Conti COMPACT Guide

Edition 05/2021
SACOME, Document CONFIDENTIEL, Ne peut être reproduit ni communiqué sans notre accord préalable.
COMPACT
TECHNICAL DOCUMENTATION

Edition 05/2021 –COMPACT –Notice technique –page 1
SACOME, Document CONFIDENTIEL, Ne peut être reproduit ni communiqué sans notre accord préalable.
Index __________________________________________________________ Page
1. TECHNICAL DOCUMENTS _______________________________________________________________2
2. DIMENSIONS_________________________________________________________________________2
3. CAUTION DURING THE USE______________________________________________________________3
4. INSTALLATION _______________________________________________________________________4
5. OPERATION _________________________________________________________________________6
6. HOW TO USE THE MACHINE _____________________________________________________________7
7. PROGRAMMING OF COFFEE DOSAGE ______________________________________________________9
8. RELATED FONCTIONS _________________________________________________________________10
9. PROGRAMMING THE MACHINE __________________________________________________________11
10. DESCRIPTION OF ALARMS _____________________________________________________________13
11. HOW TO MAKE THE PERFECT COFFEE _____________________________________________________14
12. MAINTENANCE OF MACHINES ___________________________________________________________16
13. ELECTRONIC DIAGRAM ________________________________________________________________19
14. HYDRAULIC SCHEMA__________________________________________________________________21
15. OPTION AVAILABLE___________________________________________________________________22

Edition 05/2021 - COMPACT - technical documentation - page 2
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
1. TECHNICAL DOCUMENTS
TYPE
MACHINE
HEATING POWER
(W)
INSTALLED
POWER
(W)
ELECTRICAL
CONSUMPTION
With 230V (A)
2G
2500
2800
12A
BOILER CAPACITY ( LITERS)
2G
TOTAL
7
VOLUME OF HOT WATER
5
VOLUME OF STEAM
2
WEIGHT
empty
(Kg)
WEIGHT
in operation (Kg)
2G
51
57
2. DIMENSIONS

Edition 05/2021 - COMPACT - technical documentation - page 3
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
3. CAUTION DURING THE USE
3.1. AMBIENT CONDITIONS
➢The ambient temperature around the machine had to be between 5°C et 32°C.
➢The ambient humidity must not exceed 70 %
➢The machine must be placed such as the cup warmer is located more than 1.5 meters from the
ground.
3.2. DURING INSTALLATION
➢The installation (electrical connections, water supply and drainage) must be carried out by a
qualified technician approved by CONTI.
➢The machine must be connected to a device conforming to the standards of the country where
the machine is installed. Potential costs of equipment compliance are the only responsibility of
the customer.
➢For any technical intervention, the machines must always have the power disconnected from
the mains.
➢An effective earth connected to the terminal provided for this purpose on the device is
mandatory
➢A screw located under the bottom base machine, allow if necessary, to connect several
machine on an equipotential way.
➢Devices for disconnection from the main supply, having a contact separation of at least 3mm in
all poles, must be provided in the fixed wiring in accordance with the installation rules.
3.3. DURING THE USE
➢When the machine is not operating, the water cut-off valve has to be closed and the electrical
power supply cut.
➢When the machine is not supervised it must be disconnected from the power and water supply.
➢Never disconnect the earthing when the machine is connected to the power supply.
➢Machines must always be disconnected from the main power, in case of technical
interventions.
➢We guarantee our machines subject to a correctly sized water treatment is installed backward
and adjusted according to the carbonate hardness of the water network.
3.4. RULES RELATING TO THE ENVIRONMENT
➢This device has been designed according to the European Directive No. 2002/95/EC. This refers
to the restriction of certain hazardous substances in electrical and electronic equipment
(ROHS)
➢This device has been designed in compliance with the European Directive No. 2002/96/EC
concerning waste electrical equipment (WEEE).
➢This picture informs you that this device should not be discarded with household waste.
➢At end of life, this product must be returned to a collection point or returned to an authorized
dealer. By doing so, you will help to protect the environment and human health.

