CONVEY-ALL 1214-GN User manual

TRANSFER CONVEYOR
Models:
1214-GN, 1615, 1616-RC,
2218, 2218-RC
OPERATOR’S MANUAL

LIMITED WARRANTY
Convey-All™ warrants to the buyer that the new machinery is free from defects in material and
workmanship.
This warranty is only effective as to any new machinery which has not been altered, changed,
repaired or treated since its delivery to the buyer, other than by Convey-All™ or its authorized
dealers or employees, and does not apply to accessories, attachments, tools or parts, sold or
operated with new machinery, if they have not been manufactured by Convey-All™.
Convey-All™ shall only be liable for defects in the materials or workmanship attributable to
faulty material or bad workmanship that can be proved by the buyer, and specifically excludes
liability for repairs arising as a result of normal wear and tear of the new machinery or in any other
manner whatsoever, and without limiting the generality of the foregoing, excludes application
or installation of parts not completed in accordance with Convey-All™ operator’s manual,
specifications, or printed instructions.
Written notice shall be given by registered mail, to Convey-All™ within seven (7) days
after the defect shall have become apparent or the repairs shall have become necessary,
addressed as follows:
Convey-All Industries Inc.
130 Canada Street
Winkler, Manitoba R6W 0J3
Canada
This warranty shall expire one (1) year after the date of delivery of the new machinery.
If these conditions are fulfilled, Convey-All™ shall at its own cost and at its own option either
repair or replace any defective parts provided that the buyer shall be responsible for all expenses
incurred as a result of repairs, labor, parts, transportation or any other work, unless Convey-All™
has authorized such expenses in advance.
The warranty shall not extend to any repairs, changes, alterations, or replacements made to the
new equipment other than by Convey-All™ or its authorized dealers or employees.
This warranty extents only to the original owner of the new equipment.
This warranty is limited to the terms stated herein and is in lieu of any other warranties whether
expressed or implied, and without limiting the generality of the foregoing, excluded all warranties,
expressed or implied or conditions whether statutory or otherwise as to quality and fitness for any
purpose of the new equipment. Convey-All™ disclaims all liability for incidental or consequential
damages.
This machine is subject to design changes and Convey-All™ shall not be required to retrofit or
exchange items on previously sold units except at its own option.
WARRANTY VOID IF NOT REGISTERED

WARRANTY REGISTRATION FORM
and INSPECTION REPORT
UNIT INSPECTION SAFETY INSPECTION
£All Fasteners Tight £All Guards/Shields Installed and Secured
£V-Belt(s) are Tensioned and Rotate Freely £All Safety Decals Clear and Legible
£Driveline/Motor Mount Secured to Machine £
Reflectors, Slow Moving Vehicle (SMV) Sign Clean
£Fuel is turned off at Engine £
Safety Chain on Hitch
£Machine and All Bearings Lubricated £
Reviewed Operating and Safety Instructions
£Conveyor Belt Aligned and Tensioned
£Tire Pressure Checked
I have thoroughly instructed the buyer on the above described equipment. The review included the content
of the Operator’s Manual, equipment care, adjustments, safe operation and the applicable warranty policy.
Date _______________________ Dealer’s Signature ______________________________________________
The above equipment and Operator’s Manual have been received by me. I have been thoroughly instructed as
to care, adjustments, safe operation and applicable warranty policy.
Date _______________________ Buyer’s Signature _______________________________________________
The Dealer must fill out this form. It is to be signed by both the Dealer and Buyer at the time of delivery.
Scan or photograph the completed form (be sure it is legible). Email it to: r[email protected]
A copy of this form may also be mailed to Convey-All Industries Inc, at the above address.
Buyer’s Name ________________________________ Dealer’s Name ________________________________
Address ______________________________________ Address _____________________________________
City __________________________________________ City _________________________________________
Province/State ________________________________ Province/State _______________________________
Postal Code/Zip Code _________________________ Postal Code/Zip Code _________________________
Country ______________________________________ Country _____________________________________
Phone Number ________________________________ Phone Number________________________________
Unit’s Model Number __________________________ Unit’s Serial Number __________________________
Delivery Date _________________________________ General Purpose: £Private £Commercial
CONVEY-ALL INDUSTRIES INC.
130 CANADA STREET
WINKLER, MANITOBA R6W 0B3
TF: [phone] FX: [phone]
www.convey-all.com

