Cornelius Enduro 200 User manual

IMPORTANT:
TO THE INSTALLER.
It is the responsibility of
the Installer to ensure that
the water supply to the
dispensing equipment is
provided with protection
against backflow by an air
gap as defined in
ANSI/ASME A112.1.2-1979;
or an approved vacuum
breaker or other such
method as proved effective
by test.
Water pipe connections
and fixtures directly
connected to a potable
water supply shall be
sized, installed, and
maintained according to
Federal, State, and Local
Codes.
Operator’s Manual
ICE/BEVERAGE DISPENSER
Model: Enduro 200/250
PRINTED IN U.S.A
IMI CORNELIUS INC; 2004
IMI CORNELIUS INC gOne Cornelius Place gAnoka, MN 55303
Telephone [phone] Facsimile (800) 535–4231
Part No. 92108OPR
March 2, 2004
Revised: N/A
Revision: A
THIS DOCUMENT CONTAINS IMPORTANT INFORMATION
This Manual must be read and understood before installing or operating this equipment

i92108
TABLE OF CONTENTS
Page
MAINTENANCE 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DAILY (OR AS REQUIRED) 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
WEEKLY (OR AS REQUIRED) 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MONTHLY 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
START-UP & OPERATING INSTRUCTIONS 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CLEANING INSTRUCTIONS 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DISPENSER 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BEVERAGE SYSTEM (IF APPLICABLE) 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CLEANING 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CLEANING DISPENSING VALVES 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SANITIZING 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TROUBLESHOOTING 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BLOWN FUSE OR CIRCUIT BREAKER. 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GATE DOES NOT OPEN. AGITATOR DOES NOT TURN. 6. . . . . . . . . . . . . . . . . .
GATE DOES NOT OPEN OR IS SLUGGISH. AGITATOR TURNS. 6. . . . . . . . . .
ICE DISPENSES CONTINUOUSLY. 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SLUSHY ICE. WATER IN HOPPER. 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BEVERAGES DO NOT DISPENSE. 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BEVERAGES TOO SWEET. 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BEVERAGE NOT SWEET ENOUGH. 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BEVERAGES NOT COLD (UNITS WITH BUILT–IN COLD PLATE). 7. . . . . . . . . .
FLAVOR SYRUPS DO NOT DISPENSE 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FLAVOR DISPENSES FOR MORE THAN 1 SEC 7. . . . . . . . . . . . . . . . . . . . . . . . . .
FLAVOR DISPENSES MORE THAN .5 OZ 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
WARRANTY 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

192108OPR
MAINTENANCE
The following dispenser maintenance should be performed at the intervals indicated:
DAILY (or as required)
Remove foreign material from vending area drip tray to prevent drain blockage.
WEEKLY (or as required)
Clean vending area. Check for proper water drainage from the vending area drip tray.
MONTHLY
Clean and sanitize the hopper interior and beverage system if applicable (see CLEANING INSTRUCTIONS).
START-UP & OPERATING INSTRUCTIONS
Fill the hopper with ice. Dispense several large cups of ice (approximately 20 to 30 seconds total dispensing time)
to allow ice to fill the cold plate cabinet. Add ice to the hopper as necessary to refill and replace the lid. Allow 10 to
15 minutes for the cold plate to cool down. Repeat this procedure whenever the dispenser has run out of ice. Start
up the beverage system and adjust faucets to the proper brix. Contact your local syrup distributor for complete
information on the beverage system.
In normal operation, pushing the ice dispenser mechanism will cause ice to flow from the ice chute. Ice flow will
continue until the dispenser mechanism is released. Dispensing of any faucet will provide beverage of the
appropriate flavor.
CAUTION: Use caution to avoid spilling ice when filling dispenser. Clean up immediately any
spilled ice from filling or operating the unit. To prevent contamination of ice, the lid must be
installed on the unit at all times.
If the dispenser fails to dispense ice or beverage see troubleshooting guide.
CLEANING INSTRUCTIONS
WARNING: Disconnect Power Before Cleaning! Do not use metal scrapers, sharp objects or
abrasives on the ice storage hopper, top cover and the agitator disk, as damage may result.
Do not use solvents or other cleaning agents, as they may attack the plastic material.
Soap solution - use a mixture of mild detergent and warm 100 degrees F potable water.
Sanitizing solution - use 1/2 ounce of household bleach in 1 gallon of potable water. Preparing the sanitizing
solution to this ratio will create a solution of 200 PPM.

