C A T A L O G # : T Y P E :
Specification grade, wet listed 71 watt
MR16 lamp adjustable fixture.
Adjustment mechanism features hot
aiming capability, aiming mar s and too-
less loc ing. Optics provide glare-free
50° cutoff to lamp and lamp image. For
use with all halogen MR16 lamp vari-
eties. Units small size is ideal for tight
construction areas. Insulation must be
ept 3" away from sides and top of fix-
ture. Optical element can be changed
after installation to provide a variety of
distributions e g into a Downlight
 Re f l ect o r
.040 thic aluminum spun parabolic interior
reflector in Clear, Gold, Haze, Warm Haze, Blac
Alza ® finish .
Special cone colors listed below.
 G l ass
.125 thic tempered clear glass protects lamp
from direct spray of water and is retained during
relamping.
 F la nge
Self flange reflector or die-cast flange with either
matte white or clear coat finish  Die-cast flanges
are easily removed for field painting. Elements are
eyed for proper insertion.
 A d jus tab i lit y
Removable lamp adjustment mechanism provides
up to 45° tilt and 361° rotation and loc s into any
aiming position. Unit is relamped without unloc ing
adjustments. Translating centerbeam optics maxi-
mize light output.
 L e ns
Soft focus lens standard for smooth beam
patterns. Up to two filter media can be used
which are retained during relamping.
 A t tac hm ent
Positive torsion springs pull flange tight to ceiling.
Mechanical light trap eliminates spill light at edge
of flange or reflector.
 So c ke t
GX5.3 base for Bi-pin MR16 lamps. Bac light
shield eeps interior of fixture dar .
 T ran s form er
Truvolt
™ toroidal transformer with dual-output taps
for proper 12.0V operation and quiet operation
when dimmed. Dimmer tap compensates for inher-
ent voltage loss from dimmers, resulting in 30%
more lumens than traditional laminated transform-
ers. Toroidal design, with 90% or greater efficien-
cy, features a rolled one-piece continuous core of
M3 grade grain oriented silicon steel complete with
an integral thermal to protect against overheating.
For dimming, use dimmers rated for electromagnet-
ic transformers. Transformer is warranted for 5
years and is serviceable from below ceiling
Note: If a dimming system is operated for con-
struction lighting in its "shunt" mode, i.e. bypass-
ing the dimmer modules, for an extended period of
time, fixtures with the dual-tap toroidal transformer
should be operated on the "Switched Fixture" out-
put until the dimmers are in use. Operating fixtures
on the "Dimmed Fixture" output with a full 120v
input for an extended period will overdrive the
lamp and cause shortened lamp life.
 F r ame /H ou si n g
Hot dipped galvanized 20 gauge steel frame
with built in 1/2 inch plaster lip. Gunsights allow
for consistent alignment.
 Jun c ti on Box
18 cubic inches, listed for 4#12 AWG or 6#14
AWG 90° C additional feed through conductors,
has three 1/2" pryouts.
 Bar H an ger s
No Flex
® bar hangers with positive loc ing, for
use with wood, engineered wood and steel frame
joists spaced up to 24" O.C. ship with platform.
For use in T-bar ceilings order accessory push on
clips. Nailess barb and locator lip provide consis-
tent installation height.
 C od es
Thermally protected, IP labeled. Unit is airtight and
exchanges less than 2.0 CFM with the plenum at a
pressure of 75 pascals. Insulation must be ept
three inches away from fixture sides and none on
top as to entrap heat.
 L a bel s
                  













      
3 " A D JU S T A B L E
S H O W E R

 
          
3 1/2"
[89mm]
4 3/8"
[112mm]
5 1/8"
[130mm]
5"
[127mm]
8 5/8"
[220mm]
4 3/8"
[112mm]
11 7/8"
[302mm]
E N E R G Y D A T A
120V Input
Lamp Input Operating
Watts Watts Current
20 23 .19
35 41 .34
37 42 .35
42 47 .39
50 57 .48
65 70 .58
71 77 .64
75 81 .68
Note: O.D. on SF
is 4 7/8"
Ceiling Cutout:
4 3/8" [112mm]
ADI042551
                  
S A M P L E N U M B E R : P N 3 M R - E 3 A A S R C
Complete unit consists of a platform and element
 