This page intentionally left blank

Operator’s Manual: Transfer Conveyor
iiiRevised 09.2016
TABLE OF CONTENTS
DESCRIPTION PAGE
Section 1: INTRODUCTION ............................1-1
1.1 Operator Orientation.............................1-1
1.2 Serial Number Location ..........................1-1
Section 2: SAFETY ...................................2-1
2.1 Safety Orientation...............................2-2
2.2 General Safety .................................2-2
2.3 Equipment Safety Guidelines ......................2-3
2.4 Safety Decals ..................................2-3
2.4.1 How to Install Safety Decals ...................2-3
2.5 Work Preparation ...............................2-4
2.6 Battery Safety..................................2-4
2.7 Engine Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2.8 Electrical Safety ................................2-6
2.9 Lock-Out Tag-Out Safety .........................2-6
2.10 Operating Safety...............................2-6
2.11 Workplace Hazard Area .........................2-7
2.12 Tire Safety....................................2-7
2.13 Maintenance Safety ............................2-7
2.14 Transport Safety ...............................2-8
2.15 Storage Safety ................................2-8
2.16 Safety Decal Location ..........................2-9
Section 3: OPERATION................................3-1
3.1 Machine Components ...........................3-2
3.2 Components and Controls ........................3-3
3.3 Machine Break-In ...............................3-7
3.4 Pre-Operation Checklist ..........................3-7
3.5 Attaching to Tow Vehicle .........................3-8
3.6 Conveyor Placement ............................3-9
3.7 Field Operation ................................ 3-10
3.7.1 Starting Conveyor .......................... 3-10
3.7.2 Stopping Conveyor ......................... 3-11
3.7.3 Emergency Stopping ........................ 3-11
3.7.4 Restarting after Emergency Stop ............... 3-11
3.7.5 Belt Speed ................................ 3-12
3.7.6 Unplugging................................ 3-12
3.7.7 Hold Down Wheels on “GN” Models ............ 3-12
continued on next page

Operator’s Manual: Transfer Conveyor
iv Revised 09.2016
TABLE OF CONTENTS
DESCRIPTION PAGE
3.8 Operating Hints ............................... 3-13
3.9 Transportation................................. 3-14
3.10 Storage ..................................... 3-15
Section 4: SERVICE AND MAINTENANCE.................4-1
4.1 Fluids and Lubricants ............................4-1
4.1.1 Greasing ...................................4-2
4.2 Servicing Intervals ..............................4-2
4.2.1 After 10 Hours or Daily ........................4-3
4.2.2 After 50 Hours or Weekly ......................4-4
4.2.3 After 200 Hours or Annually ....................4-5
4.3 Maintenance Procedures .........................4-6
4.3.1 Conveying Belt Tension .......................4-6
4.3.2 Conveyor Belt Alignment ......................4-7
4.3.3 Conveyor Belt Replacement ...................4-8
4.3.4 Drive Belt Tension............................4-9
4.3.5 Check Pulley Alignment ...................... 4-10
4.3.6 Drive Belt Replacement ...................... 4-10
4.3.7 “GN” Hold Down Wheels Replacement .......... 4-10
4.3.8 Changing Engine Oil and Filter................. 4-11
4.3.9 Clean/Change Air Filter ...................... 4-11
4.4 Service Record ................................ 4-13
4.5 Ordering Parts ................................ 4-14
Section 5: TROUBLESHOOTING ........................5-1
Section 6: SIGN-OFF FORM............................6-1
Section 7: REFERENCE ...............................7-1
7.1 Specifications ..................................7-1
7.2 Bolt Torque ....................................7-2

