PALLADIA
It is designed and manufactured to customer specifications, to
protect from the sun and elements, snowfall excluded; PALLADIA
must be fixed to a suitable supporting wall and may be used in
winds of up to force 8 on the Beaufort scale as shown in chart (pag.
39).
In the event the above conditions are exceeded, the awning must
be folded up. It is very dangerous to leave the awning open as it
can cause injury.
PALLADIA FLAT VERSION
It is designed and manufactured to customer specifications, to
protect from the sun and elements, snowfall excluded; PALLADIA
must be fixed to a suitable supporting wall and may be used in
winds of up to force 6 on the Beaufort scale as shown in chart 1
(page 39).
MANUAL CONTROL
If PALLADIA® is fitted with manual drive, to open and close the
canvas, insert the manual winding handle in the seat of the gearbox
and turn clockwise (to raise the canvas) or anticlockwise (to lower
the canvas).
ELECTRIC COMMAND
In case of PALLADIA with a wall-switch, push the switch in the low
area in order to move the awning downwards, push it in the up
area to move the awning upwards. Once you release the switch the
awning will stop.
The drive must be installed between 90 and 120 cm off the ground.
RADIOCOMANDO
In case of PALLADIA with a radiocontrol, use the respective switches
to move the awning upwards, downwards or to stop it (see fig.).
A working height of < 2.50 m can generate a risk of shearing/
crushing between the moving part (front terminal tube) and the
fixed part of the structure.
The person starting the manoeuvre MUST be present until the end
of the manoeuvre to ensure that no obstacles or persons are in the
proximity of the potential hazard zone; alternatively the electric
drive can be installed as described on the next page.
Keep out of reach of children
Replacing radio control 1 battery
In order to replace the battery remove the screw on the back of
the radiocontrol and replace the batteries with a similar model
(alkaline 12 Vdc mod. 23 A).
Replacing radio control 2 battery
This transmitter is powered by a CR2032 type 3 Volt battery. To
replace it, open the plate on the back and remove the flat battery,
then replace it with a new one, ensuring the polarity is correct.
Reposition the plate.
Attention: do not invert polarity.
Attention: do not use an incorrect battery type.
Risk of explosion if the battery is replaced with a model
dierent from that specied.
Dispose of the used battery in the appropriate containers.
HOW TO CONTROL PALLADIA
USAGE
Awning going
upwards
Awning going
upwards
Stop
Stop
Awning going
upwards
Awning going
downwards
Led
Indicates the
battery state
(red is working)
Awning going
downwards
Awning going
downwards

29 of 121
CORRADI SPA - USER MANUAL - PALLADIA
ITALIANOENGLISHDEUTSCHFRANÇAISESPAÑOL
20.05.2013
VERSIONS AND MOTORISATIONS
220 volt / 218 watt motor reducer complete with limit switch.
Required for 2, 3 or 4 runner awning, flat version, where the
awning remains slack, or for the taut, tilted version, with a
maximum projection of 350 cm.
220 volt / 218 watt motor reducer with microchip canvas
tension controlled and a radio command (433.92 MHz).
Required for a 2 or 3 - runner awning, tilted version, which
guarantees constant correct tension despite changes in fabric
properties caused by differing environmental circumstances.
220 volt / 218 watt + 218 watt motor reducer with a microchip
that powers 2 motors and controls the canvas tension, a radio
command (433,92 MHz) with 2 channel emitter. Required for
a 4 runner awning, tilted version, which guarantees constant
correct tension despite changes in fabric properties caused
by differing environmental circumstances.
ELECTRIC DRIVE TYPE 1
PLAN motor
ELECTRIC DRIVE TYPE 2
SLOPE motor
remote computing system exchange MONO
ELECTRIC DRIVE TYPE 3
SLOPE motor 1 (command)
PLUS motor 2
remote computing system exchange TANDEM
PALLADIA 2 RUNNERS
PALLADIA 3 RUNNERS
PALLADIA 4 RUNNERS
TILTED VERSION PALLADIA
FLAT VERSION PALLADIA
1
2
4
31
1
1
2
34
2
34
WIDTH
PROJECTION
WALL BEAM HEIGHT
PILLAR

30 of 121
CORRADI SPA - USER MANUAL - PALLADIA 20.05.2013
PALLADIA 2 RUNNERS
ELECTRIC DRIVE TYPE 1
00775-1 PLAN Motor reducer
ELECTRIC DRIVE TYPE 2
00775-2 SLOPE Motor reducer
00749 MONO Exchange
Wall mounted protection cover Wall mounted protection cover
Electric drive
Non spinning crosspiece
Frontal crosspiece
Bracket cover
protection hood
Frontal beam (optional)
Frontal beam support
Runner kit cover
Runner kit
Crosspiece drive
Modular awning protection cover
Wall bracket
Bracket cover
protection hood
Lh/rh upper brackets
Crossbar supports
Awning protection
cover cap
Runner
Fixing plate lower bracket
Lower bracket
Pillar
Pillar foot

