DESCRIPTION
The accord(TM) redefines fluorescent lighting by improving on aesthetics,
comfort and energy savings. The accord(TM) provides the right amount of
light while eliminating surface shadows commonly found in parabolics.
Therefore, accord(TM) increases the comfort level while providing
significant energy savings.
The accord(TM) is the ideal solution for offices, schools, hospitals, retail and
other applications.
A ... Construction
Shallow 3-1/4" deep housing is die
formed of code gauge, prime cold
rolled steel. Heavy gauge end
plates are securely attached with
screws for strength and rigidity
and the elimination of gaps. Four
auxiliary fixture end suspension
points are provided. Large access
plate for supply connection.
B ... Electrical*
Ballasts are Class "P" and are
positively secured. Rotor-lock
lampholders ensure positive lamp
retention. UL/CUL listed. Suitable
for damp locations.
C ... Ballast Access
Ballast is mounted on a heavy
gauge access plate and can be
accessed from above the ceiling
line.
D ... Finish
Durable cold rolled steel with
multistage, iron phosphate
pretreatment and white enamel
finish to ensure maximum bonding
and rust inhibition.
E ... Reflectors
Reflector has high reflectance
baked matte white enamel finish
for luminous uniformity.
F ... Shielding
Positively retained frosted acrylic
profile lenses provide a soft but
effective distribution of light.
AC
128T5
154T5
T5 LAMP
1' X 4' Recessed
Troffer Series
LAMPS CONTAIN MERCURY. DISPOSE ACCORDING
TO LOCAL, STATE OR FEDERAL LAWS
Safe and convenient means of
disconnecting power
G
G r i d / L a
y- i n
S t a n d a r
d
F
D r y
wall Fr a m e
K i
t
C e i l i n
g Tri m
Ty p e** Ty p e
Exposed Grid G
ConcealedT G or T
Slot Grid G or T
F l a n g e * * *
EB Ballast & STD Lamps @ 277V
128T5 (34)
Luminaire Efficacy Rating
LER =FL64 LPW
Catalog Number: AC-128T5
Yearly Cost of 1000 lumens,
3000 hrs at .08 KWH = $3.88
*Reference the lamp/ballast data in the
Technical Section for specific lamp/ballast
requirements.
**Consult Pre Sales Technical Support.
***See Drywall Frame Kit Accessory
E N E R G Y D ATA
Input Watts:
11-3/4"
[299mm]
48-3/8" [1229mm]
6"
[153mm]
X
Y
A B CDF E
COOPER LIGHTING - METALUX®

Metalux • Customer First Center • 1121 Highway 74 South • Peachtree City, GA 30269 • TEL [phone] • FAX [phone]/2008 2:37:31 PM
Specifications and Dimensions subject to change without notice.
ADF051799
ORDERING INFORMATION
PHOTOMETRICS
SHIPPING INFORMATION
AC
SAMPLE NUMBER: AC-128T5-UNV-EBT1NDIM
Number of Lamps
(Not included)
1=1 Lamp
Wattage (Length)
28T5=28WT5 (48")
54T5=54WT5HO (48")
Voltage(1)
UNV=Universal Voltage
120-277
Options
GL=Single Element Fuse
GM=Double Element Fuse
Flex=Flex installed
EL=Emergency Installed
Packaging
U=Unit Pack
PALC=Job Pack,
in carton
Shielding
Blank=Frosted Acrylic
(standard)
Ballast Type
EBT =T5 Linear Electronic
Program Rapid Start
Total Harmonic
Distortion < 10%
Ballast Factor/Type
(For 28W T5 Lamp Only)
N=Normal Light Output .95 BF(2)
H=High Light Output 1.15 BF (2), (4)
NDIM=Normal .95-1.0 BF Step Dimming(3)
HDIM=High 1.15 BF Step Dimming(3), (4)
NOTES: (1) Products also available in non-US voltages and frequencies for international markets. (2) .95 and 1.15 ballast factor available for 28WT5 lamps only. (3) Step Dimming ballast available for 28WT5 lamps only.
(4) 1-Lamp ballast in the High Ballast factor not available. 2-Lamp ballast will not operate 1-Lamp. (5) 1' x 4' Accord is not designed for continuous row mount applications. For complete product data, reference the
Fluorescent Specification binder. Specifications & dimensions subject to change without notice. Consult your Cooper Lighting Representative for availability and ordering information.
No. of Ballast
1 or 2
Lamps
L5835=T5 Lamp,
3500K
L5841=T5 Lamp,
4100K
L5835HL=T5
Lamp, 28W,
3500K, 2900
Lumens
L5841HL=T5
Lamp, 28W,
4100K, 2900
Lumens
Series
AC=Accord Series
Width(5)
Blank=1' Width
Rating
Blank=
Standard
NY=NewYork
Rated
ATW-SW4=
Chicago
Rated
C o e f fi c i e n t s o f U t i l i z a t i o n
Effective floor cavity reflectance 20%
rc 80% 70% 50% 30% 10% 0%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
0
1
2
3
4
5
6
7
8
9
10
L u m i n a n c e D a t a
Average Average Average
Angle 0-Deg 45-Deg 90-Deg
in Deg cd/sm cd/sm cd/sm
45 1768 2084 2285
55 1659 2119 2395
65 1501 2125 2125
75 1195 1600 1382
85 555 463 339
Z o n a l L u m e n S u m m a r y
Zone Lumens %Lamp %Fixture
0-30
0-40
0-60
0-90
0-180
||
C a n d l e p o we r
Angle Along II 45° Across
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
AC-128T5
Electronic Ballast
F28T5/835 Lamps
2600 Lumens
Spacing criterion:
(II) 1.2 x mounting
height, ( ) 1.4 x
mounting height
Efficiency 87.4%
Test Report:
241P113
LER = FL62
Yearly Cost of 1000
lumens, 3000 hrs at
.08 KWH = $3.88
738 738 738
734 736 736
723 730 732
705 718 725
679 701 715
647 679 702
609 654 685
565 623 663
517 588 635
465 548 601
411 502 559
354 452 511
295 396 443
236 334 334
175 248 221
115 154 133
60 75 63
18 15 11
0 1 1
104 104 104 104 102 102 102 102 97 97 97 93 93 93 89 89 89 87
95 91 87 84 93 89 86 83 85 82 80 82 80 77 79 77 75 73
86 79 73 68 84 77 72 67 74 70 66 71 68 64 69 66 63 61
78 69 62 56 76 68 49 56 65 59 55 63 58 54 60 56 53 52
72 61 53 47 70 60 43 47 58 51 46 56 50 46 54 49 45 43
66 54 46 40 64 53 38 40 51 45 40 50 44 39 48 43 39 37
61 49 41 35 59 48 34 35 46 40 35 45 39 34 43 38 34 32
56 44 36 31 55 43 31 31 42 35 30 41 35 30 40 34 30 28
52 40 33 27 51 40 28 27 38 32 27 37 31 27 36 31 27 25
49 37 29 25 47 36 25 24 35 29 24 34 28 24 33 28 24 22
46 34 27 22 44 33 23 22 33 26 22 32 26 22 31 26 22 20
585 22.5 25.8
973 37.4 42.8
1788 68.8 78.7
2271 87.4 100.0
2271 87.4 100.0