Operator’s Manual: Transfer Conveyor
1-1Revised 09.2016
Fig 1 - Serial number location
Section 1: INTRODUCTION
Congratulations on your choice of a Convey-All™ Transfer Conveyor. It is designed to efficiently move grain, pulse
crops or granular material between a truck, trailer, storage facility and another conveyor.
This equipment has been designed and manufactured to meet the exacting standards for such equipment in the
agricultural industry and will keep your seed delivery operation working at optimum efficiency.
Keep this manual handy for frequent reference. Pass it on to new operators or owners. Call your dealer, distributor
or Convey-All Industries Inc., if you need assistance, information, additional/replacement copies, or a digital copy
of the document.
Information provided herein is of a descriptive nature. Convey-All Industries Inc. reserves the right to modify the
machinery design and specifications provided herein without any preliminary notice.
Performance quality may depend on the material being handled, weather conditions and other factors.
1.1 OPERATOR ORIENTATION
The directions left, right, front and rear, as mentioned throughout this manual, are as seen from the tow vehicle
driver’s seat and facing the direction of travel. The hopper is the front of the conveyor.
1.2 SERIAL NUMBER LOCATION
Always give your dealer the serial number of your conveyor when ordering parts or requesting service or other
information. The conveyor’s serial number is located at the hopper.
Please mark the identifying numbers in the space provided for easy reference.
Conveyor Model No: __________________________
Conveyor Serial No: __________________________
Engine Model No: __________________________
Engine Serial No: __________________________

Operator’s Manual: Transfer Conveyor
1-2 01.2015
This page intentionally left blank

Operator’s Manual: Transfer Conveyor
2-1Revised 11.2017
The following signal words are used in this manual to express
the degree of hazard for areas of personal safety.
When you see the symbol and/or the signal words described below,
obey the accompanying message to avoid possible injury or death.
DANGER - Indicates a hazardous situation that, if not avoided, will result in
death or serious injury. This signal word is limited to the most
extreme situations. Typically for machine components which, for
functional purposes, cannot be guarded.
WARNING - Indicates a hazardous situation, if not avoided, could result in
death or serious injury. This word identifies hazards that are
exposed when guards are removed. It may be used to alert
against unsafe practices.
CAUTION - Indicates a hazardous situation, if not avoided, could result in
minor or moderate injury. It may be used to alert against unsafe
practices.
NOTICE - Indicates practices or situations which may result in the
malfunction of, or damage to equipment.
Section 2: SAFETY
The Safety Alert Symbol means:
ATTENTION!
BECOME ALERT!
YOUR SAFETY IS INVOLVED!
The Safety Alert Symbol identifies
important safety messages on
the Transfer Conveyor and in
this manual.
3 Big Reasons why safety
is important to you:
• Accidents Disable and Kill
• Accidents Cost
• Accidents Can Be Avoided

Operator’s Manual: Transfer Conveyor
2-2 Revised 09.2016
2.1 SAFETY ORIENTATION
YOU are responsible for the SAFE operation and
maintenance of your Convey-All™ Transfer Conveyor.
Be sure that everyone who will operate, maintain or
work around it, is familiar with the safety, operating
and maintenance procedures.
This manual will take you step-by-step through your
working day. It will alert you to all the safe practices
that should be adhered to while operating the
conveyor.
Remember, you are the key to safety. Good safety
practices not only protect you but also the people
around you. Make these practices a working part of
your workday. Be certain that all operators of this
equipment follows these procedures.
Most accidents can be prevented. Do not risk injury
or death by ignoring good safety practices.
• Conveyor owners must give operating instructions
to operators or employees before allowing them to
operate the machine.
Procedures must be reviewed annually thereafter,
as per OSHA (Occupational Safety and Health
Administration) regulation 1928.57.
• The most important safety device on this equipment
is a SAFE operator. It is the operator’s responsibility
to understand all safety and operating instructions
in this document, and to follow them.
• An untrained operator exposes himself and
bystanders to possible serious injury or death.
• Think SAFETY! Work SAFELY!
2.2 GENERAL SAFETY
• Read and understand the Operator’s
Manual and all safety decals before
operating, maintaining, adjusting or
unplugging the conveyor.
• Only trained, competent persons shall operate the
conveyor. An untrained person is not qualified to
operate the machine.
• Have a first-aid kit available for use
should the need arise and know how to
use it.
• Provide a fire extinguisher for use in
case of an accident. Store in a highly
visible place.
• Do not allow riders.
• Do not allow children, spectators or bystanders
within hazard area around the machine.
• Wear appropriate protective gear. This list may
include but is not limited to:
- Hard hat
- Protective shoes with
slip resistant soles
- Eye protection
- Work gloves
- Hearing protection
- Respirator or
filter mask
- Hi-Visibility safety vest
• Never use alcoholic beverages or drugs which can
hinder alertness or coordination while operating
this equipment.
Consult your doctor about operating this machine
while taking prescription medications.
• If the elderly are assisting with farm work, their
physical limitations need to be recognized and
accommodated.
• Review safety related items annually with all
personnel who will be operating or maintaining the
conveyor.