31 of 121
CORRADI SPA - USER MANUAL - PALLADIA
ITALIANOENGLISHDEUTSCHFRANÇAISESPAÑOL
20.05.2013
PALLADIA 3 RUNNERS
ELECTRIC DRIVE TYPE 1
00775-1PLAN Motor reducer
ELECTRIC DRIVE TYPE 2
00775-2 SLOPE Motor reducer
00749 MONO Exchange
Tettuccio a parete Wall mounted protection cover
Electric drive
Non spinning crosspiece
Frontal crosspiece
Frontal beam (optional)
Frontal beam support
Runner kit cover
Runner kit
Crosspiece drive
Modular awning protection cover
Crossbar supports
Lh/rh upper brackets
Wall bracket
Awning protection
cover cap
Runner
Fixing plate lower bracket
Lower bracket
Foot
Pillar foot
Bracket cover protection hood

32 of 121
CORRADI SPA - USER MANUAL - PALLADIA 20.05.2013
PALLADIA 4 RUNNERS
Wall mounted protection cover
Wall mounted protection cover
Modular awning protection cover
Crossbar supports
Lh/rh upper brackets
Wall bracket
Awning protection
cover cap
Runner
Fixing plate lower bracket
Lower bracket
Pillar
Pillar foot
Electric drive
Non spinning crosspiece
Frontal crosspiece
Frontal beam (optional)
Frontal beam support
Runner kit cover
Runner kit
Crosspiece drive
ELECTRIC DRIVE TYPE 1
00775-1 PLAN Motor reducer
ELECTRIC DRIVE TYPE 3
00775-2 SLOPE Motor reducer
00775-3 SLOPE Motor reducer
00757 TANDEM Exchange
Bracket cover
protection hood

33 of 121
CORRADI SPA - USER MANUAL - PALLADIA
ITALIANOENGLISHDEUTSCHFRANÇAISESPAÑOL
20.05.2013
TROUBLESHOOTING
PALLADIA
MANUAL VERSION
PALLADIA
ELECTRIC DRIVE
PROBLEM
The awning moves erratically.
The motor won’t start.
The motor starts but the awning won’t move.
The awning moves erratically.
Dirty runners, runners not properly aligned.
There is no electricity.
It is not plugged in.
The motor has overheated.
Problem setting the limit switch.
Possibly broken belts, or disconnection from drive shaft.
Dirty runners, runners not properly aligned.
Clean the runners (see instructions in chapter on maintenance).
Realign the runners.
Check the electric current.
Check that the plug is correctly connected to a suitable socket.
Wait 5-10 minutes to allow the motor to cool down. If the
problem persist check the limit switch.
Set the limit switch.
Contact dealer.
Clean the runners (see instructions in chapter on maintenance).
Realign the runners.
CAUSE CHECKS AND SOLUTIONS

34 of 121
CORRADI SPA - USER MANUAL - PALLADIA 20.05.2013
DEAR CUSTOMER,
Thank you for choosing a Corradi product.
We invite you to look at the table below, which shows the characteristics of components and materials used in Corradi Group products: Pergotenda®, sail awnings, outdoor furniture.
These features identify the materials’peculiarities and shouldn’t be considered as manufacturing imperfections.
We take this opportunity to underline that, to enter in our production cycle, materials must pass all the tests scheduled by our company quality system, according to UNI EN ISO 9001:2000 Certification.
Thank you for your attention,
Corradi SPA
PRODUCT FEATURES NON COMPLIANCE/ DEFAULT WARNINGS
GENERAL Defaults have to be reported within 8 days
starting on installation date on the customer’s site
(point of reference is the date indicated on the
declaration of correct installation issued to the
end user by the installer). See general sales term.
The structure is not watertight. In case of particularly violent storms with strong winds
water seepage may occur.
In case wind values should exceed those shown on the statement of correct installation, it
is necessary to close the awning. It is possible to use a properly calibrated anemometer.
The product does not guarantee the snow load. In presence of snow, even of low intensity,
the canvas should be closed.
To have your product warranty the certificate of proper installation is MANDATORY. A copy
must be given to the final customer and a copy shall be sent to Corradi SpA. The reception
of the duly completed certificate will activate the product warranty.
Any change to the product not expressly authorized by Corradi SpA leads to loss of warranty.
The structures that are located in an urban environment are subject to pollutants (smog, acid
rain), smoke from chimneys, fumes from cooking, and weather in general. It is normal for the
fabric and the structure to get dirty. The structures and the fabric are NOT selfcleaning.
SELF-
SUPPORTING
By applying a lateral load on the pillar an oscillation in the structure may occur. This
movement is not a sign of structural weakness, but is considered normal for the type of
structure. The structure has been calculated by qualified engineers using the Eurocodes and
is guaranteed to wind up to the level indicated in the EC certificate and in the Declaration
of correct installation.
PRODUCTS FEATURES

