AREA / ROADWAY
1165
COOPER LIGHTING
• Spun-aluminum top is
finished in premium TGIC
polyester powder coat
• Long life core-and-coil
HID ballast is hard
mounted for cooler
operation. Pole mounted
ballast assembly for
luminous units only
• Controlled and fully
rotatable optics offer
ten (10) distinct beam
patterns. Precision
hydroformed or premium
segmented optical
modules available
• Die-cast aluminum door
frame has concealed
hinges and is flush with
the bottom of the
housing
• Thermal shock- and
impact-resistant clear
tempered flat glass
• Variety of arm, spider,
yoke or wall mounting
configurations
• U.L. listed for wet
locations. CSA certified
• Approximate net weight:
65 lbs. (29 kgs.)
MCGRAW-EDISON®
CI
CIRRUS
26-57W
Compact Fluorescent
70-1000W
Metal Halide
High Pressure Sodium
ARCHITECTURAL
AREA LUMINAIRE
DIMENSIONS
YOKE MOUNT SPIDER MOUNT ARM MOUNT
DESCRIPTION
The Cirrus series sets the standard
in flexibility for architectural area
lighting. The Cirrus is available in
three (3) sizes, so a single look can
be carried through diverse areas
of a project. Combined with three
(3) mounting varieties, MH or HPS
lamps, ten (10) optical packages
and numerous colors, the Cirrus
offers unparalleled variety in one
family of fixtures. U.L. listed and
CSA certified for wet locations.
The Cirrus offers features so
versatile that it can be used in
small areas such as walkways and
large areas like parking lots, while
maintaining a look of continuity
throughout.
NOTES: 1 Segmented optics not available. Available in 120 or 277V only. 2Segmented optics not available. 3Requires 4" round straight pole for CIS. 5" round straight
pole for CIG and CIM. 6" round straight pole for CIL. 4All 70-150W lamps on formed optics and 70-175W lamps on small segmented optics are medium-base,
175-1000W are mogul-base. 5150W HPS uses S-55 lamp (arc rating of 55V). 6Must use reduced jacket ED-28 400W lamp when using a segmented optical system
in the medium housing. 71000W HPS not available in medium housing. Medium housing requires BT-37 lamp for Metal Halide and only available with formed
optics. 8Available in Type III, IV and V distributions in small, solid top housing with segmented optics only. 9Nominal length not to exceed 7". 10 Product also
available in non-US voltages and 50Hz for international markets. Consult factory for availability and ordering information. 11 Multi-Tap ballast is 120/208/240/277V
wired 277V. Triple-Tap ballast is 120/277/347V wired 347V. 12 Medium housing fixture only. 13 Other finish colors available, including a full line of RAL color
matches. Consult your Cooper Lighting Representative. 14 Add as suffix in the order shown. 15 Not available for CIG. 16 400W Maximum. 17 Order separately, replace
XX with color suffix. 18 Not for use with 250W HPS. 19 Specifications and dimensions subject to change without notice.
ORDERING INFORMATION
SAMPLE NUMBER: CIM-AM-400-MH-MT-5F-BK
Product
Family
CIS=Cirrus
Small
Solid
Top
CIG=Cirrus
Small
Luminous
Top 1
CIM=Cirrus
Medium
Solid Top
CIL=Cirrus
Large
Solid Top 2
Mounting
Method
AM=Arm
Mount
YM=Yoke
Mount 3
SM=Spider
Mount
for 3"
O.D.
Tenon 3
Lamp
Wattage 4
HID
70=70W
100=100W
150=150W 5
175=175W
250=250W
400=400W 6
1000=1000W 7
Compact
Fluorescent
26=26W
32=32W
42=42W
57=57W
Lamp Type
MH=Metal
Halide
HPS=High
Pressure
Sodium
CF=Compact
Fluorescent 8, 9
Voltage 10
120=120V
208=208V
240=240V
277=277V
480=480V
MT=Multi-Tap 11
TT=Triple-Tap 11
Distribution
1F=Type I
Formed 12
2F=Type II
Formed
2S=Type II
Segmented
3F=Type III
Formed
3S=Type III
Segmented
4S=Type IV Segmented
5F=Type V Formed
5S=Type V Segmented
FT=Forward Throw
SL=Spill Light Eliminator 6
Color 13
(add as suffix/
must specify)
BK=Black
BZ=Bronze
AP=Grey
WH=White
DP=Dark Platinum
GM=Graphite Metallic
Options &
Accessories
(See Below)
Options 14
F=Single Fuse (120, 277 or 347V)
FF=Double Fused (208, 240 or 480V)
P=Button Type Photocontrol (Specify Voltage) 15
R=NEMA Twistlock Photocontrol Receptacle 15
HS=House-side Shield
VS=Vandal Shield 16
L=Lamp Included
Accessories 17
OA/RA1016=NEMA Photocontrol/Multi-Tap—Multi-Tap
OA/RA1027=NEMA Photocontrol/Multi-Tap—480V
MA1001XX=Wall Bracket for Solid Top
MA1003XX=Wall Bracket for Luminous Top 18
E.P.A. CIS & CIG: Arm Mount 1.19, Spider & Yoke Mount 1.13 / CIM: Arm Mount 1.70, Spider & Yoke Mount 1.52
CIL: Arm Mount 2.36, Spider & Yoke Mount 2.10