Operator’s Manual: Transfer Conveyor
2-3Revised 02.2019
2.3 EQUIPMENT SAFETY GUIDELINES
•Safety of the operator and bystanders is one of the
main concerns in designing and developing this
conveyor. However, every year many accidents
occur which could have been avoided by a few
seconds of thought and a more careful approach
to handling equipment.
•Do not allow persons to operate this unit until
they have been trained. They must know all safety
precautions.
Review the safety instructions with all personnel
annually.
•In order to provide a better view, some images in
this manual may show an assembly with a safety
guards removed.
Equipment should never be operated in
this condition. Keep all guards in place.
If removal becomes necessary for
repairs, replace the guard prior to use.
•This equipment is dangerous to children and
people unfamiliar with its operation.
The operator must be responsible, properly trained
and physically able. You should be familiar with
farm machinery in general.
•Never exceed the limits of a piece of machinery.
If its ability to do a job, or to do so safely, is in
question - DON’T TRY IT.
•Do not modify the equipment in any way.
Unauthorized modification result in serious injury
or death and may impair the function and life of the
equipment.
•The design and configuration of this conveyor
includes safety decals and equipment. They need
to be clean, readable or in good condition.
2.4 SAFETY DECALS
• Keep safety decals clean and legible at all times.
•Replace safety decals that are missing or have
become illegible.
•Replaced parts that displayed a safety decal
should also display the current decal.
•All safety decals have a part number in the lower
right hand corner. Use this part number when
ordering replacements.
•Safety decals are available from your
authorized distributor, dealer or directly from
Convey-All Industries Inc.
2.4.1 How to Install Safety Decals:
1. Be sure that the area is clean and dry. Preferably,
apply the decals inside.
2. Ensure temperature is above 10°C (50°F).
3. Remove all dirt, grease, wax from the surface.
4. Clean with a non-ammonia based cleaner.
5. Wipe the clean surface with isopropyl alcohol on
paper towel, and allow to dry.
6. Determine exact position before you remove the
backing paper.
7. Peel the smallest portion of the split backing
paper.
8. Align the decal over the specified area. Use a
squeegee to carefully press the small portion,
with the exposed adhesive backing, into place.
9. Slowly peel back the remaining paper and
carefully smooth the remaining portion of the
decal into place.
10. Small air pockets can be pierced with a pin and
smoothed out using the squeegee, or a piece of
sign backing paper.