35 of 121
CORRADI SPA - USER MANUAL - PALLADIA
ITALIANOENGLISHDEUTSCHFRANÇAISESPAÑOL
20.05.2013
PRODUCTS FEATURES
PRODUCT FEATURES NON COMPLIANCE/ DEFAULT
CANVAS Depending on the installation conditions, it is possible that the cloth gets dirty (pollutants, smoke from chimneys, smog, etc.).
In this case it may be necessary to clean the fabric more frequently as indicated in the section maintenance.
The cloth is not immune from burns caused by cigarette butts, etc..
In particular situations of use of the structure, condensation may occur on the inside of the fabric.To limit this condition proceed
with an adequate ventilation of the room.
The appearance of mold in the embossing of the fabric is due to the presence of moisture on the sheet that favores the
formation of micro-organisms. It is therefore necessary to clean the fabric at regular intervals, more frequently if necessary.
The presence of folds on the fabric after the first installation may be due to packaging. It is necessary to keep the fabric in
position for at least 10 days, and evaluate the quality of the product after this period of time.
The presence of folds on the fabric after 10 days has to be
considered a default.
FALSE CEILING In particular situations of use the structure may present condensation in the area between the canvas and the ceiling. This may
cause dirt and / or mold in the intermediate zone. Remove the false ceiling and wash it.
GUTTER Periodically check that the drain pipes of the gutter and downspouts are clean. Discard leaves and other detritus that can clog
the drain holes.
In case of very heavy rainfall it is possible that the gutter is not able to drain the water. This may cause water infiltrations.
The water-conducting to the ground may not be controlled by Corradi SpA, but by the final customer.The installation conditions,
slopes and any collection wells, are the sole responsibility of the final customer.
LAMPS To maintain good efficiency in the seals, thereby ensuring the IP product protection level (shown in the manual), you must do
the maintenance indicated in the manual.
AWNING SAILS The presence of folds on the sail is due to the long winding of the sail on the roller tube. To limit this phenomenon and to have
the warranty the use of the sailcover is mandatory.
The presence of folds on the sail immediately after the first installation may be due to packaging. The folds will disappear
completely after about 6 months of installation.
VELOMBRA
FABRICS
The fabrics are“dyed in the piece”, this can cause a non-perfect uniformity and consistency of color.
WOOD WARNING: It is good to remember that any kind of wood type placed outside, and directly exposed to weather elements, may
look“lived”even after a relatively short period of time. This manifests itself mainly with:
• discoloration of the surface (the degradation varies depending on the moisture content to which the wood is subject)
• with the irregularity of the surface due to cyclic phenomena of swelling and shrinkage and possible mechanical wear of the
surface.
Since wood is a natural material, there are differences in color and grain and therefore all elements are different. Furthermore,
depending on the viewing angle the aspect is quite different because of the iridescent nature of the material. The samples and
photographic reproductions are thus regarded as indicative and not binding.
The detachment of a slat from the beams is considered a defect.