292108OPR
DISPENSER
1. CLEANING EXTERIOR SURFACES
Important: Perform the following daily.
A. Remove the cup rest from drip tray.
B. Wash the drip tray with soap solution. Rinse with clean water and allow solution to run down the drain.
C. Wash cup rest with soap solution and rinse in clean water. Install the cup rest into the drip tray.
D. Clean all exterior surfaces with soap solution and rinse in clean water.
2. COLD PLATE INSPECTION BEFORE CLEANING
A. Remove splash panel.
B. Remove the plastic cold plate cover to expose the cold plate.
C. Locate and remove any debris from the cold plate, drain trough and make certain that the drain holes
are not clogged.
D. Reinstall the cold plate cover.
E. Reinstall the splash panel in the reverse order in which it was removed.
3. CLEANING INTERIOR SURFACES
CAUTION: When pouring liquid into the hopper, do not exceed the rate of 1/2 gallon per
minute.
Important: Perform the following at least once a month.
A. Remove agitator assembly.
B. Using a long handle nylon bristle brush, clean the interior of the hopper, top, cover and cold plate with
soap solution. The cold plate can be reached by going through the ice opening on the hopper bottom.
Make certain to reach the entire surface of the cold plate including the corners. Clean the agitator
assembly with soap solution using a nylon brush or a sponge. Thoroughly rinse the hopper, top cover,
agitator and cold plate surfaces with clean potable water.
C. Remove merchandiser and ice chute cover from dispenser.
D. With a nylon bristle brush or sponge, clean the inside of the ice chute, gasket and cover with soap
solution and rinse thoroughly to remove all traces of detergent.
E. Re-assemble agitator assembly. Take special care to ensure that the thumbscrew is tight.
F. Using a mechanical spray bottle filled with sanitizing solution, spray the entire interior and agitator
assembly. Allow to air dry.
G. Re-assemble ice chute assembly.
H. Using a mechanical spray bottle filled with sanitizing solution, spray the inside of the ice chute. Allow to
air dry.
I. Reinstall merchandiser.

392108OPR
BEVERAGE SYSTEM
(IF APPLICABLE)
CLEANING
WARNING: Disconnect Power Before Cleaning! Do not use metal scrapers, sharp objects or
abrasives on the ice storage hopper, top cover and the agitator disk, as damage may result.
Do not use solvents or other cleaning agents, as they may attack the plastic material.
Soap solution - Use a mixture of mild detergent and warm 100 degrees F potable water.
Sanitizing solution - Use 1/2 ounce of household bleach in 1 gallon of potable water. Preparing the sanitizing
solution to this ratio will provide the required solution of 200 PPM.
Cleaning tank - Fill clean, empty tank with a mixture of mild detergent and five (5) gallons of warm 120 degrees F
potable water.
CLEANING DISPENSING VALVES
Refer to addendum supplied with the unit that is applicable to the manufacturer of the valves installed on the unit.
SANITIZING
IMPORTANT: Only trained and qualified persons should perform these cleaning and sanitizing
procedures.
Sanitize tank systems, Post-Mix and Pre-Mix
1. Remove all the quick disconnects from all the tanks. Fill a suitable pail or bucket with soap solution.
2. Submerge all disconnects (gas and liquid) in the soap solution and then clean them using a nylon bristle
brush. (Do not use a wire brush). Rinse with clean water.
3. Prepare sanitizing solution and using a mechanical spray bottle, spray the disconnects. Allow to air dry.
4. Using a clean, empty tank, prepare five (5) gallons of the sanitizing solution. Rinse the tank disconnects with
approximately 9 oz. of the sanitizing solution. Close the tank.
5. Prepare cleaning tank by filling clean five (5) gallon tank with a mixture of mild detergent and 120 degrees F
potable water.
6. Connect a gas disconnect to the tank and then apply one of the product tubes to the cleaning tank. Operate
the appropriate valve until liquid dispensed is free of any syrup.
7. Disconnect cleaning tank and hook up sanitizing tank to syrup line and CO2system.
8. Energize beverage faucet until chlorine sanitizing solution is dispensed through the faucet. Flush at least two
(2) cups of liquid to insure that the sanitizing solution has filled the entire length of the syrup tubing.
9. Allow sanitizer to remain in lines for fifteen (15) minutes.
10. Repeat the step above, applying a different product tube each time until all tubes are filled with the sanitizing
solution.

