Coopers of Stortford F994 User manual

Skirting Board Heater F994 Instructions for Use
Please read and retain these instructions for future reference v001: 04/03/19
Voltage Rating: 220-240 V (50/60Hz)
Power Consumption: 1100-1300W
Unit Size:
12.5cm (W)x 65cm (D) x 24.5cm (H)/
(4.92 in. (W) x 25.59 in. (D) x 9.65 in.
(H))
Unit Weight: 1.72kg/3.79 lbs
THIS PRODUCT IS ONLY SUITABLE FOR WELL INSULATED SPACES OR OCCASIONAL USE.
WARNING! DO NOT COVER WHEN IN USE.
This heater is not intended for use in bathrooms, laundry areas and similar indoor
locations. NEVER locate heater where it may fall into a bathtub or other water container.
To protect against electrical hazards, DO NOT immerse in water or other liquids.
DO NOT touch the control panel or plug with a wet hand.
Overheat Safety Feature
This heater is equipped with an overheat safety feature. When the heater’s internal components
reach a certain temperature that could cause overheating and possible fire, the heater will
automatically shut off.
WARNING: It is normal for the power cord to feel warm to the touch; however, a loose fit between
the outlet and the plug may cause overheating of the plug. If this occurs, try inserting the plug into
a different outlet. Contact a qualified electrician to inspect the original outlet for damage.
Product Diagram:
Picture 1
WARNING
DO NOT COVER

Skirting Board Heater F994 Instructions for Use
Please read and retain these instructions for future reference v001: 04/03/19
Instruction for Use
1. Connect the heater and get it started;
2. Rotate the adjustable thermostat clockwise. Turn the thermostat knob to the "MAX position "
(Pic3);
3. Users can turn the switch clockwise to the “ ”（650W）or“ ”（1300W）position according
to their needs. The power indicator light (Pic4) is on when the switch turns to “ ”（650W）;
Picture 2
Picture 3 Picture 4
WARNINGS AND SAFETY INSTRUCTIONS:
WHEN USING ELECTRICAL APPLIANCES, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE
FOLLOWED:
READ ALL INSTRUCTIONS BEFORE USE.
FOR DOMESTIC INDOOR USE ONLY. DO NOT USE OUTDOORS OR FOR COMMERCIAL USE.

Skirting Board Heater F994 Instructions for Use
Please read and retain these instructions for future reference v001: 04/03/19
BEFORE USE, CHECK THOROUGHLY FOR ANY DEFECTS AND DO NOT USE IF DEFECTS ARE
FOUND. TAKE CARE NOT TO DROP THE APPLIANCE AS HEAVY IMPACTS MAY CAUSE
INTERNAL DAMAGE.
BEFORE CONNECTING THE APPLIANCE, CHECK IF THE VOLTAGE INDICATED ON THE BOTTOM
OF THE APPLIANCE IS IN ACCORDANCE WITH THE MAINS VOLTAGE IN YOUR HOME.
CHECK THE APPLIANCE AND POWER CABLE CAREFULLY FOR DAMAGE BEFORE EACH USE.
THIS APPLIANCE CAN BE USED BY CHILDREN AGED FROM 8 YEARS AND ABOVE AND
PERSONS WITH REDUCED PHYSICAL, SENSORY OR MENTAL CAPABILITIES OR LACK OF
EXPERIENCE AND KNOWLEDGE IF THEY HAVE BEEN GIVEN SUPERVISION OR INSTRUCTION
CONCERNING USE OF THE APPLIANCE IN A SAFE WAY AND UNDERSTAND THE HAZARDS
INVOLVED. CHILDREN SHALL NOT PLAY WITH THE APPLIANCE. CLEANING AND USER
MAINTENANCE SHALL NOT BE MADE BY CHILDREN WITHOUT SUPERVISION.
CHILDREN OF LESS THAN 3 YEARS SHOULD BE KEPT AWAY UNLESS CONTINUOUSLY
SUPERVISED.
SOME PARTS OF THIS PRODUCT CAN BECOME VERY HOT AND CAUSE BURNS. PARTICULAR
ATTENTION HAS TO BE GIVEN WHERE CHILDREN AND VULNERABLE PEOPLE ARE PRESENT.
THE USE OF ANY ACCESSORY ATTACHMENTS NOT RECOMMENDED BY COOPERS OF
STORTFORD MAY CAUSE INJURIES AND INVALIDATE ANY WARRANTY YOU MAY HAVE.
DO NOT LET THE POWER CABLE HANG OVER THE EDGE OF A TABLE OR COUNTER, OR
TOUCH HOT SURFACES.
DO NOT PLACE ON OR NEAR HEAT SOURCES.
USE ON A LEVEL, STABLE SURFACE.
DO NOT COVER THE ITEM IN ANY WAY WHEN IN USE AS THIS MAY CAUSE OVERHEATING.
DO NOT USE THIS APPLIANCE FOR ANY OTHER USE THAN THE INTENDED USE IT IS DESIGNED
FOR.
ENSURE THERE IS SUFFICIENT DISTANCE BETWEEN THIS APPLIANCE AND OTHER ITEMS ON
THE WORK SURFACE OR WORK STATION, OR SUFFICIENT DISTANCE BETWEEN THE
APPLIANCE AND THE CONFINES OF THE AREA IN WHICH IT IS SITUATED. WE RECOMMEND A
MINIMUM CLEARANCE AROUND ALL FACES OF AT LEAST 10CM.
DO NOT PLACE UNDER OR NEAR FLAMMABLE MATERIALS SUCH AS CURTAINS, DRAPERIES,
SHELVES, LOOSE WALL PAPER, ETC.
ALLOW THE ITEM TO COOL THOROUGHLY BEFORE PUTTING ON OR TAKING OFF PARTS.
DO NOT PLACE THIS ITEM IMMEDIATELY BELOW A SOCKET-OUTLET.
KEEP ITEM AT LEAST 1M AWAY FROM COMBUSTIBLE MATERIAL SUCH AS FURNITURE,
CUSHIONS, BEDDING, PAPER, CLOTHES, CURTAINS ETC.
TO PROTECT AGAINST ELECTRIC SHOCK, DO NOT IMMERSE POWER CABLE, PLUG OR
APPLIANCE, IN WATER OR ANY OTHER LIQUID.
UNPLUG FROM OUTLET WHEN NOT IN USE AND BEFORE CLEANING.
•DO NOT OPERATE ANY APPLIANCE WITH A DAMAGED POWER CABLE OR PLUG OR AFTER
THE APPLIANCE MALFUNCTIONS, OR HAS BEEN DAMAGED IN ANY MANNER. WE
RECOMMEND THAT THE POWER CABLE IS NOT KINKED OR STORED IN A TWISTED MANNER,
AND THAT YOU REGULARLY CHECK ITS CONDITION.

