Conti CC100 Technical manual

- Edition 05/2015
SACOME, Document CONFIDENTIEL, Ne peut être reproduit ni communiqué sans notre accord préalable.
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
DISPLAY
TECHNICAL DOCUMENT

Edition 05/2015 - CC100
NOTES TECHNIQUES - TECHNICAL DOCUMENTS - page 1
SACOME, Document CONFIDENTIEL, Ne peut être reproduit ni communiqué sans notre accord préalable.
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
Table des matières Page
1. TECHNICAL DOCUMENTS ____________________________________________________________2
2. DIMENSIONS _______________________________________________________________________2
3. CAUTION DURING THE USE___________________________________________________________3
4. INSTALLATION______________________________________________________________________4
5. OPERATION ________________________________________________________________________6
6. HOW TO USE THE MACHINE __________________________________________________________7
7. PROGRAMMING OF COFFEE DOSAGE__________________________________________________9
8. RELATED FONCTIONS ______________________________________________________________10
9. PROGRAMMING PARAMETERS OF TECHNICAL MENU: __________________________________12
10. SUMMARY OF THE PROCEDURE RESETTING THE COUNTERS____________________________17
11. DESCRIPTION OF ALARMS __________________________________________________________18
12. HOW TO MAKE THE PERFECT COFFEE________________________________________________19
13. MAINTENANCE OF MACHINES _______________________________________________________21
14. ELECTRONIC DIAGRAM _____________________________________________________________24
15. HYDRAULIC SCHEMA _______________________________________________________________28
16. OPTION AVAILABLE ________________________________________________________________29

Edition 05/2015 - CC100 DISPLAY - TECHNICAL DOCUMENTS - page 2
SACOME, CONFIDENTIAL Document, it is forbiddento duplicate or communicate this document without previous authorization..
1. TECHNICAL DOCUMENTS
TYPE
MACHINE
HEATING
POWER
(W)
INSTALLED
POWER
(W)
ELECTRICAL
CONSUMPTION
With 230V (A)
CC102 D 3500 3800 17A
CC103 D 4700 5000 22A
CC103 D Tri 6000 6300 10A / phase
BOILER CAPACITY ( LITERS)
2G 3G
TOTAL 11 18
VOLUME OF HOT WATER 8 13
VOLUME OF STEAM 3 5
WEIGHT
empty
(Kg)
WEIGHT
in operation
(Kg)
CC102 58 69
CC103 72 90
2. DIMENSIONS
704 (2G) - 919 (3G)
704 (2G) - 919 (3G)

Edition 05/2015 - CC100 DISPLAY- TECHNICAL DOCUMENTS - page 3
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
3. CAUTION DURING THE USE
3.1. AMBIENT CONDITIONS
 The ambient temperature around the machine had to be between 5°C et 32°C.
 The ambient humidity must not exceed 70 %
 The machine must be placed such as the cup warmer is located more than 1.5 meters
from the ground.
3.2. DURING INSTALLATION
 The installation (electrical connections, water supply and drainage) must be carried out
by a qualified technician approved by CONTI.
 The machine must be connected to a device conforming to the standards of the country
where the machine is installed. Potential costs of equipment compliance are the only
responsibility of the customer.
 For any technical intervention, the machines must always have the power disconnected
from the mains.
 An effective earth connected to the terminal provided for this purpose on the device is
mandatory
 A screw located under the bottom base machine, allow if necessary, to connect several
machine on an equipotential way.
 Devices for disconnection from the main supply, having a contact separation of at least
3mm in all poles, must be provided in the fixed wiring in accordance with the installation
rules.
3.3. DURING THE USE
 When the machine is not operating, the water cut-off valve has to be closed and the
electrical power supply cut.
 When the machine is not supervised it must be disconnected from the power and water
supply.
 Never disconnect the earthing when the machine is connected to the power supply.
 Machines must always be disconnected from the main power, in case of technical
interventions.
3.4. RULES RELATING TO THE ENVIRONMENT
 This device has been designed according to the European Directive No. 2002/95/EC.
This refers to the restriction of certain hazardous substances in electrical and electronic
equipment (ROHS)
 This device has been designed in compliance with the European Directive No.
2002/96/EC concerning waste electrical equipment (WEEE).
 This picture informs you that this device should not be discarded with household waste.
 At end of life, this product must be returned to a collection point or returned to an
authorized dealer. By doing so, you will help to protect the environment and human
health.

