Conti MONTE-CARLO Guide

MONTE-CARLO - 11/2015 - SOFT V 2.11 1
TECHNICAL DOCUMENTATION

MONTE-CARLO - 11/2015 - SOFT V 2.11 2
1TECHNICAL DOCUMENTS 3
2DIMENSIONS 3
3CAUTION DURING THE USE 4
3.1 Ambient conditions 4
3.2 During installation 4
3.3 During the use 4
3.4 Rules relating to the environment 4
4INSTALLATION 5
4.1 Standby In case of a standby of the machine (standby = 2 months): 5
4.2 Protections 5
4.3 Water supply 5
4.4 Drain 5
4.5 Supplying voltage 5
4.6 Water softeners 6
5FIRST INSTALLATION: 7
6STARTING & WARM UP: 9
7HOW TO USE THE MACHINE 11
7.1 Operating elements 11
7.2 How to use the programmed doses 12
8COFFEE GROUPS: 13
8.1 Mode menu 13
8.2 Group eco mode 15
8.3 Clean button 15
9PROGRAMMING DOSES METHODOLOGY 16
9.1 Coffee doses programming: 16
9.2 Hot water dose programming: 17
10 GENERAL DISPLAY: 18
10.1 ECO MODE (general) 18
10.2 Programming on general display 18
11 COFFEE TEMPERATURE ADJUSTMENTS 37
12 QUALITY CRITERIA 38
13 STEAM CONTROL PRODUCTS ADJUSTMENTS 39
14 SOFTWARE VERSION UPDATE 40
15 MAINTENANCE OF MACHINES 42
16 ELECTRIC DESIGNATIONS 45
17 ELECTRIC DRAWING 46
17.1 CPU board 46
17.2 Electrical power diagram for “400V 3L N PE” 47
17.3 Electrical power diagram for “230 V 1L N PE” 48
17.4 Connecting diagram: 12 fuses box 49
17.5 Solid state relay interface for “400 V 3NAC” 53
17.6 Low voltage wiring 54
18 HYDRAULIC SCHEME 55
19 ALARM 57
20 POWER MANAGEMENT 59

MONTE-CARLO - 11/2015 - SOFT V 2.11 3
1 TECHNICAL DOCUMENTS
Steam boiler
Coffee boiler
Group
Outlet
Total
power
Capacity
(liter)
Power
(W)
Capacity
(liter)
Number
Power
(W)
Number
Power
(W)
Power
(W)
(W)
MC 2G
10
4200
0,9
2
1000
2
100
300
6700
MC 3G
14
6000
0,9
3
1000
3
100
300
9600
MC 2G K
10
6000
0,9
2
2500
2
100
300
11500
MC 3G K
14
6000
0,9
3
2500
3
100
300
14100
BOILER CAPACITY ( IN LITERS )
2 Groups
3 Groups
TOTAL
10
14
Hot water volume
6,5
10
Steam volume
3,5
4
Coffee boiler volume
2 x 0.9
3 x 0.9
WEIGHT (kg)
EMPTY
(Kg)
Weight
in operation (Kg)
2G
89
97
3G
99
112
2 DIMENSIONS
Cup warmer capacity: (88 espressos cups) or (56 espressos cups + 18 cappucino cups)

