Contracor CAB-135ST User manual

CONTRACOR Art. 15105/15106

DEUTSCHENGLISH
CAB-110S/CAB-135S
Blast Cabinets
INSTRUCTIONS
Strahlkabinen
BEDIENUNGSANLEITUNG — Seite 35




ENGLISH
CONTRACOR®
2
Table of contents
1. Safety 3
2. Package and description 4
3. General information 8
4. Set-up, operation and shut-down 10
5. Maintenance 17
6. Troubleshooting 22
7. Replacement parts 26
ATTENTION!
READ AND FULLY UNDERSTAND THIS MANUAL BEFORE STARTING WORK.
THE FOLLOWING INFORMATION IS IMPORTANT FOR SAFETY AND HEALTH
OF OPERATOR AND PERSONNEL IN VICINITY.
ATTENTION!
BUYING THE MACHINE, PLEASE, REQUEST TO FILL IN THE GUARANTEE
CARD CORRECTLY!
FAILURE TO PRODUCE A FILLED-IN FORM WILL MAKE YOUR GUARANTEE
INVALID.

ENGLISH
CONTRACOR® 3
1. Safety
ATTENTION!
SAFETY MEASURES FOR BLAST CABINET OPERATION.
1. You must wear protective gloves during abrasive blasting.
2. Do not use worn or damaged equipment during operation.
3. Point the nozzle only at the area to be cleaned. Never point the nozzle
toward the cabinet windows.
4. Use only dry well-sieved abrasive materials, appropriate for abrasive
blasting operations.
5. Before starting of blast cabinet operation you must:



6. During blasting process all doors on the cabinet, reclaimer or dust col-
lector must be closed.
7. After blasting, before the doors are opened and exhauster is switched
off, use the blow nozzle to blow media from the blasted parts.
8. Do not open the doors or switch off exhauster before the cabinet is
clear of abrasive dust.

ENGLISH
CONTRACOR®
4
2. Package and description
15 14
16
17
13
12
10
9
7
8
11
6
5
4
3
1
2
Picture 1

ENGLISH
CONTRACOR® 5
19 1820212223
24
25
26
27
29
30
31
28
Picture 2
 
1
2
3

ENGLISH
CONTRACOR®

4
5
 
 
8
9
 
11 
12 
13 
14 
15 
 
 
18 
19 
 
21 
22 
23 
24 
25 
 
 
28 
29 
 
31 

ENGLISH
CONTRACOR® 
  
  
















 CAB-135S 
















2.1 Package
Table 2.1

ENGLISH
CONTRACOR®
8
3. General information
3.1. General information.









3.2. Theory of operation.















ENGLISH
CONTRACOR® 9









23458 12
3        
4         
5        
Table 3.1
3.4. Blast media.




Steel blast media:


Sand and Slag:



3.3 Air jet diameter and required compressed air volume.







ENGLISH
CONTRACOR®

ATTENTION!
Abrasive blasting with sands containing crystalline silica can cause seri-
ous or fatal respiratory disease.

Aluminum Oxide, Silicon Carbide, and Garnet:




Glass Beads:


3.5 Compressed air quality




4. Set-up, operation and shut-down
4.1. Installation and Set-up.
4.1.1 Location


4.1.2 Compressed air supply line



