVD turns
off. As soon as your VCR or DVD turns off,
release [CH+]❶.
OR
b.From the VCR - DVD Setup Code list, locate and
enter a 3-digit code for your brand. If multiple
codes are listed, you may have to enter several 3-
digit codes until your VCR or DVD turns off.
4. Press [MUTE]. If your VCR or DVD turns back on,
press [VIDEO] to lock in the code. The indicator light
will blink and go out.
If your VCR or DVD does not turn back on, repeat
steps 3 and 4 until you can turn your VCR or DVD
off and on.
Write your VCR / DVD brand & setup code ______.
Refer to section 10 for code number readback.
❶Note when using the Point and Press™‚ Programming
method (step 3a). If you find a code that turns your
VCR / DVD off but not back on (step 4), you may
have gone past the correct matching code. Try
pressing [CH–] one step at a time until you find a
code that turns your VCR / DVD back on.
6. Programming Your VCR or DVD (Video device)

CheckMate TM III RT-U46C 9 CheckMate TM III RT-U46C 10 CheckMate TM III RT-U46C 11 13. Using Your RT-U46C Remote Control
Your remote has two (2) SmartkeysTM [CBL] and [TV].
Each SmartkeyTM can be programmed so whenever it’s
pressed, it can transmit up to 12 individual button
presses in sequence.
Programming and using the [CBL] SmartkeyTM
The [CBL] button normally turns on / off your cable set-
top terminal. You can also program this Smartkey™so
whenever it is pressed, it will turn on your cable set-top
terminal and TV, then tune the TV to a specific channel
with one button press.
1. Press [CBL], then [SETTINGS] together-hold both
down together until the indicator light illuminates.
2. In this order, press [CBL], [TV], [0], [3]. The indicator
light will blink and remain illuminated.
3. Press [CH+] to lock in this setting. The indicator light
will blink and go out.
To return the [CBL] button to its normal default setting,
repeat step 1, then press [CH–].
Programming and using the [TV] SmartkeyTM
The [TV] button normally turns on / off your TV. You
can also program this SmartkeyTM so whenever it is
pressed, it will turn on your TV, then tune your TV to
channel 3 with one button press.
1. Press [TV], then [SETTINGS] together - hold both
down together until the indicator light illuminates.
2. In this order, press [TV], [0], [3]. The indicator light
will blink and remain illuminated.
3. Press [CH+] to lock in this setting. The indicator light
will blink and go out.
To return the [TV] button to its normal default setting,
repeat step 1, then press [CH–].
Note : When using any SmartkeyTM to transmit a
series of button presses, be sure to keep your remote
aimed at the devices to ensure all functions are
received in their entirety.
Rev. 12/2001
© 2001, CONTEC CORPORATION
9. Programming [MOVIES], [NEWS], [SPORTS]
Each of these buttons can be programmed to store a
favorite cable channel.
For example, to program the [MOVIES] button to cable
channel 53...
1. Press [CBL], then [MOVIES] together - hold both
down until the indicator light illuminates.
2. Press [0], [5], [3]. (enter CH. # in 3-digit format)❶.
3. Press [MOVIES] to store this channel. The ndicator
light will blink and go out.
Programming the [SPORTS] or [NEWS] buttons is the
same general procedure as above.
❶May also be 4-digit (or 5-digit) format. The exact # of
digits you need to enter depends on how your cable
operator has setup your cable set-top terminal.
For Motorola DCT®or CFT2200 set-top terminals,
these buttons are pre-programmed and labeled [PPV
/ LOCK], [*HELP], [MUSIC].
2. Press [INFO] to identify your TV setup code. The
indicator light will "blink back" the code numbers, with
a 1-second interval between each digit of the code.
Example: For code "035", the indicator light will blink
10 times, then 3 times, then 5 times.
To identify the 3-digit Cable setup code, press [CBL]
then [SELECT] in step 1 above, then press [INFO].
To identify the 3-digit Video (VCR or DVD) setup code,
press [VIDEO], then [SELECT] in step 1 above, then
press [INFO].
10.Code Number Readback
To identify the 3-digit TV setup code stored under the
Point and Press™method...
1. Press [TV], then [SELECT] - hold both down until
the indicator light illuminates.
