Cooper Lighting TMU/TLU User manual

Tools Required Socket, 5/16" Socket, 3/4" Deep Well Socket, Electrical
wiring tools.
NOTE: These luminaires are designed for outdoor lighting
services, and should not be used in area of limited ventilation
or in high ambient temperature enclosures. Construction is
suitable for down lighting only. Best results will be obtained
if installed and maintained according to the following
recommendations.
1. Remove housing assembly and arm components from carton. Remove
power tray if fixture is not hard mount version.
2. With the fixture on its back, open and remove door by pressing thumb
latches outward at the same time, open the door and lift it from the
hinges. FIG. 1
3. Run the threaded rods (2) through the center of the semi-enclosed hole
details in the arm extrusion. To help orient the arm correctly with the
housing, please note that one end of the extruded arm has an angled cut
and the other has a perpendicular cut with two drain notches located on
the bottom. If assembling to a round pole, use the round pole adapter
with the drain channels located at the extruded arm end with the drain
slots. Mate the angled side of the extruded arm to the housing so that
the bottom surface of the extrusion is parallel to the bottom of the
fixture, and the drain notches are facing down and located away from
the housing. FIG. 2 Slide the threaded rods into the interior of the
housing. Attach flat washer, lock washer, and nut into place in the order
shown in FIG. 2. Torque hex nuts to 450 lb/in.
4. If necessary, remove the cap on the pole. Position the housing and arm
to assemble it to the pole. Lower the nut plate into the interior of the
pole as shown. Slide the threaded rods through the pole and thread into
the nut plate until the rod protrudes though the nut plate slightly. Tighten
both nuts located inside of the housing to 30 lb/ft of torque.
These instructions do not claim to cover all details or variations in the equipment, procedure, or process described, nor to provide directions for meeting every possible contingency
during installation, operation or maintenance. When additional information is desired to satisfy a problem not covered sufficiently for user’s purpose, please contact your nearest
representative.
Talon Medium
Sheet 1 of 3
7/23/08 IMI-687SW
INSTALLATION INSTRUCTIONS
IMPORTANT: READ CAREFULLY BEFORE INSTALLING FIXTURE.
WARNING: Risk of Fire/Electric Shock. If not qualified, consult an electrician.
WARNING: Risk of Electric Shock. Disconnect power at fuse or circuit breaker before installing or servicing.
WARNING: Risk of Burn. Disconnect power and allow fixture to cool before changing bulb or handling fixture.
WARNING: Risk of Personal Injury. Fixture may become damaged and/or unstable if not installed properly. Tighten all fixture components
to their recommended torque values.
WARNING: Risk of Fire/Electrical Shock. Upside down installation can result in overheating or accumulation of water in fixture.
Install right side up.
NOTE: Specifications and dimensions subject to change without notice.
Visit our web site at www.cooperlighting.com
Customer First Center 1121 Highway 74 South Peachtree City, GA 30269 770.486.4800 FAX [phone] ADW081604
FIG. 1
Latches
FIG. 2
Hardware: Washer,
Lock Washer, and
Hex Nut
Arm
Nut Plate
Fits Inside
of Pole
Round Pole
Adapter
(Optional)
Mounting Rod (2)

