Cooper Lighting Acorn ANE50SR2554 User manual

STREETWORKS Outdoor Lighting Solutions 55Cooper Lighting
PHOTOMETRICS [Complete IES files available at www.cooperlighting.com]
NOTE: 1 Available in 120V only. 2250W available for 120V only. 3Refer to technical section for lamp/ballast/voltage compatibility. 4Available 50-150W, 120/240 or single voltage only. 5Specify single voltage. 6Standard 8" globe.
7Available in Reactor HPF and NPF. For Hi Reactance or CWA availability consult your Streetworks Representative.
ORDERING INFORMATION
SAMPLE NUMBER: ANE50SR2554
OPTIONS (add as suffix)
1=Single Fuse, Internally Mounted
(120 or 277V)
2=Double Fuse, Internally
Mounted (208, 240, or 480V)
4=NEMA Twistlock Photocontrol
Receptacle
5=Internal Button Photocontrol 5
WH=White
BZ=Bronze
9=9" Globe 6
A=Acrylic Globe
B=Acrylic Globe 9"
F=Finial
AP=Grey
OPTIONS + ACCESSORIES [Must be ordered in alphanumeric order]
ANE ACORN
50-250W
MH/HPS/MERCURY
DECORATIVE
GLOBE
8" textured polycarbonate globe is
standard. Optional globes include a
9" polycarbonate, 8" and 9" milk
white, and 8" and 9" acrylic.
(Optional internal Type III refractor
available.)
SOCKET
Mogul-base socket for 50W through
150W HPS and 175W and 250W
Metal Halide; 50W through 150W
MH is medium base socket. All
sockets are 4KV pulse rated.
BALLAST
Easily accessible, tilt-back power
module. Standard plug-in starter
when applicable.
PHOTOCONTROL
Photocontrol receptacle available.
HOUSING
Cast aluminum housing. Standard
with two position terminal block.
Standard color is black. Other finish
colors available. Consult your
Streetworks Representative. 1" ANSI
wattage/source label.
MOUNTING
Post-top mount fits 3" tenons.
Secures with three (3) square
headed 1 1/4" polymer coated
mounting bolts.
FINISH
Standard polyester powder coat
finish in black. For more color
options see optional color or
consult your Streetworks
represenatitive for
more information.
DECORATIVE LUMINAIRE
EPA:
Effective Projective Area: 1.7
SHIPPING DATA
Approximate Net Weight:
30 lbs. (14 kgs.)
STREETWORKS™
BALLAST TYPE 3
R=Reac./NPF 1
H=Reac./HPF
N=Hi. Reac./NPF
P=Hi. Reac./HPF
W=CWA
K=10KV CWA 4
PRODUCT
FAMILY
ANE=Acorn
LAMP TYPE 3
S=High
Pressure
Sodium
V=Mercury
M=Metal
Halide
LAMP
WATTAGE 3
50=50W 1
70=70W
10=100W
15=150W
17=175W
25=250W 2
VOLTAGE 3
2=120V
0=208V
4=240V
7=277V
8=480V
F=120/240 wired 120V
G=120/240 wired 240V
W=Multi-Tap wired 120V
N=Multi-Tap wired 277V
V=Multi-Tap wired 240V
REFRACTOR
TYPE
33=Type III
55=Type V
OPTIONS +
ACCESSORIES
(See Below)
ANE15S33.IES
150-Watt HPS
16,000-Lumen Lamp
Type III
FOOTCANDLE TABLE
Select mounting height and read across for footcandle
values of each isofootcandle line. Distance in units of
mounting height.
Mounting Footcandle Values for
Height Isofootcandle Lines
ABCD
ANE15S33.IES
12' 1.36 0.68 0.34 0.13
14' 1.00 0.50 0.25 0.10
16' 0.76 0.38 0.19 0.07
ANE15S55.IES
12' 1.36 0.68 0.34 0.13
14' 1.00 0.50 0.25 0.10
16' 0.76 0.38 0.19 0.07
5
4
3
2
1
0
1
2
3
4
5
5 4 3 2 1 0 1 2 3 4 5
DC
B
A
5
4
3
2
1
0
1
2
3
4
5
5 4 3 2 1 0 1 2 3 4 5
DC
B
A
ANE15S55.IES
150-Watt HPS
16,000-Lumen Lamp
Type V
11 1/4"
[286mm]
4 1/2"
[114mm]
8"
21 1/2" [546mm]
9"
27 3/4" [705mm]
8"
14 1/4" [362mm]
9"
16 1/2" [419mm]
TILT-BACK POWER MODULE
ACCESSORIES (order separately)
AA1000=House Side Shield (9" globe)
AA1001=House Side Shield (8" globe)
OPTIONAL COLORS [Standard color is black, other finish colors available. Consult your Cooper Lighting representative]
WH
White BZ
Bronze AP
Grey DP Dark Platinum H Hartford Green
H=Hartford Green
DP=Dark Platinum
M=Milk White Globe
N=NEMA Ballast Bracket 7
S=Screw Secure Power Module
U=UL/CSA Listed