MONTE-CARLO - 11/2015 - SOFT V 2.11 4
3 CAUTION DURING THE USE
3.1 Ambient conditions
The ambient temperature around the machine had to be between 5°C and 32°C.
The ambient humidity must not exceed 70 %
The machine must be placed such as the cup warmer is located more than 1.5 meters
from the ground.
3.2 During installation
The installation (electrical connections, water supply and drainage) must be carried out by
a qualified technician approved by CONTI.
The machine must be connected to a device conforming to the standards of the country
where the machine is installed. Potential costs of equipment compliance are the only
responsibility of the customer.
For any technical intervention, the machines must always have the power disconnected
from the mains.
An effective earth connected to the terminal provided for this purpose on the device is
mandatory
A screw located under the bottom base machine, allow if necessary, to connect several
machine on an equipotential way.
Devices for disconnection from the main supply, having a contact separation of at least
3mm in all poles, must be provided in the fixed wiring in accordance with the installation
rules.
3.3 During the use
When the machine is not operating, the water cut-off valve has to be closed and the
electrical power supply cut.
When the machine is not supervised it must be disconnected from the power and water
supply.
Never disconnect the earthing when the machine is connected to the power supply.
Machines must always be disconnected from the main power, in case of technical
interventions.
3.4 Rules relating to the environment
This device has been designed according to the European Directive No. 2002/95/EC. This
refers to the restriction of certain hazardous substances in electrical and electronic
equipment (ROHS)
This device has been designed in compliance with the European Directive No.
2002/96/EC concerning waste electrical equipment (WEEE).
This picture informs you that this device should not be discarded with household waste.
At end of life, this product must be returned to a collection point or returned to an
authorized dealer. By doing so, you will help to protect the environment and human
health.

MONTE-CARLO - 11/2015 - SOFT V 2.11 5
4 INSTALLATION
4.1 Standby In case of a standby of the machine (standby = 2 months):
The first thing to do is to test your machine in a lab.
If the machine stops running for a long time, you could have sediment in some places.
More precisely in small area like the spray nozzle.
4.2 Protections
It is necessary to place before the machine:
oA water shut off valve.
oAn electrical protection standard, suitable for voltage and power consumption.
4.3 Water supply
Recommended operating pressure from 1.5 MPa to 6 MPa
Water connection pin 3/8"
The water supply pipes must resist to 145 Psi / 10 MPa
4.4 Drain
Without pressure.
A tip on the outlet of the machine and a pipe is supplied with the machine
Ensure a connection that causes no risk of fluid return, and ensure good drainage:
The drain pipe must be located lower than the machine.
Do not create a bend in the exhaust tube.
4.5 Supplying voltage
To be specify when ordering : 230V –50/60Hz Monofase
Or : 400V –50/60Hz Trifase

MONTE-CARLO - 11/2015 - SOFT V 2.11 6
4.6 Water softeners
When the mains water has a high hardness (>10°TH ou >4 °KH), it is recommanded:
oTo use a water treatment
oTo regenarate regularly the filters.
What is the total Hardness of the water ?
oThis is the amount of calcium and magnesium ions in the water.
oThese ions are partly responsible for limestone formation.
oIt is measured with the test strip provided with the machine.
oThe unit of measurement is the ° French (° TH) or the ° German (° dH).
What is the Karbonat Hardness of the water?
oThis is the amount of Carbonate Calcium ions and Carbonate Magnesium ions in the
water.
oThese ions are completely responsible for limestone formation.
oIt is measured with chemical dropper testers.
oThe unit of measurment is ° Carbonate (°KH)
There are 2 types of water treatments:
Salt water softeners
oThey treat the total water hardness (°TH)
oBy an exchange of sodium ions with calcium and magnesium ions.
oThey require periodic regeneration of the resins by the user.
oTo use when the water hardness is > à 10°TH or > 5 °GH
Resins filters :
oThey treat the Carbonat hardness water (°KH)
oBy fixing carbonate ions on the resins.
oOften fitted with microfiltration and carbon filtration.
oTo use when the Carbonat Hardness is > à 6°KH
oHighly recommended by the manufacturer :
The machines are equipped with suitable protection in accordance with flowrate
and the water encountered.
The changing cartridges is carried out by the technical service, at intervals to
be determined

MONTE-CARLO - 11/2015 - SOFT V 2.11 7
5 FIRST INSTALLATION:
A. Open the water supply tap
B. Switch on the machine using the ON/OFF switch under the drip tray.
C. During 1 second
The general display shows the software version “Monte Carlo 2.11”.
D. According the situation the display shows:
E. Enter the password to access the first installation, as follows:
1° step:
Press MENU for 6 seconds
2° step:
Press:
ON/OFF Switch
OFF
OFF
MC 2.11
Please
wait!
Push "where you want" on the display during
3 sec until:

