Cooper Lighting Shaper 210 SERIES User manual

210 SERIES
Surface Luminaire
Luminous Bowl
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
shaperlighting.com
210 Luminous Bowl features trim options and is available in two
sizes.
SPECIFICATION FEATURES
Material
Cold rolled steel mounting pan
with a matte white acrylic bowl.
Optional CamingTrim.
Finish
Standard: Matte White (MW).
Premium: Satin Chrome (SC),
Polished Chrome (PC), Satin
Brass (SB), Satin Copper (SCP),
Polished Brass (PB), Polished
Copper (PCP), Oxidized Brass
(OBRS), Lacquered Satin Chrome
(SCL), Satin Nickel (SN), Polished
Nickel (PN), Lacquered Satin
Nickel (SNL), Lacquered Satin
Aluminum (SAL), Natural
Aluminum (NA) [Sustainable
Design] or Custom Color (CC).
Matte white mounting pan.
Optics
Refer to
www.shaperlighting.com for
complete photometrics.
Ballast
Integral electronic HPF, multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
Lamp/Socket
14":Two (2) 13W (2GX7) 4-pin
low wattage CFL lamps or two (2)
60W A-19 lamps.
18":Two (2) 26W or 32W (GX24q-
3) 4-pin triple CFL lamps or two
(2) 75W A-19 lamps. CFL socket
injection molded plastic. INC
socket fired ceramic rated for
660W-250V. Lamps furnished by
others.
Installation
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring.
Options
Hand Painted Faux Alabaster
Bowl (FB), CamingTrim (CT), 3"
Dia. Stepped Finial with Caming
Trim (SFCT),Traditional Finial
(TF), 3" Dia. Stepped Finial with
Trim Ring (SFTR),Trim Ring (TR),
Decorative Finial with Double
BarTrim (DF2B), CFL Dimming
Ballast - Contact the factory for
ballast options (DM), Modified
Integral Emergency Battery -
Refer to spec sheet for drawing
(MEM), Damp Location (DL): All
Painted Finishes, Lacquered
Satin Chrome (SCL) and
Lacquered Satin Nickel (SNL)
only. MRI applications (INC only).
Energy Star Rating - consult
factory.
Labels
U.L. and C.U.L. approved for
indoor and damp location. See
options for damp location
finishing requirements.
Modifications
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard surface
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
DESCRIPTION
Catalog # Type
Date
Project
Comments
Prepared by
ADS042704
2008-09-03 11:27:33
MAGNETIC
RESONANCE
IMAGING (MRI)
SUSTAINABLE
DESIGN
Refer to the Icon Legend
Link on shaperlighting.com.
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
Shaper has a long-standing history
of offering environmentally-friendly
fixtures. The copper and bronze alloys
used in our exterior luminaires feature
up to 98% recycled content, contribute
less undesirable air emissions compared
to painted aluminum and are easy to
recycle.
ENERGY
STAR
Shaper now offers a wide variety of
fixtures that can be provided with an
Energy Star Rating.
Sample Number: 210-18-INC/2/75-120V-PCP
Voltage
120V
277V 3
347V 3
Finish
Standard
MW Matte White=
Premium
CC Custom Color=
OBRS Oxidized Brass=
PB Polished Brass=
PC Polished Chrome=
PCP Polished Copper=
SB Satin Brass=
SC Satin Chrome=
SCP Satin Copper=
SN Satin Nickel=
SNL Lacquered Satin Nickel=
SCL Lacquered Satin Chrome=
SAL Lacquered
Satin Aluminum
=
NA Natural Aluminum=
PN Polished Nickel=
Options
CT Caming Trim=
DL Damp Location=
DM CFL Dimming Ballast 4
5
=
MEM Modified Integral
Emergency Battery
=
DF2B Decorative Finial
w/ Double Bar Trim
=
SFCT 3" Diameter Stepped
Finial w/ Caming Trim
=
SFTR 3" Diameter Stepped
Finial w/ Trim Ring
=
TF Traditional Finial=
FB Hand Painted Faux
Alabaster Bowl
=
TR Trim Ring=
LNB Hand Painted
Faux Linen Bowl
=
Series
210 Bowl
Surface
Luminaire
=
Size
14"
18"
Lamp
CFL/2
(26/32W-Triple)
1
CFL/2/13 2
INC/2/60 2
INC/2/75 1
1Available in 18".
Notes:
2Available in 14".
3Available with CFL only.
4C
5Interior applications only.
onsult the factory for available options.
ORDERING INFORMATION

Specifications and dimensions subject to change without notice.
Shaper Lighting •1141 Marina Way South •Richmond, CA 94804 •ph 510.234.2370 •fax [phone] ADS042704
2008-09-03 11:27:33
210 SERIES SURFACE LUMINAIRE
COMPANION PRODUCTS
TRADITIONAL FINIAL (TF) 3" DIA. STEPPED FINIAL WITH TRIM RING (SFTR)
3" DIA. STEPPED FINIAL WITH CAMING TRIM (SFCT)
18" Ø
210 18" Ø STANDARD
MODIFIED INTEGRAL EMERGENCY BATTERY (MEM)
7-1/2"
5-1/2"
10" Ø
DECORATIVE FINIAL WITH DOUBLE BAR TRIM (DF2B)
FINIAL NUT WITH TRIM RING (TR)
210 TRIM OPTIONS
210 14" Ø STANDARD
14-1/2" Ø
4 1/2"
6-1/2"
8" Ø
11" Ø
7-3/4"
2-1/4"
5-1/2"
DIMENSIONS
499-RP404 499 642-A