Edition 05/2021 - COMPACT - technical documentation - page 4
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
4. INSTALLATION
4.1. IN CASE OF A STANDBY OF THE MACHINE (STANDBY = 2 MONTHS):
➢The first thing to do is to test your machine in a lab.
➢If the machine stop ruming for a long time, you could have scale in some places.
➢More precisely in small area like the spray nozzle.
4.2. IF THE MACHINE HAS BEEN TWO MONTHS IN STORAGE BEFORE INSTALLATION:
➢We advise you in this case to pre-test the machine on your shop.
➢After an extended storage of the machine it may appears slowly deposit of limestone;
Especially in small orifices and nozzles.
4.3. PROTECTIONS
➢It is necessary to place before the machine:
oA water shutoff valve.
oAn electrical protection standard, suitable for voltage and power consumption.
4.4. WATER SUPPLY
➢Recommended operating pressure from 1.5 MPa to 6 MPa
➢Water connection pin 3/8"
➢The water supply pipes must resist to 145 Psi / 10 MPa
4.5. DRAIN
➢Without pressure.
➢Spigot at the outlet of the machine and a pipe is supplied with the machine
➢Ensure a connection that causes no risk of fluid return, and ensure good drainage:
▪The drain pipe must be located lower than the machine.
▪Do not create a bend in the exhaust tube.
4.6. SUPPLYING VOLTAGE
➢230V –50/60Hz Monofase

Edition 05/2021 - COMPACT - technical documentation - page 5
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
4.7. WATER SOFTENER
➢When the mains water has a high hardness (>10°TH ou >4 °KH), it is recommanded:
oTo use a water treatment
oTo regenarate regularly the filters.
➢What is the total Hardness of the water ?
oThis is the amount of calcium and magnesium ions in the water.
oThese ions are partly responsible for limestone formation.
oIt is measured with the test strip provided with the machine.
oThe unit of measurement is the ° French (° TH) or the ° German (° dH).
➢What is the Karbonat Hardness of the water ?
oThis is the amount of Carbonate Calcium ions and Carbonate Magnesium ions in the water.
oThese ions are completely responsible for limestone formation.
oIt is measured with chemical dropper testers.
oThe unit of measurment is ° Carbonate (°KH)
There are 2 types of water treatments:
➢Salt water softeners
oThey treat the total water hardness (°TH)
oBy an exchange of sodium ions with calcium and magnesium ions.
oThey require periodic regeneration of the resins by the user.
oTo use when the water hardness is > à 10°TH ou > 5 °GH
➢Resins filters :
oThey treat the Carbonat hardness water (°KH)
oBy fixing carbonate ions on the resins.
oOften fitted with microfiltration and carbon filtration.
oTo use when the Carbonat Hardness is > à 6°KH
oHighly recommended by the manufacturer :
▪The machines are equipped with suitable protection in accordance with flowrate
and the water encountered.
▪The changing cartridges is carried out by the technical service, at intervals to be
determined

Edition 05/2021 - COMPACT - technical documentation - page 6
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
5. OPERATION
5.1. RECOMMANDATIONS
➢Open the general water tap, if it is closed, then open the water shutoff valve dedicated to the
machine.
➢Do not put the supplying voltage at this moment.
➢Verify the presence of water, by reading the pressure of the mains water inlet on the M2
manometer pump.
5.2. INITIAL FILLING
➢Ensure that steam taps operating levers ‘V’ are open (up).
➢Put the ON/OFF switch ‘C’ to position 1 (power on).
➢The key board turn on.
➢The boiler fills automatically, without heating.
➢The machine start to heat automatically, only when the level probe is reached by the water
➢A scrolling LED on keypads can inform the user about the status.
➢Close the steam tap “V” and wait.
➢When the scrolling leds stops : The machine is ready to operate
5.3. FURTHER FILLINGS
➢Further fillings will run automatically, according to the hot water needs.
➢The water level in the boiler is controlled by the electronics, by the means of a level probe.

