CoreTigo TigoBridge B1 User manual

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 1of 21
CoreTigo
TigoBridge B1
USER MANUAL

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 2of 21
Table of Contents
1. Introduction .........................................................................................................................................5
1.1. Structure........................................................................................................................................5
1.2. Typographical Conventions...........................................................................................................5
1.3. Symbols.........................................................................................................................................6
1.4. Deviating Views.............................................................................................................................6
2. Safety and Requirements...................................................................................................................6
2.1. General Note.................................................................................................................................6
2.2. Electrical Connection ....................................................................................................................6
2.3. Intended Use.................................................................................................................................6
2.4. Personnel Qualification .................................................................................................................7
3. Requirements ......................................................................................................................................8
4. Pre-Installation ....................................................................................................................................9
4.1. Description ....................................................................................................................................9
4.2. Overview .......................................................................................................................................9
4.2.1. Functional Diagram.............................................................................................................10
4.3. LEDS...........................................................................................................................................10
4.3.1. Power LED..........................................................................................................................10
4.3.2. Status LED..........................................................................................................................11
4.4. Pair by Button..............................................................................................................................11
4.5. Electrical Wiring...........................................................................................................................11
4.6. Electrical Connection ..................................................................................................................12
5. Mounting ............................................................................................................................................12
5.1. TigoBridge B1 Cradle..................................................................................................................12
6. Configuration & Setup......................................................................................................................13
7. Firmware Update...............................................................................................................................15
8. Diagnostics and Troubleshooting...................................................................................................16
8.1. Power LED..................................................................................................................................16
8.2. Status LED..................................................................................................................................16
9. Guidelines and Regulations.............................................................................................................17
9.1. RF Exposure Warnings...............................................................................................................17
9.2. Class A Warning .........................................................................................................................17
9.3. Modification Statements..............................................................................................................17
9.4. FCC Regulatory Notices .............................................................................................................17
10. Technical Data...................................................................................................................................18
11. Customer Support.............................................................................................................................20
Appendix A –Part Number.......................................................................................................................21

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 3of 21
List of Figures
Figure 1: TigoBridge B1................................................................................................................................5
Figure 2: TigoBridge B1 Overview................................................................................................................8
Figure 3: TigoBridge B1 Label ......................................................................................................................9
Figure 4: TigoBridge B1 Functional Diagram..............................................................................................10
Figure 5: TigoBridge B1 LEDs ....................................................................................................................10
Figure 6: Electrical Schematic Diagram......................................................................................................12
Figure 7: Cradle Dimensions.......................................................................................................................12
Figure 8: TigoBridge B1 and Cradle ...........................................................................................................13
Figure 9: TigoBridge B1 Mounted on the Cradle ........................................................................................13
Figure 10: TigoEngine Scanning Mode.......................................................................................................14
Figure 11: TigoEngine Pairing Process ......................................................................................................14
Figure 12: TigoEngine Operate Mode.........................................................................................................14
Figure 13: Port Details tab ..........................................................................................................................15
Figure 14: Unpair Button.............................................................................................................................15
List of Tables
Table 1: Power LED....................................................................................................................................10
Table 2: Status LED....................................................................................................................................11
Table 3: Status LED troubleshooting ..........................................................................................................16
Table 4: Technical Data..............................................................................................................................18
Version Control
Author Name
Description
Revision
Date
Yaniv Yardni
Creation
1.0
June 2021

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 4of 21
Acronyms and Abbreviations
Acronyms and abbreviations used in this document are listed in this table:
Symbol
Meaning
FW
Firmware
HW
Hardware
IF
Interface
IOLW
IO-Link Wireless
LED
Light-Emitting Diode
SW
Software
UID
Unique ID

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 5of 21
1. Introduction
This user manual introduces you to TigoBridge B1 (Part number: CT231-0057-01P) and enables you to
perform setup, configuration, mounting, and troubleshooting.
TigoBridge B1 is an IO-Link to IO-Link Wireless, Class B convertor. TigoBridge can convert any IO-Link
device to IO-Link Wireless as long as it is IO-Link certified. Read the manual carefully before using the
device.
Figure 1: TigoBridge B1
References:
•TigoEngine –User Manual
•TigoMaster 2TH –User Manual
1.1. Structure
The sections of this user manual build on one another.
1.2. Typographical Conventions
Enumerations are shown in list form with bullet points.
•Entry 1
•Entry 2
•Entry 3
Instructional steps are shown in list form with numbers.
1. Step 1.
2. Step 2.
3. Step 3.
Decimal numbers are shown without additional indicators and are not spelled out (e.g., 123).

