Converters.TV 693 User manual

HDMI-Video-PC to HDMI
Switcher - ID# 693
Operation Manual

Introduction
HDMI-Video-PC to HDMI Switcher which is designed to convert analog and digital
signals to HDMI 1.3 output. Includes HDMI, PC, Co posite, Co ponent, and S-
Video Input options, and outputs to your connected display via HDMI. The unit
supports a wide range of input resolutions and will output content up to high
definition 1080p (output resolution li ited by the connected TV/Monitor
specifications - please note input resolution = output resolution).
Inputs available include 2 x Co posite Video, 2 x S Video, 2 x Co ponent Video, 3
x HDMI, and 1 x PC. This allows you to connect up to 10 devices si ultaneously,
allowing you to easily switch between input devices for display on your connected
TV/Monitor. Users can switch between inputs using the front panel of the unit, or by
using the included re ote. The wide range of inputs available eans that the unit is
suitable for use with any devices including DVD Players, Ga e consoles (eg:
XBox360), Set top boxes, Blu-Ray Players, PC etc.
The HDMI-Video-PC to HDMI Switcher also has a selectable audio delay function
(150 illiseconds) which can be used to sync audio to the video signal when
needed (Not functional when input is via HDMI). The unit also has a feature which
allows you to instantly switch fro 480i/576i to 480p/576p when applicable.
Features
1. HDMI 1.3, HDCP1.1 and DVI1.0 co pliant Receiver.
2. Deep Color video up to 12bit, 1080p@(24/60)Hz.
3. Supports analog/digital video/audio input and HDMI v1.3 output.
4. HDCP keysets allows each HDMI input to work independently when connecting to
a HDMI display.
5. Supports a wide range of PC and HDTV resolutions fro VGA to
SXGA@60Hz and 480i to 1080p.
6. Support 3D co b filter.
7. Support 3D noise reduction (DNR).
8. Support for at converter fro 480i/576i to 480p/576p, si ply press the
front panel or re ote control.
9. Support audio delay for 150 s, this feature will not functional when HDMI input.
10. Suppor t IR re ote control.
11. Support RS-232 control.
Operating Functions
and
Controls
Front Panel
1. Power switch and power LED indicator: Press the switch to power on
the unit and the power LED will illuminate.
2. IR sensor.

3. Input source selection: Press the input button to switch to your desired
input sources the LED will illuminate to indicate which input source is
selected.
4. udio delay: Press to delay audio sources for 150ms the LED will
illuminate
when power on.
Rear Panel
1. Power: Plug the 5V DC power supply into this unit and connect the
adapter to AC wall outlet.
2. CV/SV inputs: Connect each of the input ports to the CV/SV and R/L
output ports of your source equipments such as DVD player or set-top box.
The CV1/SV1/Audio 1 and CV2/SV2/Audio2 are individual loops for source
equipments.
3. Component inputs: Connect each of the input component ports to the
component and R/L output ports of your source equipments such as DVD
player or set-top-box. The Component] / Component Audio] and
Component2/Component Audio2 are individual loops for source equipments.
4. HDMI inputs: Connect each of the input ports to the HDMI or DVI
output
ports of your source equipment such as DVD player or set-top-box.
5. PC input: Connect PC/audio input port to the PC/audio output port of
your source equipment such as Notebook or PC.
6. RS232: 9-pin D-Sub connector for connecting to your PC or other control
console for remote control.
7. HDMI output: Connect the output port to the HDMI display.