PN3MR = 3" Non-
IC Low Voltage
Housing
PN3MR REMOTE =
3" Non-IC Housing
for Remote
Transformer
Pla t form A cc e ss o r ie s
MBCLP = 40
Push On T Bar
Clips (for 10
Units)
PLE3 = Plaster
Lip Extension
for Max 2"
Thic Ceiling
L-SPD =
Spread Lens
L-LNR = Linear
E3AASR
= 3"
MR16
0 - 45°
Adjustable
Accent
Lensed
Reflector
Optica l
E l em en t
Blan = White
die-cast
SF= Self
Flange
SFWF= Self
Flange Painted
White
RAW= Natural
Die Cast
Flan ge Fini s h
Standard
C=Clear
H=Haze
G=Gold
WMH=Warm
Haze
W=Gloss White
B= Blac
MW= Matte
White
Custom
K=Cognac
KH=Cognac
Haze
CC=Chocolate
Custom
CCH=Chocolate
Haze
BU=Blush
Custom Cont.
BUH=Blush
Haze
GP=Graphite
GPH=Graphite
Haze
PN=Pine
PNH=Pine Haze
SK=S y
SKH=S y Haze
Spread Lens
L-UV = UV
Reduction Lens
L-LPINK =
Light Pin
L-LSTRAW =
Light Straw
Lens
L-27K =
2700K dichroic
filter
L-DAY =
Daylight Lens
L-SPINK =
Surprise Pin
Lens
L-PLAV = Pale
Lavender Lens
L-HEX= Hex
Cell Louver
For additional options please consult factory.
Matte white is recommended for self flanged reflectors

