DESCRIPTION
The Harmony EyeLite combines exceptional aesthetics with remarkable
strength. Die-cast, extra-heavy aluminum walls of the front/back housings
offer rugged durability and afford efficient heat dissipation. Lens is
fashioned from high-quality, tempered borosilicate glass. Linear prisms
provide an efficient forward throw and broad coverage. Performance-
crafted, faceted, specular aluminum reflector maximizes efficient light
distribution. A liquid injection-molded silicone gasket allows a tight seal
between the housing and lens assembly. EyeLite is listed for wet locations
in all mounting positions; a 9° tilt allows water runoff when inverted.
Application
This handsome fixture will blend
seamlessly into virtually any
unsupervised environment where
broad, low-glare light distribution
is esthetically pleasing and security
essential: shopping centers,
roadside malls, corporate building
exteriors or transportation stations.
Lens
Molded, tempered, shock-resistant
borosilicate glass is 0.225 inches
thick and floats on gasket.
Dissipates heat and is unaffected
by UV light, pollution and cleaning
solutions. Relamping hook holds
lens assembly for easier
maintenance. Chroma lens is
molded glass, sealed with gasket.
Consult factory for colors.
Optics
Linear elevating prisms create an
IES Type-III short distribution,
providing broad coverage. Faceted,
specular aluminum reflector (94%
TR) maximizes light output.
Surface Housing
Front/back housings are precision
TruGen die-cast for superior
strength and product uniformity.
Marine-grade, low-copper-alloy
aluminum resists corrosion.
Extra-heavy thickness promotes
durability and assures an efficient
heat sink for internal components.
Regressed Housing
Cast housing is nominal .125"
thick, marine grade, low copper
alloy aluminum. Comes with
concealed cast aluminum plate to
seal regressed housing to front
lens face. Two back-box
configurations are available
depending on installation. The BB
option is for stud wall and other
combustible material applications
and comes with adjustable
brackets for 18" to 24" on center
spacing.
Regressed Housing Cont.
The CP option is for concrete pour
and other non-combustible
material applications and comes
with an adjustable bracket to
accommodate variable wall
thickness. A quick-connect plug
wiring system allows for easy
installation. Back box may be
shipped separately for early
installation (see REGRESSED
HOUSING MOUNTING AND
ADVANCED ORDERING
INFORMATION). Wall mount only.
Gaskets
Long-life, injection-molded silicone
gasket promotes water- and
dust-tight seal between housing
and front-lens assembly.
1/8-inch-thick, closed-cell EDPM
gasket facilitates proper seal
between luminaire and mounting
surface. No additional caulking is
required.
Lamp
(by others)
Socket
HID socket is a 4KV rated porcelain
medium-base socket with a
nickel-plated brass screw shell. CFL
socket incorporates 26-watt
GX24q3; 32-watt GX24q3; or
42-watt GX24q4 base with
stainless-steel retention clip and a
2-pin reject that ensures proper
lamping and lamp retention.
Fluorescent socket is
polycarbonate.
Ballast
CFL ballasts are electronic
universal voltage 120-277V, less
than 10% harmonic distortion with
minimum starting temperature of
-18°C (0°F). HID ballasts are
standard HPF core & coil with
minimum starting temperatures of
-40°C (-40°F) for HPS and -30°C
(-20°F) for MH.
Fasteners
Four stainless-steel TORX® screws
with center reject pin. Screw heads
are recessed into casting to
maximize tamper-resistance.
Sealed with a gasket, fasteners are
captive.
Finish
Finish is TGIC, textured, thermoset
polyester-powdercoat that is
applied in five-stage process at
2.0-mil thickness and baked on at
400° F. Finish is 500-hour-salt-
spray test-rated and has an impact
rating of 160 inch/pounds.
Labels
CUL wet-listed for wall and ceiling.
EYELITE 12"
Harmony(TM)
26W - 42W
Compact Fluorescent
50W - 100W
High Pressure Sodium
Metal Halide
EFS-12, ERS-12,
ELS-12, ENR-12
50W-100W HPS/MH
26W-42W CT
EFR-12, ERR-12,
ELR-12, ENR-12
50W-70W HPS/MH
26W-32W CT
12”dia.
305mm
8.875"
225mm
10”
254mm
12" dia.
305mm
8“
204mm
3.75"
95mm
4"
102mm
FAIL-SAFE®

Fail-Safe • Customer First Center • 1121 Highway 74 South • Peachtree City, GA 30269 • TEL [phone] • FAX [phone]/2007 2:42:06 PM
Specifications and Dimensions subject to change without notice.
ADC041340
ORDERING INFORMATION
PHOTOMETRICS
.
HARMONY EYELITE 12"
8.5" dia.
217mm
J-Box Mounting Plate
.250" dia.
Mounting K.O.
SURFACE HID & COMPACT FLUORESCENT &
COMPACT FLUORESCENT WITH EMERGENCY
BATTERY PACK
Candlepower Distribution
Footcandle Multipliers
6' 8' 10' 12' 14'
x1.7 x1.0 x0.64 x0.44 x0.32
Shipping Information
Cat. No. Weight
EFS - 1
2 - XXMH 12.0 lbs
EFS - 1
2 - XXHPS 12.0 lbs
EFR - 12 - XXMH 15.0 lbs
EFR - 12 - XXHPS 15.0 lbs
EFR - 12 - XXCT 10.0 lbs
For other than 8’ mounting heights
use appropriate mulitplier value:
ENERGY DATA
Input Watts:
Electronic
(1) 26W Compact Triple 27.0 Watts
(1) 32W Compact Triple 37.0 Watts
(1) 42W Compact Triple 47.0 Watts
High Power Factor
(1) 50W HPS 60.0 Watts
(1) 70W HPS 95.0 Watts
(1) 100W HPS 130.0 Watts
(1) 50W MH 69.0 Watts
(1) 70W MH 94.0 Watts
(1) 100W MH 125.0 Watts
J-Box Mounting
Surface Mounting
Rotationally adjustable mounting bracket is
screwed to J-Box. Fixture attaches to plate
with (2) 1/4”- 20 studs and nuts.
6 knock outs are provided in casting for
mounting directly to surface. Mounting
hardware supplied by others.

Fail-Safe • Customer First Center • 1121 Highway 74 South • Peachtree City, GA 30269 • TEL [phone] • FAX [phone]/2007 2:42:06 PM
Specifications and Dimensions subject to change without notice.
ADC041340
REGRESSED HOUSING MOUNTING AND ADVANCED ORDERING INFORMATION
Cut-out Template Dimensions Included
Center lines
to aid in
placement
Finished
fixtures
trim
Do not cut
outside of
pattern
perimeter
5 11/32
3 3/8
3 1/16 3 1/16
5 11/32
4 15/32
1 7/16
1 19/32
4 1/2
3 3/8
REGRESSED SAMPLE NUMBER
EFR-12-50MH-DT-BK-BB
Complete Unit
EXAMPLE: RBB-12
WITH THE STUDWALL
BRACKETS
EFR-12-LH-50MH-DT-BK-BB RBB-12
+
=
BB=Combustible Material Application
CP=Brick or Concrete Pour
LH= Less
Regressed
Housing
The following regressed
housings may be ordered
in advance
RBB-12-F=For Combustible (Studwall)
Applications - Fluorescent Fixtures Only
RBB-12=For Combustible (Studwall) Applications
- HID and Incandescent Fixtures Only
RCP-12=For Non-Combustible (Brick, Concrete-
Pour) Applications - HID, Fluorescent, and
Incandescent Fixtures
