The Streetworks Talon is the most versatile, functionally designed,
universally adaptable outdoor luminaire available. The Talon brings
outstanding performance to walkways, parking lots, roadways, loading
docks, building areas, and any security lighting application. U.L. listed and
CSA certified for wet locations. IP65 Rated.
Construction
One-piece heavy-wall, die-cast
aluminum construction with
integral reveal channels along top
surface of housing. Internal cast-in
wall separates optical and
electrical chambers allowing
components to operate cooler.
One-piece die-cast aluminum door
frame with integral cast-in gasket
channel seals optical chamber to
an IP65 rating. Stainless steel
latches and hinges allow for
toolless opening and removal of
door frame.
Reflector
Choice of 14 high efficiency optical
systems utilizing horizontal and
vertical lamp orientations. Optional
high efficiency segmented optical
systems constructed of premium
95% reflective anodized aluminum
sheet. Optical segments are rigidly
mounted inside a thick gauge
aluminum housing for superior
protection. All segment faces are
clean of rivet heads, tabs or other
means of attachment which may
cause streaking in the light
distribution.
Standard with mogul-base socket.
All optical modules feature quick
disconnect wiring plugs and are
field rotatable in 90° increments.
Electrical
Electrical componentry mounted
on a swing-down galvanized steel
power tray with integral handle.
Electrical disconnects allow tray to
be completely removed from the
housing providing ample hand and
tool room for attachment of fixture
during installation.
Mounting
Extruded 10 1/2" aluminum arm
includes internal bolt guides
allowing for easy positioning of
fixture during installation to pole
or wall surface. Standard single
carton packaging of housing,
square pole arm and round pole
adapter for contractor friendly
arrival of product on site.
Finish
Housing and arm finished in a 5
stage premium TGIC polyester
powder coat paint, 2.5 mil nominal
thickness for superior protection
against fade and wear. Standard
colors include black, bronze, grey,
white, dark platinum, and graphite
metallic.
TLU
TALON LARGE
250-1000W
High Pressure Sodium
Pulse Start Metal Halide
Super Metal Halide
Metal Halide
AREA LUMINAIRE
E N E R G Y D ATA
CWI Ballast Input Watts
250W HPS HPF (300 Watts)
CWA Ballast Input Watts
250W MH HPF (295 Watts)
320W MP HPF (365 Watts)
350W MP HPF (400 Watts)
400W MP HPF (448 Watts)
400W MH HPF (455 Watts)
400W HPS HPF (465 Watts)
750W MP HPF (820 Watts)
1000W HPS HPF (1100 Watts)
1000W MH HPF (1080 Watts)
Effective Projected Area: (Sq. Ft.)
Without Arm: 1.83
10 1/2" Arm: 0.68
S H I P P I N G D ATA
E P A
Approximate Net Weight:
400W 91 lbs. (41.36 kgs.)
1000W 98 lbs. (44.54 kgs.)
875W MP HPF (940 Watts)
S
Y
S
T
E
M
S
C
E
R
T
I
F
I
E
D
LAMP TYPE WATTAGE
Metal Halide 250, 400, 1000W
Pulse Start Metal Halide 250, 320, 350, 400, 450, 750, 875, 1000W
Super Metal Halide 250, 400, 750, 1000W
High Pressure Sodium 250, 400, 1000W
14 1/8"
[359mm]
3 1/8" 10 1/2"
[267mm]
[79mm]
21 5/8" [549mm]
31" [787mm]
T Y P E “ M ” WA L L M O U N T
3/4" [20mm]
dia. hole
(2) 5/8" [16mm]
dia. holes
4 7/8" [124mm]
2 7/16" [124mm]
2 5/16"
[59mm]
12"
[305mm]
4 7/8"
[124mm]
9/16" [14mm]
Dia. Hole (4)
6 1/2"
[165mm]
8"
[203mm]
10 1/2"
[267mm]
STREETWORKS™

Streetworks • Customer First Center • 1121 Highway 74 South • Peachtree City, GA 30269 • TEL [phone] • FAX [phone]/2008 6:08:05 PM
Specifications and Dimensions subject to change without notice.