MONTE-CARLO - 11/2015 - SOFT V 2.11 8
3° step:
Press:
4° step:
Press:
5° step:
The display shows:
F. The display shows:
Let the machine doing the 1° installation.
During this time, the air inside coffee groups are automatically vaccum by an opening cycle of vaccum
valves, pump and groups valves.
G. The process is finished when the display shows:
Press
H. The display shows:
First Install
First Install
No
First Install
Yes
First Install
In progress
First Install
Press twice

MONTE-CARLO - 11/2015 - SOFT V 2.11 9
6 STARTING & WARM UP:
A. Switch ON the machine by pressing on the main display.
B. The key boards are lighting, and shows the coffee boilers temperature settings
Coffee buttons are blinking. General display blinking
C. When the temperature setting of coffee boilers is reached (2 or 3 minutes): automatic purge goes on.
The leds stay On General display blinking
D. When the steam boiler temperature reaches 105°C: hot water button lights up.
The leds stay On General display blinking
E. When the steam boiler temperature setting is reached (ex.125°C).
The machine is ready. All the lights stay On.
General display shows manometers
Please
wait!

95°C
95°C
95°C
95°C
Please
wait!
Please
wait!
95°C
95°C

MONTE-CARLO - 11/2015 - SOFT V 2.11 10
F. Main display
When the machine is ready, the general display shows:
Boiler pressure (bar) Pressure
(network/pump pressure)
Level information
(In progress)
Press “where you want” on the display, during 3 sec to switch OFF the machine
The display shows:
ON/OFF

MONTE-CARLO - 11/2015 - SOFT V 2.11 11
7 HOW TO USE THE MACHINE
7.1 Operating elements
STEAM FUNCTION
Two steams taps levers « V » are provided to allow:
The heating of liquids by spraying steam.
The milk foam production to create Cappuccino or Macchiatto.
The liquid to be heated should preferably be placed in a deep container.
The tip of the steam wand outlet must be immersed in the liquid, without touching the bottom of the
container.
The steam may also be used to sterilise and warm glasses.
After each use and absolutely after heating milk, always clean the stainless steel steam nozzle and
the outlet nozzles with a damp cloth, removing all traces present.
A rinsing of the steam lance inner holes is to be done by a short pulse on the lever downwards to
release a jet of steam.
HOT WATER FUNCTION
Two electric taps “E” are provided for preparing tea, grog, etc.
Be careful, not to be burnt by the pressure water spray.
For that, the valve is coupled to cold water mixing for adjusting the water T° for tea and avoids spitting
hot water.
Each electric tape is controlled with 2 buttons for 2 different times