Edition 05/2015 - CC100 DISPLAY- TECHNICAL DOCUMENTS - page 4
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
4. INSTALLATION
4.1. IN CASE OF A STANDBY OF THE MACHINE (STANDBY = 2 MONTHS):
 The first thing to do is to test your machine in a lab.
 If the machine stop ruming for a long time, you could have scale in some places.
 More precisely in small area like the spray nozzle.
4.2. PROTECTIONS
 It is necessary to place before the machine:
o A water shutoff valve.
o An electrical protection standard, suitable for voltage and power consumption.
4.3. WATER SUPPLY
 Recommended operating pressure from 1.5 MPa to 6 MPa
 Water connection pin 3/8"
 The water supply pipes must resist to 145 Psi / 10 MPa
4.4. DRAIN
 Without pressure.
 Spigot at the outlet of the machine and a pipe is supplied with the machine
 Ensure a connection that causes no risk of fluid return, and ensure good drainage:
 The drain pipe must be located lower than the machine.
 Do not create a bend in the exhaust tube.
4.5. SUPPLYING VOLTAGE
According to the model:
 230V – 50/60Hz Monofase
 400V – 50/60Hz Trifase

Edition 05/2015 - CC100 DISPLAY- TECHNICAL DOCUMENTS - page 5
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
4.6. WATER SOFTENER
 When the mains water has a high hardness (>10°TH ou >4 °KH), it is recommanded:
o To use a water treatment
o To regenarate regularly the filters.
 What is the total Hardness of the water ?
o This is the amount of calcium and magnesium ions in the water.
o These ions are partly responsible for limestone formation.
o It is measured with the test strip provided with the machine.
o The unit of measurement is the ° French (° TH) or the ° German (° dH).
 What is the Karbonat Hardness of the water ?
o This is the amount of Carbonate Calcium ions and Carbonate Magnesium ions in the
water.
o These ions are completely responsible for limestone formation.
o It is measured with chemical dropper testers.
o The unit of measurment is ° Carbonate (°KH)
There are 2 types of water treatments:
 Salt water softeners
o They treat the total water hardness (°TH)
o By an exchange of sodium ions with calcium and magnesium ions.
o They require periodic regeneration of the resins by the user.
o To use when the water hardness is > à 10°TH ou > 5 °GH
 Resins filters :
o They treat the Carbonat hardness water (°KH)
o By fixing carbonate ions on the resins.
o Often fitted with microfiltration and carbon filtration.
o To use when the Carbonat Hardness is > à 6°KH
o Highly recommended by the manufacturer :
 The machines are equipped with suitable protection in accordance with
flowrate and the water encountered.
 The changing cartridges is carried out by the technical service, at intervals to
be determined

Edition 05/2015 - CC100 DISPLAY- TECHNICAL DOCUMENTS - page 6
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
5. OPERATION
5.1. RECOMMANDATIONS
 Open the general water tap, if it is closed, then open the water shutoff valve dedicated to
the machine.
 Do not put the supplying voltage at this moment.
 Verify the presence of water, by reading the pressure of the mains water inlet on the M2
manometer pump.
5.2. INITIAL FILLING
 Ensure that steam taps operating levers ‘V’ are open (up).
 Put the ON/OFF switch ‘C’ to position 1 (power on).
 The key board turn on.
 The boiler fills automatically, without heating.
 The machine start to heat automatically, only when the level probe is reached by the water
 A scrolling LED on keypads can inform the user about the status. (info display :« machine
en chauffe »)
 Close the steam tap “V” and wait.
 When the scrolling leds stops : The machine is ready to operate
(info display : « < 60°C CONTI ESPRESSO »)
5.3. FURTHER FILLINGS
 Further fillings will run automatically, according to the hot water needs.
 The water level in the boiler is controlled by the electronics, by the means of a level
probe.

