Installation Instructions
ED5200(S)N & ED5600N Series Exit Devices
(Includes: Rim & Mortise)
IN120 WiFi
WARNING
This product can expose
you to lead which is
known to the state of
California to cause cancer
and birth defects or other
reproductive harm. For
more information go to
www.P65warnings.ca.gov.
08/2018

2
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5200N & ED5600N Series
Exit Devices For 9100/9M100
IN120 Series Trim
1) Warning
Table of Contents
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a resi-
dential installation.
This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no guarantee that the inter-
ference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced technician for help
The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were
met. This Class B digital apparatus meets all requirements of the Canadian Interference Causing Equipment Regulations.
Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause undesired operation.
Cet appareillage numérique de la classe B répond à toutes les exigences de l’interférence canadienne causant des
règlements d’équipement. L’opération est sujette aux deux conditions suivantes: (1) ce dispositif peut ne pas causer
l’interférence nocive, et (2) ce dispositif doit accepter n’importe quelle interférence reçue, y compris l’interférence qui
peut causer l’opération peu désirée.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
!
To comply with “Fire Listed” doors, the batteries must be replaced with alkaline batteries only.
Observe precautions for handling electrostatic sensitive devices.
!
1) Warning .................................................................................... 2
2) General Description.................................................................. 3
3) Specifications / Features ......................................................... 3
4) Product Illustration .................................................................. 4
5) Rim Exit Installation Instructions ............................................ 5
6) Mortise Exit Installation Instructions......................................10
7) IN120 Installation Instructions................................................17
8) Operational Check................................................................... 26

3
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5200N & ED5600N Series
Exit Devices For 9100/9M100
IN120 Series Trim
2) General Description
3) Specifications / Features
• Latch – Stainless steel, ¾” (19mm) throw deadlocking
fire latch
• Deadlocking latch prevents manipulation when door
closed
• Door Thickness – 1-3/4” (44mm) to 2” (50mm) Standard
Optional 2” (50mm) to 2-1/4” (57mm) optional
• ADA Compliant
• ANSI/BHMA A156.25 Listed Grade 1 Compliant
• May be used for indoor and outdoor applications
Electrical Specifications:
NOTE: A weather-protective gasket is required for outdoor applications.
Hardware Specifications
• Multiple time zone and holiday access scheduling
• First-in unlock or automatic unlock configuration,
based on specified time schedule
• 2,400 users per lock; 10,000 event audit trail
• Privacy button
• Power Requirements: 55VDC, 90mA
• HID®multiCLASS SE®technology offers support for
the following credentials:
• 2.4 GHz credential compatibility:
• 125 kHz credential compatibilty:
• HID Prox®
• 13.56 MHz credential compatibility:
• iCLASS®
• iCLASS SE®(SIO-enabled)
• iCLASS Seos®
• SIO on MIFARE®Classic
• SIO on MIFARE®DESfire®EV1
• MIFARE®Classic
• DESfire®EV1
• NFC-enabled mobile phones
• Secure Identity Object™(SIO) on Mobile IDs
(Bluetooth Smart)
• UL 294 Access Control Performance Ratings:
Destructive Attack Level I
Line Security Level I
Endurance Level IV
Standby Power Level I
• UL Listed - UL 294 Indoor Use
• CUL Listed - S319: Class 1
!*To comply with “Fire Listed” doors, the batteries must be replaced with alkaline batteries only.
The Corbin Russwin IN120 pairs a sleek, attractive design with the latest in access control technology to address
the evolving needs of today’s facilities. Featuring HID®multiCLASS SE®technology, this innovative WiFi lock
makes it easy and affordable to expand your access control system.
This product is operated by six (6) “AA” alkaline batteries, or can be hard-powered using an optional 9-24VDC
power supply connected by a harness through the door.
Corbin Russwin mortise locks are designed with quality components to provide high security, performance
and durability.

