0° Aiming Angle 30° Aiming Angle 30° Aiming Angle 45° Aiming Angle
Horizontal Footcandles Horizontal Footcandles Vertical Footcandles Vertical Footcandles
D FC L W D FC L W CB D FC L W CB D FC L W CB
FC FC
FC
CB
CB
L L
L
30° 30°
D
W
D
W
W
Lamp Performance Data
D = Distance to the horizontal or vertical surface.
FC = Initial footcandles at the center of the beam.
L = Length of the beam where candlepower is reduced to 50%
of center beam candlepower.
W = Width of the beam where candlepower is reduced to 50%
of center beam candlepower.
CB = Distance to the center of the beam.
Lamp data given is typical and is based on bare lamp performance.
Contact lamp manufacturers for availability and specific performance.
Distance, length and width given in decimal feet.
PAR38 Halogen E26 Medium Base
45 PAR /CAP /SPL /SP9 OSI 6 278 1.3 1.3 4 469 1.2 1.1 2.3 3 278 2.3 1.3 5.2 5 200 2.0 1.5 5.0
Beam Spread = 9° x 9° 8 156 1.7 1.7 6 208 1.7 1.5 3.5 4 156 3.0 1.7 6.9 6 139 2.3 1.7 6.0
CBCP = 10,000 10 100 2.0 2.0 8 117 2.1 1.8 4.6 5 100 3.6 2.0 8.7 7 102 2.6 2.0 7.0
Rated Life = 2,500 Hrs. 12 69 2.3 2.3 10 75 2.5 2.2 5.8 6 69 4.2 2.3 10.4 8 78 2.9 2.2 8.0
45 PAR /CAP /SPL /FL30 OSI 3 167 2.0 2.0 2 281 1.9 1.6 1.2 2 94 5.9 2.5 3.5 2 188 2.7 1.9 2.0
Beam Spread = 30° x 30° 4 94 2.5 2.5 3 125 2.6 2.3 1.7 3 42 8.6 3.6 5.2 3 83 3.9 2.7 3.0
CBCP = 1,500 5 60 3.1 3.1 4 70 3.3 2.9 2.3 4 23 11.3 4.7 6.9 4 47 5.0 3.4 4.0
Rated Life = 2,500 Hrs. 6 42 3.6 3.6 5 45 4.1 3.5 2.9 5 15 14.1 5.8 8.7 5 30 6.2 4.2 5.0
45 PAR /CAP /SPL /WFL50 OSI 2 175 2.3 2.3 2 131 3.1 2.5 1.2 1 175 11.1 2.3 1.7 2 88 5.2 3.0 2.
Beam Spread = 50° x 50° 3 78 3.2 3.2 3 58 4.4 3.6 1.7 2 44 21.9 4.1 3.5 3 39 7.5 4.4 3.0
CBCP = 700 4 44 4.1 4.1 4 33 5.8 4.7 2.3 3 19 32.6 6.0 5.2 4 22 9.9 5.7 4.0
Rated Life = 2,500 Hrs. 5 28 5.1 5.1 5 21 7.1 5.8 2.9 4 11 43.3 7.9 6.9 5 14 12.3 7.0 5.0
60 PAR /CAP /SPL /SP9 OSI 8 250 1.7 1.7 7 245 1.9 1.7 4.0 4 250 3.0 1.7 6.9 6 222 2.3 1.7 6.
Beam Spread = 9° x 9° 11 132 2.1 2.1 9 148 2.3 2.0 5.2 5 160 3.6 2.0 8.7 8 125 2.9 2.2 8.0
CBCP = 16,000 14 82 2.6 2.6 11 99 2.7 2.4 6.4 6 111 4.2 2.3 10.4 10 80 3.6 2.6 10.0
Rated Life = 3,000 Hrs. 17 55 3.1 3.1 13 71 3.1 2.8 7.5 7 82 4.9 2.6 12.1 12 56 4.2 3.1 12.0
60 PAR /CAP /SPL /NFL25 OSI 4 206 2.2 2.2 3 275 2.2 1.9 1.7 2 206 4.6 2.2 3.5 3 183 3.2 2.3 3.0
Beam Spread = 25° x 25° 5 132 2.6 2.6 4 155 2.8 2.4 2.3 3 92 6.6 3.1 5.2 4 103 4.1 2.9 4.0
CBCP = 3,300 6 92 3.1 3.1 5 99 3.4 3.0 2.9 4 52 8.7 3.9 6.9 5 66 5.1 3.5 5.0
Rated Life = 3,000 Hrs. 7 67 3.5 3.5 6 69 4.0 3.5 3.5 5 33 10.8 4.8 8.7 6 46 6.0 4.2 6.0