Edition 05/2015 - CC100 DISPLAY- TECHNICAL DOCUMENTS - page 7
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
6. HOW TO USE THE MACHINE
6.1. OPERATING ELEMENTS
 STEAM FUNCTION
Two steams taps levers « V » are provided to allows:
• The heating of liquids by spraying steam.
• The milk foam production to create Cappuccino or Macchiatto.
The liquid to be heated should preferably be placed in a deep container.
The tip of the steam wand outlet must be immersed in the liquid, without touching the bottom of the
container.
The steam may also be used to sterilise and warm glasses.
After each use and absolutely after heating milk, always clean the stainless steel steam nozzle and
the outlet nozzles with a damp cloth, removing all traces present.
A rinsing of the steam lance inner holes is to be done by a short opening of the tap to release a jet of
steam.
 HOT WATER FUNCTION
A manual tap 'E' is provided for preparing tea, grog, etc.
Be careful, not to be burnt by the pressure water spray.
 FILTERS
The machine is equipped with two types of filters: 1 cup and 2 cups.
Each filter is operating with its own holder-filter to produce respectively 1 cup or 2 cups of coffee.
Filters need to be unclogged and clean, so they need to be cleaned almost once a day with hot
water, by being removed from the holder filters.
Take care to remove all residual traces of coffee and ensure proper cleanliness of perforations in the
bottom of the filter.
 FILTER-HOLDER
Never remove the filter-holder during operation of the group. The end of extraction is checkable with
coffee spouts: they no longer have to eject liquid.
Be careful to always keep the filter-holder engaged in the group, emptied of coffee cake, to keep
them warm.
In case of an extended stopping period, remove the filter-holder from the group, taking care to eject
the used grounds remain in the filter-holder.
Tighten the filter-holder until to be in contact with the seal, exceeding a little bit. The sealing is
guaranteed.
Do not unnecessarily try to crush the seal by tightening the filter at the maximum of your possibilities.
It may damage the seal or age it prematurely.
To empty the coffee filters used, turn the filter holder upside-down and lightly tap it on the edge of a
wooden box. Never strike it against metal or other hard objects.
 BUTTON TO CAPTIVATE MANUALLY THE COFFEE
This button allows you to make coffee in the case where electronics is faulty.

Edition 05/2015 - CC100 DISPLAY- TECHNICAL DOCUMENTS - page 8
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
 MANOMETER M1 : BOILER PRESSURE
The boiler pressure is adjusted in factory between 0,8 MPa (12 PSI) and 1 MPa (15 PSI). This value
varies slightly around its nominal temperature, due to the PID system which controls the heating and
limit the current consumption to its minimum.
NOTE: An over-heating thermostat will cut the heating, in case of an abnormal high temperature.
 MANOMETER M2 : PUMP PRESSURE
The pump pressure is adjusted at 9 MPa in the factory. Value which allows the best extraction of
coffee flavors. A bypass system evacuates over-pressure.
NOTE: Simultaneous operation of all the groups can impact a little bit the pressure level.
Visualization of the presence of water network is done by consulting the gauge
6.2. HOW TO USE THE PROGRAMMED DOSES
 Simply select one of the buttons available on each keypad to obtain the doses or the
programmed drinks.
 The selected dose is shown by a blinking led on the keypad.
 The flow can be stopped by repressing:
o The same button or
o The STOP button (which is also the programming and continuous flow button).

