PM615cbi
60 Amp Busway
Catalog #
Type
Project
A machined aluminum track fixture for low voltage
PAR36 lamps for 35 or 50 watts. For use with RSA
Profile Series 60 Amp Busway, 20 Amp 1 or 2 Circuit
Track or 20 Amp 2 Circuit / 2 Neutral Track.
Integral low voltage electronic transformer in
aluminum housing.
Front loading lamp with bayonet action lens /
accessory bezel. Optical accessories are captured
in the bezel with a threaded retainer ring preventing
accessory spill-out during relamping. Can accom-
modate up to three optical accessories.
Auto extending / retracting lamp holder. Lamps
extend for easy access and automatically retract
to optimum position. This is extremely helpful when
dealing with varying accessory combinations or dif-
fering manufacturer lamp dimensions.
Optical accessories include color filters, UV fil-
ters, screens, spread lenses, louvers, hex louvers,
snoots. Consult RSA for details.
Locking on both the horizontal and vertical
planes. 370º vertical rotation possible due to over-
center locking mechanism (60 amp busway only).
270º horizontal locking adjustment.
UL and CUL listed
Available in White, Black, Natural Aluminum or
custom finishes.
PAR36 12V
Closed Back Machined Fixture w/ Integral Transformer
PM615cbi | PM415cbi | PM215cbi | PM115cbi
Ordering Example: PM615cbi-50-AL-120
PM415cbi
20 Amp Track
2 Cct. 2 Ntl.
PM115cbi
PM215cbi
20 Amp Track
1 or 2 Cct.
Closed Back Machined Fixture w/ Integral Transformer Lamp Wattage Finish Voltage
❑ PM615cbi - PAR36 for 60 Amp Busway
❑ PM115cbi - PAR36 for 20 Amp 1 Circuit Track
❑ PM215cbi - PAR36 for 20 Amp 2 Circuit Track
❑ PM415cbi - PAR36 for 20 Amp 2 Circuit / 2 Neutral Track
❑ 35 35 Watt 12V PAR36 ❑ WH White ❑ 120 120 Volts primary
❑ 50 50 Watt 12V PAR36 ❑ BK Black ❑ 277 277 Volts primary
❑ AL Natural Alum.
❑ PT Custom Finish

PM61
®
0° Aiming Angle 30° Aiming Angle 30° Aiming Angle 45° Aiming Angle
Horizontal Footcandles Horizontal Footcandles Vertical Footcandles Vertical Footcandles
D FC L W D FC L W CB D FC L W CB D FC L W CB
FC FC
FC
CB
CB
L L
L
30° 30°
D
W
D
W
W
Lamp Performance Data
D = Distance to the horizontal or vertical surface.
FC = Initial footcandles at the center of the beam.
L = Length of the beam where candlepower is reduced to 50%
of center beam candlepower.
W = Width of the beam where candlepower is reduced to 50%
of center beam candlepower.
CB = Distance to the center of the beam.
Lamp data given is typical and is based on bare lamp performance.
Contact lamp manufacturers for availability and specific performance.
Distance, length and width given in decimal feet.
PAR36 12V Halogen Screw Terminal
35 PAR36 /H /SP5 GEL 10 250 1.0 1.0 8 254 0.9 0.9 4.6 3 347 1.0 0.5 5.2 6 246 1.0 0.7 6.0
Beam Spread = 5° x 5° 14 128 1.4 1.4 10 162 1.1 1.1 5.8 5 125 1.7 0.8 8.7 8 138 1.3 0.9 8.0
CBCP = 25,000 18 77 1.9 1.9 12 113 1.4 1.3 6.9 7 64 2.4 1.1 12.1 10 88 1.6 1.0 10.0
Rated Life = 4,000 Hrs. 22 52 2.3 2.3 14 83 1.6 1.5 8.1 9 39 3.0 1.5 15.6 12 61 1.9 1.4 12.0