MONTE-CARLO - 11/2015 - SOFT V 2.11 12
FILTERS
The machine is equipped with two types of filters: 1 cup (10 G) and 2 cups (18 G)
Each filter is operating with its own holder-filter to produce respectively 1 cup or 2 cups of coffee.
Filters need to be unclogged and clean, so they need to be cleaned almost once a day with hot water,
by being removed from the holder filters.
Take care to remove all residual traces of coffee and ensure proper cleanliness of perforations in the
bottom of the filter.
FILTER-HOLDER
Never remove the filter-holder during operation of the group. The shutdown is controllable with coffee
spouts: they no longer have to eject liquid.
Be careful to always keep the filter-holder engaged in the group, emptied of coffee cake, to keep them
warm.
In case of an extended stopping period, remove the filter-holder from the group, taking care to eject
the used grounds remain in the filter-holder.
Tighten the filter-holder until to be in contact with the seal, exceeding a little bit. The sealing is
guaranteed.
Do not unnecessarily try to crush the seal by tightening the filter at the maximum of your possibilities.
It may damage the seal prematurely.
To empty the coffee filters used, turn the filter holder upside-down and lightly tap it on the edge of a
wooden box. Never strike it against metal or other hard objects.
DIGITAL MANOMETER M1 : BOILER PRESSURE
The boiler pressure is adjusted in factory between 0,8 MPa (12 PSI) and 1 MPa (15 PSI). This value
varies slightly around its nominal temperature, due to the PID system which controls the heating and
limits the current consumption to its minimum.
Factory settings: 1.2 MPa with setting range from 0.8 MPa to 1.4 MPa .
NOTE: An over-heating thermostat cut the power on the general relay, in case of an abnormal high
temperature. The machine is not anymore supplied.
DIGITAL MANOMETER M2 : PUMP PRESSURE
The pump pressure is adjusted at 9 MPa in the factory. Value which allows the best extraction of
coffee flavors. A bypass system evacuates over-pressure.
NOTE: Simultaneous operation of all the groups can impact a little bit the pressure level.
Visualization of the presence of water network is done by consulting the gauge
7.2 How to use the programmed doses
Simply select one of the buttons available on each keypad to obtain the doses or the
programmed drinks.
The selected dose is shown by a blinking led on the keypad.
The flow can be stopped by repressing:
oThe same button or
oThe STOP button (which is also the programming and continuous flow button).

MONTE-CARLO - 11/2015 - SOFT V 2.11 13
8 COFFEE GROUPS:
8.1 Mode menu
Press the "Menu/Enter" button to enter in the programming mode.
The "Esc" button is used to escape from the programming mode.
MENU/ENTER - +
Esc
95°C
Coffee boiler T°
Group temperature
MENU A
Pre brewing
Dose setting
MENU C
Counters
MENU E
NORMAL MODE
ESC
ESC
ESC
ESC
ESC
-+
MENU D
"MENU"
-+
-+
-+
MENU B

MONTE-CARLO - 11/2015 - SOFT V 2.11 14
A) COFFEE BOILER TEMPERATURE
B) GROUP TEMPERATURE
C) DOSE SETTING
Coffee boiler T°
95°C
ENTER
+
-
Coffee boiler T°
Coffee boiler T°
94°C
ESC
Press "menu" to validate and "ESC" to escape
Group temperature
88°C
ENTER
+
-
Group temperature
Group temperature
89°C
Dose setting
ENTER
Dose setting
ESC
All the leds are OFF
It is enough to program the left group so that both
groups are configured in the same way.
Do the dose and stop at the desired volume.
When the dose is programmed the led button
remain lighting
Do the same for the others buttons
The continuous is not programmable.
The hot water button (close to the keyboard)
is programmable like the coffee dose.
Press "menu" to validate and "ESC" to escape
PRESS "MENU"to validate and "ESC" to escape
ESC

MONTE-CARLO - 11/2015 - SOFT V 2.11 15
D) PRE BREWING
E) COUNTERS
8.2 Group eco mode
If you press on the "ECO" button, you enter in the "ECO" mode: the coffee boiler switches off. The
group is desabled but the group head is maintained at temperature. The other groups remain
functionning. Press again on the "ECO" button to enable the group.
8.3 Clean button
If you press on the "CLEAN" button, the cleaning cycle starts.
Prepare the blind filter holder and cleaning tablet
Put it on the group head
Press the "CLEAN" button
The machine starts the cleaning cycle without any special indication.
A bar graph indicates the cleaning progress.
Prebrew. EV open sec
Espresso 20
ENTER
+
-
Pre brewing
Espresso
10
ENTER
+
-
Counters
Other button
xx
Press "menu" to reset the counters
PRESS "MENU"to validate and "ESC" to escape
to adjust the closed time
Prebrew. EV closed sec
Espresso 20
MENU to adjust the other button
+
-
to adjust the delay time
Closed
Delay
Time
ESC
ESC

