PORTFOLIO™
Height varies with socket position; see reflector line drawing below for overall
fixture height. Add 1/2" height for Chicago Plenum option.
HOUSING
HD4MRI=Non-Ferrous Incandescent
HD4MRICP=Non-Ferrous Incandescent, Chicago Plenum
ACCESSORIES
TRR4=Rimless Trim Ring, White*
*Not compatible with Self Flange
TRIM
4501=Self Flanged
FINISH
LI=Low Iridescent Clear
H=Haze
WMH=Warm Haze
G=Gold
WH=Wheat
B=Black
W=Gloss White
GP=Graphite
GPH=Graphite Haze
K=Cognac
KH=Cognac Haze
OPTIONS
WF=White
Painted
Flange (Self
Flanged only)
DR=Derated
Wattage
Label
OPTIONS
WF=White
Painted
Flange (Self
Flanged only)
DR=Derated
Wattage
Label
OPTIONS
WF=White
Painted
Flange (Self
Flanged only)
DR=Derated
Wattage
Label
OPTIONS
WF=White
Painted
Flange (Self
Flanged only)
DR=Derated
Wattage
Label
Open Downlight
A19 100W Max (Medium Beam)
HOUSING
TRIM
Non-ferrous downlight for MRI suites. Medium and
wide beam distribution for general and task lighting
from a variety of vertically mounted incandescent and
halogen lamps. Adjustable socket position maintains
focus for varied reflector types. Rated for DC operation.
4" Non-Ferrous Downlight
A19
PAR16/20
R20
4"
Dimensions Length Width Height Cutout
Standard Housing 11-1/8" 13-5/8" H" 5-1/8"
Chicago Plenum 11-1/8" 13-5/8" H"
4-7/16"
5-3/4"
TRIM
4551=Self Flanged
4550=Molded Trim Ring, White
FINISH
LI=Low Iridescent Clear
H=Haze
WMH=Warm Haze
G=Gold
WH=Wheat
B=Black
W=Gloss White
GP=Graphite
GPH=Graphite Haze
K=Cognac
KH=Cognac Haze
Open Downlight
A19 100W Max (Wide Beam)
4-7/16"
5-3/4"
8"
8"
TRIM
4511=Single Wall Wash, Self Flanged
4510=Single Wall Wash, Molded Trim Ring, White
4521=Double Wall Wash, Self Flanged
4520=Double Wall Wash, Molded Trim Ring, White
4531=Corner Wall Wash, Self Flanged
4530=Corner Wall Wash, Molded Trim Ring, White
FINISH
LI=Low Iridescent Clear
H=Haze
WMH=Warm Haze
G=Gold
WH=Wheat
B=Black
W=Gloss White
GP=Graphite
GPH=Graphite Haze
K=Cognac
KH=Cognac Haze
Open Wall Wash
GRUVI
A19 100W Max
4-7/16"
5-3/4"
8"
TRIM
4201=Self Flanged
4200=Molded Trim Ring,
White
Open Downlight
PAR16/20 60W Max
R20 60W Max
4-7/16"
5-3/4"
8-1/4" GPH=Graphite Haze
K=Cognac
KH=Cognac Haze
BB=Black Baffle
(4200 only)
WB=White Baffle
(4200 only)
FINISH
LI=Low Iridescent Clear
H=Haze
WMH=Warm Haze
G=Gold
WH=Wheat
B=Black
W=Gloss White
GP=Graphite
Ordering Example
Housing, Trim, Accessories and Lamps ordered as separate line items.
Housing Trim Accessories
HD4MRI 4501LI TRR4
4" INCANDESCENT – MRI
HD4MRI