Edition 05/2015 - CC100 DISPLAY- TECHNICAL DOCUMENTS - page 9
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
7. PROGRAMMING OF COFFEE DOSAGE
7.1. PROGRAMMING PROCEDURES
Programming is done on the group 1 (left group), the 5 keys are defined as follows:
+ - ENTER MENU
P1 Gr1 P2 Gr1 P3 Gr1 P5 Gr1
1shot 2shots 1regular continuous
espresso espresso coffee flow
2 ways of programming are possible to set the coffee dose.
 Choose 1st group (on the left when the user is in front of the machine)
o To program all groups at the same time with the same value.
o The programmed key will have its equivalent key programmed identically on the
others groups
 Choose the others groups separately, if the groups need to have different value.
Methodology:
Put the ground coffee (1 dose or 2 doses according to the programmed key), in the suitable filter
holder.
Press the key n°5 "P5 Gr1" from the selected group during 10 seconds, until it’s blinking.
Release the key n°5 "P5 Gr1"
Display shows “Press dose selection within 30s”
The operation can start in a delay of 10 seconds. Otherwise it go back from the programming
mode.
Press the key to be programmed to start the flow, and press again when water quantity is correct.
The value is directly registered.
Then, continue programming the next key within 10 seconds, and so on for the other keys.
You can use any coffee button after the message “Press dose selection within 30s” disappears
Note : On the factory, each machine undergoes a test protocol on which a program has already been
completed, according to the following settings:
1 espresso = 2,5 cl / 2 espressos = 5 cl / 1 coffee = 4,5 cl / 2 coffee = 9 cl

Edition 05/2015 - CC100 DISPLAY- TECHNICAL DOCUMENTS - page 10
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
8. RELATED FONCTIONS
8.1. ECO MODE SETTING
The evening or before a long period of inactivity, the economic mode of the machine allows the
standby position.
The boiler is then maintained at a temperature of 60°C, which allows:
• saving energy when the temperature drop
• and during the day, as the setpoint temperature is low, this phase mobilizes little energy.
To activate the "ECO" mode, proceed as follows:
• hold the "P5 Gr1" key,
• and press "P3 Gr1"
• all lights will turn off to indicate the change in "ECO" mode,
• the display indicate
• And the "L1 Gr1" led blinks slowly (0.2 sec ON / OFF 2.8 sec).
Output of the "ECO" mode allows the machine to return quickly to its normal functionning mode,
without spending lot of energy.
To return to normal operation, proceed as follows:
• Press the button "P3 Gr1".
• All the LEDs light up to indicate the return to normal operation.
• The machine will heat up to reach the programmed temperature.
The display indicate
The machine will heat up to reach the programmed temperature.
ECO
CONTI ESPRESSO
117°
CONTI ESPRESSO

Edition 05/2015 - CC100 DISPLAY- TECHNICAL DOCUMENTS - page 11
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
8.2. AUTOMATIC CLEANNING OF COFFEE GROUP
The cleaning of coffee group is made group by group, preferably at the end of service, before the
machine is stopped or put in "ECO" mode, using this specific function managed by the machine.
The procedure for cleaning coffee groups is as follows:
• Remove the filter-holder from the group and clean the seal with the supplied brush.
• Insert blind filter (provided with the machine) in the filter-holder.
• Put a detergent tablet (CONTI brand code: 466662) in the blind filter, and engage the filter-
holder in the group.
• Keep pressing key “P5 Gr1”, then press the key “P1 Gr1”.
• The cleaning process starts automatically, with somes ON/OFF cycles. The purpose is to
disolve the tablet, and release the cleaning agent on the coffee group circuit and on the
coffee valve.
• the display indicate
• When the cleaning cycle is finished, and the group is available again.
• Repeat this operating mode on each group.
The cleaning cycle can be interrupted, pushing any key of the concerned group. But, you will lost the
following steps, and will compromise the cleaning efficiency.
It is possible to perform an automatic washing cycle for each group independently
8.3. RESETTING DATA
If necessary, it is possible to re-configure the machine with data by default.
The procedure is as follows:
• Turn off the power supply of the machine.
• Keep pressing simultaneously the keys “P1 Gr1” + “P3 Gr1”+”P5 Gr1”
• Turn the machine on.
• the display indicate
To return to normal operation, turn off and on the machine.
Cleaning Gr x
In progress
Preset value
completed