35 PAR36 /H /SP8 GEL 8 312 0.8 0.8 7 265 0.8 0.7 4.0 3 278 0.9 0.5 5.2 5 283 0.7 0.6 5.
Beam Spread = 8° x 8° 12 139 1.2 1.2 10 130 1.1 1.0 5.8 4 156 1.2 0.7 6.9 7 144 1.0 0.7 7.0
CBCP = 20,000 16 78 1.6 1.6 13 77 1.4 1.4 7.5 5 100 1.5 0.8 8.7 9 87 1.3 0.9 9.0
Rated Life = 4,000 Hrs. 20 50 2.0 2.0 16 51 1.7 1.7 9.2 6 69 1.8 1.0 10.4 11 58 1.5 1.1 11.0
35 PAR36 /H /FL30 GEL 2 225 0.9 1.3 2 165 1.1 1.4 1.2 1.0 204 0.8 1.0 1.7 1.5 190 1.0 1.2 1.5
Beam Spread = 30° x 30° 3 100 1.4 2.0 3 73 1.7 2.2 1.7 1.5 91 1.3 1.5 2.6 2.0 107 1.4 1.7 2.0
CBCP = 900 4 56 1.9 2.6 4 41 2.3 2.9 2.3 2.0 51 1.7 2.0 3.5 2.5 68 1.7 2.1 2.5
Rated Life = 4,000 Hrs. 5 36 2.3 3.3 5 26 2.8 3.6 2.9 2.5 33 2.1 2.5 4.3 3.0 48 2.1 2.5 3.0
50 PAR36 /H /SP5 GEL 10 350 1.0 1.0 9 281 0.9 1.0 5.2 4 273 1.1 0.7 6.9 7 253 0.9 0.9 7.0
Beam Spread =5° x 5° 15 156 1.5 1.5 13 135 1.4 1.4 7.5 6 122 1.6 1.1 10.4 9 153 1.2 1.1 9.0
CBCP = 35,000 20 87 2.0 2.0 17 79.0 1.8 1.8 9.8 8 68 2.2 1.5 13.9 11 102 1.4 1.4 11.0
Rated Life = 4,000 Hrs. 25 56 2.6 2.6 21 52.0 2.2 2.3 12.1 10 44 2.7 1.9 17.3 13 73 1.7 1.6 13.0
50 PAR36 /H /SP8 GEL 10 300 1.0 1.1 8 304 0.9 0.9 4.6 4 234 1.4 0.8 6.9 6 295 1.0 0.8 6.0
Beam Spread = 8° x 8° 15 133 1.6 1.6 12 135 1.4 1.4 6.9 5 150 1.7 1.1 8.7 8 166 1.3 1.1 8.0
CBCP = 30,000 20 75 2.1 2.1 16 76 1.8 1.8 9.2 6 104 2.1 1.3 10.4 10 106 1.6 1.3 10.0
Rated Life = 4,000 Hrs. 25 48 2.6 2.7 20 49 2.3 2.3 11.5 7 77 2.4 1.5 12.1 12 74 2.0 1.6 12.0
50 PAR36 /H /FL30 GEL 2 325 0.9 1.3 2.0 224 1.2 1.4 1.2 1.0 262 1.0 1.0 1.7 1.5 248 1.1 1.2 1.5
Beam Spread = 30° x 30° 3 144 1.4 1.9 3.0 99 1.8 2.1 1.7 1.5 117 1.5 1.5 2.6 2.0 140 1.5 1.6 2.0
CBCP = 1,300 4 81 1.9 2.5 4.0 56 2.3 2.8 2.3 2.0 66 2.0 2.0 3.5 2.5 89 1.9 2.0 2.5
Rated Life = 4,000 Hrs. 5 52 2.3 3.2 5.0 36 2.9 3.6 2.9 2.5 42 2.6 2.5 4.3 3.0 62 2.2 2.4 3.0
PAR36 12V Incandescent Screw Terminal
50 PAR36 VNSP GEL 8 297 1.3 1.3 8 223 1.5 1.4 4.6 4 297 2.1 1.3 6.9 6 264 1.7 1.3 6.0
Beam Spread = 5° x 5° 12 132 1.7 1.7 11 118 1.9 1.7 6.4 6 132 2.8 1.7 10.4 9 117 2.3 1.7 9.0
CBCP = 19,000 16 74 2.1 2.1 14 73 2.3 2.1 8.1 8 74 3.6 2.1 13.9 12 66 2.8 2.2 12.0
Rated Life = 2,000 Hrs. 20 48 2.4 2.4 17 49 2.7 2.4 9.8 10 48 4.4 2.4 17.3 15 42 3.4 2.6 15.0
50 PAR36 /NSP GEL 6 306 0.7 0.8 6 198 0.9 0.9 3.5 2 344 0.9 0.6 3.5 4 243 0.9 0.8 4.0
Beam Spread = 8° x 8° 8 172 1.0 1.1 8 112 1.2 1.3 4.6 3 153 1.3 0.9 5.2 5 156 1.1 1.0 5.
CBCP = 11,000 10 110 1.2 1.2 10 71 1.5 1.6 5.8 4 86 1.7 1.1. 6.9 6 108 1.3 1.2 6.0
Rated Life = 2,000 Hrs. 12 76 1.4 1.4 12 50 1.8 1.9 6.9 5 55 2.2 1.4 8.7 7 79 1.6 1.4 7.0