4
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5200N & ED5600N Series
Exit Devices For 9100/9M100
IN120 Series Trim
4) Product Illustration
1
4
3
2
Reader Module
**Specify finish
ITEM PART NUMBER/ORDER STRING DESCRIPTION COLOR/TRIM QTY
1* IN-120-EM01-[B]IP-B Reader assembly - black plastic Black 1
IN-120-EM01-[B]IP-W Reader assembly - white plastic White 1
IN-120-EM01-[B]IP-MB-[finish]** Reader assembly - black plastic with metal trim Black with metal trim 1
IN-120-EM01-[B]IP-MW-[finish]** Reader assembly - white plastic with metal trim White with metal trim 1
IN-120-EM01-[B]IPS-B Reader assembly - black plastic Black 1
IN-120-EM01-[B]IPS-W Reader assembly - white plastic White 1
IN-120-EM01-[B]IPS-MB-[finish]** Reader assembly - black plastic with metal trim Black with metal trim 1
IN-120-EM01-[B]IPS-MW-[finish]** Reader assembly - white plastic with metal trim White with metal trim 1
IN-120-EM01-[B]CP-B Reader assembly - black plastic Black 1
IN-120-EM01-[B]CP-W Reader assembly - white plastic White 1
IN-120-EM01-[B]CP-MB-[finish]** Reader assembly - black plastic with metal trim Black with metal trim 1
IN-120-EM01-[B]CP-MW-[finish]** Reader assembly - white plastic with metal trim White with metal trim 1
2 782F718 Inside Mounting Kit (mounting plate & hardware) 1
3 784F259 Controller Assembly 1
4 782F729 Inside Escutcheon Black 1
782F739 Inside Escutcheon White
783F725 FIN** Inside Escutcheon Black with metal trim
783F735 FIN** Inside Escutcheon White with metal trim
5 FM355 Field prep template (not shown) 1
6 T31203 Door manufacturers template (not shown) 1
-- FM432 Instructions (this manual) 1
*Specifying Bindicates BLE (Bluetooth) option when ordering

5
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5200N Series Exit Devices For
9100 IN120 Series Trim
1. Verify Hand and Bevel of door:
Door should be fitted and hung.
Verify box label for size of exit device,
function and hand. Left Hand
Reverse
LHR Outside
Inside
Right Hand
Reverse
RHR
Inside of Door
2. Prep door according to Door Marker (FM429)
Wood Door Preparation
Fig. 1
Fig. 2
Backplate
Mount Holes
Trim Tailpiece
Hole
Door Position Switch
(DPS) Raceway
Raceway
for Auxiliary
Hard-power
For door manufacturer templates visit www.corbinrusswin.com
and reference template #’s T31235 & T31236.
Outside of Door
Through-bolt
Holes
Through-bolt
Holes
Raceway
for Auxiliary
Hard-power
5) Rim Exit Installation Instructions
Through-bolt
Holes

6
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5200N Series Exit Devices For
9100 IN120 Series Trim
a. Insert DPS into the raceway on the latch edge of the door.
b. Push wires through raceway toward lock prep.
c. Push DPS firmly into place by hand.
Note: DO NOT TAP SWITCH WITH ANY TOOL.
d. Install magnet into door frame. Push firmly into place by hand.
See instruction A7983.
3. Install Door Position Switch (DPS)
CAUTION: if DPS is not installed or is installed
improperly, door status monitoring features will
not function.
5) Rim Exit Installation Instructions (Continued)
Fig. 3

7
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5200N Series Exit Devices For
9100 IN120 Series Trim
Cylinder Collar Chart
Cylinder Length Collar
Inches Millimeters
1-1/8" 29mm None
1-1/4" 32mm 422F88*
1-1/2" 38mm 686F98*
*Specify Finish Fig. 4a
Rim Cylinder
Cylinder Collar
(if necessary)
Escutcheon
Assembly
4. Trim Assembly Instructions:
a. Check cylinder components:
Cylinders longer than 1-1/8" (29mm) require collars.
Refer to Cylinder Collar Chart (Fig. 4a).
(for Mortise, skip to Step 5)
b. If required, modify by cutting cylinder tailpiece:
Correct length is 1/16" to 3/16" (2 to 5mm)
beyond cylinder housing cam.
c. Assemble cylinder:
1. Insert cylinder housing prongs into matching notches of escutcheon.
2. Pass cylinder tailpiece through cylinder collar (if required) and slot in cylinder cam.
3. Fasten cylinder in escutcheon recess or collar using 2 mounting screws.
Do not overtighten screws.
d. Escutcheon Assembly (Fig. 4b):
The lever is handed (LHR shown).
Note: Lever Return Spring handing can be identified by the color of the spring:
• LHR: Part Number 651F618 (Red)
• RHR: Part Number 651F628 (Blue)
Fig. 4b
5) Rim Exit Installation Instructions (Continued)
Cam must be postitioned as shown
when cylinder tailpiece is assembled
Cylinder Housing
Cam
(2) Cylinder Mounting Screws
(supplied with cylinder)

