278 SERIES
Surface Luminaire
Starter Collection
Ring Baffle
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
shaperlighting.com
278 Starter Collection ring Baffle features a direct downlight
component.
SPECIFICATION FEATURES
Material
Solid aluminum. Aluminum
hexel louver or optional
tempered sandblasted glass
lense.
Finish
Standard: Natural Aluminum
(NA) [Sustainable Design].
Premium: Matte White (MW),
Lacquered Satin Aluminum
(SAL), Clear Anodized Aluminum
(CAL) or Custom Color (CC).
Optics
Refer to
www.shaperlighting.com for
complete photometrics.
Ballast
Integral electronic HPF, multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
Lamp/Socket
One (1) 26W (G24q-3) 4-pin quad
CFL lamp, 32W (GX24q-3) 4-pin
triple CFL lamp, 100W A-19,
50PAR20H, 75PAR30LH or
90PAR38H lamp. CFL socket
injection molded plastic. INC
socket fired ceramic rated for
660W-250V. Lamps furnished by
others.
Installation
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring.
Options
Tempered Sandblasted Glass
Lense (TL), Acrylic Baffle - CFL
only (AB), Perforated Band (PFB),
Remote Emergency Battery -
Supplied by others (REM), MRI
applications (INC only) - Contact
factory. Damp Location (DL): All
Painted Finishes only. Energy
Star Rating - Consult Factory.
Labels
U.L. and C.U.L. approved for
indoor and damp location. See
options for damp location
finishing requirements.
Modifications
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard surface
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
DESCRIPTION
Catalog # Type
Date
Project
Comments
Prepared by
SUSTAINABLE
DESIGN
Shaper has a long-standing history of
offering environmentally-friendly fixtures.
The copper and bronze alloys used in our
exterior luminaires feature up to 98% re-
cycled content, contribute less undesirable
air emissions compared to painted alumi-
num and are easy to recycle.
Shaper’s exclusive Starter Collection fixtures
are featured throughout the Shaper product
line. The concept of offering highly styled,
affordable fixtures was introduced over
fourteen years ago and has become one of
our fastest growing lines. The design
premise, basic construction, clean lines
and unadorned shapes are highly desirable
in modern architectural environments.
STARTER
COLLECTION
Refer to the Icon Legend
Link on shaperlighting.com.
MAGNETIC
RESONANCE
IMAGING (MRI)
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
ENERGY
STAR
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
ADS042715
2008-09-04 11:38:56
Sample Number: 278-INC/1/100-120V-CAL
Finish
Standard
NA Natural Aluminum=
Premium
CAL Clear Anodized
Aluminum
=
CC Custom Color=
MW Matte White=
SAL Lacquered Satin
Aluminum
=
Options
AB Acrylic Baffle 1
2
=
DL Damp Location=
REM Remote
Emergency Battery 3
=
PFB Perforated Band=
TL Tempered Sandblasted
Glass Lens
=
Voltage
120V
277V 1
347V 1
Series
278 Ring Baffle
Surface
=
Lamp
CFL/1/26
CFL/1/32
INC/1/100
PARH/1/90
1Available with CFL only.
Notes:
2
S
3
Interior applications only.
upplied by others.
ORDERING INFORMATION

Specifications and dimensions subject to change without notice.
Shaper Lighting •1141 Marina Way South •Richmond, CA 94804 •ph 510.234.2370 •fax [phone]
420-RP 420 476 689
COMPANION PRODUCTS
8" ø 6" ø
2-3/4"
7-5/8"
2-1/8"
278 INC STANDARD
6-1/4" ø
8-1/2"
2-1/8"
2-3/4"
278 CFL STANDARD
6-1/4" ø
TEMPERED SANDBLASTED
GLASS LENSE (TL)
PERFORATED BAND (PFB)
278 OPTIONS
ACRYLIC BAFFLE (AB)
DIMENSIONS
ADS042715
2008-09-04 11:38:56
278 SERIES SURFACE LUMINAIRE