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 6of 21
1.3. Symbols
Symbol
Meaning
Note: This symbol indicates a general note.
Warning: This symbol indicates a security notice which must be observed.
Reference: This symbol indicates a cross-reference to other documentation.
1.4. Deviating Views
The product views and illustrations in this user manual may deviate from the actual product. They are
intended only as illustrative material.
2. Safety and Requirements
2.1. General Note
This user manual is intended for any qualified personnel using the device. All safety messages, integrated
safety messages, property damage messages, and valid legal regulations must be observed by its users.
Technical capabilities on behalf of the user are presumed.
2.2. Electrical Connection
The TigoBridge B1 shall be supplied by an isolated power source that meets the following requirements:
•Limited-Energy Circuit in accordance with UL/CSA 61010-1
or
•Limited Power Source (LPS) in accordance with (UL/CSA 60950-1 or EN 62368-1, Annex Q)
or
•Class 2 supply source which complies with the National Electrical Code (NEC), NFPA 70, Clause
725.121 and Canadian Electrical Code (CEC), Part I, C22.1.
Warning: Input current is not limited. No fire protection.
2.3. Intended Use
The TigoBridge B1 is an IO-Link Wireless Class B Bridge with an IP67 enclosure.
The TigoBridge B1 is intended for indoor use only.
The TigoBridge B1 converts IO-Link to IO-Link Wireless. The TigoBridge B1 houses internal antenna and
two M12 connectors for data and power.
TigoBridge is a device that connects a wired IO-Link device, via IO-Link Wireless, to an IO-Link Wireless
Master. A device can be an IO-Link sensor, IO-Link actuator, or IO-Link hub.
Warning: Product applications other than those described in this user manual are not permitted.

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 7of 21
2.4. Personnel Qualification
The product may only be mounted, configured, operated, or demounted by qualified personnel. When
working with electricity, technical skills must be demonstrated under all the following circumstances:
•Safety and health at work
•Mounting and connecting of electrical equipment
•Measurement and analysis of electrical functions and systems
•Evaluation of the safety of electrical systems and equipment
Warning: CoreTigo Ltd. does not assume any warranty or liability for damage caused to the
product due to non-compliance with security measures or incorrect product installation.

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 8of 21
3. Requirements
TigoBridge B1 is implemented based on the IO-Link Wireless standard for W-Bridge devices. TigoBridge
B1 is part of an IO-Link Wireless environment. It communicates with an IO-Link Wireless master.
Therefore, to use it, you need an IO-Link Wireless master, IO-Link device, and a power cable. See the
illustration.
Figure 2: TigoBridge B1 Overview
A. IO-Link Class B Device
B. IO-Link Wireless Master
C. 2x Power Sources –24VDC (for 1L+ and 2L+)
D. Mounting Accessory –TigoBridge Cradle
E. TigoBridge B1

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 9of 21
4. Pre-Installation
4.1. Description
An IO-Link device can be connected to a TigoBridge B1 directly or using an M12 cable. TigoBridge B1
can be connected to an IO-Link Wireless Master by TigoEngine, Integrated web server tool, or PLC. Each
IO-Link Wireless master can operate up to 16 TigoBridges.
4.2. Overview
Figure 3: TigoBridge B1 Label
Label:
A. TigoBridge Model
B. Output Power Supply Range
C. Product Number
D. Input Power Supply Range
E. QR CODE (URL)
F. Refer to Warning in section 2.2
G. FCC ID
A
B
C
E
D
F
G

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 10 of 21
4.2.1. Functional Diagram
Figure 4: TigoBridge B1 Functional Diagram
A. Device Connector
B. Pairing Button
C. Power Supply Connector
D. Power LED (Green)
E. Status LED (RGB)
4.3. LEDS
Figure 5: TigoBridge B1 LEDs
A. Status LED (RGB)
B. Power LED (Green)
4.3.1. Power LED
Table 1: Power LED
LED Color
Indication
Green
Power supply connected

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 11 of 21
4.3.2. Status LED
Table 2: Status LED
LED Color
Indication
Magenta
Unpaired wireless
Blue
Operational wireless bridge
Green
Operational wired device
Yellow
Non-operational wired device
White
Wireless Error (see Note)
Blinking Green
Firmware update mode
4.4. Pair by Button
The Pair by button is used to replace existing TigoBridge B1 with a new one.
The TigoBridge B1 must be powered off to assure that the TigoMaster disconnects before installing a new
TigoBridge B1.
Pairing Button currently disabled. To enable, contact CoreTigo Support.
4.5. Electrical Wiring
TigoBridge B1 has two M12 connectors.
•IO-Link Connector: 5 pins, A-Coded female connector.
Maximum Current supply to IO-Link device 1L+ port is 1 A when using 24 VDC.
Maximum Current supply to IO-Link device 2L+ port is 2.5 A under 50°C, linearly
de-rated to 1 [A] at 60°C
•Power Connector: 5 pins, A-Coded male connector.
Higher voltage than 32 VDC is restricted, as it can damage the TigoBridge.

