Operation & Service Manual
823072 2/01
45MTC & 55MTC Series
Fixturized Nutrunners
Transducerized Solenoid Controlled
Gear Train Designation:
2
34
6
Controller:
TC
XX
Motor:
45 & 55
Series:
M XTC --
6" Retractable
Spindle:
R6
R6 X-
3/8"3 1/2"4
Output Drive:
NORTH AMERICA EUROPE
CooperTools
P.O. Box 1410
Lexington, SC 29071
Cooper PowerTools GmbH & Co.
Postfach 30
D-73461 Westhausen

2
CAUTION!
Personal hearing protection is
recommended when operating
or working near this tool.
Safety Recommendations
For your safety and the safety of others, read and under-
stand the safety recommendations and operating instruc-
tions before operating any tool.
Always wear protective equipment:
For additional information on eye protection and face
protection,refertoFederalOSHARegulations,29Codeof
Federal Regulations, Section 1910.133., Eye and Face
Protection, and American National Standards Institute,
ANSIZ87.1, Occupationaland EducationalEye andFace
Protection. Z87.1 is available from the American National
Standards Institute, Inc., 11 West 42nd Street New York,
NY. 10036.
Hearingprotectionisrecommendedinhighnoiseareas85
dBAorgreater.Theoperationofothertoolsandequipment
in the area, reflective surfaces, process noises and reso-
nant structures can substantially contribute to, and in-
crease the noise level in the area. Excessive air pressure
above 90 PSIG or worn motor components can also
increase sound level emitted by tool. For additional infor-
mationonhearingprotection,refertoFederalRegulations,
Section1910.95,OccupationalNoiseExposure,andAmeri-
can National Standards Institute, ANSI S12.6, Hearing
Protectors.
Cleco tools are designed to operate on 90 psig (6.2 bar)
maximum air pressure. If the tool is properly sized and
applied,higherairpressureis unnecessary.Excessiveair
pressure increases the loads and stresses on the tool
parts, sockets, and fasteners and may result in breakage.
Installation of a filter-regulator-lubricator in the air supply
line ahead of the tool is recommended.
Before the tool is connected to the air supply, check the
throttle for proper operation (i. e., throttle moves freely
and returns to closed position). Being careful not to
endangeradjacentpersonnel,cleartheairhoseofaccu-
mulated dust and moisture. Before removing a tool from
serviceorchangingsockets,makesuretheairlineisshut
off and drained of air. This will prevent the tool from
operating if the throttle is accidently engaged.
Some individuals may be susceptible to disorders of the
hands and arms when performing tasks consisting of
highly repetitive motions and/or exposure to extended
vibration. Cumulative trauma disorders such as carpal
tunnelsyndromeandtendonitismaybecausedoraggra-
vated by repetitious, forceful exertions of the hands and
arms. Vibration may contribute to a condition called
Raynaud's Syndrome. These disorders develop gradu-
ally over periods of weeks, months, and years. It is
presentlyunknowntowhatextent exposuretovibrations
or repetitive motions may contribute to the disorders.
Hereditary factors, vasculatory or circulatory problems,
exposureto coldanddampness,diet,smokingandwork
practices are thought to contribute to the conditions.
Anytooloperator shouldbe awareofthe followingwarn-
ing signs and symptoms so that a problem can be
addressedbeforeitbecomesadebilitatinginjury.Anytool
operator should be aware of the following warning signs
and symptoms so that a problem can be addressed
beforeitbecomesadebilitatinginjury.Anyusersuffering
prolongedsymptomsoftingling,numbness,blanchingof
fingers, clumsiness or weakened grip, nocturnal pain in
the hand, or any other disorder of the shoulders, arms,
wrists, or fingers is advised to consult a physician. If it is
WARNING!
Impact resistant eye protection
must be worn while operating
or working near this tool.
Repetitive work motions and/or vibration
may cause injury to hands and arms.
Use minimum hand grip force consistent
with proper control and safe operation.
Keep body and hands warm and dry.
Avoid anything that inhibits blood circulation.
Avoid continuous vibration exposure.
Keep wrists straight.
WARNING
!
Avoid repeated bending of wrists and hands.