Operator’s Manual: Transfer Conveyor
2-4 Revised 02.2019
•Clear the working area of stones, branches or
hidden obstacles that might be hooked, snagged
or tripped over, causing injury or damage.
• Operate only in daylight or good artificial light.
•Be sure machine is in a stable position, is adjusted
and in good operating condition.
•Ensure that all safety guards and safety decals are
properly installed and in good condition.
•Before starting, inspect the unit for any loose bolts,
worn parts, cracks, leaks or frayed belt.
Make the necessary repairs.
Always follow the maintenance instructions.
2.6 BATTERY SAFETY
•Keep all sparks and flames away from batteries, as
gas given off by electrolyte is explosive.
•Avoid contact with battery electrolyte. Wash off
any spilled electrolyte immediately.
• Wear safety glasses when working
near batteries.
•Do not tip batteries more than 45 degrees, to avoid
electrolyte loss.
•To avoid injury from spark or short circuit,
disconnect battery ground cable before servicing
any part of electrical system.
•When storing the conveyor for an extended period:
- Remove the battery
- Be sure it is fully charged
- Store it inside
- Do not sit the battery on a cold, concrete floor
•Before using the battery, after it has been in
storage, be sure it is fully charged.
2.5 WORK PREPARATION
•Never operate the conveyor until you have read
this manual, and comprehend the information.
Also, read the engine operator’s manual.
Be familiar with the safety messages found on the
decals around this unit.
• Personal protection equipment including:
- Hard hat
- Eye protection
- Protective shoes
- Work gloves
are recommended during placement,
operation, maintaining and repairing,
transportation and storage of the
equipment.
•Do not allow long hair, loose fitting clothing or
jewelry to be around equipment.
•PROLONGED EXPOSURE TO LOUD NOISE MAY
CAUSE PERMANENT HEARING LOSS!
Agricultural equipment can often be
noisy enough to cause permanent,
partial hearing loss. We recommend
that you wear hearing protection on
a full-time basis, if the noise exceeds
80db.
Noise over 85db on a long-term basis can cause
severe hearing loss.
Noise over 90db adjacent to the operator over
a long-term basis may cause permanent, total
hearing loss.
Note:
Hearing loss from loud noise
(tractors, chain saws, radios, etc.)
is cumulative over a lifetime
without hope of natural recovery.

Operator’s Manual: Transfer Conveyor
2-5Revised 02.2019
2.7 ENGINE SAFETY
• Read and understand the operating
manual provided with the engine.
• Use proper tools to service engine.
• Do not run engine in an enclosed area. Exhaust
gases contain carbon monoxide, an odorless and
deadly poison.
• Store fuel in approved safety containers.
• Do not store fuel near an open flame.
Appliances such as a stove, furnace, or
water heater use a pilot light which can
create a spark.
• No smoking when filling the fuel tank.
• Do not remove fuel cap while engine is
running.
• Do not refuel indoors where area is not well
ventilated. Outdoor refueling is preferred.
• Do not refuel while engine is running. Allow engine
to cool for 5 minutes before proceeding.
• Use fresh fuel. Stale fuel can gum carburetor and
cause leakage.
• Check fuel lines and fittings frequently for cracks or
leaks. Replace if necessary.
• Do not operate engine if fuel has spilled. Move
machine away. Avoid creating any ignition until the
fuel has evaporated.
• Do not run engine above rated speeds. This may
result in damage and injury.
• Do not tamper with the engine speed selected by
the original equipment manufacturer.
• Do not tamper with governor springs, governor
links or other parts which may increase the
governed engine speed.
• Do not strike flywheel with a hard object or metal
tool. This may cause it to shatter in operation.
• Keep cylinder fins and governor parts free of grass
and other debris which can affect engine speed.
• Do not operate engine with grass, leaves, dirt or
other combustible materials in muffler area.
• Do not operate engine without muffler.
WARNING: Hot Equipment
Do not touch muffler, cylinder or fins while
engine is running. Contact will cause
burns.
• Do not use this engine on any forest
covered, brush covered, or grass
covered, unimproved land, unless a
spark arrester is installed on the muffler.
The arrester must be maintained in
effective working order by the operator.
In the State of California the above is required
by law (Section 4442 of the California Public
Resources Code). Other states may have similar
laws. Federal laws apply on federal lands.
• Inspect muffler periodically. Replace if necessary.
If engine is equipped with a muffler deflector,
inspect periodically. Replace with correct part.
• Do not check for spark, or crank the engine while
the spark plug or spark plug wire is removed.
• Do not run engine with its air filter cover removed.
WARNING: Possible Engine Damage
Decelerate engine slowly to stop. Avoid
choking the carburetor to stop engine.
Choke only for an emergency stop.

