DECORATIVE LUMINAIRE
LXD DAYFORM LEXINGTON 70-175W MH/HPS
DECORATIVE
HOUSING
Die-cast aluminum base housing.
Standard color is black. Other finish
colors available. Consult your
Streetworks Representative.
1" ANSI wattage/source label.
TOP
Hinged die-cast aluminum top with
cupola cover.
REFLECTOR
Anodized aluminum reflector with
field adjustable socket.
REFRACTOR
Clear acrylic refractor panels.
CHIMNEY
Decoractive glass chimney and
brass holder.
SCREWS
Captive retaining screw.
STARTER
Plug-in starter.
TERMINAL BLOCK
Terminal block standard.
MOUNTING
Self-aligning pole-top fitter fits
2 3/8" and 3" O.D. tenons. Square
headed 1 1/4" polymer coated
mounting bolts.
ORDERING INFORMATION
SAMPLE NUMBER: LXD70SR2334
EPA:
Effective Projective Area: 1.7
SHIPPING DATA
Approximate Net Weight:
25 lbs. (11 kgs.)
OPTIONS [Must be ordered in alphanumeric order]
STREETWORKS™
NOTE: 1 Refer to technical section for lamp/ballast/voltage compatibility. 2Medium-base porcelain socket standard. 3HPS only.
BALLAST TYPE 1
H=Reac./HPF 3
N=Hi. Reac./NPF
R=Reac./NPF
OPTIONS (add as suffix)
1=Single Fused, Internally Mounted (120 or 277V)
4=Photocontrol Receptacle
WH=White
BZ=Bronze
AP=Grey
P=Polycarbonate Lens Panels
S=Snap Latches for Toolless Lamp Replacement
T=3/4" Pendant Mount Provision
U=UL/CSA Listed
PRODUCT
FAMILY
LXD=Dayform
Lexington
LAMP TYPE 1
S=High
Pressure
Sodium
M=Metal
Halide 2
LAMP
WATTAGE1
70=70W
10=100W
15=150W
17=175W
VOLTAGE 1
2=120V DISTRIBUTION
22=Type II
33=Type III
OPTIONS
(See Below)
25"
[635mm]
21"
[533mm]
15" [381mm]
OPTIONAL PENDANT MOUNT
OPTIONAL COLORS [Standard color is black, other finish colors available. Consult your Cooper Lighting representative]
WH
White BZ
Bronze AP
Grey

STREETWORKS Outdoor Lighting Solutions 63Cooper Lighting
LXD DAYFORM LEXINGTON DECORATIVE
PHOTOMETRICS [Complete IES files available at www.cooperlighting.com]
LXD10S22.IES
100-Watt HPS
9,500-Lumen Lamp
Type II
FOOTCANDLE TABLE
Select mounting height and read across for footcandle values of each
isofootcandle line. Distance in units of mounting height.
Mounting Footcandle Values for
Height Isofootcandle Lines
ABCDE
LXD10S22.IES
12' 1.50 0.75 0.30 0.15 0.08
15' 1.00 0.50 0.20 0.10 0.05
20' 0.50 0.25 0.10 0.05 0.03
LXD10S33.IES
12' 1.50 0.75 0.30 0.15 0.08
15' 1.00 0.50 0.20 0.10 0.05
20' 0.50 0.25 0.10 0.05 0.03
6
5
4
3
2
1
0
1
2
3
4
5
6
6 5 4 3 2 1 0 1 2 3 4 5 6
AB
CDE
6
5
4
3
2
1
0
1
2
3
4
5
6
6 5 4 3 2 1 0 1 2 3 4 5 6
AB
CD
E
LXD10S33.IES
100-Watt HPS
9,500-Lumen Lamp
Type III
