Cooper Lighting Area Luminaire RCL70SP23D4 User manual

NOTE: 1 Hard mount ballast only. 2150W HPS units are for S55 lamp. 3Refer to technical section for lamp/ballast/voltage compatibility. 4ED28 Lamp.
HOUSING
Die-cast aluminum housing and
door. ANSI wattage/source label.
LENS
Tempered glass lens.
REFLECTOR
Hydroformed anodized aluminum
reflector.
SOCKET
Mogul-base porcelain lamp socket.
GASKET
The optical chamber is sealed with
a die-cut, dacron polyester gasket.
BALLAST
Removable swing-down ballast
assembly available on arm mount
RCL only. Ballast standard hard
mounted in RCS slipfitter. Optional
hard mount ballast. (RCL only).
DOOR
Die-cast aluminum with
spring-loaded latches for toolless
entry.
SLIPFITTER (RCS)
Optional internal slipfitter fits
1 1/4"-2 3/8" O.D. pipe.
FINISH
Standard polyester powder coat
finish in bronze. For more color
options see optional colors or
consult your Streetworks
represenatitive for more
information.
ORDERING INFORMATION
SAMPLE NUMBER: RCL70SP23D4
OPTIONS +
ACCESSORIES
(See Below)
ARM-MOUNTED AREA/SITE LUMINAIRE
OPTIONS (add as suffix)
1=Single Fused, Internally Mounted (120 or 277V)
2=Double Fused, Internally Mounted (208, 240, or 480V)
4=Photocontrol Receptacle
WH=White
BK=Black
AP=Grey
V=External, Auxiliary Vandal Shield, 1/8" Thick Polycarbonate
B=House Side Cutoff
H=Plug-in Starter Receptacle
P=Prismatic Drop Lens
R=Hard Mount Ballast (for arm mount fixture only)
T=Terminal Block
U=U.L. Listed
AIR=Arm Included for Round Pole
AIS=Arm Included for Square Pole
ACCESSORIES (order separately)
OA1224=TufGuard Vandal Shield
OA1016=105-285V Photocontrol
OA1013=Shorting Cap
OA1027=480V Photocontrol
OA1061=Direct Mount Plate for Square Pole
OA1062=10" Arm for Square Pole (EPA .53)
OA1063=Direct Mount Plate for Round Pole
OA1064=10" Arm for Round Pole (EPA .53)
OA1065=Wall Mount Bracket
OA1090=Adjustable Slipfitter for 2 3/8" O.D. Vertical Tenon
PRODUCT
FAMILY
RCL=Arm Mount
RCS=Slipfitter Mount 1
DISTRIBUTION
1D=Type I MCO
2D=Type II MCO
3D=Type III MCO
AC=Area Cutoff-Type IV 4
LAMP WATTAGE
70=70W
10=100W
15=150W 2
17=175W
20=200W
25=250W
31=310W
40=400W
24=250/400W wired 250W
42=400/250W wired 400W
LAMP TYPE 3
S=HPS
R=SMH
M=MH
BALLAST TYPE 3
H=Reac./HPF
N=Hi. Reac./NPF
P=Hi. Reac./HPF
R=Reac./NPF
W=CWA
C=CWI
K=10KV CWA
VOLTAGE 3
2=120V
0=208V
4=240V
7=277V
8=480V
W=Multi-Tap wired 120V
F=120/240 wired 120V
P=240V
N=Multi-Tap wired 277V
V=Multi-Tap wired 240V
RC AREA LUMINAIRE 70-400W MH/HPS/SMH
AREA
SHIPPING DATA
Approximate Net Weight:
46 lbs. (21 kgs.)
OPTIONS + ACCESSORIES [Must be listed in the order shown and separated by a dash]
STREETWORKS™
102 STREETWORKS Outdoor Lighting Solutions Cooper Lighting
IP65 RATED
8"
[203mm]
10" [254mm]
15 1/2" [394mm]
23 7/8" [606mm]
OPTIONAL COLORS [Standard color is bronze, other finish colors available. Consult your Cooper Lighting representative]
WH
White BK
Black AP
Grey

STREETWORKS Outdoor Lighting Solutions 103Cooper Lighting
PHOTOMETRICS [Complete IES files available at www.cooperlighting.com]
RC AREA LUMINAIRE AREA
ACCESSORY & MOUNTING SYSTEMS
RC40SAC.IES
400-Watt HPS
50,000-Lumen Lamp
Area Cutoff
FOOTCANDLE TABLE
Select mounting height and read across for
footcandle values of each isofootcandle line.
Distance in units of mounting height.
Mounting Footcandle Values for
Height Isofootcandle Lines
ABCDEF
RC40SAC.IES
20' 14.40 7.20 2.88 1.44 0.72 0.28
25' 10.00 5.00 2.00 1.00 0.50 0.20
30' 7.50 3.75 1.50 0.75 0.37 0.15
RC40M3D.IES
20' 14.40 7.20 2.88 1.44 0.72 0.28
25' 10.00 5.00 2.00 1.00 0.50 0.20
30' 7.50 3.75 1.50 0.75 0.37 0.15
4
3
2
1
0
1
2
3
4
5 4 3 2 1 0 1 2 3 4 5
ABCDE
F
RC40M3D.IES
400-Watt MH
34,000-Lumen Lamp
Type III
4
3
2
1
0
1
2
3
4
5 4 3 2 1 0 1 2 3 4 5
ABC
DE
OA1061 OA1062 OA1063 OA1064 OA1065 OA1090
No Arm 10" Arm Adapter 10" Arm Wall Bracket Adjustable Slipfitter for
Tenon Mount
Square Pole Round Pole Wall mounting bracket—
mounts over 4" square or
round electrical box.
Includes 10" arm.
NOTE: Standard color bronze. Other colors available. Consult Streetworks Representative.
MOUNTING CONFIGURATIONS
Wall Mount Arm Mount Single Arm Mount 2 @ 180° Arm Mount 2 @ 90° Arm Mount 3 @ 120°
(Round Pole Only) Arm Mount 4 @ 90°Arm Mount 3 @ 90°
DRILLING PATTERNS
TYPE “M” WALL MOUNT DRILLING
3/4'' [20mm]
dia. hole
(2) 5/8'' [16mm]
dia. holes
4 7/8'' [124mm]
2 7/16'' [124mm]
2 11/16''
[69mm] 12"
[305mm]
8"
[203mm]
6 1/2"
[165mm]
4 7/8"
[124mm]
9/16" [14mm]
dia. hole (4)
10 1/2"
[267mm]
E.P.A. TABLE SINGLE
DRILL PATTERN [W/Arm where applicable] 2 @ 180° 2 @ 90° 3 @ 90° 3 @ 120° 4 @ 90°
RCL + RCS “M” 2.11 4.22 4..22 5.8 5.8 6.59
