78
DIRECT
PERIMETER
NOTES: For complete product data, refer to the Neo-Ray Specification Binder. Specifications and dimensions subject to change without notice. Products may be
modified for use in international markets. Please contact your Cooper Lighting Sales Representative for availability and ordering information.
768 COOPER LIGHTING
PERIMETER
Construction
20-gauge steel housing.
Shielding
Parabolic or bold baffle.
Electrical
120, 277, 347 or Universal Voltage electronic ballast.
Fixtures and electrical components certified to UL
and CUL standards.
Finish
Durable, low gloss, white, powder coated acrylic
finish.
Staggered Lamps
T8=3”, T5=6”
Mounting
Recessed.
ORDERING INFORMATION:
Sample number: 78-1T8-36-2EB-SI-S72
Series
78=Perimeter
Number of Lamps (not included)
1=1 Lamp 2=2 Lamps
Lamp Type
T8 T5 T5HO
* Staggered lighting strips2
Run Length
Overall Nominal Run Length__ft. (Any combination of 8’, 6’, 4’ and 3’
sections)
Voltage 1
1=120V 2=277V 3=347V U=Universal
Ballast
EB=Electronic Ballast (Standard) DB=Dimming Ballast
Switching
SI=Single Switching DU=Dual Switching
Emergency
EM=Emergency Pack (Consult Factory)
Fusing
GLR GMF
Shielding
S72=White Bold Baffle
S79=Semi-specular Aluminum Parabolic Baffle
1 Due to various constraints, some options may not be combined with others.
2 T8 - 3” Staggered
T5 - 6” Staggered
• Direct wall wash light
distribution.
• The light is continuous and
unbroken.
• T5 and T8 lamping.
• Staggered lamps.
• Die formed steel housing,
nominal illuminated sections
3’, 4’, 6’ and 8’.
• Runs are field adjustable.
• 90 degree mitered corners.
• Extruded aluminum ceiling
trims.
• Selection of diffuser options.
9-1/4" [235mm]
CEILING OPENING
7-11/16" [195mm]
8-23/32" [221mm]
9-1/2" [242mm]
8" [203mm]
9/16" [15mm]
1/4" [7mm]
RUNS AND PATTERNS
SHIELDING OPTIONS
S72 Bold Baffle S79 Parabolic Baffle
STANDARD
ILLUMINATED
SECTIONS
12 5/16" OUTSIDE
MITERED CORNER
STANDARD ILLUMINATED
SECTIONS MITERED CORNERS ARE
INSTALLED CONTINUOUS AND
UNBROKEN, AND ARE FIELD ADJUSTED
12-1/16" INSIDE
MITERED CORNER
FIELD CUT TO SUIT
STAGGERED LAMPS
3”
T8
6”
T5
NEO-RAY™