3
Safety Recommendations
determined that the symptoms are job related or aggra-
vated by movements and postures dictated by the job
design,itmaybenecessaryfortheemployertotakesteps
to prevent further occurrences. These steps might in-
clude,butarenotlimitedto,repositioningtheworkpieceor
redesigningtheworkstation,reassigningworkerstoother
jobs, rotating jobs, changing work pace, and/or changing
the type of tool used so as to minimize stress on the
operator. Some tasks may require more than one type of
tooltoobtaintheoptimumoperator/tool/taskrelationship.
The following suggestions will help reduce or moderate
the effects of repetitive work motions and/or extended
vibration exposure:
• Use a minimum hand grip force consistent with
proper control and safe operation
• Keep body and hands warm and dry (cold
weather is reported to be a major factor contrib
uting to Raynaud's
Syndrome)
• Avoid anything that inhibits blood circulation
—Smoking Tobacco (another contributing
factor)
—Cold Temperatures
—Certain Drugs
• Tasks should be performed in such a manner
that the wrists are maintained in a neutral posi-
tion, which is not flexed, hyperextended, or
turned side to side.
• Stressful postures should be avoided — select
a tool appropriate for the job and work location
• Avoid highly repetitive movements of hands
and wrists, and continuous vibration exposure
(after each period of operation, exercise to
increase blood circulation)
• Keep tool well maintained and replace worn
parts
Work gloves with vibration reducing liners and wrist sup-
ports are available from some manufacturers of industrial
work gloves. Tool wraps and grips are also available from
anumberofdifferentmanufacturers.Thesegloves,wraps,
and wrist supports are designed to reduce and moderate
the effects of extended vibration exposure and repetitive
wrist trauma. Since they vary widely in design, material,
thickness, vibration reduction, and wrist support qualities,
itisrecommendedthattheglove,toolwrap,orwristsupport
manufacturer be consulted for items designed for your
specific application. WARNING! Proper fit of gloves is
important.Improperlyfitted glovesmayrestrictblood
flow to the fingers and can substantially reduce grip
strength.
For more information on the safe use of portable air tools,
see the latest edition of ANSI B186.1, Safety Code for
Portable Air Tools, available from the American National
Standards Institute, Inc. 11 West 42nd Street New York,
NY. 10036.
Warning Labels
The warning labels found on these tools are an essential
partofthisproduct.Labelsshouldnotberemoved.Labels
shouldbecheckedperiodicallyforligibility.Replacewarn-
ing labels when missing or when the information can no
longerberead.Replacementlabelscanbeorderedas any
spare part.
Extension Neutral Flexion Radial Deviation Neutral Ulnar Deviation
Avoid Avoid Avoid
OK Avoid OK

4
OPERATING INSTRUCTIONS
LUBRICATION
An automatic in-line filter-lubricator-regulator is recom-
mended as it increases tool life and keeps the tool in
sustainedoperation.Thein-linelubricatorshouldberegu-
larlycheckedandfilledwithagoodgradeof10Wmachine
oil.Properadjustmentofthein-linelubricatorisperformed
by placing a sheet of paper next to the exhaust ports and
holding the throttle open for approximately 30 seconds.
The lubricator is properly set when a very light stain of oil
collectsonthe paper.Excessive amounts ofoil shouldbe
avoided.
Application of the tool should govern how frequently it is
greased. It is recommended that the idler gears and right
angle gears receive a generous amount of NLGI 2-EP
greasethroughthegreasefittingsafter40hoursofopera-
tion.
STORAGE
Intheeventthatitbecomesnecessarytostorethetoolfor
an extended period of time, it should receive a generous
amountoflubricationatthattimeandagainwhenreturned
to service. The tool should be stored in a clean and dry
environment.Thisinhibitscorrosionof theprecisioninter-
nal components and bearings.
TORQUE ADJUSTMENT
The 55MTC nutrunner is designed to develop maximum
rated torque at 90 psig. The torque setting is achieved by
entering a number within the tool's torque range into the
torquecontrolmonitor.Seecatalogfortorquerangeoftool.
The torque setting entered into the torque control monitor
must not exceed maximum torque range of tool or the
automatic shut-off device will not function and the tool will
operate as a stall tool. Operator should be prepared to
resist torque reaction until throttle is released.
AIR SUPPLY
For maximum performance, use a 1/2" I.D. air hose no
longer than 8' in length. If additional length is required, a
5/8" or larger hose should be connected to the 1/2" hose.
Beingcarefulto avoid endangeringadjacent personnel or
yourself, theairhoseshouldbeclearedofaccumulateddirt
andmoisture,thenone(1)teaspoonfulof10Wmachineoil
shouldbe pouredinto thetool'sairinletbeforeconnecting
the hose to the tool.