Unit Number: P N3 M R - E 3 A A S R _
Notes and Definitions:
Luminance : To convert cd/m
2 to footlamberts, multiply by 0.2919
• Data is based upon bare lamps photometrics.
• Beam spread is to 50% center beam candlepower (CBCP.)
D=Distance to floor or wall.
FC=Footcandles on floor or wall at center beam aiming location.
L =Effective Visual Beam length in feet (50% of maximum footcandle level.)
W=Effective Visual Beam width in feet (50% of maximum footcandle level.)
CB=Distance across or down to center beam location. Note:
Specifications and Dimensions subject to change without notice. Visit our web site at www cooperlighting com
Customer First Center 1121 Highway 74 South Peachtree City, GA 30269 770.486.4800 FAX [phone] ADI042551
Cooper Lighting 5925 McLaughlin Rd. Mississauga, Ontario, Canada L5R 1B8 905.507.4000 FAX [phone]
PH OT OM ETR IC S
Lamp
Beam Spread: 10°
CBCP: 14,000
D FC L W
4' 618 0.7 0.7
7' 202 1.1 1.1
10' 99 1.6 1.6
12' 6" 63 2 2
D FC L W CB
4' 250 1 1 2.3
7' 82 1.7 1.8 4.0
10' 40 2.4 2.5 5.8
12' 6" 26 3 3.2 7.2
D FC L W CB
2' 220 1.2 0.8 3.5
3' 98 1.9 1.3 5.2
4' 55 2.5 1.7 6.9
5' 35 3.1 2.1 8.7
D FC L W CB
2' 712 0.6 0.5 2.0
3' 316 0.9 0.7 3.0
4' 178 1.2 0.9 4.0
5' 114 1.5 1.2 5.0
Test # H1269 Test # H21273 Test # H21273 Test # H21274
Degree@ 180°@ 90°
°
°
°
°
°
Beam Spread: 40°
CBCP: 2,100
D FC L W
4' 130 2.3 2.3
7' 42 4 4
10' 21 5.8 5.8
12' 6" 13 7.2 7.2
D FC L W CB
4' 85 2.8 2.7 2.3
7' 28 5 4.7 4.0
10' 14 7.1 6.8 5.8
12' 6" 9 8.9 8.4 7.2
D FC L W CB
2' 104 2.1 1.9 3.5
3' 46 3.2 2.9 5.2
4' 26 4.3 3.9 6.9
5' 17 5.3 4.8 8.7
D FC L W CB
2' 195 1.5 1.7 2.0
3' 87 2.3 2.5 3.0
4' 49 3.0 3.3 4.0
5' 31 3.8 4.2 5.0
Test # H21263 Test # H21264 Test # H21264 Test # H21265
Beam Spread: 15°
CBCP: 9,500
D FC L W
4' 445 1 1
7' 145 1.8 1.8
10' 71 2.5 2.5
12' 6" 46 3.1 3.1
D FC L W CB
4' 291 1.2 1.2 2.3
7' 95 2.1 2.1 4.0
10' 47 3 3 5.8
12' 6" 30 3.7 3.7 7.2
D FC L W CB
2' 252 1.5 1.0 3.5
3' 112 2.2 1.5 5.2
4' 63 2.9 1.9 6.9
5' 40 3.7 2.4 8.7
D FC L W CB
2' 639 0.8 0.7 2.0
3' 284 1.2 1.1 3.0
4' 160 1.6 1.5 4.0
5' 102 2.1 1.8 5.0
Test # H21240 Test # H21243 Test # H21243 Test # H21244
Degree@ 180°@ 90°
°
°
°
°
°
Beam Spread: 25°
CBCP: 3,000
D FC L W
4' 174 1.6 1.6
7' 57 2.9 2.9
10' 28 4.1 4.1
12' 6" 18 5.1 5.1
D FC L W CB
4' 108 2 2.2 0
7' 35 3.5 3.8 0
10' 17 5 5.4 0
12' 6" 11 6.2 6.7 0
D FC L W CB
4' 27 4.5 3.4 6.9
6' 12 6.7 5.1 10.4
10' 4 11.2 8.5 17.3
12' 3 13.4 10.2 20.8
D FC L W CB
6' 28 3.9 3.8 6
8' 16 5.2 5.1 8
10' 10 6.5 6.4 10
12' 7 7.8 7.7 12
Test # H21187 Test # H1193 Test # H21193 Test # H21185
Degree@ 180°@ 90°
°
°
°
°
°
Beam Spread: 40°
CBCP: 1,700
D FC L W
4' 129 2.0 2.0
7' 42 3.4 3.4
10' 21 4.9 4.9
12'6" 13 6.1 6.1
D FC L W CB
4' 66 2.8 2.8 2.3
7' 22 5.0 4.8 4.0
10' 11 7.1 6.9 5.8
12'6" 7 8.9 8.6 7.2
D FC L W CB
2' 100 1.8 1.7 3.5
3' 45 2.7 2.5 5.2
4' 25 3.6 3.3 6.9
5' 16 4.5 4.1 8.7
D FC L W CB
2' 159 1.5 1.6 2
3' 71 2.3 2.4 3
4' 40 3 3.2 4
5' 25 3.8 4 5
Test # H21249 Test # H21199 Test # H21202 Test # H21203
Degree@ 180°@ 90°
°
°
°
°
°
Beam Spread: 9°
CBCP: 12,500
D FC L W
4' 498 0.5 0.8
7' 163 0.9 1.4
10' 80 1.2 2
12' 6" 51 1.6 2.5
D FC L W CB
4' 284 0.8 0.8 2.3
7' 93 1.4 1.4 4.0
10' 45 2.1 2 5.8
12' 6" 29 2.6 2.5 7.2
D FC L W CB
2' 261 1.0 0.7 3.5
3' 116 1.5 1.0 5.2
4' 65 2.0 1.4 6.9
5' 42 2.5 1.7 8.7
D FC L W CB
2' 571 0.5 0.6 2.0
3' 254 0.7 1.0 3.0
4' 143 0.9 1.3 4.0
5' 91 1.2 1.6 5.0
Test # H21212 Test # H21211 Test # H21211 Test # H21210
Degree@ 180°@ 90°
°
°
°
°
°
Beam Spread: 7°
CBCP: 7,400
D FC L W
4' 312 0.5 0.5
7' 102 0.8 0.8
10' 50 1.2 1.2
12' 6" 32 1.5 1.5
D FC L W CB
4' 153 0.8 0.5 2.3
7' 50 1.4 0.9 4.0
10' 24 2.1 1.3 5.8
12' 6" 16 2.6 1.7 7.2
D FC L W CB
2' 150 0.9 0.5 3.5
3' 67 1.3 0.8 5.2
4' 38 1.7 1.0 6.9
5' 24 2.1 1.3 8.7
D FC L W CB
2' 482 0.4 0.3 2.0
3' 214 0.6 0.5 3.0
4' 120 0.8 0.6 4.0
5' 77 1.0 0.8 5.0
Test # H21232 Test # H21234 Test # H21234 Test # H21237
Degree@ 180°@ 90°
°
°
°
°
°
Beam Spread: 8°
CBCP: 16,000
D FC L W
4' 696 0.6 0.8
7' 227 1.1 1.4
10' 111 1.6 2
12'6" 71 2 2.5
D FC L W CB
4' 342 1 0.9 2.3
7' 112 1.8 1.7 4.0
10' 55 2.5 2.4 5.8
13' 32 3.3 3.1 7.2
D FC L W CB
2' 300 1.3 0.8 3.5
3' 133 2.0 1.2 5.2
4' 75 2.6 1.5 6.9
5' 48 3.3 1.9 8.7
D FC L W CB
2' 722 0.7 0.7 2.0
3' 321 1.0 1.0 3.0
4' 181 1.3 1.3 4.0
5' 116 1.7 1.6 5.0
Test # H21223 Test # H21227 Test # H21227 Test # H21228
Degree@ 180°@ 90°
°
°
°
°
°
Beam Spread: 10°
CBCP: 13,100
D FC L W
4' 681 0.6 0.8
7' 222 1.1 1.4
10' 109 1.6 2
12'6" 70 1.9 2.5
D FC L W CB
4' 356 1 0.9 2.3
7' 116 1.7 1.5 4.0
10' 57 2.5 2.1 5.8
12'6" 36 3.1 2.7 7.2
D FC L W CB
2' 303 1.3 0.7 3.5
3' 135 2.0 1.1 5.2
4' 76 2.6 1.4 6.9
5' 48 3.3 1.8 8.7
D FC L W CB
2' 909 0.7 0.5 2.0
3' 404 1.0 0.7 3.0
4' 227 1.3 1.0 4.0
5' 145 1.6 1.2 5.0
Test # H21253 Test # H21254 Test # H21254 Test # H21255
Degree@ 180°@ 90°
°
°
°
°
°
Test # H21261
Test # H21248
Test # H21185
Test # H21204
Test # H22402
Test # H21210
Test # H21250
Test # H21237
