Coredy R650 User manual

Owner’s Manual
R650 Ultra

Important Safety Information
01
About Your Robot
04
Use Your Robot
10
Care and Maintenance
21
Troubleshooting
28
Specifications
31
Table of Contents
Thank you for purchasing Coredy robot vacuum cleaner, please carefully read all instructions before using this robot, and keep
this user manual properly for future reference.

Usage Restrictions
Important Safety Information
This appliance can be used by children ages from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge only if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision. Children younger than 8 years old should not use this device.
The robot must be used in accordance with the directions in this Instruction Manual. Coredy Inc. cannot be held liable or
responsible for any damages or injuries caused by improper use.
Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local
authority for information regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps,
hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well-being. Please
contact your local or regional waste authority for more information on collection, reuse and recycling programs.
To reduce the risk of injury or damage, keep these safety precautions in mind when setting up, using and maintaining your
robot:
Your robot is for indoor use only. Do not use the robot in outdoor, commercial or industrial environments.
Before using this device, pick up objects like clothing, loose papers, pull cords for blinds or curtains, power cords, and any
fragile objects. If the device passes over a power cord and drags it, there is a chance an object could be pulled off of a table
or shelf.
Read all safety and operating instructions before operating your robot.
Retain the safety and operating instructions for future reference.
Heed all warnings on your robot, battery, charging Dock and in the owner’s manual.
Follow all operating and use instructions.
The symbol on the product or its packaging indicates:
01

Battery and Charging
Your robot is not a toy. Do not sit or stand on this device. Small children and pets should be supervised when your robot is
operating.
Store and operate your robot in room temperature environments only.
Do not use this device to pick up anything that is burning or smoking.
Do not use this device to pick up spills of bleach, paint, or other chemicals, or anything wet.
If the room to be cleaned contains a balcony, a physical barrier should be used to prevent access to the balcony and ensure
safe operation.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure they do not play with the robot. Cleaning and maintenance shall not be performed
by children without supervision.
Do not place anything on top of your robot.
Be aware that the robot moves on its own. Take care when walking in the area in which the robot is operating in to avoid
stepping or tripping on it.
Do not operate the robot in areas with exposed electrical outlets in the floor.
Use only rechargeable battery packs with the correct specification approved by Coredy.
Charge using a standard outlet only. Product may not be used with any type of power converter. Use of other power convert-
ers will immediately void the warranty.
Do not use a Charging Dock with a damaged cord or plug. If the cord or plug is damaged, it must be serviced by the manu-
facturer or similarly qualified persons.
Always charge and remove the battery from your robot and accessories before long-term storage or transportation.
Charge indoors only.
02

FCC Statement
Your robot’s Charging Dock may be protected with a surge protector in the event of severe electrical storms.
Never handle the Charging Dock with wet hands.
Always disconnect your robot from the Charging Dock before cleaning or maintaining it.
Please ensure voltage rating for enclosed Charging Dock matches standard outlet voltage.
Used battery packs should be placed in a sealed plastic bag and disposed of safely according to local environmental regula-
tions.
Before every use, check the battery pack for any sign of damage or leakage. Do not charge damaged or leaking battery
packs.
If the battery pack is leaking, contact Coredy Customer Service for disposal.
The battery pack must be removed from the robot before disposal.
Do not crush or dismantle battery packs. Do not heat or place the battery pack near any heat source.
Do not incinerate the battery pack. Do not short-circuit the battery pack.
Do not immerse the battery pack in any liquid.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
03

About Your Robot
Robot
a. Top & Side
Press and hold for 3 seconds to turn on or off
Press to start Auto Cleaning
Press to pause current cleaning task
Press to return the robot to the charging dock
Press again to pause
Press and hold both buttons for 5 seconds to reset Wi-Fi connection
+
04
Cover
Ventilation Holes
Recharge Button
Power Button
Wi-Fi Status Light
Bumper
Infrared Sensor

b. Bottom
c. Dustbin
05
Dust Bin
Left/Right Wheel
On/Off
Cliff Sensors
Charging Contact Pins
Universal Wheel
Side Brushes
Battery Compartment
Rolling Brush Guard
Rolling Brush
Release Button Suction Inlet

06
Status Light
Charging Contact Pins
Power Socket
Power Cord Storage Compartment
d. Charging Dock

07
e. Remote Control
Mode and time display screen
Automatic re-charging button
Automatic cleaning
Direction buttons
Clock setup button Scheduling button
Start / Pause button
Spot cleaning button Edge cleaning button
Random cleaning button Changing cleaning suction button
Install 2 AAA batteries (included in the package) before using the remote control.
MAX

Accessories
Charging Dock Adapter Remote Control
DustbinSide Brush
Cleaning Tool
Rolling Brush
MAX
08

09
Indication
Light Status Status
Breathing Blue Charging
Solid Blue Turn On/ Standby/ Cleaning/ Pause/Return to Charge
Red Error
Off Turn Off/ Sleep
+
Wi-Fi Status Light Status
Slowly Flashing Blue Wi-Fi Pairing
Rapidly Flashing Blue Waiting for connection
Solid Blue Wi-Fi connected

Use Your Robot
Notes Before Cleaning
Before using Robot, pick up objects like clothing, loose papers, pull cords for blinds or curtains, power cords,
and any fragile objects. If the Robot passes over a power cord and drags it, there is a chance an object could be
pulled off of a table or shelf.
The robot may not run on certain dark or black colored surfaces since the Anti-drop Sensors that recognize an
edge or a stair may regard this color as an edge.
10

Prepare Your Robot
1. Remove the protective form before use.
2. Install the side brushes.
3. Turn on the main power switch on the bottom of the robot.
Place Charging Dock
11
1. Place the charging dock on a hard, level surface and
against a wall.
2.Ensure the charging dock is in an open and uncluttered
area leaving at least:
- 6ft/2m in the front of the charging dock.
- 3ft/1m on both sides of the charging dock.
3.Connect the charging dock to the power outlet.
- When the charging dock connects to AC power, the LED
indicator on the charging dock is Solid White.
Wrap out the extra power cord.
Always keep the charging dock plugged in, otherwise
robot will not automatically return to it.