36 of 121
CORRADI SPA - USER MANUAL - PALLADIA 20.05.2013
PRODUCT FEATURES NON COMPLIANCE/ DEFAULT
The beams may present vertical stripes of different shades. This is normal and is due to stacking that occurs
inside the autoclave during the impregnation treatment (the beams are spaced apart by transverse beams).
The presence of resin is a characteristic of coniferous wood.
A dimensional variation of wood products after exposure to moisture is normal. The reference humidity for
the measuring is 12% (defined in the UNI EN390: 1997).
FLOOR The floor may dent in collisions or falling objects and the implementation of concentrated loads on a small
area, such as chairs with wheels, high heels and ladders is not suitable.
The floor can scratch as a result of contact with small objects such as nails or stones present beneath the
soles of shoes.
At the time of delivery, the floor may be different from that of the samples after exposure to light which
causes a change in the wood color.
MOTORS Electrical system: it must be performed by a licensed electrician who shall issue a certificate of conformity
of the electrical system.
The system has to have an appropriate degree of protection being installed outside. A licensed electrician is
able to properly size the system and choose the right components (adequate IP protection).
Any voltage drop or radio interference may result in loss of the limit switches of the engines. In this case it is
necessary to proceed with a new programming as indicated in the Manual.
STAINLESS
STEEL
The components in stainless steel require no maintenance. The appearance of micro-oxidation, most
frequently in maritime environments characterized by salt spray, does not affect the quality and durability
of the product such oxidations are believed to be normal. In case you need to remove these oxidized points
you can use a steel wool or a metal bristle brush (in stainless steel). The protective film of chromium oxide
(autopassivation) will reset in a natural way with the only exposure to air, without any intervention by the
user.
ALUMINIUM The presence of marks and scratches is considered a fault only if these are visible at a distance of 2 meters. If the signs and/or dents are visible at a distance of 2 meters these are to be
considered a defect.
Do not use acid to clean the painted aluminum, but only mild soap and water.
FINISH Orange peel: the surface of the coating film has an uneven look like orange peel.
Blistering: bumps on the surface of the coating film in various sizes and frequency.
Sagging of the outer layer: localized and well defined irregular accumulations of
coating products, in the form of rounded edges and shallow that affect the outer
layer.
Posting - Veneer: the coating film lifts from the substrate in form of small flakes
PRODUCTS FEATURES

37 of 121
CORRADI SPA - USER MANUAL - PALLADIA
ITALIANOENGLISHDEUTSCHFRANÇAISESPAÑOL
20.05.2013
PRODUCT FEATURES NON COMPLIANCE/ DEFAULT
Porosity - Cissing: Small holes like craters or indentations in the
surface of the coating film, ranging in size: from small pinhole
up to a diameter of up to 1 cm.
Impurities in the outer and inner layers: the coating film has a
rough and irregular surface, easily perceptible to the touch.
Scrapings for interference: the coating film is damaged and
presents lesions of varying depth and extent depending on the
cause.
GLAZING For aluminum frames refer to the ALUMINIUM voice.
ERMETIKA The temperature inside the protection hood can reach very high values, if exposed to direct sunlight during the summer. This
may result in bonding of the fabric if the awning is not handled for long periods. It is recommended to open and close the
awning on a frequent basis to avoid this problem.
If the fabric is rolled up for long periods creases and wrinkles may appear on the fabric. The fabric is made of PVC and its nature
is not comparable to a glass. It is necessary to keep the awning stretched for at least 48h to soften creases and wrinkles.
In case of installation in areas affected by dust and wind (e.g. beach facing the sea) it is possible that the fabric may be damaged
losing the transparency due to the combined action of wind and sand.
To maintain a good efficiency on the awning and the locking device it is necessary to maintain the vertical runners clean as
shown in the maintenance chapter.
Make sure there are no obstructions that may impede the orderly movement of the awning. This may cause malfunction of
the locking devices of the awning.
If there is ice/snow runners should be cleaned thoroughly before operating the awning.
RUNNERS After some time from the installation and if no periodic maintenance is performed on the runners, as indicated in the manual,
there may be noise in the runners and sliders.
Noise on the runners soon after the installation is is considered
a default.
PRODUCTS FEATURES

38 of 121
CORRADI SPA - USER MANUAL - PALLADIA 20.05.2013
1
MAINTENANCE
WARNING:
THE RUNNERS SHOULD NEVER BE LUBRICATED
UNDER ANY CIRCUMSTANCES.
WARNING:
During all maintenance and repair operations or product registration,
the electric supply must always be disconnected.
It is also advisable to place a warning sign over the mains supply
switch with the following phrase:
“DO NOT TOUCH: work in progress”.
The use of ladders, access platforms or the like is restricted to specialist
personnel only, who must comply with current safety regulations and
must use personal protective equipment.
PREMESSA
PALLADIA is a unique product that offers the highest quality and
longest lifespan thanks to its construction and the materials used.
Routine maintenance is therefore minimal, thus allowing users to
keep the product perfectly functional and attractive with just a few
operations.
The few, simple rules to be followed are given below:
RUNNERS
Once a year in normal conditions of use, or once a month when
exposed to sea air, wash the inside of the runners with a jet of water
and if possible use a brush to remove all traces of dirt and/or incrusted
salt, as described in fig. 1.
Warning: the runners should never be lubricated under any
circumstances.
CANVAS
Canvas maintenance is limited to cleaning.
Se si desidera mantenere come nuova la parte esposta alle
intemperie, è necessario lavarla 2 o 3 volte l’anno in modo da evitare
che la polvere o lo smog che si depositano sul telo si fissino su di esso
attraverso l’azione del sole.
Per lavare il telo procedere spruzzando acqua e sapone neutro sullo
stesso, aspettare qualche minuto per far si che il prodotto abbia il
tempo di agire, dopodichè, mediante l’utilizzo di una spugna,
rimuovere lo sporco senza però fare eccessiva pressione meccanica,
ripetere se necessario, e sciacquare abbondantemente.
HARDWARE
The hardware is made of stainless steel. Once a year under normal
conditions, or once a month if exposed to salinity, the hardware must
be rinsed with a water jet to remove any trace of dirt and/or salt
incrustation.
The appearance of small rust spots, more frequent in coastal areas
with salt spray, does not jeopardise the quality and duration of the
product; these spots are to be considered as normal. Should you
wish to remove the rust spots, use a scouring pad or metal bristle
brush (stainless steel). The protective film of chromium oxide (self-
passivation) will restore itself naturally when exposed to the air,
without the need for any intervention by the user.