Edition 05/2021 - COMPACT - technical documentation - page 7
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
6. HOW TO USE THE MACHINE
6.1. OPERATING ELEMENTS
➢STEAM FUNCTION
Two steams taps levers « V » are provided to allows:
•The heating of liquids by spraying steam.
•The milk foam production to create Cappuccino or Macchiatto.
The liquid to be heated should preferably be placed in a deep container.
The tip of the steam wand outlet must be immersed in the liquid, without touching the bottom of the
container.
The steam may also be used to sterilise and warm glasses.
After each use and absolutely after heating milk, always clean the stainless steel steam nozzle and the
outlet nozzles with a damp cloth, removing all traces present.
A rinsing of the steam lance inner holes is to be done by a short opening of the tap to release a jet of steam.
➢HOT WATER FUNCTION
A electrical ON/OFF switch 'E' is provided for preparing tea, grog, etc.
Be careful, not to be burnt by the pressure water spray.
➢FILTERS
The machine is equipped with two types of filters: 1 cup and 2 cups.
Each filter is operating with its own holder-filter to produce respectively 1 cup or 2 cups of coffee.
Filters need to be unclogged and clean, so they need to be cleaned almost once a day with hot water, by
being removed from the holder filters.
Take care to remove all residual traces of coffee and ensure proper cleanliness of perforations in the
bottom of the filter.
➢FILTER-HOLDER
Never remove the filter-holder during operation of the group. The end of extraction is checkable with coffee
spouts: they no longer have to eject liquid.
Be careful to always keep the filter-holder engaged in the group, emptied of coffee cake, to keep them
warm.
In case of an extended stopping period, remove the filter-holder from the group, taking care to eject the
used grounds remain in the filter-holder.
Tighten the filter-holder until to be in contact with the seal, exceeding a little bit. The sealing is guaranteed.
Do not unnecessarily try to crush the seal by tightening the filter at the maximum of your possibilities. It
may damage the seal or age it prematurely.
To empty the coffee filters used, turn the filter holder upside-down and lightly tap it on the edge of a
wooden box. Never strike it against metal or other hard objects.

Edition 05/2021 - COMPACT - technical documentation - page 8
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
➢MANOMETER M1 : BOILER PRESSURE
The boiler pressure is adjusted in factory between 0,8 MPa (12 PSI) and 1 MPa (15 PSI). This value varies
slightly around its nominal temperature, due to the PID system which controls the heating and limit the
current consumption to its minimum.
NOTE: An over-heating thermostat will cut the heating, in case of an abnormal high temperature.
➢MANOMETER M2 : PUMP PRESSURE
The pump pressure is adjusted at 9 MPa in the factory. Value which allows the best extraction of coffee
flavors. A bypass system evacuates over-pressure.
NOTE: Simultaneous operation of all the groups can impact a little bit the pressure level.
Visualization of the presence of water network is done by consulting the gauge
6.2. HOW TO USE THE PROGRAMMED DOSES
➢Simply select one of the buttons available on each keypad to obtain the doses or the programmed
drinks.
➢The selected dose is shown by a blinking led on the keypad.
➢The flow can be stopped by repressing:
oThe same button or
oThe STOP button (which is also the programming and continuous flow button).

Edition 05/2021 - COMPACT - technical documentation - page 9
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
7. PROGRAMMING OF COFFEE DOSAGE
7.1. PROGRAMMING PROCEDURES
Programming is done on the group 1 (left group), the 5 keys are defined as follows:
P1 Gr1 P2 Gr1 P3 Gr1 P4 Gr1 P5 Gr1
1shot 2shots 1regular 2regular continuous
espresso espresso coffee coffee flow
2 ways of programming are possible to set the coffee dose.
➢Choose 1st group (on the left when the user is in front of the machine)
oTo program the right group at the same time with the same value.
oThe programmed key will have its equivalent key programmed identically on the right
group
➢Choose the right group separately, if the groups need to have different value.
Methodology:
Put the ground coffee (1 dose or 2 doses according to the programmed key), in the suitable filter holder.
Press the key n°5 "P5 Gr1" from the selected group during 10 seconds, until it’s blinking.
Release the key n°5 "P5 Gr1"
The operation can start in a delay of 10 seconds. Otherwise it go back from the programming mode.
Press the key to be programmed to start the flow, and press again when water quantity is correct. The
value is directly registered.
Then, continue programming the next key within 10 seconds, and so on for the other keys.
Wait 10 seconds to escape from the programming mode, and then you can use machine normally.
Note : On the factory, each machine undergoes a test protocol on which a program has already been
completed, according to the following settings:
1 espresso = 2,5 cl / 2 espressos = 5 cl / 1 coffee = 4,5 cl / 2 coffee = 9 cl