TLU_ADH081550
ORDERING INFORMATION
TALON LARGE
TLU
SAMPLE NUMBER: TL91SWW3VFG
TLU
Product Family 1
TLU=Talon Site
Large
Lamp Wattage
25=250W
32=320W 2
35=350W 2
40=400W
75=750W
87=875W 2
91=1000W 3
Distribution
Horizontal Lamp
2F=Type II Formed
2S=Type II Segmented 4
3F=Type III Formed
3S=Type III Segmented 4
4F=Type IV Formed
4S=Type IV Segmented 4
5F=Type V Formed
5S=Type V Segmented 4
SL=Spill Light Eliminator 3
Vertical Lamp
3V=Type III Vertical
4V=Type IV Vertical
AR=Area Round
AS=Area Square
AF=Automotive Front Row
Lens Type
F=Flat Glass
S=Sag Glass
Options (add as suffix/must be
ordered in alphanumeric order)
1=Single Fuse
[120, 277 or 347V] 5
2=Double Fuse
[208, 240 or 480V] 5
3=Three Place Terminal Block
4=NEMA Twistlock
Photocontrol Receptacle
B=Internal House-side Shield 6
DM=Direct Mount for Pole
E=Quartz Restrike w/Delay
[Also Strikes at Cold Start] 7
H=Plug-in Starter Receptacle 8
HL=Hi/Low Dimming 9
L=Lamp Included
Q=Quartz Restrike
[Hot Restrike Only] 7
U=U.L. Listed
WM=Wall Bracket with
10 1/2" Arm
Accessories
(order separately/replace XX with color designation)
OA/RA1016=NEMA Photocontrol (105-285V)
OA/RA1027=NEMA Photocontrol (480V)
OA/RA1201=NEMA Photocontrol (347V)
OA/RA1013=Shorting Cap
MA1010-XX=Single Tenon Adapter for 3 1/2" O.D. Tenon
MA1011-XX=2 @ 180° Tenon Adapter for 3 1/2" O.D. Tenon
MA1012-XX=3 @ 120° Tenon Adapter for 3 1/2" O.D. Tenon
MA1013-XX=4 @ 90° Tenon Adapter for 3 1/2" O.D. Tenon
MA1014-XX=2 @ 90° Tenon Adapter for 3 1/2" O.D. Tenon
MA1015-XX=2 @ 120° Tenon Adapter for 3 1/2" O.D. Tenon
MA1016-XX=3 @ 90° Tenon Adapter for 3 1/2" O.D. Tenon
MA1017-XX=Single Tenon Adapter for 2 3/8" O.D. Tenon
MA1018-XX=2 @ 180° Tenon Adapter for 2 3/8" O.D. Tenon
MA1019-XX=3 @ 120° Tenon Adapter for 2 3/8" O.D. Tenon
MA1045-XX=4 @ 90° Tenon Adapter for 2 3/8" O.D. Tenon
MA1048-XX=2 @ 90° Tenon Adapter for 2 3/8" O.D. Tenon
MA1049-XX=3 @ 90° Tenon Adapter for 2 3/8" O.D. Tenon
MA1213-XX=External House-side Shield Kit [EPA=0.38] 6
NOTES: 1 10 1/2" arm and round pole adapter included with fixture. 2320/350/875W Pulse Start Metal Halide lamp only. 3Requires reduced envelope lamp. 4Maximum wattage on segmented optical distributions is 400W.
400W Metal Halide lamp must use reduced envelope ED-28 lamp. 5Must Specify Voltage. 6House-side shield not available on 5S, 5F, AS, AR and SL optics. 7Quartz options not available with SL and AF optics.
8Not available in 1000W. 9Requires vertical lamp orientation. Provides 24V low voltage leads used in dimming control. 10 Specifications and dimensions subject to change without notice.