39 of 121
CORRADI SPA - USER MANUAL - PALLADIA
ITALIANOENGLISHDEUTSCHFRANÇAISESPAÑOL
20.05.2013
TABLES
TABLE 1 - STRENGTH AND EFFECTS OF WIND ON BEAUFORT SCALE
TABLE 2 - MAXIMUM SIZE TABLE 3 - DEFLECTION (minimum values in cm for single canvas at PALLADIA)
* According to the UNI EN 13561 standard
Values in cm for the maximum size of single canvases
Degree Class* Load (N/mq) Knots Km/h m/s Envir. conditions Eects of wind
0 0 < 40 0-1 0-1 < 0,3 Calm Smoke rises vertically
1 0 < 40 1-3 1-5 0,3-1,5 Light air Direction of wind shown by smoke drift, but not by weather vanes
2 0 < 40 4-6 6-11 1,6-3,3 Light breeze Wind felt on face, ordinary vanes moved by wind
3 0 < 40 7-10 12-19 3,4-5,4 Gentle breeze Leaves and small twigs in constant motion
4 1 40 11-16 20-28 5,5-7,9 Moderate breeze Raises dust and loose paper; small branches are moved
5 2 70 17-21 29-38 8-10,7 Fresh breeze incominciano ad oscillare i piccoli alberi
6 3 110 22-27 39-49 10,8-13,8 Strong breeze Large branches in motion; umbrellas used with difficulty
7 >3 >110 28-33 50-61 13,9-17,1 Strong wind Whole trees in motion; inconvenience felt when walking against wind
8 >3 >110 34-40 62-74 17,2-20,7 Fresh gale Branches break off trees; generally impedes progress
9 >3 >110 41-47 75-88 20,8-24,4 Strong gale Tiles come off roofs
10 >3 >110 48-55 89-102 24,5-28,4 Whole gale Trees uprooted
11 >3 >110 56-63 103-117 28,5-32,6 Storm Serious damage to buildings
12 >3 >110 >64 >118 > 32,7 Hurricane Immense damagei
Model Nr. of
runners
Width Projection
PALLADIA flat 2 350 650
3 700 650
4 1050 650
PALLADIA tilted 2 500 650
3 900 650
4 1300 650
Width (cm)
250 300 350 400~500 550~600 650~700 750~900 950~1050
11 14 17 11 14 17 14 17
2 runners 3 runners 4 runners

40 of 121
CORRADI SPA - USER MANUAL - PALLADIA 20.05.2013
TABLES
TABLE 6 - MINIMUM SLOPE (minimum values in cm for single canvas tilted Palladia)
Width (cm)
200 250 300 350 400 450 500 500 550 600 650 700 750 800 850 900 950 1000 1050 1100 1150 1200 1250 1300
250 15 20 25 29 34 39 43 20 23 25 27 29 32 34 37 39 27 28 29 32 33 34 37 38
300 19 25 30 36 41 47 52 25 28 30 33 36 39 41 44 47 34 35 36 39 40 41 45 46
46 22 29 36 42 48 55 61 29 33 36 39 42 45 48 52 55 40 41 42 46 47 48 53 54
400 26 34 41 48 56 63 71 34 38 41 45 48 52 56 60 63 46 47 48 54 55 56 61 62
450 31 39 47 55 63 72 80 39 43 47 51 55 59 63 68 72 53 54 55 61 62 63 70 71
500 35 44 53 62 71 80 90 44 49 53 58 62 67 71 76 80 60 61 62 69 70 71 78 79
550 39 49 59 69 79 89 99 49 54 59 64 69 74 79 84 89 67 68 69 77 78 79 87 88
600 43 54 65 76 87 98 109 54 60 65 71 76 82 87 93 98 74 75 76 85 86 87 96 97
650 48 60 71 83 95 107 119 60 66 71 77 83 89 95 101 107 81 82 83 93 94 95 105 106
Projection (cm)
2 runners 3 runners 4 runners