8
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5200N Series Exit Devices For
9100 IN120 Series Trim
5) Rim Exit Installation Instructions (Continued)
Fig. 5b (door not shown)
Tailpiece
Fig. 5d
Tighten
securely
Fig. 5a
Outside Face of
Door
5. Install Exit Device:
a. Feed trim harness through upper hole in cutout (Fig. 5a).
b. Seat device against door being careful to align vertical trim tailpiece to engage with
cross hole of device cam - see Figure 5b.
c. Fasten device to trim assembly using (2) 1/4-20 pan head screws (Fig. 5c).
d. Follow instructions packed with device to secure device to door.
e. Tighten all (4) screws (Fig. 5d).
Inside Face of
Door
Fig. 5c
Tailpiece
Door
Position
Switch

9
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5200N Series Exit Devices For
9100 IN120 Series Trim
6. Harness Connections:
a. Connect motor harness adapter to chassis harness connector (Fig. 6).
b. Connect rail assembly harness adapter to chassis harness connector (Fig. 6).
5) Rim Exit Installation Instructions (Continued)
Chassis
Harness
Rail Assembly
Harness Adapter
Fig. 6
Not used*
*Not used in typical installation

10
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5200N Series Exit Devices For
9100 IN120 Series Trim
5) Rim Exit Installation Instructions (Continued)
7. Install Head Cover:
a. Lay device wire harnesses across 1” hole (Fig. 7a).
b. Tuck wires into hole when installing cover so that wires are not pinched between head cover
and door.
c. Attach head cover using (2) #8-32 flat head screws (Fig. 7b).
Use 1” hole to
tuck trim and
device wire
harness under
head cover
Fig. 7a Fig. 7b
Important Note: Rim Exit Installation Continues on Page 15 - Section 7

11
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5600N Series Exit Devices For
9M100 IN120 Series Trim
1. Verify Hand and Bevel of door:
Door should be fitted and hung.
Verify box label for size of exit device,
function and hand. Left Hand
Reverse
LHR Outside
Inside
Right Hand
Reverse
RHR
Inside of Door
2. Prep door
Wood Door Preparation
Fig. 8
Fig. 9
For door manufacturer templates visit www.corbinrusswin.com
and reference template # T31237 (Wood).
Outside of Door
Raceway
for Auxiliary
Hard-Power
Through-bolt Holes Trim Tailpiece
Hole
6) Mortise Exit Installation Instructions
Raceway
for Auxiliary
Hard-Power
Door
Position
Switch

12
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5600N Series Exit Devices For
9M100 IN120 Series Trim
a. Insert DPS into the raceway on the latch edge of the door.
b. Push wires through raceway toward lock prep.
c. Push DPS firmly into place by hand.
Note: DO NOT TAP SWITCH WITH ANY TOOL.
d. Install magnet into door frame. Push firmly into place by hand.
See instruction A7983.
3. Install Door Position Switch (DPS)
CAUTION: if DPS is not installed or is installed
improperly, door status monitoring features will
not function.
Fig. 10
6) Mortise Exit Installation Instructions (Continued)

13
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5600N Series Exit Devices For
9M100 IN120 Series Trim
4. Install Mortise and Outside Trim Assembly:
a. Make sure tailpiece is oriented vertically.
b. Feed trim wire harness through wire harness hole (Fig. 11a).
c. Mount trim assembly to door pulling slack wire towards device side of door.
Note: Be careful not to pinch wire harness.
d. When mounting trim, lift tailpiece to pass through hole on device side (Fig. 11b).
Note: Ensure tailpiece is still oriented vertically.
e. Fasten trim assembly to door using (2) 1/4-20 oval head screws and (2) finish washers (Fig. 11b).
Note: Finger tighten only.
Fig. 11a Fig. 11b
6) Mortise Exit Installation Instructions (Continued)

14
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5600N Series Exit Devices For
9M100 IN120 Series Trim
5. Install Exit Device:
a. Seat device against door being careful to align vertical trim tailpiece to engage with
cross hole of device cam - see Figure 12a.
b. Fasten device to trim assembly using (2) 1/4-20 pan head screws (Fig. 12a).
c. Follow instructions packed with device to secure device to door.
d. Tighten all (4) screws (Fig. 12b).
Tighten
securely
6) Mortise Exit Installation Instructions (Continued)
Fig. 12a
Fig. 12b
Inside Face of
Door
Door
Position
Switch