MONTE-CARLO - 11/2015 - SOFT V 2.11 16
9 PROGRAMMING DOSES METHODOLOGY
9.1 Coffee doses programming:
MENU/ENTER - +
Esc
2 ways of programming are possible to set the coffee dose.
Choose 1st group (on the left when the user is in front of the machine)
oTo program all groups at the same time with the same value.
oThe programmed key will have its equivalent key programmed identically on the others
groups
Choose each group separately, if they the groups need to have different value.
Methodology:
Put the ground coffee (1 dose or 2 doses according to the programmed key), in the suitable filter
holder.
Press the “MENU” key: the display show “Coffee boiler T”
Press 2 times the “+” key: the display shows “Doses setting”
Press the “MENU” key: the display shows:
The button to be programmed are not lighting.
Press the key to be programmed to start the flow, and press again when water quantity is correct.
The value is directly registered
The programmed key remains On
Then, keep programming the next key, and so on for the others keys.
Note : On the factory, each machine undergoes a test protocol on which a program has already been
completed, according to the following settings:
1 espresso = 2,5 cl / 2 espressos = 5 cl / 1 coffee = 4,5 cl / 2 coffee = 9 cl
Doses setting
XX s YY ml
95°C

MONTE-CARLO - 11/2015 - SOFT V 2.11 17
9.2 Hot water dose programming:
«Hot water» key «Hot water» key
Methodology:
One programming dose is available for each outlet:
Press key the coffee “MENU” from the group nearest the outlet to be programmed.
the display show “Coffee boiler T”
Press 2 times the “+” key: the display shows “Doses setting”
Press the “MENU” key: the display shows:
Push hot water key to start the flow, and push again when the water volume is correct.
The timing key is registered.
Doses setting
XX s YY ml

MONTE-CARLO - 11/2015 - SOFT V 2.11 18
10 GENERAL DISPLAY:
10.1 ECO MODE (general)
The entire machine goes in eco mode. The steam boiler is maintened at 60°C.
Products can’t be extracted.
To come back on the main menu, press "where you want" on the display during 3 seconds.
10.2 Programming on general display
If a password is not entered, the steps available are only those marked with: (*)
To access to the complete menu, go to the last step “Password” and enter the good password
10.2.1 Language (*)
Available languages : French / English / Italian / Spanish / German / Portuguese
Press the menu button
for 5 seconds
- + ENTER
Esc.
To change the language
Press the eco button
for eco mode
Language
Language
English
To validate
Next step
First step
*
*

MONTE-CARLO - 11/2015 - SOFT V 2.11 19
10.2.2 Machine Version
This is to configure the machine in 2 or 3 groups and in coffee or steam control model.
10.2.3 First install (*)
10.2.4 Power boiler
This step is to define the maximum power supply available for the machine.
Exemple: 2 Max 22 Amp.(see chapter power management)
To select the group
2 or 3 group
Machine version
N. group
2
To validate
Next step
Machine version
Coffee
To validate
To select
Coffee / steam control
First install
Next step
See chapter : First installation
To select the value
Range: 1 to 6
Boiler Power
Boiler Power
2
To validate
Next step
*

MONTE-CARLO - 11/2015 - SOFT V 2.11 20
10.2.5 Technical parameters
10.2.5.1 Unit of measurment
This step allows choosing the unit of temperature °C / °F for the machine.
10.2.5.2 Filling up with pump
This step allows the machine to fill the tanker with or without the pump.
In case of “kit solo” system the machine need to be adjusted with a filling up with pump.
10.2.5.3 Probe sensitivity
Technical Par
Next step
To access to the following sub menu
The display backlighting change on the reverse mode
To select
Range: °C / °F
Unit of measure
Temperature
°C
To validate
Next step
To select
With pump / without pump
Boiler filling up
Boiler filling up
With pump
To validate
Next step
To select
Range: MIN / MID / MAX
Probe Sensitivity
Probe Sensitivity
Mid
To validate
Next step