41 of 121
CORRADI SPA - USER MANUAL - PALLADIA
ITALIANOENGLISHDEUTSCHFRANÇAISESPAÑOL
20.05.2013
WARRANTY
ART. 1 - USE:
PALLADIA is a pergola with retractable awning to cover outdoor
areas such as gardens, balconies, rooftop gardens, yards, etc.
PALLADIA and its components have been designed, patented
and registered as trademarks by Corradi Spa - Bologna, Italy - and
have been manufactured in accordance with applicable technical
standards.
The warranties hereunder are valid if installation and use of the
awning conform to the specifications indicated in the articles and
tables below. Only the finest materials, suited to outdoor use, have
been used in the manufacture of PALLADIA components.
PALLADIA is designed and manufactured to customer specifications,
to protect from the sun and precipitations with a resistance to water
accumulation over Class 2 (56 lt/hour x mq) of the UNI EN 13561,
snowfall excluded and a wind resistance over Class 3 (49 km/hour)
of the UNI EN 13561.
ART. 2 - VERSIONS:
PALLADIA TILTED VERSION must be fixed to a suitable supporting
wall and may be used in winds of up to force 8 on the Beaufort scale
as shown in table 1.
PALLADIA FLAT VERSION must be fixed to a suitable supporting wall
and may be used in winds of up to force 6 on the Beaufort scale as
shown in table 1.
ART. 3 - INSTALLATION:
PALLADIA shall always be fixed to a suitable supporting structure
(wall or ceiling): all conditions in table 2 “Maximum size”, table 3
“Deflection“ table 4-5 “Maximum load”, table 6“Minimum slope”shall
be complied with.
The retailer has to give the“USER MANUAL”to the client.
ART. 4 – WARRANTY VALIDITY:
The warranty is only valid if the installation and utilisation conditions
as specified in art. 3 are observed.
The warranty covers the repair or entire replacement free of charge
(labour excluded) of all components that may be nonconforming
or faulty, including transport charges. Damage from non-enjoyment
of PALLADIA for any period of non-use before and during the repair
shall not be covered.
No compensation may be claimed for“actual damages or lost profit”.
The above mentioned warranty will be effective only in the state in
which the retailer or the concessionaire has his own office.
ART. 5 - WARRANTY STARTING POINT:
The warranty starts from the date on which work ends with delivery
of the User Manual and, in any case, from the date on which Corradi
Spa receives copy of the declaration of correct installation complete
in all its parts and signed by the end buyer and by the authorised
retailer.
ART. 6 – WARRANTY EXCLUSIONS:
The warranty is not valid in the cases listed below, by way of
illustrative and non-limiting example:
a) For damage arising from impact or extraordinary natural events
(lightning, flooding, earthquake, hail, etc.)
b) For damage caused by the actions of persons or technicians not
authorised by Corradi Spa;
c) If the electrical voltage has a variation above or below 5% of the
rated value (IEC standard 2-3 July 1988)
ART. 7 - DURATION OF WARRANTY:
5 YEARS (five):
For the structure, the handling system and the ECLISSI fabric.
2 YEARS (two):
CRISTAL and VINITEX fabric for any outer fasteners (roll up canvases,
sliding canvases, canvases with zippers, etc. The wind resistance of
these components depends on the solution installed and will be
certified, upon request, for each single installation.
ART. 8 - COMPLAINT:
According to art. 1495 sub-section 1 and 1511 sub-section 1 of the
Civil Code, the customer may inform the retailer of any apparent
fault found on the goods in writing only and no later than 8 (eight)
days of receiving the goods. According to art.
1495 sub-section 1 of the Civil Code, the customer may inform the
retailer of any non-apparent fault found on the goods in writing
only and no later than 8 (eight) days of the discovery date, providing
photographic proof of the fault. Both legal actions by the buyer
towards the retailer become statutebarred one year after receiving/
installing the goods (Art. 1495 sub-section 2).
According to art. 1512 of the Civil Code, the customer may inform
the retailer of any operating fault in writing only and no later than
15 (fifteen) days of discovery under penalty of cancellation of the
warranty.