Edition 05/2021 - COMPACT - technical documentation - page 10
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
8. RELATED FONCTIONS
8.1. ECO MODE SETTING
The evening or before a long period of inactivity, the economic development mode of the machine allows
the standby position.
The boiler is then maintained at a temperature of 60°C, which allows:
•saving energy when the temperature drop
•and during the day, the setpoint temperature maintenance is low, this phase mobilizes little energy.
To activate the "ECO" mode, proceed as follows:
•hold the "P5 Gr1" key,
•and press "P3 Gr1"
•all lights will turn off to indicate the change in "ECO" mode,
•LEDs and "L1 Gr1" blinks slowly (0.2 sec ON / OFF 2.8 sec).
The output of "ECO" mode allows the machine to return quickly to its mode of operation, without large
expenditures of energy.
To return to normal operation, proceed as follows:
•Press the button "P3 Gr1".
•All the LEDs light up to indicate the return to normal operation.
•The machine will heat up to reach the programmed temperature.
8.2. AUTOMATIC CLEANNING OF COFFEE GROUP
The cleaning of coffee group is made group by group, preferably at the end of service, before the machine is
stopped or put in "ECO" mode, using this specific function managed by the machine.
The procedure for cleaning coffee groups is as follows:
•Remove the filter-holder from the group and clean the seal with the supplied brush.
•Insert blind filter (provided with the machine) in the filter-holder.
•Put a detergent tablet (CONTI brand code: 466662) in the blind filter, and engage the filter-holder in
the group.
•Keep pressing key n°5 (P5 Gr1), then press the key n°1 (P1 Gr1).
•The cleaning process starts automatically, with somes ON/OFF cycles. The purpose is to disolve the
tablet, and release the cleaning agent on the coffee group circuit and on the coffee valve.
•When the cleaning cycle is finished, and the group is available again.
•Repeat this operating mode on each group.
The cleaning cycle can be interrupted, pushing any key of the concerned group. But, you will lost the
following steps, and will compromise the cleaning efficiency.
It is possible to perform an automatic washing cycle for each group independently
8.3. RESETTING DATA
If necessary, it is possible to re-configure the machine with data by default.
The procedure is as follows:
•Turn off the power supply of the machine.
•Keep pressing simultaneously the keys “P1 Gr1” + “P3 Gr1”+”P5 Gr1”
•Turn the machine on.
•When led n°1, n°3 and n°5 are lighting, release the button
To return to normal operation, turn off and on the machine.