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 12 of 21
4.6. Electrical Connection
Figure 6: Electrical Schematic Diagram
Warning: TigoBridge B1 does not have reverse polarity power connection protection!
5. Mounting
TigoBridge B1 should be mounted safely and securely next to the device to which it is connected.
TigoBridge B1 can be mounted with or without the cradle accessory.
5.1. TigoBridge Cradle
The cradle is designed to simplify mounting of the TigoBridge B1 on flanges or any other
surface/machine/device. The cradle can be secured to any surface using either cable ties or M3 screws.
Figure 7: Cradle Dimensions

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 13 of 21
Figure 8: TigoBridge B1 and Cradle
Figure 9: TigoBridge B1 Mounted on the Cradle
Cradle Mounting Guidelines:
1. Secure the cradle on the flange (or machine or any other surface) using M3 screws or cable ties.
2. Mount the TigoBridge B1 onto the cradle by pushing it in.
3. Pull the TigoBridge B1 from the cradle to unmounting it.
6. Configuration & Setup
Commissioning Prerequisites:
•TigoEngine software installed and running on PC.
•TigoMaster/TigoGateway successfully connected to PC.
Installation:
1. Plug a 24VDC power supply to TigoBridge B1 M12 power connector via M12 cable.
2. The Power LED lights up green. If it does not, check the power connection.
3. Once the power supply is connected, a reset cycle occurs. The reset cycle duration is a few
seconds and displays a red green blue color sequence.
4. Once the reset cycle is complete, the status LED alternates between magenta and yellow.
5. Plug the TigoBridge B1 to an IO-Link device (sensor/actuator).
Note, if TigoBridge B1 cannot connect directly to the device, you may use an M12 cable. Once
successfully connected the Status LED alternates between Magenta and Green.
6. Open the TigoEngine and scan the network for the IO-Link Wireless TigoBridge B1.

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 14 of 21
Figure 10: TigoEngine Scanning Mode
7. Identify the TigoBridge B1 using the UID. Select the requested TigoBridge B1. Select an empty
port on the Master side and click Pair.
Figure 11: TigoEngine Pairing Process
8. When the pairing process is complete, the TigoEngine Port Mode should indicate OPERATE.
The TigoBridge B1 Status LED alternates between blue and green. Configuring the IO-Link
device is done through the Port Details tab.
Figure 12: TigoEngine Operate Mode

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 15 of 21
Figure 13: Port Details tab
Unpair –To replace a TigoBridge B1, click the unpair button, on the TigoEngine interface, and repeat the
instructions to unpair it. Once unpaired, the TigoBridge B1 status LED alternates between magenta and
green.
Figure 14: Unpair Button
7. Firmware Update
Firmware (FW) is updated wirelessly using the TigoEngine. Refer to the TigoEngine User Manual for
detailed instructions. Contact CoreTigo Support if needed.

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 16 of 21
8. Diagnostics and Troubleshooting
Troubleshooting is done using the LEDs display or the TigoEngine software. Refer to TigoEngine User
Manual for detailed instructions.
8.1. Power LED
Power LED –if a power supply is connected to the TigoBridge B1 and the Power LED is off, the power
supply is not properly connected, or it is providing a power supply different than the expected range.
8.2. Status LED
Status LED –indicates the IO-Link device connection status and the IO-Link Wireless communication
status with the IO-Link Master. Therefore, it alternates to show both the status of the IO-Link device
connection and the IO-Link Wireless connection.
Table 3: Status LED troubleshooting
IO-Link Wireless
Wired IO-Link
Paired
Unpaired
Operational
Alternating Blue and Green
Alternating Magenta and Green
Non-Operational
Alternating Blue and Yellow
Alternating Magenta and Yellow
Alternating Blue and Green –fully Operational: both IO-Link device and IO-Link Wireless
communication properly functioning.
Alternating Magenta and Green –TigoBridge B1 is unpaired from the TigoMaster while the IO-Link
device is properly connected to the TigoBridge B1. Re-Scan and Re-Pair the TigoBridge B1 to the
TigoMaster through the TigoEngine.
Alternating Blue and Yellow –TigoBridge B1 is successfully paired to the TigoMaster while the IO-Link
device is not properly connected to or not fully functioning with the TigoBridge B1. Check the IO-Link
device connectivity with the TigoBridge B1.
Alternating Magenta and Yellow –Both TigoBridge B1 IO-Link Wireless communication are unpaired
and the IO-Link device is not connected/functioning. Power down the TigoBridge B1 and power it back
up, reconnect the IO-Link device, scan, and pair the TigoBridge B1.

