Cooper Lighting PM132cb User manual

®
RSA Lighting 9660-9700 Topanga Canyon Blvd. Chatsworth, CA 91311
Toll Free: 800-356-3030 • 818-349-3030 • Fax: [phone]
©2004 RSA Lighting • All Rights Reserved • Specifications are subject to change without notice www.cooperlighting.comwww.rsalighting.com
PM92
#
,
#
,
"537!9/242!#+
352&!#%
,OCKING
!DJUSTABILITY
"USWAYONLY
,OCKING
!DJUSTABILITY
v v
v
v
v
v
 v h
"USWAY
 v v
 #CT.TL4RACK
 v v
OR#CT4RACK
PM632cb
60 Amp Busway
Catalog #
Type
Project
A machined aluminum track fixture for PAR20MH
lamps 20 or 39 watts. For use with RSA Profile Series
60 Amp Busway, 20 Amp 1 or 2 Circuit Track or 20
Amp 2 Circuit / 2 Neutral Track.
Integral electronic metal halide ballast in aluminum
housing. Ballast by Aromat®.
Front loading lamp with bayonet action lens /
accessory bezel. Optical accessories are captured
in the bezel with a threaded retainer ring preventing
accessory spill-out during relamping. Can accom-
modate up to three optical accessories.
Auto extending / retracting lamp holder. Lamps
extend for easy access and automatically retract
to optimum position. This is extremely helpful when
dealing with varying accessory combinations or dif-
fering manufacturer lamp dimensions.
Optical accessories include color filters, UV fil-
ters, screens, spread lenses, louvers, hex louvers,
snoots. Consult RSA for details.
Locking on both the horizontal and vertical
planes. 370º vertical rotation possible due to over-
center locking mechanism (60 amp busway only).
270º horizontal locking adjustment.
UL and CUL listed
Available in White, Black, Natural Aluminum or
custom finishes.
PAR20 Metal Halide
Closed Back Machined Fixture w/ Integral Ballast
PM632cb | PM432cb | PM232cb | PM132cb
Ordering Example: PM632cb-39-AL-120
PM432cb
20 Amp Track
2 Cct. 2 Ntl.
PM132cb
PM232cb
20 Amp Track
1 or 2 Cct.
Closed Back Machined Fixture w/ Integral Ballast Lamp Wattage Finish Voltage
❑ PM632cb - PAR20MH for 60 Amp Busway
❑ PM132cb - PAR20MH for 20 Amp 1 Circuit Track
❑ PM232cb - PAR20MH for 20 Amp 2 Circuit Track
❑ PM432cb - PAR20MH for 20 Amp 2 Circuit / 2 Neutral Track
❑ 20 20 Watt PAR20MH ❑ WH White ❑ 120 120 Volts primary
❑ 39 39 Watt PAR20MH ❑ BK Black ❑ 277 277 Volts primary
❑ AL Natural Alum.
❑ PT Custom Finish

PM93
®
0° Aiming Angle 30° Aiming Angle 30° Aiming Angle 45° Aiming Angle
Horizontal Footcandles Horizontal Footcandles Vertical Footcandles Vertical Footcandles
D FC L W D FC L W CB D FC L W CB D FC L W CB
FC FC
FC
CB
CB
L L
L
30° 30°
D
W
D
W
W
Lamp Performance Data
D = Distance to the horizontal or vertical surface.
FC = Initial footcandles at the center of the beam.
L = Length of the beam where candlepower is reduced to 50%
of center beam candlepower.
W = Width of the beam where candlepower is reduced to 50%
of center beam candlepower.
CB = Distance to the center of the beam.
Lamp data given is typical and is based on bare lamp performance.
Contact lamp manufacturers for availability and specific performance.
Distance, length and width given in decimal feet.
PAR20MH Ceramic Metal Halide
CDM35 /PAR20 /M /SP PHI 9 284 1.7 1.7 9 184 2.2 2.7 5.2 3 319 2.2 2.2 5.2 6 226 2.3 1.6 6.0
Beam Spread = 10° x 10° 13 136 2.4 2.4 13 88 3.2 3.9 7.5 4 180 3.0 3.0 6.9 8 127 3.0 2.1 8.0
CBCP = 23000 16 90 3.0 3.0 16 58 4.0 4.8 9.2 5 115 3.7 3.7 8.7 10 81 3.8 2.7 10.0
Rated Life = 9,000 Hrs. 20 57 3.7 3.7 20 37 5.0 6.0 11.5 6 80 4.5 4.5 10.4 12 56 4.5 3.2 12.0
CDM35 /PAR20 /M /FL PHI 4 313 2.2 2.2 4 228 2.5 2.3 2.3 2 285 2.0 1.6 3.5 3 269 2.2 1.9 3.0
Beam Spread = 30° x 30° 6 139 3.3 3.3 6 101 3.8 3.5 3.5 3 127 2.9 2.3 5.2 4 151 3.0 2.6 4.0
CBCP = 5000 8 78 4.3 4.3 8 57 5.1 4.6 4.6 4 71 3.9 3.1 6.9 5 97 3.7 3.2 5.0
Rated Life = 9,000 Hrs. 10 50 5.4 5.4 10 37 6.4 5.8 5.8 5 46 4.9 3.9 8.7 6 67 4.4 3.9 6.0
Optivex UV
Filter
Red Color
Filter
Blue Color
Filter
Amber Color
Filter
Cosmetic Peach
2800K Filter
Milk White
Lens
Diffusion Spread
Lens
Linear Spread
Lens
LN45 LN46 LN47 LN49 CP20 LN44 LN41 LN43
Prismatic Spread
Lens
20% Reduction
Screen
30% Reduction
Screen
40% Reduction
Screen
Hex Cell
Louver
Cross
Baffle
Snoot
LN42 RS2020 RS3020 RS4020 LN40 CB20 SN20