Edition 05/2015 - CC100 DISPLAY- TECHNICAL DOCUMENTS - page 12
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
9. PROGRAMMING PARAMETERS OF TECHNICAL MENU:
Machine must be in Eco mode (keep pressing MENU button and press ENTER to be in ECO mode).
9.1. FLOW CHART TECHNICAL MENU
ENTER
MENU
USER NAME
CONTI ESPRESSO
MENU
ENTER
Press MENU on group n°1 for 10 sec to access technical menu
+ or - : type name
Press ENTER to go right
+ or - : to choose character
Languagee
GB - USA
MENU
Coffee
Counters
Water liters
xxxx
MENU
Water
Counter
Cumulative total
0000
MENU
Espresso
Group x: 0000
MENU
2 Espresso
Group x: 0000
MENU
1 Coffee
Group x: 0000
MENU
2 Coffee
Group x: 0000
MENU
Continuous
Group x: 0000
MENU
Service Tel.
0000000000
MENU
ECO
CONTI ESPRESSO
MENU
+ or - : type service phone number
Press ENTER to go right
+ or - : to choose character
+ or - : set language (English (GB- USA), French (F), German, Italian)

Edition 05/2015 - CC100 DISPLAY- TECHNICAL DOCUMENTS - page 13
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
MENU
+ ou -
Temperature
117°C
MENU
Temperature
118°C
+ ou -
Time Out filling up
360 sec
MENU
Time Out filling up
450 sec
+ ou -
Filter
0 liters
MENU
Filter
xxxx liters
+ ou -
Pre – brewing
Active
MENU
Pre – brewing
Locked
+ ou -
Filling up
With pump
MENU
Filling up
Without pump
+ ou -
Version machine
Group 2 = coffee
MENU
Version machine
Group 2 = tea
ECO
CONTI ESPRESSO
MENU
+ ou -
Continuous button
Active
MENU
Continuous button
Locked
+ ou -
Program doses
Active Program doses Locked
+ ou -
Temperature Unit
°C Temperature Unit °F
+ or - : to set steam boiler temperautre
+ or - : to set water filter service
Hold the key for 5 seconds scroll faster
+ or - : to set 2
nd
group for tea or coffee mode

Edition 05/2015 - CC100 DISPLAY- TECHNICAL DOCUMENTS - page 14
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
9.2. EXPLANATION FOR THE PROGRAMMING STEPS OF THE
TECHNICAL MENU:
 Language:
There are 4 languages available : ENGLISH (GB-USA) – FRENCH (F) – GERMAN (G) – ITALIAN (I).
 Water counter:
This menu is dedicated to the water softeners system.
This step allows to see the quantity of water consumed (in liter, from 0 to 9999 liters) by the machine
from the last water softener installation.
The quantity of consumed water is made of:
Coffee water going throught the flowmeter.
The water interring in the boiler.
To escape, youneed to press MENU.
 Coffee counters:
Allows partial reading of doses distributed cafes.
Press ENTER to access the menu Counters.
Press MENU to see each key, the display shows:
Cumulative total cycles number (service purpose).
espresso number (1 small cup) on group 1, 2 and 3
2 espresso number (2 small cups) on group 1, 2 and 3
coffee number (1 large cup) on group 1, 2 and 3
2 coffees (2 large cups) on group 1, 2 and 3
NB:
- The counter goes up to 65535 for each button. Then it restarts from 0.
- A distribution is accounted for 1 time for keys " P1 Grx " or "P3 Grx" or "P5 Grx" and 2 times for
the keys " P2 Grx " and "P4 Grx" when you press a key.
 Explanation about counters reset:
Coffee counter reset: when the display shows «Cumulative total», press "P4 Gr1" for 3 seconds,
the display shows then « Total Reset ».
Only the counters of each key is reset. The total counters of products is not reseted.