5
SERVICE INSTRUCTIONS
DISASSEMBLY — GENERAL
Disconnect tool from air supply. Clamp the motor housing
in a vise. Remove bolts from spindle and remove from
transducer housing. Remove bolts from transducer hous-
ingandremovehousingandgeartrainfrommotorhousing.
Slip the complete motor unit out the front of the housing.
Clamp the angle head in the vise and unscrew (left hand
threads) the right angle housing lock nut, No. 867521, to
remove the transducer housing.
Gear Train -2, -3, -4, -6, & -10
Important:Do notbend, strike,pushorpullinanyway that
willcausestrainintheplasticcoatedareaofthetransducer.
Remove the gear train from the front of the ring gear.
Removetheretainerringandballbearing.Driverollpin,No.
812164,infarenoughtocleartheringgearandslipthering
gear off the transducer.
Gear Train -7
Important: Do not bend, strike, push or pull on the plastic
coatedareaofthetransducer.Driverollpin,No.812164,in
farenoughtocleartheringgear.Removetheringgearand
align the idler gears with the pockets machined in the ring
gear.Slipthespiderassemblyouttherearoftheringgear.
Removetheretainerringandballbearinganddrivetheroll
pin into the bearing bore.
Motor Unit
Clampthecylinderlightlyin avise withthegear endof the
rotorup.Note:Rotorpinion,No.867524,usedonthe-4and
-6 models should be removed at this time. Drive the rotor
outofthefrontrotorbearing,No.619377.Becarefulnotto
damage the rotor. The front bearing plate, No. 867536,
cylinder, and rotor blades, No. 203219, can now be re-
moved from the rotor. Clamp the rotor in the vise with the
rear bearing plate up. After unscrewing the bearing lock
nut,No.865352,therotorcanbedrivenoutoftherearrotor
bearing.
Motor Housing
Clamp the flats of the motor housing in the vise. Remove
solenoid retainer, No. 203369, with wrench and remove
solenoid, No. 203363. Remove exhaust deflector, No.
202558, exhaust screen, No. 202177, and muffler, No.
202012, from the rear of the housing.
Remove throttle valve cap, No. 864531, valve cap, No.
203380 and shut-off valve cap, No. 203550 with screw-
driver to check seals and "O"-rings.