Edition 05/2021 - COMPACT - technical documentation - page 11
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
9. PROGRAMMING THE MACHINE
9.1. PROGRAMMING OF PRE-BREWING (1SEC ON / 1SEC OFF)
The pre-brewing is only available on Espresso (1 or 2 shots).
The pre-brewing is adjusted by default on these 2 buttons, if the user wants to delete it, he needs to do as
follows:
➢Settings without pre-brewing:
•Turn off the machine.
•Keep pressing the key “P2 Gr1” then turn the machine on.
•When the LED of the key “P5 Gr1” key lights, turn off the machine again.
•Wait a few seconds then turn on the machine.
If the user want to put the pre-brewing he needs to do as follows:
➢Setting the machine with pre-infusion:
•Turn off the machine.
•Keep pressing the key “P1 Gr1” then turn the machine on.
•When the LED of the “continuous flow” key lights, turn off the machine again.
•Wait a few seconds then turn on the machine.
9.2. PROGRAMMING OF BOILER TEMPERATURE
The factory temperature setting is adjusted at 117 °C by default.
The temperature can be set between 105 ° C and 124 ° C, to change the setting proceed as follows:
•Turn off the machine.
•Keep pressing the keys "P3 Gr1 +" P4 Gr1 + "P5 Gr1" and turn on the machine.
The technician can view the temperature by flashing the LEDs “L1 Gr1 " L2 Gr1" "L3 Gr1. It
corresponds to the hundreds, tens and units of the temperature (in ° C). There is a pause of 2
seconds between 2 visualizations of temperature to allow the user to make a new recording. If a
value is zero, the corresponding LED does not light.
Example of reading for a temperature at 115 ° C:
Reading the number of flashes of the hundred: 1
Reading the number of flashes of the ten: 1
Reading the number of flashes the unit: 5
•To change the set point you have to press the key "P1 Gr1" to decrease (- key) or "P2 Gr1" to
increase (+ key). For each action on the key the value is changed by 1 unit. During the changes, the
LEDs remain off.
If the electronic does not detect any change in the setting for more than one second, the sequence
of displaying the temperature start again for a new visualization.
To exit the programming phase, turn off and on again the machine.

Edition 05/2021 - COMPACT - technical documentation - page 12
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
P1 Gr1 pre_brewing active
P2 Gr1 pre_brewing disabled
P3 Gr1 P4 Gr1 P5 Gr1 temperature setting
P1 Gr1 P4 Gr1 filling up with pump
P2 Gr1 P4 Gr1 filling up without pump
P1 Gr1 P3 Gr1 P5 Gr1 resetting data
9.3. PROGRAMMING THE FILLING UP THE BOILER WITH THE PUMP
If the machine is connected to a water network, it is not necessary to use the pump for filling the boiler
(minimum inlet pressure 1.5bar).
If the machine is connected to a water tank, to fill the boiler you have to activate the pump.
The machine is configured by default "without pump" to fill the boiler.
If the technician wants to use the pump to fill the boiler, it must proceed as follows:
➢Settings of the machine to use the pump to fill up the boiler:
•Turn off the machine.
•Keep pressing the keys "P1 Gr1" + "P4 Gr1" and turn on the machine.
•When the LEDs "L1 Gr1" + "L4 Gr1" light, turn off the machine again.
•Wait a few seconds then turn on the machine.
If the technician wants to eliminate the use of the pump when filling boiler, you must proceed as
follows:
➢Settings of the machine to suppress the pump to fill up the boiler
•Turn off the machine.
•Keep pressing the keys "P2 Gr1" +"P4 Gr1" and turn on the machine.
•When the LED "L2 Gr1" + "L4 Gr1" light, turn off the machine again.
•Wait a few seconds and then turn on the machine.
9.4. SUMMARY OF PROGRAMMABLE FUNCTIONS

Edition 05/2021 - COMPACT - technical documentation - page 13
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
10. DESCRIPTION OF ALARMS
These alarms occur when there is a defect on the machine, they are indicated differently depending on the
nature of the defect.
➢ALARM TIME OUT 1ST FILLING
If the electronic does not receive information from the SN level probe for more than 360 seconds (at the 1st
filling), the LED "L2" & "L3" of all groups will flash to indicate failure.
➢ALARM FLOWMETER
If, during the distribution of coffee, the mother board does not receive pulses from a flowmeter for more
than 4 seconds, all LEDs of the concerned group start flashing to indicate failure. After 45 seconds, the
machine automatically stops the solenoid valve of the concerned coffee group and the pump also.
➢ALARM TEMPERATURE SENSOR DISCONNECTED
If the mother board does not receive information from the temperature sensor for more than 3 seconds, the
electronics automatically cut off the solid state relay and leds “L1”& "L4" from all groups will flash to
indicate default.
➢OVER TEMPERATURE ALARM
If the electronics detects a temperature > 140 °C for more than 5 seconds in the boiler, the LEDs “L3” of all
groups will flash at the same time and the management of the heating is stopped automatically.The alarm
is removed when the temperature drops below 125 ° C.