Operator’s Manual: Transfer Conveyor
2-6 Revised 02.2019
2.8 ELECTRICAL SAFETY
•Have only a qualified electrician
supply power. All wiring should comply
with the ANSI/NFPA 70 electrical
requirements.
For North America make certain that sufficient
amperage, at proper voltage and appropriate
frequency for your geographical area is available
before connecting power. All wiring should comply
with ANSI/NFPA 70 electrical requirements.
Have a licensed electrician provide power to the
machine.
•Make certain that the conveyor motor is properly
grounded at the power source.
•Make certain that all electrical switches are in the
OFF position before plugging in the conveyor.
•Turn machine OFF, shut down and lock out power
supply (safety lock-out devices are available
through your Convey-All dealer parts department)
and wait for all moving parts to stop before
assembling, servicing, adjusting, maintaining or
repairing.
• Disconnect power before resetting any motor.
•Replace any damaged electrical plugs, cords,
switches and components immediately.
•Do not work on the conveyor’s electrical system
unless the power cord is unplugged or the power
supply is locked out.
2.9 LOCK-OUT TAG-OUT SAFETY
•Establish a formal Lock-Out Tag-Out program for
your operation.
•Train all operators and service personnel before
allowing them to work around the area.
•Provide tags on the machine and a sign-up sheet
to record tag out details.
2.10 OPERATING SAFETY
•Be sure that anyone who will be
operating the conveyor, or working
around the unit, reads the manual. They
must know the operating, maintenance
and safety information.
Review the manual annually.
•Clean or replace all safety decals if they cannot be
clearly read and understood.
•Place all controls in neutral, and stop the engine.
Remove the ignition key. Wait for all moving parts
to stop before adjusting, repairing or unplugging.
•Keep all bystanders, especially children, away from
the machine when running.
Also, when authorized personnel are carrying out
maintenance work.
•Establish a Lock-Out, Tag-Out policy for the work
site. Be sure all personnel are trained in and follow
all procedures.
Lock-out and tag-out all power sources before
servicing the unit or working around equipment.
•Be familiar with machine hazard area. If anyone
enters hazard areas, shut down machine
immediately. Clear the area before restarting.
•Keep hands, feet, hair and clothing
away from all moving and/or rotating
parts.
•Do not allow riders on the conveyor when moving
or transporting.
• Keep working area clean and free of
debris to prevent slipping or tripping.
•Do not operate machine when any guards are
removed.
• Chock wheels of conveyor before starting.

Operator’s Manual: Transfer Conveyor
2-7Revised 02.2019
2.11 WORKPLACE HAZARD AREA
INTAKE
AREA HAZARD
KEEP AWAY
DISCHARGE
AREA HAZARD
KEEP AWAY
KEEP OUT OF
SHADED HAZARD AREA
WORK AREA
AUTHORIZED
PERSONNEL
ONLY
WHEEL
CHOCKS
WHEEL
CHOCKS
2.12 TIRE SAFETY
•Failure to follow procedure when
mounting a tire on a wheel or rim can
produce an explosion and may result in
serious injury or death.
•Do not attempt to mount a tire unless you have the
proper equipment and experience to do the job.
•Have a qualified tire dealer or repair service perform
required tire maintenance.
•When replacing worn tires, make sure they meet
the original tire specifications.
Never undersize.
•Reference the tire side wall for information on the
maximum cold tire pressure (PSI). Keep the tires
inflated to this setting.
2.13 MAINTENANCE SAFETY
•Review Section 4: Service and
Maintenance, of this Manual before
maintaining or operating the conveyor.
• Follow good shop practices:
- Keep service area clean and dry.
- Be sure electrical outlets and tools
are properly grounded.
- Use adequate light for the job.
•Place all controls in neutral or off. Stop the engine
and remove ignition key. Wait for all moving parts
to stop before servicing, adjusting or repairing.
•Relieve pressure from hydraulic circuit before
servicing.
•Before applying pressure to a hydraulic system,
make sure all components are tight. The hoses and
couplings must be in good condition.
• Keep hands, feet, hair and clothing
away from all moving and/or rotating
parts.
•Replace parts with genuine factory replacements
parts to restore your equipment to original
specifications.
Convey-All Industries Inc. will not be responsible
for injuries or damages caused by the use of
unapproved parts and/or accessories.
•Make sure there is plenty of ventilation. Never
operate the engine in a closed building. The
exhaust fumes may cause asphyxiation.
•Clear the area of bystanders, especially children,
when carrying out any maintenance and repairs or
making any adjustments.
•Before resuming operation, install and secure all
guards when maintenance work is completed.
•Keep safety decals clean. Replace any decal that
is damaged or not clearly visible.