11. Resetting Your Remote Control
To reset your remote control to its factory default
settings...
1. Press [CBL], then [SELECT] - hold both down until
the indicator light illuminates.
2. Press [SETTINGS], then [SETTINGS] again. The
indicator light will blink and go out.
12. Helpful Tips and Troubleshooting
1. Your remote is equipped with a Point and Press™
Programming label on the back of its case. This will help
you quickly program the remote without using codes.
2. The indicator light will remain on while the remote is
in a programming mode. In the absence of an entry,
the light will go out after 45 seconds.
When locking in your devices, the indicator light will
blink and go out.
3. When using the Point and Press™‚ programming
method, you may find a code that turns your device
off but not back on. If this happens...
a. the correct code has not been found. Continue
pressing [CH+] until your devices turn on and off.
OR
b. you may have gone past the correct matching
code. Try pressing [CH–] one step at a time until
you find a code that turns your cable set-top
terminal back on.
4. If you have any questions concerning the operation
of your cable set-top terminal, contact your cable
operator.
5.If the same button is pressed and held for 45
seconds, your remote control will turn itself off. This
extends the battery life by should the remote
become lodged under or between heavy objects, for
example sofa cushions.
CheckMate TM III RT-U46C 8
Tune directly to favorite Movie, Sports,
News channels. (On Motorola DCT set-top
terminals, these buttons are pre-programmed
to [PPV / LOCK], [*HELP] and [MUSIC] functions)
Harman/Kardon 044
Hitachi 025 046 059 106 113
Instant Replay 008 017 034
JC Penney 005 008 017 028 034 044 046
JVC 004 005 007 038 026 060 095 102
JCL 008
Kenwood 004 005 007 060 106
Logik 042
Lloyd 025 106
LXI 002 025 106
Magnavox 008 025 034 036 106
Marantz 005 008 036 044 060
Marta 002
Matsui 094
Memorex 002 005 025 030 034 104 106 110
Mitsubishi 023 029 031 047 106
MTC 025 028 106
Montgomery Ward 014 025 027 034 037 062
Multi Tech 025 028 042 106
NEC 004 005 007 044 070 071
Orion 022 049 065 066 067 068
Panasonic 008 013 034 099
Pentax 046
Philco 008 034 036 106
Philips 008 017 034 036 106
Pioneer 004 045 046
Portland 058
ProScan 027 041
Quasar 013 034
Quartz 005 009
RCA 001 008 016 017 027 028 037 041 046 106
Realistic 005 014 025 030 034 106
Samsung 021 028 039 098 108 111
Sansai 042
Sansui 004 093
Sanyo 005 024 114
Sayyo 030
Scott 003 006 031 042
Sears 002 005 015 030 046
Sharp 014 056
Shintom 042
Signature 2000 014 025 027 037 062
Sony 032 035 050
Soundesign 106
Sylvania 008 016 017 025 034 036 047 054 065 073
074 106
Symphonic 025 106
Tandy 005 025 106
Tashiko 002
Tatung 007
Teac 007 025 106
Technics 008
Teknika 002 053 106
Thomas 106
TMK 091
Toshiba 006 015 046 052 096
Totevision 002 028
Unitech 028
Vector Research 031 044
Video Concepts 044 106
Wards 002 014 025 028 060 106
XR-1000 042
Yamaha 005 007 044 106
Zenith 004 018 035 038 061 106
When you first program your remote, volume and mute
are controlled through your TV.
To control volume / mute through your cable set-
top terminal:
1. Press [CBL], then [SELECT] together - hold both
down until the indicator light illuminates.
2. Press [VOL+], then [CBL] for cable volume. The
indicator light will blink and go out.
To return volume control back to your TV, repeat step 1
above, then press [VOL+], then [TV] in step 2.
7. Programming Volume Control
Denon 076
GE 077 078
Hitachi 117
JVC 079
KLH 118
LG 079
Magnavox 081 082
Mitsubishi 083
Panasonic 084
Pioneer 085
Samsung 086
Sharp 119
Sony 087
Thomson 120
Toshiba 088
Yamaha 089
Zenith 089
8. Your Remote’s Smartkeys TM
DVD Setup Codes
