1-1/2" [38mm]
7”
[179mm]
803
S
See mounting notes
NOTES: For complete product data, refer to the Neo-Ray Specification Binder. Specifications and dimensions subject to change without notice. Products may be
modified for use in international markets. Please contact your Cooper Lighting Sales Representative for availability and ordering information.
730 COOPER LIGHTING
WALL
SCALA
803-IW
802-IW
DIRECT-INDIRECT
1-1/2" [38mm]
3/8"
[
10mm
]
802
7-3/4”
[196mm]
ORDERING INFORMATION:
Sample number: 802IW-1T5-48-1EB-SI-S28A
Series
802=Scala 803=Scala
Light Output
I=Indirect
Mounting
W=Wall
Number of Lamps (not included)
1=1 Lamp
Lamp Type
T5 T5HO
Run Length
Overall Nominal Run Length__ft. (Any combination of 8’, 6’, 4’ and 3’
sections)
Voltage 1
1=120V 2=277V 3=347V U=Universal
Ballast
EB=Electronic Ballast (Standard) DB=Dimming Ballast
[Only slim line ballast (small case)]
Switching
SI=Single Switching DU=Dual Switching
Emergency
EM=Emergency Pack (Consult Factory)
Diffuser Type
28A=Ribbed Clear Plastic 28C=Ribbed Blue Plastic
28B=Ribbed Texture Plastic 28D=Ribbed Green Plastic
Special Finish Options
CB=Chrome housing with black gloss ends
SB=Satin housing with black gloss ends
1 Due to various constraints, some options may not be combined with others.
Construction
Housing is die formed cold rolled steel forming an
1-1/2” x 7-3/4” architectural profile. Standard 4’-0”
and 8’-0” fixture lengths combine for individual or
continuous runs.
End Caps
End caps are precision die-cast aluminum
mechanically attached without exposed fasteners.
Reflectors
Optical reflectors are die-formed high reflectance
white painted steel.
Electrical
Fixtures use UL listed Class P, T5 program rapid
start electronic ballasts. Power factor of 97% with
less than 10% THD. Fixtures and electrical
components certified to UL and CUL standards.
Diffusing Media
Standard ribbed semi-transparent/translucent
diffusing lens are available. Custom diffusers can
be specified (consult factory.
Finish
Baked on low-gloss white powder coated acrylic
finish.
Mounting
Fixture mounts directly to existing structure over a
2” x 4” standard electrical box mounted
horizontally in the wall.
803 Mounting Notes
803 mounts to blocking (by others) behind sheet
rock that is then plastered over for refined aesthetic.
Flexible conduit (by others) feeds directly into
fixture arm with home run (elec.) to each row.
• 803 IW Regressed canopy
creates illusion of an
illuminated floating rail
(pictured above)
• Single T5 lamping utilizes
wall surface for indirect
lighting component
• Customizable diffuser
material available including
architectural patterned glass
• Fixture may be used without
diffusion material for refined
minimalist appearance
• Slim 1-1/2” Height x 7-1/8”
Extension
• Die-cast aluminum end caps
• Modular construction allows
easy creation of rows with
included joiners
• Precision formed steel
fixture body available in
Polished and Satin Chrome
finishes
• Companion Scala pendant
available
48"[1219mm]*
96"[2438mm]*
*Dimensions do not include end caps.
36"
72"
= Slim Line Ballast only.
S
S
STANDARD LUMINAIRE LENGTHS* SPECIAL ORDER
NEO-RAY™
803
802