Lamp Type
S=High Pressure Sodium
R=Super Metal Halide
M=Metal Halide
P=Pulse Start Metal Halide
Ballast Type
C=CWI
H=Reac./HPF
K=10KV CWA
M=Mag. Reg.
N=Hi. Reac./NPF
P=Hi. Reac./HPF
R=Reac./NPF
W=CWA
Colors (add as suffix/
must specify)
WH=White
BK=Black
AP=Grey
BZ=Bronze
DP=Dark Platinum
GM=Graphite Metallic
Voltage
2=120V
0=208V
4=240V
7=277V
8=480V
9=347V
N=Multi-Tap wired 277V
W=Multi-Tap wired 120V
V=Multi-Tap wired 240V

Streetworks • Customer First Center • 1121 Highway 74 South • Peachtree City, GA 30269 • TEL [phone] • FAX [phone]/2008 6:08:05 PM
Specifications and Dimensions subject to change without notice.
TLU_ADH081550
PHOTOMETRICS [Complete IES files available at www.cooperlighting.com]
MOUNTING CONFIGURATIONS
Footcandle Table
Select mounting height and read across for
footcandle values of each isofootcandle line.
Distance in units of mounting height.
Mounting Footcandle Values for
Height Isofootcandle Lines
A B C D E
400W [3F]/1000W [AS/SL]
25' 2.88 1.44 0.72 0.29 0.14
30' 2.00 1.00 0.50 0.20 0.10
35' 1.46 0.73 0.37 0.15 0.07
400W [AR]
25' 1.44 0.72 0.29 0.14 --
30' 1.00 0.50 0.20 0.10 --
35' 0.73 0.37 0.15 0.07 --
A B C D E
TLU40MXX3FF
400-Watt MH
36,000-Lumen Clear Lamp
Type III Formed
Flat Glass
A B C D
TLU40MXXARS
400-Watt MH
36,000-Lumen Clear Lamp
Area Round
Sag Glass
A B C D E
TLU40MXXASF
1000-Watt MH
110,000-Lumen Clear Lamp
Area Square
Flat Glass
A B C D E
TLU40MXXSLF
1000-Watt MH
110,000-Lumen Clear Lamp
Spill Light Eliminator
Flat Glass
Footcandle Table
Select mounting height and read across for
footcandle values of each isofootcandle line.
Distance in units of mounting height.
Mounting Footcandle Values for
Height Isofootcandle Lines
A B C D E
1000W [3V/4V-HS/3V-EHS]
25' 7.20 2.88 1.44 0.72 0.29
30' 5.00 2.00 1.00 0.50 0.20
35' 3.65 1.46 0.73 0.37 0.15
1000W [AF]
25' 30.00 10.00 3.00 1.00 0.20
27' 25.50 8.50 2.55 0.85 0.17
30' 20.70 6.90 2.07 0.69 0.14
A B C D E
TLU91MXX3VF
1000-Watt MH
110,000-Lumen Clear Lamp
Type III Vertical
Flat Glass
A B C D E
A B C DE
A B C D E
TLU91MXX4VFB
1000-Watt MH
110,000-Lumen Clear Lamp
Type IV Automotive Perimeter
Flat Glass w/House-side Shield
TLU91MXX3VFEHS
1000-Watt MH
110,000-Lumen Clear Lamp
Type III Vertical
Flat Glass—External
House-side Shield
TLU91MXXAFF
1000-Watt MH
110,000-Lumen Clear Lamp
Automotive Front Row
Flat Glass
Wall Mount Arm Mount Single
E.P.A.
TLU 2.51
Arm Mount 2 @ 180°
E.P.A.
TLU 5.02
Arm Mount 2 @ 90°
E.P.A.
TLU 5.02
Arm Mount 3 @ 120°
E.P.A.
TLU 6.85
Arm Mount 3 @ 90°
E.P.A.
TLU 6.85
Arm Mount 4 @ 90°
E.P.A.
TLU 7.77