492108OPR
11. For post-mix valves, remove the nozzle and syrup diffuser and clean them in a mild soap solution. Rinse
with clean water, then reinstall the nozzle and syrup diffuser on the valve.
12. For pre-mix valves, disconnect all product tubes from the tank of sanitizing solution and then open the valves
to allow the pressure to be relieved. Remove the valves from the dispenser, disassemble and wash
thoroughly in a mild soap solution.
13. Rinse the parts in clean water, reassemble the valve and reconnect it to the dispenser.
14. Discard the tank of sanitizing solution and reconnect the product (syrup or pre-mix) tanks. Operate the
valves until all sanitizer has been flushed from the system and only product (syrup or pre-mix) is flowing.
Sanitize syrup lines, B-I-B Systems
1. Remove all the quick disconnects from all the B-I-B containers.
2. Fill a suitable pail or bucket with soap solution.
3. Submerge all disconnects (gas and liquid) in the soap solution and then clean them using a nylon bristle
brush. (Do not use a wire brush). Rinse with clean water.
4. Using a plastic pail, prepare approximately five (5) gallons of sanitizing solution.
5. Rinse the B-I-B disconnects in the sanitizing solution.
6. Sanitizing fittings must be attached to each B-I-B disconnect. If these fittings are not available, the fittings
from empty B-I-B bags can be cut from the bags and used. These fittings open the disconnect so the
sanitizing solution can be drawn through the disconnect.
7. Place all the B-I-B disconnects into the pail of sanitizing solution. Operate all the valves until the sanitizing
solution is flowing from the valve. Allow sanitizer to remain in lines for fifteen (15) minutes.
8. Remove the nozzle and syrup diffuser from each valve and clean them in a soap solution. Rinse with clean
water and reassemble the nozzle and syrup diffuser to the valve.
9. Remove the sanitizing fittings from the B-I-B disconnects and connect the disconnects to the appropriate
B-I-B container. Operate the valves until all sanitizer has been flushed from the system and syrup is flowing
freely.

592108OPR
WARNING: Disconnect Power Before Cleaning !
Soap solution –Use a mixture of mild detergent and warm (100_F) potable water.
Sanitizing solution –Use ½ounce of household bleach in 1 gallon of potable water. Preparing the sanitizing
solution to this ratio, the required solution of 200 PPM will be obtained.
Cleaning tank –Fill clean, empty tank with a mixture of mild detergent and five (5) gallons of warm potable water
(120_F).
Sanitize Flavor syrup lines, B–I–B System
1. Remove all the quick disconnects from all the B–I–B containers.
2. Fill a suitable pail or bucket with soap solution.
3. Submerge all disconnects (gas and liquid) in the soap solution and then clean them using a nylon bristle
brush. (Do not use a wire brush). Rinse with clean water.
4. Using a plastic pail, prepare approximately five (5) gallons of sanitizing solution.
5. Rinse the B–I–B disconnects in the sanitizing solution.
6. Sanitizing fittings must be attached to each B–I–B disconnect. If these fittings are not available, the fittings
from the empty B–I–B bags can be cut from the bags and used. These fittings open the disconnect so the
sanitizing solution can be drawn through the disconnect.
7. Place all the B–I–B disconnects into the pail of sanitizing solution. ‘Purge’all the flavor valves until the
sanitizing solution is flowing from inner nozzle. This can easily be accomplished by holding down each
keypad button for at least 15 seconds. After 15 seconds the valve will go into ‘purge’mode and continuously
dispense for the next 60 seconds. Allow sanitizer to remain in lines for at least thirty (30) minutes.
8. Remove nozzle cover (outer nozzle) from flavor module housing. Clean in a soap solution and rinse with
clean water.
9. Remove the sanitizing fittings from the B–I–B disconnects and connect the disconnects to the appropriate
B–I–B container. Operate the flavor valves until all sanitizer has been flushed from the system and flavor
syrup is flowing freely.

692108OPR
WARNING: If repairs are to be made to a product system, remove quick disconnects from
the applicable product tank, then relieve the system pressure before proceeding. If repairs
are to be made to the CO2system, stop dispensing, shut off the CO2supply, then relieve the
system pressure before proceeding. If repairs are to be made to the refrigeration system, make sure
electrical power is disconnected from the unit.
TROUBLESHOOTING
IMPORTANT: Only qualified personnel should service internal components or electrical wiring.
Should your unit fail to operate properly, check that there is power to the unit and that the hopper con-
tains ice. If the unit does not dispense, check the following chart under the appropriate symptoms to aid
in locating the defect.
Trouble Probable Cause
BLOWN FUSE OR CIRCUIT BREAKER. A. Short circuit in wiring.
B. Defective gate solenoid.
C. Defective agitator motor.
GATE DOES NOT OPEN. AGITATOR DOES NOT
TURN.
A. No power.
B. Bent depressor plate (does not actuate switch).
C. Defective dispensing switch.
GATE DOES NOT OPEN OR IS SLUGGISH.
AGITATOR TURNS.
A. Defective gate solenoid.
B. Excessive pressure against gate slide.
C. Defective Rectifier.
ICE DISPENSES CONTINUOUSLY. A. Stuck or bent depressor plate (does not
release switch).
B. Defective dispensing switch.
C. Improper switch installation.
SLUSHY ICE. WATER IN HOPPER. A. Blocked drain.
B. Unit not level.
C. Poor ice quality due to water quality or
icemaker problems.
D. Improper use of flaked ice.
BEVERAGES DO NOT DISPENSE. A. No 24 volt power to faucets.
B. No CO2pressure.
BEVERAGES TOO SWEET. A. Carbonator not working.
B. No CO2pressure in carbonator.
C. Faucet brix requires adjusting.