Edition 05/2015 - CC100 DISPLAY- TECHNICAL DOCUMENTS - page 15
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
 Name:
Type name to be showed on the display.
Press ENTER to go right
To change character press + or –
To finish press MENU
 Service phone number:
Shown on the display together with an alarm message.
Press ENTER to go right
To change number press + or –
To finish press MENU
 Dose programming access:
Dose programming authorization access.
Change with + or -.
 Continual dose access:
Continual dose authorization access.
Change with + or -.
 Temperature unit choice:
°C or °F
All values are automatically converted.
 Steam boiler temperature adjustment:
Adjustment range: 80 to 125 °C (176 °F … 257°F)
We advise 117°C .
To change temperature press + or –
To exit, press MENU, or wait 30 seconds.
 Filling up Time out adjustment:
Adjust maximum opening time of the inlet solenoid valve ; beyond this time, machine stops and an
alarm message is displayed in order to indicate that no water goes in the boiler.
Adjust time with + or – ( up to 360 sec max)
To exit, press MENU, or wait 30 seconds.
CONTI ESPRESSO

Edition 05/2015 - CC100 DISPLAY- TECHNICAL DOCUMENTS - page 16
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
 Water Filter:
Adjust water volume for the water softener maintenance (0 to 9999 litres)
Press + or – to adjust. (Hold the key for 5 seconds scroll faster)
To exit, press MENU, or wait 30 seconds.
When water volume is reached, display shows:
Procedure to reset the water counter :
When the programmed amount of water has been consumed by the machine, the message "Change
Filter" and the service phone number to contact, appears on the display
This message prompts the user to change the cartridge system of water treatment but does not
forbid the distribution of products.
Once the cartridge has been changed, you have to clear the message:
- Switch off the machine (the button ON / OFF).
- Keep pressing the keys “P3 Gr1” and “P4 Gr1” (on left group).
- Turn on the machine (the button ON / OFF), the display shows:
The count resumed at zero.
 Pre Brewing utilisation:
Enables or disables pre-brewing on the 2 keys espresso.
Change with + or -.
 Filling the boiler:
Allows to choose the filling of the boiler :
With pump (if the machine works with tank)
Without pump (if the machine is connected on the network)
Change
H2O filter
Reset H2O filter
counter … wait

Edition 05/2015 - CC100 DISPLAY- TECHNICAL DOCUMENTS - page 17
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
10. SUMMARY OF THE PROCEDURE RESETTING THE COUNTERS
10.1. HOW TO RESET THE COFFEE COUNTER
Put the machine in the "ECO" mode with the key "P5Gr1" and "P3Gr1"
Enter in the programming mode, pressing during 10 seconds the "continuous" key (P5Gr1).
Repeat to press this "P5Gr1" key several time in order to reach "Coffee counters" menu.
Press the key "P3Gr1" to enter in this menu: the display shows «Cumulative total».
Press the key "P4 Gr1" for 3 seconds,
The display shows then « Total Reset ».
Only the counters of each key is reseted. The total counters of products is not reseted.
10.2. RESETTING DATA
If necessary, it is possible to re-configure the machine with data by default.
The procedure is as follows:
• Turn off the power supply of the machine.
• Keep pressing simultaneously the keys “P1 Gr1” + “P3 Gr1”+”P5 Gr1”
• Turn the machine on.
• the display indicate
To return to normal operation, turn off and on the machine.
10.3. PROCEDURE TO RESET THE WATER COUNTER :
When the programmed amount of water has been consumed by the machine, the message "Change
Filter" and the service phone number to contact, appears on the display
This message prompts the user to change the cartridge system of water treatment but does not
forbid the distribution of products.
Once the cartridge has been changed, you have to clear the message:
- Switch off the machine (the button ON / OFF).
- Keep pressing the keys “P3 Gr1” and “P4 Gr1” (on left group).
- Turn on the machine (the button ON / OFF), the display shows:
The count resumed at zero.
Preset value
completed
Reset H2O filter
counter … wait