60 PAR /CAP /SPL /FL30 OSI 3 278 2.0 2.0 3 208 2.6 2.3 1.7 2 156 5.9 2.5 3.5 3 139 3.9 2.7 3.0
Beam Spread = 30° x 30° 4 156 2.5 2.5 4 117 3.3 2.9 2.3 3 69 8.6 3.6 5.2 4 78 5.0 3.4 4.0
CBCP = 2,500 5 100 3.1 3.1 5 75 4.1 3.5 2.9 4 39 11.3 4.7 6.9 5 50 6.2 4.2 5.0
Rated Life = 3,000 Hrs. 6 69 3.6 3.6 6 52 4.8 4.1 3.5 5 25 14.1 5.8 8.7 6 35 7.3 4.9 6.0
90 PAR /CAP /SPL /SP9 OSI 9 274 1.8 1.8 8 260 2.1 1.8 4.6 5 222 3.6 2.0 8.7 7 227 2.6 2.0 7.0
Beam Spread = 9° x 9° 12 154 2.3 2.3 11 138 2.7 2.4 6.4 6 154 4.2 2.3 10.4 9 137 3.2 2.4 9.0
CBCP = 22,000 15 99 2.8 2.8 14 85 3.3 2.9 8.1 7 113 4.9 2.6 12.1 11 92 3.9 2.8 11.0
Rated Life = 2,500 Hrs. 18 69 3.2 3.2 17 58 4.0 3.5 9.8 8 87 5.5 2.9 13.9 13 66 4.5 3.3 13.0
90 PAR /CAP /SPL /FL30 OSI 4 219 2.5 2.5 3 292 2.6 2.3 1.7 2 219 5.9 2.5 3.5 3 194 3.9 2.7 3.0
Beam Spread = 30° x 30° 6 97 3.6 3.6 4 164 3.3 2.9 2.3 3 97 8.6 3.6 5.2 4 109 5.0 3.4 4.0
CBCP = 3,500 8 55 4.7 4.7 5 105 4.1 3.5 2.9 4 55 11.3 4.7 6.9 5 70 6.2 4.2 5.
Rated Life = 2,500 Hrs. 10 35 5.8 5.8 6 73 4.8 4.1 3.5 5 35 14.1 5.8 8.7 6 49 7.3 4.9 6.
120 PAR /CAP /SPL /FL30 OSI 4 288 2.5 2.5 4 216 3.3 2.9 2.3 2 288 5.9 2.5 3.5 3 256 3.9 2.7 3.0
Beam Spread = 30° x 30° 5 184 3.1 3.1 5 138 4.1 3.5 2.9 3 128 8.6 3.6 5.2 4 144 5.0 3.4 4.0
CBCP = 4,600 6 128 3.6 3.6 6 96 4.8 4.1 3.5 4 72 11.3 4.7 6.9 5 92 6.2 4.2 5.
Rated Life = 3,000 Hrs. 7 94 4.1 4.1 7 70 5.5 4.7 4.0 5 46 14.1 5.8 8.7 6 64 7.3 4.9 6.0
120 PAR /CAP /SPL /WFL55 OSI 3 222 3.5 3.5 3 167 5.0 4.0 1.7 2 125 44.9 4.6 3.5 2 250 6.1 3.3 2.0
Beam Spread = 55° x 55° 4 125 4.6 4.6 4 94 6.5 5.2 2.3 3 56 67.2 6.6 5.2 3 111 9.0 4.8 3.0
CBCP = 2,000 5 80 5.6 5.6 5 60 8.0 6.4 2.9 4 31 89.5 8.7 6.9 4 63 11.8 6.3 4.0
Rated Life = 3,000 Hrs. 6 56 6.6 6.6 6 42 9.6 7.6 3.5 5 20 112 10.8 8.7 5 40 14.7 7.8 5.0
250 PAR /CAP /SPL /SP10 OSI 13 275 2.7 2.7 11 288 3.0 2.6 6.4 7 237 5.4 2.8 12.1 9 287 3.6 2.6 9.0
Beam Spread = 10° x 10° 18 144 3.5 3.5 15 155 3.9 3.4 8.7 9 144 6.8 3.5 15.6 13 138 5.0 3.6 13.0
CBCP = 46,500 23 88 4.4 4.4 19 97 4.8 4.2 11.0 11 96 8.3 4.2 19.1 17 80 6.4 4.6 17.0
Rated Life = 4,500 Hrs. 28 59 5.3 5.3 23 66 5.8 5.0 13.3 13 69 9.7 4.9 22.5 21 53 7.8 5.6 21.0
250 PAR /CAP /SPL /FL30 OSI 6 250 3.6 3.6 5 270 4.1 3.5 2.9 3 250 8.6 3.6 5.2 4 281 5.0 3.4 4.0
Beam Spread = 30° x 30° 8 141 4.7 4.7 7 138 5.5 4.7 4.0 4 141 11.3 4.7 6.9 5 180 6.2 4.2 5.0
CBCP = 9,000 10 90 5.8 5.8 9 83 7.0 6.0 5.2 5 90 14.1 5.8 8.7 6 125 7.3 4.9 6.0
Rated Life = 4,500 Hrs. 12 63 6.8 6.8 11 56 8.4 7.2 6.4 6 63 16.8 6.8 10.4 7 92 8.5 5.7 7.0