6
REASSEMBLY — GENERAL
Thetoolis reassembled inthe reverse orderof disassem-
bly. Clean all parts thoroughly in kerosene and inspect for
damageorwear.Checkallbearingsforwearwhichcanbe
detected by excessive end play and/or roughness which
would indicate a brinelled condition. The rotor blades
should be replaced at every repair cycle if they measure
less then 1/4" (6.4mm) at either end. All gear teeth, bear-
ings, and pins should receive a close inspection and be
replaced if necessary.
NOTE:Duringreassemblyofthecompletetool,itisimpor-
tant that the motor be free. After the tool is completely
assembled, the square drive spindle should turn freely
using a small hand wrench. If the spindle does not turn
freely,themotorshouldbecheckedforproperspacing.Do
not run the tool until the spindle turns freely. Failure to do
this could result in damage to motor components.
Motor Unit
Install the rear rotor bearing into the rear bearing plate.
Makesuretheouterbearingraceisfirmlyseatedinbearing
plate. Clamp the rotor lightly in the vise with the threaded
end up and slip the rear bearing plate assembly onto the
rotor shaft far enough for the bearing lock nut to start.
Tighten the lock nut until there is approximately .0015"
clearance between the rotor and bearing plate. The outer
bearing race should be firmly seated and the rotor held
forward when checking this clearance.
Pack both rotor bearings with a good grade of No. 2 Moly
grease after assembly of the motor unit.
Gear Train -7
When installing the spider assembly the idler gears must
bealignedwiththepocketsmachinedintheringgear.Line
up the hole in the ring gear with the hole in the transducer
and install the pin, No. 812164.
Transducer Wiring Connection
NOTE: Do not bend, strike, push or pull the transducer on
the plastic coated area of the transducer. Connect the
cable connector, No. 202183, to the transducer and wrap
the wiring around the transducer until the cable connector
is one (1) wrap past the connection and then thread the
connectorthrutheholein thetransducer. Installthetrans-
duceronthemotorhousing,feedingtheconnectorthruthe
holeinthehousing.Lineupthetangsonthetransducerwith
the grooves in the housing being careful not to pinch the
connector.
Pour a few drops of 10W machine oil into the air inlet after
complete assembly to ensure immediate lubrication of all
motor parts when air is applied.
SAFETY CHECK
Afterrepairorreplacementofparts,toolsequippedwithan
automatic shut-off device should be tested to verify that it
isfunctioningproperly.Thetorque settingentered intothe
torque control monitor must not exceed maximum torque
range or tool will stall and not shut-off.
SERVICE INSTRUCTIONS
Must be replaced if
7/32" (5.6mm) or less
at either end.
SOFT
JAWED
VISE
.0015"
Clearance

7
TRANSDUCER SPECIFICATIONS
MAXIMUM TORQUE CAPACITY 55 Series - 51.6 ft. lbs. (70.0 Nm), 75 Series - 147.6 ft. lbs. (200.0 Nm)
OUTPUT VOLTAGE (Vo) 2 Millivolts per volt at maximum torque capacity
BRIDGE RESISTANCE (Rbr) 700 ohms
TRANSDUCER CABLE ITT Cannon #KPTO2-10-6P (mates with KPTO6-10-6S (SR) or equivalent)
CALIBRATION INSTRUCTIONS
TRANSDUCER SERIES FULL SCALE VALUE (FS)
FT. LBS. Nm
45 & 55 MT-R6 51.6 70.0
75 147.5 200.0
45 & 55 MT-R8 63.8 86.5
If a 87.15kohm shunt calibration resistor is used, no calculations are required. The full scale value of the transducer may be
used for the calibration value.
If a 110kohm resistor is used, the calibration value is 79.3% of rated full scale value (see calculation below).
In order to calculate the calibration value for the system in % full scale, the following formula may be used:
% FS = Rbr 1 1
------------------ X ----- X -----
2(Rcal) + Rbr Vo 2
Where Rcal = Calibration Resistor Value in ohms of the torque monitor used.
The following is an example of a 55 series and a torque monitor with a 110 kohm calibration resistor.
The values are: FS = 51.6
Rbr = 700ohm
Vo = .002
Rcal = 110,000ohm
700ohm 1 1
% FS = --------------------------- X ------ X ----- = 79.3%
2(110,000ohm) + 700ohm .002 2
Calibration Value = 51.6 (.793) = 40.9 ft. lbs.
AA
BB
CC
DD
BLACK
GREEN
RED
WHITE
TOOL RECEPTACLE
CABLE CONNECTORS
R
WIRING DIAGRAM
EE
FF
(+) SIGNAL
(-) SIGNAL
SHIELD
(+) EXCITATION
(-) EXCITATION
Ro/2Rm/2
R
R
R
tC
t
C
Ro/2Rm/2
Rcal
R= Gage Resistance
Rm= Modulus Resistor
Ro= Output Scaling Resistor
Rm & Ro may be omitted
Rcal= Shunt Calibration Resistor

