Continental Girbau CG30-40 User manual

For replacement parts, contact the distributor
from which the dryer was purchased or
ContinentalGirbau,Inc.®
2500State Road 44
Oshkosh WI 54904
Telephone:[phone] / Fax:[phone]
www.cont-girbau.com
030703JEV/wmarelli CGIPartNo.A113170
CG30-40
(Gas/Electric/Steam)
Phase 7
Installation Manual
WARNING: Foryoursafetytheinformationin
this manual must be followed to minimize the
risk of fire or explosion or to prevent property
damage,personalinjury or death.
—Donot store or use gasolineor otherflammable
vapors and liquids in the vicinity of this or any
otherappliance.
—WHATTO DOIF YOUSMELL GAS:
•Donottry to lightany appliance.
•Donottouchanyelectricalswitch; do not
useanyphoneinyourbuilding.
•Cleartheroom,buildingorarea of all
occupants.
•Immediatelycallyourgas supplier froma
neighbor’sphone. Followthegas supplier’s
instructions.
•Ifyoucannotreach your gassupplier,call
thefiredepartment.
—Installationand service must be performed by a
qualified installer, service agency or the gas
supplier.
AVERTISSEMENT: Assurez-vous de bien
suivrelesinstructionsdonnéesdanscettenotice
pourréduire auminimum lerisque d’incendie
ou d’explosion ou pour éviter tout dommage
matériel,touteblessureoulamort.
—Ne pas entreposer ni utiliser d’essence ni
d’autres vapeurs ou liquides inflammables à
proximité de cet appareil ou de tout autre
appareil.
—QUEFAIRESIVOUSSENTEZUNEODEUR
DEGAZ:
•Nepas tenter d’allumer d’appareils.
•Netouchez à aucun interrupteur. Ne pas
vousservirdes téléphones setrouvant dans
lebâtiment.
•Évacuezlapièce,lebâtimentoulazone.
•Appelezimmédiatementvotrefournisseur
degazdepuisunvoisin. Suivezles
instructionsdufournisseur.
•Sivousnepouvezrejoindrelefournisseur
degaz, appelez leservice des incendies.
—L’installationetl’entretiendoiventêtreassuréspar
uninstallateur ou unservice d’entretien qualifié
ouparlefournisseur de gaz.

Retain This Manual In A Safe Place For Future Reference
Continental Girbau, Inc.®product embodies advanced concepts in engineering, design, and safety. If this product is
properly maintained, it will provide many years of safe, efficient, and trouble-free operation.
ONLY qualified technicians should service this equipment.
OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation manual included with
the dryer.
The following “FOR YOUR SAFETY” caution must be posted near the dryer in a prominent location.
“IMPORTANTNOTETO PURCHASER”
Informationmustbeobtainedfromyourlocalgassupplierontheinstructions
tobefollowed if theusersmells gas. These instructionsmustbepostedin a
prominentlocationnearthedryer.
We have tried to make this manual as complete as possible and hope you will find it useful. Manufacturer reserves the right
to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change
or discontinue models. The illustrations included in this manual may not depict your particular dryer exactly.
Important
For your convenience, log the following information:
DATEOFPURCHASE ___________________________ MODELNO. __________________________________________
DISTRIBUTOR’SNAME __________________________________________________________________________________
Serial Number(s) ________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
Replacement parts can be obtained from your distributor or Continental Girbau, Inc.®Please specify the dryer model
number and serial number in addition to the description and part number, so that your order is processed accurately and
promptly.
FORYOURSAFETY
Donot store or use gasolineor
otherflammablevapors and
liquidsinthevicinityofthisor
anyother appliance.
POURVOTRE SÉCURITÉ
Nepas entreposerni utiliserd’essence
nid’autresvapeursouliquides
inflammablesàproximitédecet
appareilou detout autreappareil.
CG30-40

IMPORTANT
YOUMUSTDISCONTINUEANDLOCKOUTTHEELECTRICSUPPLYANDTHEGAS
SUPPLY OR THE STEAM SUPPLY BEFORE ANY COVERS OR GUARDS ARE
REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING,
ADJUSTING, INSTALLATION, OR TESTING OF ANY EQUIPMENT PER OSHA
(OccupationalSafety and HealthAdministration)STANDARDS.
CHILDRENSHOULDNOTBEALLOWEDTOPLAYONORNEARTHEDRYER(S).
WARNING
CHILDRENSHOULDBESUPERVISEDIFNEARDRYERSINOPERATION.
DRYERSSHOULDNEVERBELEFTUNATTENDEDWHILEINOPERATION.
CAUTION
FORYOURSAFETY
DONOTDRYMOPHEADSINTHEDRYER.
DONOTUSEDRYERINTHEPRESENCEOFDRY CLEANINGFUMES.
WARNING
UNDER NO CIRCUMSTANCES should the dryer door switches, lint drawer switch,
or heat safety circuit ever be disabled.
“Caution: Label all wires prior to
disconnection when servicing controls. Wiring
errors can cause improper operation.”
«Attention: Lordes opérations d’entretien
des commandes étiqueter tous fils avant
de les déconnecter. Toute erreur de
câblage peut étre une source de danger et
depanne.»

WARNING
The dryer must never be operated with any of the back guards, outer tops, or service
panelsremoved. PERSONALINJURYORFIRECOULD RESULT.
IMPORTANT
PLEASEOBSERVEALLSAFETYPRECAUTIONSdisplayedontheequipmentand/or
specified in the installation manual included with the dryer.
WARNING
DRYERMUSTNEVERBE OPERATEDWITHOUTTHELINTFILTER/SCREENIN
PLACE,EVENIFANEXTERNALLINTCOLLECTIONSYSTEMISUSED.
Dryer mustnotbe installed or stored in an area where it willbeexposed to water or weather.
The wiring diagram for the dryer is located in the front electrical control box area.
IMPORTANT
Dryer must be installed in a location/environment, which the ambient temperature
remains between 40° F (4.44° C) and 130° F (54.44° C).

Table of Contents
SECTION I
IMPORTANT INFORMATION................................................................................3
A. ReceivingandHandling ............................................................................................................... 3
B. SafetyPrecautions ...................................................................................................................... 4
SECTION II
SPECIFICATIONS/COMPONENT IDENTIFICATION.....................................6
A. Specifications ............................................................................................................................. 6
B. ComponentIdentification ............................................................................................................ 8
SECTION III
INSTALLATION PROCEDURES..........................................................................10
A. LocationRequirements ............................................................................................................. 10
B. Unpacking/SettingUp ............................................................................................................... 11
C. DryerEnclosureRequirements .................................................................................................. 12
D. FreshAirSupplyRequirements ................................................................................................. 13
E. ExhaustRequirements ............................................................................................................... 14
F. ElectricalInformation ................................................................................................................ 20
G. GasInformation ........................................................................................................................ 27
H. SteamInformation .................................................................................................................... 31
I. PreparationFor Operation/Start-Up ......................................................................................... 36
J. PreoperationalTests ................................................................................................................. 37
K. PreoperationalInstructions ........................................................................................................ 39
L. ShutdownInstructions............................................................................................................... 39
SECTION IV
SERVICE/PARTS INFORMATION ......................................................................40
A. Service ..................................................................................................................................... 40
B. Parts ........................................................................................................................................ 40
SECTION V
WARRANTY INFORMATION ...............................................................................41
A. Warranty .................................................................................................................................. 41
B. ReturningWarrantyParts .......................................................................................................... 41