Edition 05/2021 - COMPACT - technical documentation - page 14
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
11. HOW TO MAKE THE PERFECT COFFEE
Obtaining a good cup of coffee is the result of certain conditions: the 5 golden rules of perfect espresso:
MIX / GRINDER / MACHINE / HAND / and MAINTENANCE.
➢The Mix:
oThe type of coffee is very important. It can be distinguished 2 mains qualities:
▪ARABICA:
It gives a fragant taste, sweet, chocolaty, slightly acid, with a pleasant bitterness. The coffee color is
hazelnut cream
▪ROBUSTA:
It gives a less fragrant taste, rough, astringent and significantly more bitter. The caffeine content is
about twice. The coffee color is greyish brown.
oThe roaster has a great importance on the quality of each coffee (choice of grain, selection
processes, roasting, packaging processes, ...).
➢The Grinder:
The grinder and the grind adjustment are essential:
oThe coffee grinder:
grinding capacity of the coffee beans must be commensurate with the needs of the user.
Indeed, excessive use causes overheating of the mill wheels and thus a rapid realignment of
the mill.
oThe grind adjustment:
setting the mill to choose the fineness of the grind and the right dose required to achieve
optimum coffee. The dose should be adjusted to 7 grams for a cup; finesse should allow a
flow time of coffee in the cup about 20 - 25 seconds: this time ensures the dissemination of
flavors in the cup.
➢The Machine:
It must be well adjusted and kept very clean !
oPump Pressure limited to 9 MPa.
oWater temperature out of the shower must be between 86 °C and 92 ° C
oCorrect programming doses.
oDaily cleaning performed every evening.
oEnsure that the water treatment is operating well.
oFollow the maintenance recommendations

Edition 05/2021 - COMPACT - technical documentation - page 15
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
➢The Hand:
Skill of the operator: He must of course control the above three factors, but also:
➢He know how to maintain coffee.
oFor exemple, a milling do not remain in the open air.
oHe know that coffee bean loses 1% of its flavor by day ground coffee, it loses 45% day.
oTherefore he avoid grinding too much coffee at once, or keep in drawers.
➢The filter-holder need to be warm, so it must be maintained on the group.
➢The cups need to be warm, about 40 ° C. They are therefore placed on the cup warmer.
➢He damp correctly the coffee in the filter-holder.
➢He ensure proper regularity milling for constant quality coffees.
➢The Maintenance
This is the necessary condition for the success of a good coffee:
At the end of each daily period of activity, it is strongly recommended to perform a cleaning operation on
each group coffee.
Double impact:
oImprove coffee quality by eliminating oxidized fats
oEnsure the proper operation of the coffee group.

Edition 05/2021 - COMPACT - technical documentation - page 16
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
12. MAINTENANCE OF MACHINES
➢DAILY MAINTENANCE
-Clean the hot water outlet and the steam outlets with a scouring pad:
oUse a needle to keep the diffuser outlets unclogged.
oThen purge by opening the tap a few seconds.
-Clean the drip tray and the basin, removing them from the machine.
-Remove the filter-holder from the groups and clean the seal injection filter-holder with the brush.
-Use the automatic process cleaning:
oInsert blind filter in the filter holder and place the CONTI cleaning tablet code n°466662
oEngage this filter-holder on the group to be cleaned
oSimultaneously press the 5th (continuous) and the first key (1 espresso)
oThe automatic cleaning process of the group is started
oRepeat this procedure on each group.
-Brush the filters in water containing detergent:
oIn order to unclog the holes
oNever use a needle or a flame.
-For sanitary reasons, be sure to consume at least 2 liters of hot water per day.
➢HALF YEAR MAINTENANCE
-A kit n° 470891, for the following operation is available for sale.
-For each group:
oRemove the sprinkler, diffuser, and seal gasket.
oScrub the gasket groove and the supplying hole on the group head.
oClean the diffuser. Clear all the holes with a needle.
oReassemble the diffuser on the group head
oPlace NEW Filter gasket, and NEW sprinkler.
-Remove and clean the level sensor (limestone deposit).