8
KK
LL
(+) SOLENOID
(-) SOLENOID
TOOL RECEPTACLE CABLE CONNECTORS
BLACK
RED
SOLENOID SPECIFICATIONS
6V DC-8V DC CONTINUOUS VOLTAGE
24V DC-36V DC FOR 15 msec MAX.
14.95ohm RESISTANCE
SOLENOID RETAINER
PLUNGER PIN
HAT
.015/.020
1. Solenoid plunger pin to hat dimension should be .015/.020 as shown. A new plunger pin should be
spaced as shown; however, a previously used plunger pin must be pressed to this dimension.
2. Assemble the solenoid components as shown. Solenoid retainer must be torqued to 10 to 12 ft. lbs.
using 242 Loctite. Note: Overtightening may damage solenoid body. Undertightening may result in
air leakage that may affect operation.
3. Connect tool to air supply. Air supply operating pressure should be between 40 and 90 PSI.
ADJUSTMENT SCREW

9
6. While keeping throttle lever fully depressed and using the 5/64" hex
wrench, turn adjustment screw counterclockwise until motor stops. At this
point rotate the screw an additional 1/2 turn counterclockwise.
7. Connect tool electronics. Tool should now shut off automatically at programed
torque limits.
SOLENOID RETAINER
PLUNGER PIN
HAT
ADJUSTMENT SCREW
5/64 HEX WRENCH
SOLENOID SEAT VALVE PLUNGER
SOLENOID RETAINER
PLUNGER PIN
HAT
4. Using a 5/64" hex wrench, turn adjustment screw clockwise until plunger pin is pressed through
hat and valve plunger is fully seated in solenoid seat.
5. Depress throttle and check tool for rated speed at 90PSI. If tool does not perform according
to specifications, valve plunger may not be fully depressed. Continue to turn
adjustment screw clockwise.
Note: Do not exceed 76 in. lbs. torque.
ADJUSTMENT SCREW
5/64 HEX WRENCH
SOLENOID SEAT VALVE PLUNGER

10
TRANSDUCERIZED & SOLENOID CONTROL TOOL WIRING DIAGRAM
TRANDUCER
WHITE
BLACK
GREEN
RED
A + EXCITATION
BLACK
GREEN
RED
SHIELD
CAMBION
CONNECTORS
6 PIN CONNECTOR
WHITE B - EXCITATION
C + SIGNAL
D - SIGNAL
E SHIELD
A + SOLENOID
RED
RED
SOLENOID
CAMBION
CONNECTORS
BLACK
BLACK
FIXTURE MOUNTED SOLENOID CONTROL TOOL WIRING DIAGRAM
B - SOLENOID
C
3 PIN CONNECTOR
F

11
R6 FIXTURE MOUNTED TOOL
TRANSDUCERIZED SPINDLE ASSEMBLIES
PARTS LIST —SPINDLE ASSEMBLIES
NAME OF PART
Spindle Drive (Std.)
Spindle Retainer
Spring
Retractable Spindle 1/2" (incl. 844011,
844013, 844014)
Dowel Pin
Flanged Transducer (incl. 202931,
202932, 203000, 413224)
Needle Bearing
Button Head Cap Screw (incl. in 202925)
Socket Hex Cap Screw
Spindle Drive (2" Ext.)
Spindle Drive (4" Ext.)
Spindle Drive (6" Ext.)
PART NO.
202912
202914
202915
202918
202920
202925
202930
202932
202957
202966
202967
202968
QTY.
1
1
1
1
1
1
1
4
2
1
1
1
PART NO.
202976
203000
413224
843179
844011
844013
844014
844016
844017
863093
864471
NAME OF PART
Retractable Spindle 3/8" Sq. Dr. (incl.
844013, 844016, 844017)
Gasket (incl. in 202925)
Button Head Cap Screw 6-32UNC x 1/4
(incl. in 202925)
Retainer Ring
Lock Pin (incl. in 202918)
Lock Pin Sleeve (incl. in 202918 &
202976-7)
Lock Pin Spring (incl. in 202918)
Lock Pin (incl. in 202976)
Lock Pin Spring (incl. in 202976)
"O"-ring 1-1/8" x 1"
Ball Bearing
QTY.
1
1
6
1
1
1
1
1
1
1
1
The complete spindle assemblies can be purchased as a sub-assembly using the following part numbers: 201346 - 1/2" sq. dr.
201374 - 3/8" sq. dr.
202912 Std.
202966 2
202967 4
202968 6
202930
202925
864471
843179
863093
*202932 (4Req.)
*202931
*203000
202976 3/8"
202918 1/2"
844016 3/8"
844011 1/2"
202920
202915
202914
844017 3/8"
844014 1/2"
844013 3/8"
844013 1/2"
202957 (2Req.)