Skirting Board Heater F994 Instructions for Use
Please read and retain these instructions for future reference v001: 04/03/19
•ANY REPAIRS MUST BE CONDUCTED BY A QUALIFIED ELECTRICIAN OR ELECTRICAL SERVICE
AGENT.

Skirting Board Heater F994 Instructions for Use
Please read and retain these instructions for future reference v001: 04/03/19
COMMISSION REGULATION (EU) 2015/1188 HEATING TECHNICAL DETAILS:
Model identifier(s): F994
Item
Symbol
Value
Unit
Heat output
Nominal heat output
Pnom
1,3
kW
Minimum heat output (indicative)
Pmin
0,65
kW
Maximum continuous heat output
Pmax,c
1,3
kW
Auxiliary electricity consumption
At nominal heat output
elmax
0
kW
At minimum heat output
elmin
0
kW
in standby mode
elSB
0
kW
Item
Unit
Type of heat input, for electric storage local space heaters only (select one)
manual heat charge control, with integrated thermostat
No
manual heat charge control with room and/or outdoor temperature feedback
No
electronic heat charge control with room and/or outdoor temperature feedback
No
fan assisted heat output
No
Type of heat output/room temperature control (select one)
single stage heat output and no room temperature control
No
Two or more manual stages, no room temperature control
No
with mechanic thermostat room temperature control
Yes
with electronic room temperature control
No
electronic room temperature control plus day timer
No
electronic room temperature control plus week timer
No
Other control options (multiple selections possible)
room temperature control, with presence detection
No
room temperature control, with open window detection
No
with distance control option
No
with adaptive start control
No
with working time limitation
No
with black bulb sensor
No
Contact details:
COOPERS OF STORTFORD,
11 BRIDGE STREET,
BISHOPS’S STORTFORD, HERTFORDHSIRE, UK CM23 2JU
PLUG WIRING (UK & IRELAND)
This appliance is fitted with a BS 1363 13-amp plug. If you have to replace the fuse, only those that
are ASTA or BSI approved to BS1362 and with a rated current of 13-amps should be used. If there is
a fuse cover fitted, this cover must be re-fitted after changing the fuse. If the fuse cover is lost or
damaged the plug must not be used. Spare fuse holders and fuses are available from electrical
outlets. If the socket outlets in your home or office are not suitable for this product’s plug, the plug

Skirting Board Heater F994 Instructions for Use
Please read and retain these instructions for future reference v001: 04/03/19
must be removed and disposed of safely. Attempts to insert the plug into the wrong socket is likely
to cause electric hazard. A replacement plug should be wired according to the following
instructions:
The cable
A mains electricity cable contains two or three inner wires. Each has a core of copper and an outer
layer of flexible plastic. This product is earthed; the wires in the plug are colour coded in the
following way:
BLUE NEUTRAL
BROWN LIVE
GREEN & YELLOW EARTH
The diagram below shows the key features of a correctly wired three-pin mains plug.
MAINTENANCE
1. Turn off the power switch in the rear of the unit.
2. Unplug the unit and let it cool completely.
3. To keep the heater clean, the outer shell may be cleaned with a soft, damp cloth. You may
use a mild detergent if necessary. After cleaning, dry the unit with a soft cloth. CAUTION: DO
NOT let liquid enter the heater.
4. DO NOT use alcohol, gasoline, abrasive powders, furniture polish, or rough brushes to clean
the heater. This may cause damage or deterioration to the surface of the heater.
5. DO NOT immerse the heater in water.
6. Wait until the unit is completely dry before use.
STORAGE
Store the heater in a cool, dry location when not in use. To prevent dust and dirt build-up,
use the original packaging to repack the unit.
TROUBLESHOOTING
If the heater will not operate, please check the following before seeking repair of service:
Check if the power cord is plugged into an electrical outlet, if not, plug in.
Check if electricity to the main fuse is working.
CARE AND CLEANING INSTRUCTIONS

Skirting Board Heater F994 Instructions for Use
Please read and retain these instructions for future reference v001: 04/03/19
Always switch off and unplug before cleaning.
Do NOT immerse in water. Risk of electric shock.
Do NOT use abrasive cleaners or sharp utensils to clean this appliance.
Wipe surfaces with a soft dry cloth.
Allow to dry thoroughly before further use.
Store the appliance in a cool, dry place.
DISPOSAL
•Dispose of all packaging, paper, cartons and plastic, plastic bags in accordance with your local
recycling regulations.
•At the end of the product’s lifespan please dispose of it at an authorised household WEEE waste
recycling centre.