Edition 05/2021 - COMPACT - technical documentation - page 17
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
➢ANNUAL MAINTENANCE
-A kit n° 470892, for the following operation is available for sale.
-Change the pump inlet filter (No. 411861)
-On the boiler:
oChange vaccum valve (No. 408898)
oChange the safety valve (No. 404326)
-On the inlet bloc valves:
oChange the filter (No. 470199)
oReplace the gasket (No. 219100) of 2 non-return valves
oRemove and clean the gasket limiter 12 Bars
oClean the nucleus of the solenoid inlet water boiler
-On the coffee groups
oChange the O-ring nozzle (No. 403457) and the filter nozzle (No. 403458)
oClean the 3rd way and the nucleus of the solenoid coffee valves
-On the 2 steam taps
oChange the 2 O-rings (No. 403457)
oChange the 2 gasket (No. 407502)
-On the 2 "steam" output and on the "hot water" output
oChange the O-ring (No. 061200)
oChange the O-ring (No. 055300)
-For water quality issues, it is recommended to completely drain the boiler.

Edition 05/2021 - COMPACT - technical documentation - page 18
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
➢BIENNiAL ENTRETIEN
-A kit n° 470892, for the following operation is available for sale.
-Change the pump inlet filter (No. 411861)
-On the boiler:
oChange vaccum valve (No. 408898)
oChange the safety valve (No. 404326)
-On the inlet bloc valves:
oChange the filter (No. 470199)
oReplace the gasket (No. 219100) of 2 non-return valves
oRemove and clean the gasket limiter 12 Bars
oChange the inlet boiler valve (No. 470161) + 2 PTFE gasket (No. 407500)
-On the coffee groups:
oRemove all the parts and uncork all the holes in the group head.
oChange the O-ring nozzle (No. 403457)
oChange the filter nozzle (No. 403458)
oChange the solenoid coffee (No. 407329) + 2 PTFE gasket (No. 407500)
-On the 2 steam tap:
oChange the 2 O-rings (No. 403457)
oChange the 2 gasket (No. 407502)
-On the rotary lever:
oChange the damper O-ring (n° 055200)
-On the 2 "steam" output and on the "hot water" output:
oChange the O-ring (No. 061200)
oChange the O-ring (No. 055300)
oChange the washer (No. 401320)
oChange the O-ring of steam nozzles (No. 055400)
-Change the silicone tubes evacuation 3-way valves cafes (No. 405621)

Edition 05/2021 - COMPACT - technical documentation - page 19
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
13. ELECTRONIC DIAGRAM
13.1. DESIGNATION OF USEFUL CODES
REF.
DESIGNATIONS
DESIGNATION
CE
Carte électronique
Electronic controller
CN
Connecteur tableau
Panels connector
CV
Compteur volumétrique
Flow meter
EC
EV eau chaude
Solenoid valve hot water
EE
EV entrée eau
Solenoid valve water feeding
EVG
EV de groupe
Group solenoid valve
MP
Motopompe
Motor/pump
RC
Résistance chauffage
Immersion heater
SSR
Relais statique 12Vdc - 230Vac 25A
Solid state relay 12Vdc - 230Vac 25A
ST
Sonde de température
Temperatur sensor
TS
Thermostat de surchauffe
Overheating thermostat
CODE
COULEUR
FILS
CABLE
COLOUR
CODE
1
marron
Brown
2
rouge
Red
3
orange
orange
4
jaune
Yellow
5
vert
Green
6
bleu
Blue
6f
bleu foncé
Blue dark
7
violet
violet
8
gris
Grey
9
blanc
White
0
noir
black
