Coolaroo 3M PRIVACY SCREEN User manual

2 1
145 Woodlands Drive, Braeside,
Victoria 3195 Australia
Coolaroo is a registered trademark
MADE IN CHINA
For help with product assembly
or for any other questions you
may have, contact our Customer
Service Department.
Australia toll free: 1800 331 521
New Zealand toll free: 0800 555 171
United States Ph: [phone]
Middle East Ph: [phone]
China Ph: [phone]
coolaroo.com
THANK YOU
FOR PURCHASING A COOLAROO PRODUCT
WARNING
When assembling and using this product, safety precautions should always be followed to reduce the
risk of personal injury and damage to equipment. Please read all instructions before assembly and use.
At least two or more people are recommended for safe assembly.
Keep all children and pets away from assembly area.
Check all nuts and bolts for tightness before and during usage.
Non permanent structure. Do not use in extreme weather conditions including heavy rain or high winds.
Do not leave the gazebo unattended. Louvres must remain in the open position when not in use.
3m Privacy Screen
Item Code: 506902
Exposure to ultraviolet (UV) radiation from the sun is the major cause of
skin cancer. In some countries the UV radiation is strong enough to cause
sunburn in just 11 minutes on a ne summers day. To prevent sun damage
we recommend following the Sun Smart steps: slip on clothing, slop on
sunscreen, slap on a hat, slide on sunglasses and seek shade.
To register your product go to coolaroo.com. The product code can be
found printed above the barcode on the product packaging, alternatively
you can nd it on the relevant coolaroo.com product page.
ATTENTION: The illustrations in this manual are for assembly and operation purposes only.
They may dier from the product's actual appearance.
3M PRIVACY SCREEN
SUITS COOLAROO
FAIRHAVEN GAZEBOS
ASSEMBLY GUIDE

2 3
A
PICTUREREF PART NAME QTY
Blind housing assembly
Housing xing channel
Right hand side rail channel
Le hand side rail channel
4.8x25mm tek screw
M6x15 hex screw
Allen key
E
F
G
B
C
D
1
20
4
2
1
1
1
PARTS SUMMARY
3M PRIVACY SCREEN
Screen is to remain in the up position
when not in use. To avoid damage to your
screen and gazebo, never leave the screen
down during storms or inclement weather.
WARNING
ASSEMBLY
STEP 1
Tape Measure Electric Screwdriver
Ladders Minimum 2 People
Gloves Knife
Mallet
Hard Hat
Check that no parts are missing from the box. Ensure you have the required tools
and safety equipment shown below.

4 5
STEP 2
Attach the Housing xing channel (B) to the gazebo beam and gutter. Insert the
lip of the xing channel over the top lip of the internal gutter.
STEP 3
STEP 4
When securing the Housing xing channel (B), ensure that it is at an even distance from
each post (le and right). Fix to the bottom of the beam by using a screw (E), six times.
Take the Blind housing assembly (A) and connect to the Housing xing channel (B) by
ensuring the channels on both part A and part B interlock. Place the assembly on an angle
and then push upwards.
x6

6 7
STEP 5
STEP 6
Ax the four hex screws (F) into the Blind housing Assembly (A) tightly with allen key (G).
Ensure all four screws are spaced evenly apart.
Loosen the screws on the Right hand side rail channel (C) with the allen key (F). Install the
rectangular aluminium prole on the gazebo leg post rst.
x4
STEP 7
STEP 8
In order to install the rectangular aluminium prole on the vertical post correctly, you can
make the use of the positioning rib on the top prole as illustrated. Insert six Tek screws (E)
into the aluminum channel and into the vertical post.
Loosen the screws on the Le hand side rail channel (D) with the allen key (F). Install the
rectangular aluminium prole on the gazebo leg post rst.
Angular aluminium
needs to be aligned
with the inner side
x6

8 9
STEP 9
STEP 10
In order to install the rectangular aluminium prole on the vertical post correctly, you can
make the use of the positioning rib on the top prole as illustrated. Insert 6 x Tek screws (E)
into the aluminum channel and into the vertical post.
Slide the zippers attached to the canvas into the plastic guide rail of part C
and part D respectively.
Angular aluminium
needs to be aligned
with the inner side
x6
STEP 11
Aer the screen is correctly inserted into the le and right channels, the le (C) and
right (D) corner aluminum and rectangular tubes are re-attached using the hex screws
(F), ve on each side.
x10

10 11
The screen is to remain in the up position when not in use.
To avoid damage to your screen and gazebo, never leave
the screen down during storms or inclement weather.
WARNING
STEP 12
Pull the horizontal channel up and down to test whether the screen operates smoothly
within the track. Enjoy your new Coolaroo privacy screen.