42 of 121
CORRADI SPA - USER MANUAL - PALLADIA 20.05.2013
WARRANTY
The legal action by the buyer towards the retailer becomes statute-
barred six months after discovery (Art. 1512 subsection 1).
The customer may inform the retailer of any non-conformity covered
by articles 128 to 1134 of legislative decree 206 / 2005 (Consumers
Code) in writing only and no later than 2 (two) months of discovery.
The legal action by the buyer towards the retailer becomes statute-
barred within 26 months of the discovery date announced in the
terms (Art. 132 sub-section 4 Consumers Code).
ART. 9 - TERRITORIAL EXTENTION OF THE WARRANTY:
The above mentioned warranty will be effective only in the state in
which the client has his own domicile.
Productsdirectlyorindirectlysold,installed orgrantedforcommodate
to customers outside the client’s domicile ar e specifically excluded
from warranty unless agreed in writing by Corradi Srl.

43 of 121
CORRADI SPA - USER MANUAL - PALLADIA
ITALIANOENGLISHDEUTSCHFRANÇAISESPAÑOL
20.05.2013
CE MARKING
Crushing hazard
Electric shock hazard
CE MARKING
CE MARKING PALLADIA 2-3-4-5 RUNNERS VERSIONS
Corradi Srl - Via G. Brini, 39 - 40128 Bologna Italy
Model: PALLADIA 2-3-4-5 runners
Serial nr: 00000/00
Power supply: 230 V ~
Number of phases: 2
Wind-resistance: Class 3 EN 13561
Power: 218 W
Frequency: 50 Hz
Year of production: 0000

CORRADI SPA - USER MANUAL - PALLADIA
44 of 121
20.05.2013
CE DECLARATION OF CONFORMITY
The following CE Declaration of Conformity is subordinated to the observance of constraints and indications in the product warranty, as well as the correct installation done by the person in
charge in accordance with the installation and lay-out instructions established by Corradi Spa.
The person authorised to draw up technical documentation is: EngineerGianmarco Biagi C/o sede Corradi via Brini, 39 40128 Bologna
THE MANUFACTURER
I declare that the above described product conforms to the indications and requirements in the above mentioned Directives.
CHIEF EXECUTIVE OFFICER
Eng. Gianmarco Biagi
(*) Directives exclusively applicable to products with motorizations and automations [see User manual ]
(**) Wind resistance class: the wind resistance class has been verified using installation supports with features as in the Load table in the Installation manual
Costruttore: Corradi Spa
Via G. Brini, 39 - 40128 Bolgna Italy
Descrizione del prodotto: PALLADIA
Modello: PALLADIA 2 - 3 - 4 - 5 runners
Numero di matricola: (see CE marking on product)
Anno di fabbricazione: (see CE marking on product)
Destinazione d’uso: (see Userhandbook-Original Instructions and concerning Warranty)
With the following document the company declares on its own responsibility, that the above
mentioned product satisfies the Directives indicated on the side:
REFERENCE DIRECTIVES appliable to the following CE Declaration of
Conformity
Construction Production Directive 89/106/CEE;
Electromagnetic Compatibility Directive2004/108/CE(*);
Machinery Directive 2006/42/CE(*);
Low Voltage Directive 2006/95/CE(*);
The conformity has been verified with the aid of the following norms:
- Performance requirements, safety included UNI EN 13561:2009
- Wind resistance class: Class 3(**) (method according to UNI EN 1932: 2002);
INDICATION / CONDITIONS TO WHICH THE USAGE OFTHE PRODUCT IS SUBJECT:
The CORRADI product is subject to the installation activity done for the Client.
The Authorized Installer has to draw up and hand over the suitable DECLARATION OF CORRECT INSTALLATION AND CLASSIFICATION OF WIND RESISTANCE to the user, which testifies the
correct installation, in accordance with the instructions supplied by the manufacturer and applied in accordance with the state and morphology of the installation site and corresponding
to the using conditions for which it has been realized.
The Installer has to follow the reference instructions in the“INSTALLATION HANDBOOK”and“USER HANDBOOK” .
The Installer fills out and signs the DECLARATION OF CORRECT INSTALLATION AND CLASSIFICATION OF WIND RESISTANCE, in accordance with the model in the USER HANDBOOK.
RESERVED FOR QUALIFIED TECHNICIANS

