Cordex TC7000 Quick guide

INSTRUCTIONS
FOR SAFE
OPERATIONS
TC7000
INTRINSICALLY
SAFE THERMAL
IMAGING CAMERA
RUGGED AUTHORITY www.cord-ex.com

CONTENTS READ THIS FIRST
Read This First
Safety Information
Faults and Damage
Safety Regulations
Special conditions for safe use
3
3
3
3
3
Labelling 4
Operational Cautions 5
Certification
EC Declaration of Conformity
ATEX / IECEx Certificate
6
7
8
The CorDEX Instruments TC7000 intrinsically
safe thermal imaging camera is designed for
non-contact temperature measurement. Read
and understand all Warnings and Cautions
before using this product.
Safety Information
This instruction manual contains information
and warning that must be observed for safe
operation under the conditions described.
Faults and Damage
If there are any grounds for believe the unit
is no longer safe to use, it must be taken out
of service and measures taken to prevent its
further unintentional use. The safety of the
device may be impaired if, for example:
• External damage to the unit is visible
• The device has not been stored correctly
• The unit has suffered transport damage
Safety Regulations
When using the TC7000, the appropriate
regulations must be observed to avoid
incorrect operation of the unit.
ATTENTION! Ensure that the case is securely
fastened when using the device. The device
must not be opened in the hazardous area.
Special Conditions for Safe Use
• The TC7000 Intrinsically safe thermal
imaging camera is powered by a Lithium Ion,
rechargeable battery pack.
• Do not remove or replace batteries within
the hazardous area.
• The battery pack must be removed from the
equipment in the safe area when charging
and the battery pack can only be charged in
the safe area.
• USB terminal must only be connected in the
safe area.
• For M2 only, the equipment must be de-
energized and removed from the hazardous
atmosphere is detected.
RUGGED AUTHORITY
T7000 – Intrinsically Safe Thermal Imaging Camera
3

Focus Ring 135˚ Swivel Lens
LABELLING
CorDEX Instruments Ltd. 1 Owens Rd, Middlesbrough, TS6 6HE, UK
TC7000- Thermal Camera
Ex i.b. IIC T4 GbTamb -10°C to +40°C
Ex i.b. IIIC T200°C DbTamb -10°C to +40°C
Ex i.b. I Mb
ATEX - TRAC12ATEX0037X
IECEx - IECEx TRC 12.0019X
Serial Number- XXXX-XX-XXXX
Year of Construction- YYYY
Powered by - Refer to Manual
I/II M2/2 GD
0518
DO NOT OPEN WHEN EXPLOSIVE ATMOSPHERE PRESENT
OPERATIONAL
CAUTIONS
The cautions contained in this section do not
relate specifically to safe use in hazardous
area applications but should be followed
to help prevent damage to the device or
personnel.
• Keep out of reach of children
• The TC7000 is a precision instruction. Do not
drop it, strike it or use excessive force when
handling
Maintenance
For safety critical maintenance, please refer
to EN60079-17
RUGGED AUTHORITY
T7000 – Intrinsically Safe Thermal Imaging Camera
5

CERTIFICATION
Model TC7000
ATEX Certificate No. TRAC12ATEX0037X
Standards EN60079-0:2009, EN60079-11:2012
ATEX Coding
0518
II 2G Ex ib IIC T4 Gb
II 2D Ex ib IIIC T200°C Db
I M2 Ex ib I Mb
Tamb -10°C to +40°C
IECEx Certificate No IECEx TRC 12.0019X
Standards IEC60079-0:2007, IEC60079-11:2011
IECEx Coding Ex ib IIC T4 Gb
Ex ib IIIC T200°C Db
Ex ib I Mb
Tamb -10°C to +40°C
USB Terminal Parameters Um= 253V
Ambient Temperature -10 to +40°C
Power Supply 2 x Lithium Ion cells
EC DECLARATION
OF CONFORMITY
These will need
replacing with new
branded ones
RUGGED AUTHORITY
T7000 – Intrinsically Safe Thermal Imaging Camera
7

EC DECLARATION
OF CONFORMITY
RUGGED AUTHORITY
T7000 – Intrinsically Safe Thermal Imaging Camera
9

Copyright © 2014, CorDEX Instruments Limited.
All other brand and product names are
trademarks of CorDEX Instruments Limited. Document Reference: TC7000SOM Rev. B