12
Charge Your Robot
Place your robot on the charging dock by aligning its
charging pins with the charging pins on the dock.
Robot cannot start cleaning if the battery power is low,
so please make sure the robot is fully charged before
first use.
Start/Stop Cleaning
Press on robot or / on the remote control
to start a cleaning cycle in Auto Mode.
Make sure the main power switch on the bottom of
robot is turned on before use.
Press on robot or on the remote control to stop
cleaning.
You can also start or stop cleaning via Coredy Robot app.
MAX
MAX

13
Reset Wi-Fi Connection
Press and hold + on the Robot for around 5
seconds until you hear two beeps from the robot and
the indicator lights on Robot is rapidly flashing blue.
Connect with Coredy App
Open the app and create a user account, and then follow
the instructions to add your R650 Ultra robot. (Refers to
“App Installation Guide” for detailed guidance.)
Select a Cleaning Mode
Auto Cleaning
Coredy R650 Ultra moves from the Charging Dock and
automatically determines its cleaning route, following a
row-by-row cleaning path. When the cleaning cycle is
finished, it automatically returns to the Charging Dock.
If the battery reaches low charge before finishing a
cleaning cycle, the robot will return to the Charging
Dock to recharge.
If the Charging Dock is inaccessible, robot will not be
able to recharge, please place the robot manually on
Charging Dock for charging.
Press on robot or / on the remote control to
start cleaning in Auto Cleaning mode.
MAX

14
Select a Suction Power Level
Press on the Remote Control to switch suction
power level, or select a suction power level in the Coredy
Robot app according to your needs:
Boost-Intellect Feature
Spot Cleaning
R650 Ultra supports Boost Intellect technology, when a
carpet is detected, suction is increased to 1600Pa suction
power from current suction power level. Once off the
carpet, normal suction returns.
If the level of the suction power is the maximum level
before cleaning on a carpet, the robot will continue
cleaning the carpet with the maximum power after moving
on the carpet.
When you select Spot Cleaning, robot intensely cleans a
localized area by spiraling outward about 3 feet (1 meter)
in diameter and then spiraling inward to where it started.
When Spot Cleaning, robot boosts its vacuum power to
provide the best cleaning possible where you need it.
To use Spot Cleaning, place robot on top of the localized
debris and press on the Remote Control, or select
Spot Cleaning mode in the Coredy Robot app.
Small
Standard (Default)
Strong
MAX
MAX
Coredy Robot

15
Edge Cleaning
After robot finishes cleaning the open areas of your floor,
it uses Edge Clean to ensure that it has cleaned along
walls and around furniture legs for a thorough clean.
Manual Cleaning
You can direct R650 Ultra to clean a particular area by
using the directional buttons on the remote control or
control in the Coredy Robot app.
If you prefer a quicker edge cleaning, press on
Remote Control or select Edge Cleaning mode in the
Coredy Robot app.
MAX
Coredy Robot
MAX
Coredy Robot
Move forward
Move backward
Turn left Turn right

16
Make sure the strip is placed FLAT on the floor.
If the Boundary Strip is rolled up, remove and
re-apply on the floor with adhesive tape. Otherwise,
the Boundary Strip may not work well.
Make sure the Boundary Strip is placed on the same
surface plane R650 Ultra is used on.
Be careful not to damage the floor when using
adhesive tape. It is not recommended for use on
carpets.
Keep the Boundary Strip away from objects that emit
excessive heat.
Random Cleaning Use the Boundary Strip
With the Boundary Strip, you can keep R650 Ultra away
from any area or item you do not want R650 Ultra to
clean. R650 Ultra will recognize the Boundary Strip and
will not cross into the blocked-off area.
1. Identify the area or item you do not want R650 Ultra to
get close to.
2. If necessary, use scissors to cut the Boundary Strip to
a shorter length. Be sure to correctly measure the length
before cutting.
3. Apply adhesive tape to lay the Boundary Strip flat on
the floor.
Press on Remote Control or select Random
Cleaning mode in the Coredy Robot app.
MAX
Coredy Robot
Boundary strip is sold separately.

17
Wet-Dry Mop Cleaning
Coredy R650 Ultra has a mopping system with an
electronically-controlled water pump, can automatically
control water flow to start/stop, offers 3 water flow levels,
ensuring intelligent mopping cleaning for your home.
1.Attach the mopping cloth to the Water Tank and fill the
Water Tank with water.
2. Remove the Dustbin from the robot.
Mop Cleaning cleans best on smooth hard surfaces
and may not perform so well on uneven tiles, heavily
waxed floors or rough surfaces
Do not use the mopping mode on a carpeted floor.
It is recommended to place boundary strips to avoid
cleaning the carpeted area.
The mopping mode is not recommended when no
one is at home.
Water tank and mopping cloth are sold separately.

18
3. Install the Water Tank into the robot.
4. Select a mopping level to start mopping.
Use the Coredy Robot App to select from 3 water flow
levels for mopping cleaning on the different surface floor.
5. When robot finishes working and returns to the Charging
Dock, press the release button to remove the Water Tank.
6. Put the Dustbin back into the robot.
After mopping, remove the water tank, empty any
remaining water and clean the mopping cloth to
prevent mildew or unpleasant smells.
