Corbin K-LR-22-RAL User manual

1. Begin by removing the stock seat (refer to
your owner’s manual).
2. Saddle mounts just like stock with brackets
preinstalled on the saddle.
3. To install your Rally saddle,
slide the Corbin
saddle into position and secure using the stock
bolts (Figure 1).
HEATER INSTALLATION:
1. If you ordered the heated model, we also
included a wiring pigtail that hooks into your stock
fusebox, so start by unlatching the fusebox cover.
2. Remove the 10 amp fuse from the
BRAKE/HORN position (Figures 2 & 3) and insert
the fuse into the adapter at the end of the wiring
pigtail (Figure 4).
3. When the pigtail is in place, the stock fuse
cover will not fit, so pull up on the fusebox to
release it from the clip (Figure 5), put the
provided rain cover over the clip (Figure 6), then
put the fusebox back in place, insert the adapter
into the fusebox in the space previously occupied
by the BRAKE/HORN fuse (Figure 7), then slip
the fuse adapter through the small hole on the
rain cover and cover the entire fusebox.
4. Connect wiring adapters together (Figure 8).
Part Number: K-LR-22-RAL(E) & K-LR-22-DL(E)
Description: Rally Saddle
Fitment: 2022 Kawasaki KLR 650
Revision: 1
Tools Required Parts List
10mm Socket or Combination Wrench
Needlenose Pliers 1 #CB-PWR-HRN-36=12” Wiring Harness / pigtail 1 #FACC-05 Small Fuse Adapter
1 Small Fuse Box Rain Cover
1 6" Zip Tie
FIG 1
FIG 2
FIG 4
FIG 3
FIG 5

Questions? Give us a holler...
800-223-4332
[e-mail]
5. Find a convenient place to ground the
negative lead of the pigtail to your chassis. We
used the spot shown in Figure 9, but any location
with good contact to ground will work fine.
6. Bundle loose wiring and secure it out of the
way with the included zip tie. Do not tighten
excessively or you may damage the wiring... just
secure it in place for cleanliness.
7. Plug in seat and test. To do this, just plug the
pigtail into the seat, turn on your ignition switch
and flip the switch on the saddle. If the switch
illuminates, the saddle heater is working.
8. Proceed with saddle mounting as outlined
above.
Enjoy your new saddle!
NOTE: The heater is controlled by the switch
along the side of the saddle. The temperature is
regulated by an internal thermostat when the
heater switch is turned on.
FIG 6
FIG 7
FIG 8
FIG 9