5. With the pole and fixture(s) raised into position, place the power tray
onto the hinges of the housing electrical compartment and let
it hang free. Locate the power connector plug and rotate the power tray
until the connection can be made with the mating connector in the
housing. Raise the powertray until the two wing screws engage and
tighten until fully snug.
6. Replace door on the hinges at the rear of the housing, rotate into
position, and assure that both latches are fastened securely.
FIXTURE MAINTENANCE
RELAMPING
1. Disengage both latches and open the door. Do not let the door swing
freely on the hinges.
2. Replace the lamp with the appropriate type and wattage and reassemble
the refractor to the upper housing. FIG. 3
3. Close the door and assure that the latches are securely fastened.
PLUG-IN STARTER REPLACEMENT
This procedure applies to fixtures with a plug-in type starter. Disengage
both latches and open the door. Do not let the door swing freely on the
hinges. Loosen the power tray thumb screws, unplug the power connector
as you lower the powertray, and continue lowering until the powertray
hangs free on the hinges. The starter is located in the position shown.
Remove and replace. Reverse the directions to secure the powertray and
the door after starter replacement.
1. Remove the plug-in starter from the receptacle and replace.
FIG. 4 and FIG. 5
2. Assure that the wing screws on the powertray and both latches on the
door are fastened securely.
These instructions do not claim to cover all details or variations in the equipment, procedure, or process described, nor to provide directions for meeting every possible contingency
during installation, operation or maintenance. When additional information is desired to satisfy a problem not covered sufficiently for user’s purpose, please contact your nearest
representative.
Talon Medium
Sheet 2 of 3
7/23/08 IMI-687SW
INSTALLATION INSTRUCTIONS
IMPORTANT: READ CAREFULLY BEFORE INSTALLING FIXTURE.
WARNING: Risk of Fire/Electric Shock. If not qualified, consult an electrician.
WARNING: Risk of Electric Shock. Disconnect power at fuse or circuit breaker before installing or servicing.
WARNING: Risk of Burn. Disconnect power and allow fixture to cool before changing bulb or handling fixture.
WARNING: Risk of Personal Injury. Fixture may become damaged and/or unstable if not installed properly. Tighten all fixture components
to their recommended torque values.
WARNING: Risk of Fire/Electrical Shock. Upside down installation can result in overheating or accumulation of water in fixture.
Install right side up.
NOTE: Specifications and dimensions subject to change without notice.
Visit our web site at www.cooperlighting.com
Customer First Center 1121 Highway 74 South Peachtree City, GA 30269 770.486.4800 FAX [phone] ADW081604
FIG. 3
Thumbscrews (2)
Powertray
FIG. 4
FIG. 5
Plug-In Starter

NEMA PHOTOCONTROL REPLACEMENT
1. The photocontrol is mounted on top the housing. FIG. 6
2. Remove the photocontrol by twisting counterclockwise and
replace.
OPTIC DISTRIBUTION AND ORIENTATION
The Talon Medium fixture is offered with some optics that
have directional distributions. For aiming purposes, the Talon
Medium was designed with the flexibility to allow each of its optics
to be rotated to any of four positions, located at 90° increments.
To change the optic orientation, open the door and remove the
lamp. Use a screwdriver to remove the four screws as shown in
FIG. 7. Reposition the optic, insert the screws and tighten securely.
These instructions do not claim to cover all details or variations in
the equipment, procedure, or process described, nor to
provide directions for meeting every possible contingency
during installation, operation or maintenance. When additional
information is desired to satisfy a problem not covered
sufficiently for user's purpose, please contact your nearest
representative.
These instructions do not claim to cover all details or variations in the equipment, procedure, or process described, nor to provide directions for meeting every possible contingency
during installation, operation or maintenance. When additional information is desired to satisfy a problem not covered sufficiently for user’s purpose, please contact your nearest
representative.
Talon Medium
Sheet 3 of 3
7/23/08 IMI-687SW
INSTALLATION INSTRUCTIONS
IMPORTANT: READ CAREFULLY BEFORE INSTALLING FIXTURE.
WARNING: Risk of Fire/Electric Shock. If not qualified, consult an electrician.
WARNING: Risk of Electric Shock. Disconnect power at fuse or circuit breaker before installing or servicing.
WARNING: Risk of Burn. Disconnect power and allow fixture to cool before changing bulb or handling fixture.
WARNING: Risk of Personal Injury. Fixture may become damaged and/or unstable if not installed properly. Tighten all fixture components
to their recommended torque values.
WARNING: Risk of Fire/Electrical Shock. Upside down installation can result in overheating or accumulation of water in fixture.
Install right side up.
NOTE: Specifications and dimensions subject to change without notice.
Visit our web site at www.cooperlighting.com
Customer First Center 1121 Highway 74 South Peachtree City, GA 30269 770.486.4800 FAX [phone] ADW081604
FIG. 7
Remove Optic, Rotate
To Desired Position
and Fasten Into Place
FIG. 6
NEMATwistlock
Photocontrol
