210-D SERIES
Surface Luminaire
Luminous Bowl
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
shaperlighting.com
Catalog # Type
Date
Project
Comments
Prepared by
210-D Luminous Bowl features direct/indirect illumination with an
Integral Downlight and is available in two sizes.
SPECIFICATION FEATURES
Material
Painted and chromed cold rolled
steel, solid brass or solid
aluminum with a matte white
acrylic bowl.
Finish
Standard: Matte White (MW).
Premium: Lacquered Satin
Aluminum (SAL), Satin Chrome
(SC), Satin Copper (SCP), Satin
Brass (SB), Polished Chrome
(PC), Satin Nickel (SN), Polished
Nickel (PN), Polished Copper
(PCP), Polished Brass (PB),
Oxidized Brass (OBRS),
Lacquered Satin Chrome (SCL),
Lacquered Satin Nickel (SNL),
Natural Aluminum (NA)
[Sustainable Design] or Custom
Color (CC). Matte white
mounting pan.
Optics
Refer to
www.shaperlighting.com for
complete photometrics.
Ballast
Integral electronic HPF, multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
Lamp/Socket
18":Three (3) 13W (2GX7) 4-pin
low wattage CFL lamps or three
(3) 40W A-19 lamps.
24":Three (3) 26W (G24q-3) 4-pin
quad CFL lamps or three (3) 60W
A-19 lamps. Downlight: One (1)
50W PAR20H or one (1) 13W
(G24q-1) 4-pin quad CFL lamp.
CFL socket injection molded
plastic. INC socket fired ceramic
rated for 660W-250V. Lamps
furnished by others.
Installation
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring. Provided
with 2-circuit wiring.
Options
Hand Painted Faux Alabaster
Bowl (FB), Hand Painted Faux
Linen Bowl (LNB), CamingTrim -
At top edge of bowl (CT),Trim
Ring (TR), Double BarTrim (2B),
CFL Dimming Ballast (26W only)
- Contact the factory for ballast
options (DM), Remote
Emergency Ballast - Supplied by
others (REM). Damp location
(DL): All Painted Finishes,
Lacquered Satin Nickel (SNL) and
Lacquered Satin Chrome (SCL)
only. MRI Applications (INC only)
- Contact Factory. Energy Star
Rating - consult factory.
Labels
U.L. and C.U.L. approved for
indoor and damp location. See
options for damp location
finishing requirements.
Modifications
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard surface
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
DESCRIPTION
MAGNETIC
RESONANCE
IMAGING (MRI)
ENERGY
STAR
SUSTAINABLE
DESIGN
Refer to the Icon Legend
Link on shaperlighting.com.
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
Shaper has a long-standing history of
offering environmentally-friendly fixtures.
The copper and bronze alloys used in our
exterior luminaires feature up to 98% re-
cycled content, contribute less undesirable
air emissions compared to painted alumi-
num and are easy to recycle.
Shaper’s Quick Ship program
features over thirty-four fixtures
with finish options such as Satin
Chrome, Natural Aluminum and
Satin Brass and a wide variety of
lamp selections. All products ship
in five days from receipt of order.
QUICK SHIP (QS)
Sample Number: 210-D-18-CFL/3/13-PARH/1/50-277V-PCP
Downlight
Lamp
CFL/1/13
PARH/1/50
Finish
Standard
MW Matte White=
Premium
CC Custom Color=
OBRS Oxidized Brass=
PB Polished Brass=
PC Polished Chrome=
PCP Polished Copper=
PN Polished Nickel=
SAL Lacquered
Satin Aluminum
=
NA Natural Aluminum=
SB Satin Brass=
SCL Lacquered Satin Chrome=
SC Satin Chrome=
SCP Satin Copper=
SN Satin Nickel=
SNL Lacquered Satin Nickel=
Options
2B Double Bar Trim
=
TR Trim Ring=
CT Caming Trim=
DL Damp Location=
DM CFL Dimming
Ballast 4, 5
=
REM Remote
Emergency
Battery 6
7
=
FB Hand Painted
Faux Alabaster
Bowl
=
Size
18"
24"
Series
210-D Bowl
Surface
with
Downlight
=
Lamp
CFL/3/13 1
CFL/3/26 2
INC/3/40 1
INC/3/60 2
Voltage
120V
277V 3
347V 3
1Available in 18".
Notes:
2Available in 24".
3Available with CFL only.
4Not available in 26W.
5Consult the factory
6S
7Interior applications only.
upplied by others.
for available options.
ORDERING INFORMATION
ADS042705
2008-09-03 08:26:48

Specifications and dimensions subject to change without notice.
Shaper Lighting •1141 Marina Way South •Richmond, CA 94804 •ph 510.234.2370 •fax [phone]
COMPANION PRODUCTS
ADS042705
2008-09-03 08:26:48
210-D SERIES SURFACE LUMINAIRE
5-5/8"
7-3/8"
10" ø
TRIM RING
(TR)
24" ø 4" 5-5/8"
CAMING TRIM (CT)
210-D 18" ø STANDARD
210-D TRIM OPTIONS
210-D 24" ø STANDARD
7-5/8" 5-7/8"
10" ø
DOUBLE TRIM BAR (2B)
18" ø 5-5/8"
4"
DIMENSIONS