Remote Control
1.Audio Delay: Press to delay audio output for 150 s.
2.Format selection: To switch between Interlace and
Progressive for at.
3.Power: Press the button to turn on/off the unit.
4.Component 1 2: Press to select Co posite 1 or 2 inputs.
5. PC: Press for PC input.
6.S-Video1 2: Press to select S-Video 1 or 2 inputs.
7.Video1 2: Press to select Video 1 or 2 inputs. 8.
HDMI 1/2/3: Press to select HDMI 1, 2 or 3 inputs.
RS-232 Remote
Control Protocol
The connection between this unit and re ote controller with RS-232
modem cable.
Pins definition of modem cable
System Remote Controller
Pin Definition Pin Definition
1 NC 1 NC
2 TxD 2 RxD
3 RxD 3 TxD
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
* RS-232 transmission format: Baud Rate : 9600 bps
Data Bit : 8 bits
Parity : None
Stop Bit : 1 bit

RS-232 transmission format:
(a)Set Co and
Command Code Response Description
S POWER 0 > POWER OFF POWER OFF
S POWER 1 > POWER ON POWER ON
S SOURCE 0 > SOURCE HDMI1 HDMI1 INPUT
S SOURCE 1 > SOURCE HDMI2 HDMI2 INPUT
S SOURCE 2 > SOURCE HDMI3 HDMI3 INPUT
S SOURCE 3 > SOURCE PC PC INPUT
S SOURCE 4 > SOURCE COMP1 COMPONENT] INPUT
S SOURCE 5 > SOURCE COMP2 COMPONENT2 INPUT
S SOURCE 6 > SOURCE SV1 SV1 INPUT
S SOURCE 7 > SOURCE SV2 SV2 INPUT
S SOURCE 8 > SOURCE CV1 CV1 INPUT
S SOURCE 9 > SOURCE CV2 CV2 INPUT
S AUDIODELA 0 > AUDIODELA OFF OFF : NO DELA
S AUDIODELA 1 > AUDIODELA ON ON : DELA 150ms
S SD_ITOP 0 > 480i/576i TO
480p/576p OFF OFF : NO 480i/5761 TO 480p/576p
S SD_ITOP 1 >480i/576i TO
480p/576p ON ON : 480i/5761 TO 480p/576p
S RESET 1 > RESET ON RESET ACTION
Command Code Response Description
R POWER > POWER ON-OFF SHOW POWER STATUS
R SOURCE > SOURCE HDMI-CV SHOW SOURCE STATUS
R AUDIODELA > AUDIODELA OFF-ON SHOW AUDIO DELA STATUS
R SD_ITOP >480i/576i TO 480p/576p
OFF-ON
SHOW 4801/576i TO 480p/576p
STATUS
R FW_VER > FIRMWARE VERSION : Vx.xx SHOW FIRMWARE VERSION

Installation
Specifications
Frequency bandwidth: 2.25Gbps (single link)
•Input: 3 x HDMI fe ale ports (Type A connector)
1 x PC with audio jack
2 x Y/Pb/Pr with R/L
2 x CV/SV with R/L
•Output: 1 x RS-232
1 x HDMI fe ale port (signal link)
•Power: 5VDC/2.6A (US/EU standards, CE/FCC/UL certified)
•Dimension: 280(W) x 147(D) x 44(H)
•Weight: 1380g
•Chassis Material: Metal
•Silk Skin Color: Grey
•Operating Temperature: Operating fro 0°C – 40°C

Input Signal Specifications
PC Resolution Vert Rate
VGA
SVGA
XGA
SXGA
640x480
800x600
1024x768
1280x1024
60/72/75/85Hz
56/60/72/75/85Hz
60/70/75/85Hz
60Hz
HDTV Resolutions Vert Rate
480p
480i
576p
576i
720p
1080i
1080p
720x480
720x480
720x576
720x576
1280x720
1920x1080i
1920x1080p
60Hz
60Hz
50Hz
50Hz
50,60Hz
50, 60Hz
50, 60Hz
Output Signal Specifications
PC Resolution Vert Rate
VGA
SVGA
XGA
SXGA
640x480
800x600
1024x768
1280x1024
60/72/75/85Hz
56/60/72/75/85H
z 60/70/75/85Hz
60Hz
H TV Resolutions Vert Rate
480p
480i
576p
576i
720p
1080i
1080p
720x480
720x480
720x576
720x576
1280x720
1920x10801
1920x1080p
60Hz
60Hz
50Hz
50Hz
50, 60Hz
50, 60Hz
50, 60Hz