Operator’s Manual: Transfer Conveyor
2-8 Revised 11.2017
2.14 TRANSPORT SAFETY
•If transporting on a trailer, be sure that it is equipped
with brakes that are in good working order. Be
familiar with their operation.
•Check that all the lights, reflectors and
other lighting requirements are installed
and in good working condition.
• Never allow riders on the conveyor.
•Comply with all local laws governing safety and
transporting of equipment on public roads.
•Do not exceed a safe travel speed. Slow down for
rough terrain and when cornering.
• Plan your route to avoid heavy traffic.
• Do not drink and drive.
•Be a safe and courteous driver. Always yield to
oncoming traffic in all situations, including narrow
bridges, intersections, etc. Watch for traffic when
operating near or crossing roadways.
2.15 STORAGE SAFETY
• Store in an area away from human activity.
•If required, make sure the unit is solidly blocked up.
•Remove the battery and store a in dry location. Do
not sit it on a cold concrete floor.
•Make certain all mechanical locks are safely and
positively connected before storing.
•Do not permit children to play on or around the
stored machine.
KEEP OUT OF
SHADED HAZARD AREA
Fig 2 - Transporting hazard area
3630000004
3617000005

Operator’s Manual: Transfer Conveyor
2-9Revised 02.2019
2.16 SAFETY DECAL LOCATION
The following illustrations show the general location of decals on this conveyor. The position of decals may vary
depending on the machine’s options. Decals are not shown at actual size.
Fig 3 - 1615 Conveyor
REMEMBER - If safety decals have been damaged, removed, become illegible, or parts were replaced without
signage, new ones must be applied. New decals are available from your authorized dealer.
3630000010
3630000004
3617000005

Operator’s Manual: Transfer Conveyor
2-10 01.2015
This page intentionally left blank

Operator’s Manual: Transfer Conveyor
3-1Revised 09.2016
It is the responsibility of the owner, and operators to become familiar with the operating procedures in this section.
Follow the instructions safely. It is everyone’s business to provide a safe working environment for their co-workers.
The design and configuration of this conveyor includes safety decals and equipment. Hazard controls and accident
prevention depend on the personnel operating and maintaining the equipment. Their concern, attentiveness and
proper training are crucial.
Many features incorporated into this machine are the result of suggestions made by customers like you. Read this
manual carefully for instructions on how to set it, to provide maximum efficiency.
By following the these procedures, in conjunction with a good maintenance program, your Transfer Conveyor will
provide many years of trouble free service.
Section 3: OPERATION
• Read and understand the Operator’s Manual.
Be familiar with all safety decals, before using.
•Stop the engine or motor. Remove ignition key.
Wait for all moving parts to stop before servicing,
adjusting, repairing or unplugging.
•Clear the area of bystanders, especially children,
before starting.
•Be familiar with machine hazard area. If anyone
enters hazard areas, shut down machine
immediately. Clear the area before restarting.
• Keep hands, feet, hair and clothing away from all
moving and/or rotating parts.
Operating Safety
•Do not allow riders on the conveyor when
transporting.
•Do not operate machine when any guards are
removed.
• Chock wheels of conveyor before starting.
•Keep working area clean and free of debris to
prevent slipping or tripping.
•Establish Lock-Out Tag-Out policy for the work
site. Be sure all personnel are trained in and
follow all procedures.

Operator’s Manual: Transfer Conveyor
3-2 Revised 02.2019
Fig 4 - Transfer conveyor
f
i
g
h
b
c
a
e
d
3.1 MACHINE COMPONENTS
The Transfer Conveyor is portable and low enough
to fit under trucks or low storage facilities. The “RC”
models have an extra low profile to fit under rail cars.
Normally, the discharge is directed into another
conveying system.
A gas engine, electric or hydraulic motor can supply
power to the drive located at the discharge end.
A manual winch is used to raise and lower the hopper
frame.
The main components, and their general location are
listed below:
a. Conveyor Tube
b. Hopper
c. Hopper Winch
d. Discharge Hood
e. Engine/Motor Mount (gas engine shown)
f. Drive Belts or Hydraulic Motor
g. Axle and Wheels
h. Hitch
i. Document Holder