12
FIXTURE MOUNTED TOOL
TRANDUCERIZED AND NON-TRANDUCERIZED GEAR TRAINS
The complete Non-Transducerized Gear Trains can be purchased as a subassembly using the following part numbers:
-2 - 201310, -3 - 201311, -4 - 201312, -5 - 201313.
The complete Transducerized Gear Trains can be purchased as a subassembly using the following part number:
-2 - 201350, -3 - 201351, -4 - 201352, -5 - 201353.
*Parts not included in subassemblies
PART NO.NAME OF PART
-2, -3, -4, -6 —Ring Gear (Transducerized
Only)*
-2, -3, -4, -6 —Hex Soc. Hd. Cap Screw*
-2, -4 —2nd Red. Spider
-3, -6 —2nd Red. Spider
-2, -4 —2nd Red. Gear (incl. 844774)
-3, -6 —2nd Red. Gear- (15T) (incl. 844774)
Gear Case Spacer (Non-Transducerized Only)
2nd Red. Gear Pin
-2, -3, -4, -6 —1st Red. Gear Pin
Gear Bearing
QTY.
QTY.
1
2
1
1
3
3
1
3
3
9
NAME OF PART
PART NO.
202907
202957
203104
203105
203106
203107
203192
204809
832125
844774
861484
861485
861486
861525
867523
867524
867526
867544
-4 —1st Red. Spider- (13T) (incl. Pin)
-3 —1st Red. Spider- (19T) (incl. Pin)
-6 —1st Red. Spider- (19T) (incl. Pin)
-2 —1st Red. Spider- (13T) (incl. Pin)
-4, -6 —1st Red. Gear- (17T) (incl. 844774)
-4, -6 —Rotor Pinion- (16T)
-2, -3 —1st Red. Gear- (21T) (incl. 844774)
Gear Case- (50T) (Non-Transducerized Only)
1
1
1
1
3
1
3
1
844774
867544
Non-Trans.
Only
832125
Part No. Model
203104-5 -2
203105-2 -3
203104-5 -4
203105-2 -6
Part No. Model
203106 -2
203107 -3
203106 -4
203107 -6
204809
Part No. Model
861525 -2
861485 -3
861484 -4
861486 -6
Part No. Model
867526 -2
867526 -3
867523 -4
867523 -6
Part No. Model
NONE -2
NONE -3
867524 -4
867524 -6
202907
Trans. Only
(Not Included
in Sub-assembly)
202980
Trans. Only
(Not Included
in Sub-assembly)
202957
Trans. Only
(Not Included
in Sub-assembly)
203192
Non-Trans.
Only
Part No. Model
844774 -2
844774 -3
844774 -4
844774 -6

