Cooper Lighting Nimbus II Wall Series 701-IW User manual

Catalog #
Project
Comments
Prepared by
Type
Date
SPECIFICATION FEATURES
07/20/2007 9:40:15 AM
Consult your representative for additional options and finishes.
Specifications and Dimensions subject to change without notice.
ADN070872
ORDERING INFORMATION
DESCRIPTION
The Nimbus II Wall series offers simple design and flexibility without
sacrificing performance. Multiple lamp configurations in T8 and T5 high
output fluorescent provide maximum flexibility for the architectural
environment. Nimbus II creates a comfortable and uniformly balanced
environment. All of these elements combined make the Neoray Nimbus II an
excellent selection for private offices, open office areas, VDT workspaces,
classrooms and corridors.
A ... Construction
Housing is one-piece, die-formed,
cold rolled steel, forming a 7" x
2-1/2" architectural profile.
Perforated sections are 33% open
with .1563" staggered hole pattern
and opal diffuser. Standard 4'-0"
and 8'-0" luminaire lengths
combine for continuous runs.
B ... End Caps
Standard end caps are precision
die-cast aluminum mechanically
attached without exposed
fasteners.
C ... Reflectors
Reflector is die-formed, semi-
specular anodized aluminum.
D ... Electrical
Luminaires are prewired with quick
wire connectors and use UL list
Class P, 265ma T8 electronic
ballasts. Power factor of 95% with
less than 20% THD. Fixtures and
electrical components certified to
UL and CUL standards.
E ... Finish
Luminaire housings are standard
white using electrostatically
applied acrylic powder coat paint.
Mounting
Fixture mounts directly to existing
structure over a 2" x 4" standard
electrical box mounted horizontally
in the wall. Refer to installation
section for details.
Nimbus II
701-IW
2T8
WALL-MOUNT
SEMI-INDIRECT
Light Distribution
Indirect - 95.7%
Direct - 4.3%
7" [177mm]
2-1/2"
[63mm]
A C ED END CAP B
5" [127mm]
2-1/2"
[64mm]
7-1/8" [181mm]
STANDARD LUMINAIRE LENGTHS
MODULAR ROW CONFIGURATION
• Standard length sections join easily to create rows.
• Sections align with T-grid.
• All sections prewired for through-wiring with quick connectors.
SAMPLE NUMBER: 701IW-SP-2T8-1C-1-SU-WA-24
1Due to various constraints, some options may not be combined with others.
Please consult your Cooper Lighting Representative for availability.
Series
701IW=Nimbus II
Wall Mount
701IW
Optics Up
S=Specular
S
Number of Lamps
(not included)
1=1 Lamp
2
Lamp Type
(Length)
T8=32W
(4' Unit)
T8
Number of
Circuits 1
1=1 Circuit
1
Voltage 1
1=120V
2=277V
3=347V
SU-WA= Surface/Wall
Mount
SU-WA
Run Length
Individual or
continuous runs will
be configured with
4' and 8' sections only
(see sample catalog #)
Wiring 1
C=Standard Circuit
D=Dimming
E=Emergency/Night Light
B=Battery Pack
Optics Down
P=Perforated
P
U= Universal
2=2 Lamps
NEO-RAY

Neo-Ray • Customer First Center • 1121 Highway 74 South • Peachtree City, GA 30269 • TEL [phone] • FAX [phone]/2007 9:40:15 AM
Specifications and Dimensions subject to change without notice.
ADN070872
PHOTOMETRICS
STANDARD BATTERY AND EMERGENCY/NIGHTLIGHT LOCATIONS
701-IW
Nimbus II
701IW-SP-2T8
(1) F32T8/TL841
3000 Lumens
Efficiency 62.3%
Test Report
#LSI16234
Coefficients of Utilization
Effective floor cavity reflectance 20%
rc 80% 70% 50% 30% 10% 0%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
0
1
2
3
4
5
6
7
8
9
10
60 60 60 60
55 52 50 48
49 45 42 39
45 40 36 32
41 35 31 27
38 30 26 23
35 28 23 20
32 25 20 17
29 22 18 15
27 20 16 13
25 18 14 11
52 52 52 52
47 45 43 41
43 39 36 34
39 34 31 28
35 30 27 24
32 27 23 20
30 24 20 17
27 21 18 15
25 19 15 13
23 17 14 11
22 16 12 10
36 36 36
31 30 29
27 26 24
24 22 20
21 19 17
19 16 15
17 14 13
15 13 11
14 11 09
12 10 08
11 09 07
22 22 22
19 18 18
17 16 15
15 14 13
13 12 11
12 10 09
10 09 08
09 08 07
09 07 06
08 06 05
07 06 05
09 09 09
08 07 07
07 06 06
06 06 05
05 05 04
05 04 04
04 04 03
04 03 03
03 03 02
03 03 02
03 02 02
03
02
02
02
01
01
01
01
01
01
01
Candela
Angle Along II 45° Across
0 28 28 28
5 27 29 30
15 26 32 35
25 23 33 37
35 20 29 36
45 15 29 35
55 11 24 32
65 3 20 27
75 0 12 24
85 0 6 13
90 0 3 7
95 16 58 34
105 101 323 352
115 187 536 518
125 266 611 773
135 334 569 778
145 391 560 658
155 435 579 615
165 464 563 597
175 478 505 516
180 473 473 473
Luminance Data
Angle 0-Deg 45-Deg 90-Deg
in Deg cd/sm cd/sm cd/sm
45 373 554 592
55 337 504 610
65 125 488 577
75 0 371 590
85 0 242 388
Zonal Lumen Summary
Zone Lumens %Lamp %Fixture
0-30 21 .72 1.16
0-40 34 1.16 1.87
0-60 60 2.01 3.22
0-90 79 2.65 4.25
40-90 44 1.48 2.38
60-90 19 .64 1.03
90-180 1789 59.65 95.75
0-180 1868 62.29 100.00
48" [1219mm]
96" [2438mm]
B/EM
Power Feed Battery or Night-light
B/EM
B/EM