15
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5600N Series Exit Devices For
9M100 IN120 Series Trim
6) Mortise Exit Installation Instructions (Continued)
6. Harness Connections:
a. Connect motor harness adapter to chassis harness connector (Fig. 13).
b. Connect rail assembly harness adapter to chassis harness connector (Fig. 13).
Chassis
Harness
Not used*
Rail Assembly
Harness Adapter
Fig. 13
*Not used in typical installation

16
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5600N Series Exit Devices For
9M100 IN120 Series Trim
6. Install Head Cover:
a. Lay device wire harnesses across ¾” hole (Fig. 14a).
b. Tuck wires into hole when installing cover so that wires are not pinched between
head cover and door.
c. Attach head cover using (2) #8-32 flat head screws (Fig. 14b).
Use 3/4” hole to
tuck trim and
device wire
harness under
head cover
6) Mortise Exit Installation Instructions (Continued)
Fig. 14a Fig. 14b
Mortise Exit Installation Continues on Next Page - Section 7

17
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5200N & ED5600N Series
Exit Devices For 9100/9M100
IN120 Series Trim
7) IN120 Installation Instructions
Fig. 15a
Outside Face of
Door
Reader Assembly
with Harness
LED
1. Install Outside Reader
a. Orient the reader so the LED lens is at the top.
b. Feed the reader harness through the door (from outside to inside).
c. Install the reader to the outside of door by aligning the mounting posts with the door
preparation holes. Hold the reader flush against door while ensuring proper alignment.

18
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5200N & ED5600N Series
Exit Devices For 9100/9M100
IN120 Series Trim
7) IN120 Installation Instructions (Continued)
1. Install Outside Reader - (Continued)
Gasket*
Mounting Plate
*Gasket is required for outdoor installations.
If installing with gasket; separate gasket from mounting plate to feed cables
through holes as indicated (Fig. 15b).
Once cables/connectors are fed through, reattach gasket to mounting plate.
Lock body Harness
Ground Lug
DPS
Reader Harness
e. When all connections have been made, tuck ferrite bead
and excess cable into wire hole on inside of door.
f. Secure the mounting assembly while ensuring proper
alignment of outside reader and tighten the (2) through-bolts
on the inside of the door to secure the reader (Fig. 15b).
g. Secure ground lug with #6-32 machine screw (Fig.15c).
d. Next feed the cables/connectors through the inside mounting assembly (and gasket if required*).
NOTE: Cable lengths exaggerated for illustrative purposes.
Inside of Door
Through -
bolt
Through -
bolt
Fig. 15c
Fig. 15b

19
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5200N & ED5600N Series
Exit Devices For 9100/9M100
IN120 Series Trim
7) IN120 Installation Instructions (Continued)
2. Installation of Connectors
CAUTION - Do not touch or allow debris to enter connector contacts.
*NOTE: Optional 2-pin external 12-24VDC power connector.
DPS (4-pin)
A
Lock
Body
(10-pin)
12-24VDC
Power*
Fig. 16a
Ground
Lug B
C
IMPORTANT: Do not run wires through hole in plate (Fig. 16b,c) - this
will damage wires and the controller connector.
Route wires around flange, do not route wires through the
flange hole (Fig. 16a, b).
D. Secure the 24-pin card reader connector (Fig. 16d).
Reader
(24-pin)
Board-to-Board
Connector
Fig. 16b
C
Secure the following connectors to their respective terminals (Fig. 16a ):
A. Secure the 4-pin DPS connector.
B. Secure the 10-pin lock body assembly connector.
C. Secure ground lug to #6-32 machine screw.
Fig. 16c
Inside
Face of
Door
Fig. 16d

20
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
ED5200N & ED5600N Series
Exit Devices For 9100/9M100
IN120 Series Trim
CAUTION: To avoid possible damage to board-to-board connectors, care should be taken
when securing controller to mounting plate. If there is resistance when securing,
detach controller to determine cause before re-attaching controller.
3. Install Controller Assembly
7) IN120 Installation Instructions (Continued)
Fig. 17a
Secure controller assembly to mounting plate by using bottom tab of mounting plate to locate
then gently push controller towards mounting plate until top tabs click into place (Fig. 17a-17c).
Fig. 17c
Tabs click in
here
Fig. 17b