792108OPR
Trouble Probable Cause
BEVERAGE NOT SWEET ENOUGH. A. Empty syrup tank.
B. Faucet brix requires adjusting.
BEVERAGES NOT COLD (UNITS WITH BUILT–IN
COLD PLATE).
A. Unit standing with no ice in hopper –no ice in
cold plate cabinet.
FLAVOR SYRUPS DO NOT DISPENSE A. No 24 volt power to PC board.
B. No CO2 pressure.
C. Empty syrup tank.
D. Kinked tubing.
E. Clogged inner nozzle.
F. Defective PC board.
G. Defective harness from keypad.
H. Defective Flow control.
I. Defective solenoid harness.
J. Defective keypad.
FLAVOR DISPENSES FOR MORE THAN 1 SEC A. Dip switch settings on control board incorrect.
B. PC board defective.
C. Defective flow control.
FLAVOR DISPENSES MORE THAN .5 OZ A. Dip switch settings on control board incorrect.
B. Flow control incorrectly set.
C. PC board defective.
D. Defective flow control.
NOTE: Contact your local syrup or beverage equipment distributor for additional information and
troubleshooting of beverage system.

892108OPR
WARRANTY
IMI Cornelius Inc. warrants that all equipment and parts are free from defects in material and
workmanship under normal use and service. For a copy of the warranty applicable to your Cornelius,
Remcor or Wilshire product, in your country, please write, fax or telephone the IMI Cornelius office
nearest you. Please provide the equipment model number, serial number and the date of purchase.
IMI Cornelius Offices
AUSTRALIA DP. O . 210, DRIVERWOOD, DNSW 2210, AUSTRALIA D(61) 2533 3122 DFAX (61) 2534 2166
AUSTRIA DAM LANGEN FELDE 32 DA-1222 DVIENNA, AUSTRIA D(43) 1233 520 DFAX (43) 1-2335-2930
BELGIUM DBOSKAPELLEI 122 DB-2930 BRAASCHAAT, BELGIUM D(32) 3664 0552 DFAX (32) 3665 2307
BRAZIL DRUA ITAOCARA 97 DTOMAS COELHO DRIO DE JANEIRO, BRAZIL D(55) 21 591 7150 DFAX (55) 21 593 1829
ENGLAND DTYTHING ROAD ALCESTER DWARWICKSHIRE, B49 6EU, ENGLAND D(44) 789 763 101 DFAX (44) 789 763 644
FRANCE D71 ROUTE DE ST. DENIS DF-95170 DEUIL LA BARRE DPAR IS, FRANCE D(33) 134 28 6200 DFAX (33) 134 28 6201
GERMANY DCARL LEVERKUS STRASSE 15 DD-4018 LANGENFELD, GERMANY D(49) 2173 7930 DFAX (49) 2173 77 438
GREECE D488 MESSOGION AVENUE DAGIA PARAS KEVI D153 42 DATHENS, GREECE D(30) 1600 1073 DFAX (30) 1601 2491
HONG KONG D1104 TAIKOTSUI CENTRE D11-15 KOK CHEUNG ST DTAIKOKTSUE, HONG KONG D(852) 789 9882 DFAX [phone]
ITALY DVIA PELLIZZARI 11 D1-20059 DVIMARCATE, ITALY D(39) 39 608 0817 DFAX (39) 39 608 0814
NEW ZEALAND D20 LANSFORD CRES. DP. O . BOX 19-044 AVONDALE DAUCKLAND 7, NEW ZEALAND D(64) 98200 357 DFAX (64) 98200 361
SINGAPORE D16 TUAS STREET DSINGAPORE 2263 D(65) 862 5542 DFAX (65) 862 5604
SPAIN DPOLIGONO INDUSTRAIL DRIERA DEL FONOLLAR DE-08830 SANT BOI DE LLOBREGAT DBARCELONA, SPAIN D(34) 3640 2839 DFAX (34) 3654 3379
USA DONE CORNELIUS PLACE DANOKA, MINNESOTA D(763) 421-6120 DFAX [phone]
LD004
4/21/98

One Cornelius Place
Anoka, Minnesota 55303-6234
[phone]
[phone]
Corporate Headquarters:
IMI CORNELIUS INC.