13
55MTC SOLENOID CONTROLLED FIXTURE MOUNTED TOOL
MOTOR UNITS
PART NO.
202230
203101
203102
203182
619377
QTY.
1
1
1
5
1
NAME OF PART
Rear Motor Bearing
Cylinder Roll Pin
Rotor Lock Nut
Rotor Blade
Rear Bearing Plate
PART NO.
843444
863887
865352
869569
869572
QTY.
1
1
1
1
1
NAME OF PART
"O"-ring 1-5/8" x 1-1/2"
Cylinder (incl. 863887)
Rotor
Front Bearing Plate
Front MotorBearing
PARTS LIST —55MTC MOTOR UNITS
203102
863887
619377
869569
867536
843444
865352
869572
202230 203101

14
45MTC SOLENOID CONTROLLED FIXTURE MOUNTED TOOL
MOTOR UNITS
PART NO.
202230
203168
203169
203182
619377
812164
QTY.
1
1
1
5
NAME OF PART
Rear Motor Bearing
Rotor Lock Nut
Rear Bearing Plate
Rotor Blade
PART NO.
843444
865352
869574
869575
QTY.
1
1
1
1
1
1
NAME OF PART
"O"-ring 1-5/8" x 1-1/2"
Rotor
Cylinder (incl. 812164)
Front Bearing Plate
Front Motor Bearing
Cylinder Roll Pin
PARTS LIST —45MTC MOTOR UNITS
203168
812164
619377
869575
843444
865352
869574
202230 203169
203182
Not shown
203678 Transducer Adaptor
204360 Connector Spacer

15
203423
863241
203369
203363
203365
203368
203367
844265
203366
847710
203380
203377
863399
203428
203155
863454
202932
203426
203378
203550
203379
202012 202558
617754 867732
867758
843434
203181
844307
844568
202012 617754
203552
203189
45 Models Only
843434
The Motor Housing Subassembly can be purchased using
part number 201414.
*Parts not included in subassemblies.
PART NO.
202012
202558
202932
203155
203181
203189
203363
203365
203366
203367
203368
203369
203377
203378
203379
203380
203423
203426
203428
203550
203552
617754
843434
844265
844307
844568
847710
863241
863399
863454
867732
867758
NAME OF PART
Muffler
Exhaust Deflector
Button Head Cap Screw
Button Head Cap Screw
Flow Valve
Motor Cage (45 Models Only)*
Solenoid
Valve Plunger
Solenoid Valve Spring
Solenoid Seat Gasket
Solenoid Seat
Solenoid Retainer (incl. 863241)
Valve Piston (incl. 863399)
Shut-off Valve (incl. 203379)
Seal
Valve Cap (incl. 847710)
Shut-off Valve Spring
Solenoid Connector
Connector Block
Shut-off Valve Cap (incl. 863454)
Backhead
"O"-ring 1-1/4" x 1-3/8"
Pipe Plug
Ball (1/8" Dia.)
"O"-ring 1-1/4" x 1-3/8"
Retainer Ring
"O"-ring 1/2" x 5/8"
Set Screw
"O"-ring 7/16" x 9/16"
"O"-ring 9/16" x 11/16"
"O"-ring 1-5/16" x 1-3/16"
Inlet Bushing
QTY.
2
1
4
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3
2
1
1
1
1
1
1
1
1
1
PARTS LIST —MOTOR HOUSINGS
45MTC & 55MTC FIXTURE SOLENOID CONTROLLED MOUNTED TOOL
MOTOR HOUSINGS

16
CooperTools
670 Industrial Drive
Lexington, SC 29072
Phone: (803) 359-1200
Fax: (803) 359-2013
www.cooperindustries.com
This manual suits for next models
1
Table of contents
Other Cooper Tools Power Tools manuals

Cooper Tools
Cooper Tools Cleco 5 SAD Series Installation and operating instructions

Cooper Tools
Cooper Tools Cleco 250PTHF226 User manual

Cooper Tools
Cooper Tools 35 Series Installation and operating instructions

Cooper Tools
Cooper Tools Cleco 30PTH Series User manual

Cooper Tools
Cooper Tools Cleco LIVEWIRE 47BA B Series User manual

Cooper Tools
Cooper Tools Cleco 88 Series Installation and operating instructions

Cooper Tools
Cooper Tools CLECO 20PH Series User manual