Edition 05/2015 - CC100 DISPLAY- TECHNICAL DOCUMENTS - page 18
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
11. DESCRIPTION OF ALARMS
These alarms occur when there is a defect on the machine, they are indicated differently depending
on the nature of the defect.
 ALARM TIME OUT 1ST FILLING
If the electronic does not receive information from the SN level probe for more than 360 seconds (at
the 1st filling), the LED "L2" & "L3" of all groups will flash to indicate failure.
 ALARM FLOWMETER
If, during the distribution of coffee, the mother board does not receive pulses from a flowmeter for
more than 4 seconds, all LEDs of the concerned group start flashing to indicate failure. After 45
seconds, the machine automatically stops the solenoid valve of the concerned coffee group and the
pump also.
 ALARM TEMPERATURE SENSOR DISCONNECTED
If the mother board does not receive information from the temperature sensor for more than 3
seconds, the electronics automatically cut off the solid state relay and leds “L1”& "L4" from all groups
will flash to indicate default.
 OVER TEMPERATURE ALARM
If the electronics detects a temperature > 140 °C for more than 5 seconds in the boiler, the LEDs
“L3” of all groups will flash at the same time and the management of the heating is stopped
automatically.The alarm is removed when the temperature drops below 125 ° C.
 ALARM CLEANING GROUP
After making 250 distributions on a same group, the display shows
The machine is still usable but the message does not disappear until the cleaning has not been
made.
To start the cleaning procedure, see chapter: related fonctions.
Clean please
Gr: X
Temperature probe
not connected
Alarm flowmeter
Group x
Alarm Time Out
Fil
ling
Over temperature
steam boiler

Edition 05/2015 - CC100 DISPLAY- TECHNICAL DOCUMENTS - page 19
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
12. HOW TO MAKE THE PERFECT COFFEE
Obtaining a good cup of coffee is the result of certain conditions: the 5 golden rules of perfect
espresso:
MIX / GRINDER / MACHINE / HAND / and MAINTENANCE.
 The Mix:
o The type of coffee is very important. It can be distinguished 2 mains qualities:
 ARABICA:
It gives a fragant taste, sweet, chocolaty, slightly acid, with a pleasant bitterness. The coffee
color is hazelnut cream
 ROBUSTA:
It gives a less fragrant taste, rough, astringent and significantly more bitter. The caffeine
content is about twice. The coffee color is greyish brown.
o The roaster has a great importance on the quality of each coffee (choice of grain,
selection processes, roasting, packaging processes, ...).
 The Grinder:
The grinder and the grind adjustment are essential:
o The coffee grinder:
grinding capacity of the coffee beans must be commensurate with the needs of the
user. Indeed, excessive use causes overheating of the mill wheels and thus a rapid
realignment of the mill.
o The grind adjustment:
setting the mill to choose the fineness of the grind and the right dose required to
achieve optimum coffee. The dose should be adjusted to 7 grams for a cup; finesse
should allow a flow time of coffee in the cup about 20 - 25 seconds: this time ensures
the dissemination of flavors in the cup.
 The Machine:
It must be well adjusted and kept very clean !
o Pump Pressure limited to 9 MPa.
o Water temperature out of the shower must be between 86 °C and 92 ° C
o Correct programming doses.
o Daily cleaning performed every evening.
o Ensure that the water treatment is operating well.
o Follow the maintenance recommendations