45 of 121
CORRADI SPA - USER MANUAL - PALLADIA
ITALIANOENGLISHDEUTSCHFRANÇAISESPAÑOL
20.05.2013
PROCEDURE FOR INSTALLING THE PLAN 75  TYPE 1 MOTOR ONLY FOR INSTALLERS
B
A
M1
1
2
3
13
2
A
B
Panel
PLAN 75 Motor
230 V/50 Hz
In= 0,97 A
Pn= 218 W
IP= 54
Open male plug
supplied
Insulated extend
button 230 V
WIRE TYPE
FG70R 3X1,5 mmq
WIRE TYPE
FG70R 3X1,5 mmq
WORK MUST BE CARRIED OUT BY INSTALLER
COMMON
EXTEND
RETRACT
Insulated retract
button 230 V
RESERVED FOR QUALIFIED TECHNICIANS
WARNING
a qualied technician must initially adjust the motor.
When there is an electrical current, proceed with maximum caution in
accordance with the safety regulations in force.
When everything has been assembled, check that the transmission system
is properly connected: shafts, tubes, side shafts and motor heads, with the
sliders stacked at the top of the awning. The motor is in neutral in this
position. Before assembling the awning proceed as follows:
1)TEMPORARY ADJUSTMENT OF THE OPENING LIMIT SWITCH
Press push-button A and Bwith a screwdriver, turning it slightly in order to
secure the push-button. Press the pushbutton
panel to move the awning to 3/4 of the runner. To store the limit switch
and quit the procedure press push-button A and B with a screwdriver
and turn slightly to release, to store the limit switch position and quit the
procedure.
2) ASSEMBLING THE AWNING
Assemble the end and intermediate tubes to the structure,
securing them to the sliders.
3) ADJUSTING THE CLOSING LIMIT SWITCH, WITH AWNING
RETRACTED
Go back to the neutral position, retracting the awning until it stops, then
press push-button B* with a screwdriver, turning it slightly in order to
secure the push-button. Set the closing limit switch 5 cm ahead of the
neutral position, so that the sliders are slightly slack. Press push-button
Bwith a screwdriver and turn slightly to release, to store the limit switch
position and quit the procedure.
4) PERMANENT ADJUSTMENT OF THE OPENING LIMIT SWITCH
Open the awning until it stops (temporary opening limitswitch) then press
push-button a with a screwdriver, turning it slightly in order to secure the
push-button. Roll down the awning until it reaches the right opening
position. To store the limit switch and quit the procedure press push-
button a with a screwdriver and turn slightly to release, to store the limit
switch position and quit the procedure.
* Do not try to force the push-button if it does not move when pressed, but
ensure that the motor is positioned on the limit switch.

CORRADI SPA - USER MANUAL - PALLADIA
46 of 121
20.05.2013
ADJUSTING THE COMMANDS
ELECTRIC DRIVE TYPE 1 PLAN 75 MOTOR
B
A
M1
1
2
3
13
2
A
B
PLAN 75 Motor
230 V/50 Hz
In= 0,97 A
Pn= 218 W
IP= 54
Open male plug
supplied
Insulated extend
button 230 V
WIRE TYPE
FG70R 3X1,5 mmq
WIRE TYPE
FG70R 3X1,5 mmq
WORK MUST BE CARRIED OUT BY INSTALLER
COMMON
EXTEND
RETRACT
Insulated retract
button 230 V
RESERVED FOR QUALIFIED TECHNICIANS RESERVED FOR QUALIFIED TECHNICIANS
LIMIT STOP ADJUSTMENT PLAN 75 MOTOR
The end user of the product must refer to the limit stop adjustment
procedure described here below. This procedure differs from the initial
adjustment of the motor set by the technical installer (see Installation
Manual).
LIMIT SWITCH: OPENING AWNING EXTENDED
If the INSTALLATION KIT panel is present, connect it to the motor so that it
can be manoeuvred.
N.B. For those who don’t have a push-button panel ask a qualied
technician to realize one, as in the wiring scheme.
Run down the awning to the pre-set position for the opening limit switch;
the awning must be in this position to set the opening limit switch.
Push the A* button on the motor box using a screwdriver, making a slight
rotation, block the push-button in depressed position. The actual limit
switch will be cancelled.
When the push-button is pushed inside, operate the panel until the
awning is in the right limit switch position. Press pushbutton Awith a
screwdriver and turn slightly to release, to
store the limit switch position and quit the procedure.
*Do not try to force the push-button if it does not move when pressed,
but ensure that the motor is positioned on the limit switch.
LIMIT SWITCH: CLOSING AWNING RETRACTED
Connect the panel to the motor. Raise the awning to the preset position
for the closing limit switch. The awning must be in this position to set
the closing limit switch. Press push-button B* on the motor body with a
screwdriver, turning it slightly in order to secure the push-button.
When the push-button is pushed inside and secured, operate the panel
until the awning is in the right limit switch position.
Press push-button Bwith a screwdriver and turn slightly to release, to store
the limit switch position and quit the procedure.
