Cooper Lighting METALUX F-BAY 2HBG Series User manual

INDUSTRIALS
447
COOPER LIGHTING
• Specular enhanced
aluminum standard for
optical distribution. White
painted optics optional
• Available as open optics or
lensed with reinforced
aluminum door, mitered
corners
• Four auxilary fixture end
suspension points
provided
• End plate grid lock feature
• Superior lumen
maintenance exceeds that
of HID 90-95% of initial light
output at end of life
• Instant strike and re-strike
ability
• Occupancy sensor is
available to instantly turn
lights on and off.
Saves
more energy!
• UL/CUL Listed. Suitable for
damp locations
DESCRIPTION
The 2HBG series is an outstanding
solution for high mounting height
industrial or retail applications that
require recessed luminaire. The 2HBG
optic has been optimized to provide
maximum performance from either T5
or T8 lamps. The 2HBG’s high lumen
package allows the benefits of
fluorescent to be applied to
applications requiring a recessed
luminaire used at high mounting
heights. The primary benefits include
exceptional color rendering, high
system efficacy, 95% lumen
maintenance, long lamp life, instant
on/instant re-strike, economical
dimming, and uniform brightness
control. Primary applications include
"big box" retail, shopping malls, light
industrial, etc.
F-BAY 2HBG
SERIES
Recessed
2' x 4' High-Bay
4 or 6 Lamp
RECESSED HIGH-BAY
INDUSTRIAL LUMINAIRE
DIMENSIONS
ORDERING INFORMATION
SAMPLE NUMBER: 2HBG-654T5-A-UNV-EBT2-U
No. of Lamps
4=4 Lamps
6=6 Lamps
Lamp Type
32=32W T8 Lamps (48")
28T5=28W T5 Lamps (48")
54T5=T5HO Lamps (48")
Series
HB=High Bay
Width
2=24"
Voltage(1)
UNV=Universal
120/277 Voltage
UNC=Universal
347/480 Voltage (T5 linear only)
120V=120 Volt(3)
277V=277 Volt(3)
347V=347 Volt(3)
Downlight Optic
Blank=Open
A=Prismatic Acrylic
Lens & Aluminum
Doorframe
CL=Clear Acrylic
Lens & Aluminum
Doorframe
Distribution Optic
Blank=Aisle (Specular Aluminum)
G=General (White Painted)
Trim Type
G=Grid/Lay-in (Standard)
F=Flange Trim
Options
GL=Single Element Fuse
GM=Double Element Fuse
Lamps - for lamps installed,
see lamp options table
Emergency (T8 only) - for EM
installed, see EM options
table(2)
5-5/8"
[143mm]
23-3/4" [603mm]
Options
(See Options &
Accessories Section)
Packaging
U=Unit Pack
PAL=Job
Pack, out of
carton
PALC=Job
Pack, in
carton
Ballast Type(1)
EB8 = T8 Electronic Instant Start.
Total Harmonic Distortion < 10%
EB8 /PLUS= T8 Electronic Instant Start.
High Ballast Factor >1.13. Total
Harmonic Distortion < 20%
ER8 = T8 Electronic Program Rapid Start.
Total Harmonic Distortion < 10%
EBT =T5 Linear Electronic Program Rapid
Start. Total Harmonic Distortion < 10%
(For complete details on generic or to specify
manufacturer’s ballast see pg. 469)
No. of Ballast
2
No. of
Ballast
2
No. of Ballast
2
No. of Ballast
2
NOTES: (1)Products also available in non-US voltages and frequencies for international markets. (2)Not available when specifying emergencies, voltage must be specific.
(3)Voltage to be specified when using cord & plug.
For complete product data, reference the Fluorescent Specification binder. Specifications & dimensions subject to change without notice. Consult your Cooper Lighting
Representative for availability and ordering information.
COOPER LIGHTING - METALUX®
2' x 4', 4 LAMP
5-5/8"
[143mm]
23-3/4" [603mm]
2' x 4', 6 LAMP