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 17 of 21
9. Guidelines and Regulations
FCC ID: 2ATSM-TGBRIDGEB1
9.1. RF Exposure Warnings
Warning: This device is authorized for use in a static application only. Always keep a distance of
at least 20 cm between theTigoBridge B1 device and the user's body.
9.2. Class A Warning
The FCC Wants You to Know
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference, in which case the
user will be required to correct the interference at his own expense
9.3. Modification Statements
FCC Warning (Modification statement)
CoreTigo LTD has not approved any changes or modifications to this device by the user. Any changes or
modifications can void the user’s authority to operate the equipment.
9.4. FCC Regulatory Notices
Interference statement (if it is not placed in the device)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Wireless Notice
This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and
meets the FCC radio frequency (RF) Exposure Guideline. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 18 of 21
10. Technical Data
Table 4: Technical Data
Electrical Data
Input Voltage
18-32 [V]*
Output Voltage on L+
Equals to Input Voltage
Typical Current Consumption
21 [mA]**
MaxOutputSupplyCurrent - 1L+
1L+ = 1 [A]
Max Output Supply Current - 2L+
Max current of 2.5 [A] under 50°C, linearly de-rated to 1 [A] at 60°C.
Max Output Peak Current
1L+ = 1.2 [A]***
Wireless Parameters
Operating Frequency
2.4 GHz ISM Band
Communication Standard
IO-Link Wireless
Modulation
GFSK, Modulation index = 0.5
Radio Peak Output Power
10 [dBm]
Interfaces
LEDs
•IO-Link –RGB three color LED
•Power –Green color LED
Button
Pairing - external push button
Connectors
•Input connector: Plug M12, A coded, power Connector
oPin number 1: Input 1L+ Power supply
oPin number 2: Input 2L+ Power supply
oPin number 3: Input L - GND
oPin number 5: Input 2L - GND
•Output Connector: Socket M12, A coded, IO Link Class B
Connector
oPin number 1: 1L+ positive supply to IO Link device
oPin number 2: 2L+ positive supply to IO Link device
oPin number 3: 1L- GND supply to IO Link device
oPin number 4: CQ IO Link Serial Communication
oPin number 5: 2L- GND supply to IO Link device
Antenna
Internal isotropic antenna
Communication
Protocols
•IO Link
oSupported transmission types: COM1, COM2, COM3
oRevision 1.0
oClass B
•IO Link Wireless
oVersion 1.1

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 19 of 21
Regulation
CE
•EN 301489
•EN 300328
•EN 62479
•EN 61326-1
FCC
•FCC ID: 2ATSM-TGBRIDGEB1
•FCC CFR Title 47 Part 15 Subpart C Section 15.247
•FCC CFR Title 47 Part 15 Subpart B
Safety
IEC 61010-1
UL61010-1 and CSA C22.2 No. 61010-1
RoHS
Complied
Reach
Complied
Qualifications
Shock & Vibrations
•Sine Vibration: IEC 60068-2-6
•Random vibration: IEC 60068-2-64
•Shock: IEC 60068-2-27
•Bumps: IEC 60068-2-27
* TigoBridge B1 should be supplied from a limited, Class 2, power supply or via overcurrent protective
device (fuse, breacker, etc.) rated 3A max.
** For 24 VDC Supply input, without IO Link device current consumption
*** For 30 minutes
To read more about IO-Link Wireless solutions follow this link https://www.coretigo.com/solutions/.
Operating Conditions
Operating Temperature
-25°C to 60°C
Relative Humidity Rating
Relative 90%, non-condensing
Altitude
Up to 2000 m
Pollution
Degree 3
IP rating
IP67
Emission
• EN 61000 -6-2
o EN55016-2-3 Radiated emission
o EN55022 Conducted emission
Immunity
• EN 61000-6-2
oEN31000-4-2 Electrostatic discharge
oEN61000-4-4 Fast transients/burst
o EN61000-4-5 Surge immunity
o EN61000-4-6 Conducted immunity

TigoBridge B1 User Manual
Copyright © 2021 CoreTigo Ltd.
Page 20 of 21
Block Diagram
Dimensions
11. Customer Support
For any issue, question, or to report a bug, contact sup[email protected]
