Courtyard Creations Fabric Hammock With Canopy User manual

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
INTENDED FOR RESIDENTIAL USE ONLY.
KUS2017
PAGE 1 OF 3 COURTYARD CREATIONS INC.
PARTS LIST
PART
NO. MATERIAL CODE PART Q’TY
61K2018C00001BA
SKIN 1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
2
2
4
1
1
2
1
1
2
1
1
1
4
4
4
2
2
2
2
1
62KUS2160J102
KUS2015-CS01
KUS2015-CS02
62KUS2010B201
KUS2018-CS01
62KUS2010I101
KUS2018-CS02
62KUS2018H101
62KUS2018I101
62K2018G00001BA
61K2018K00001BA
61K2018D00001BA
180701010301
17XA0901-----Y3
17XA0703-----Y3
17XA1001-----Y3
17KAA0101----Y4
18000337004
17FA05040301-Y4
17C33A0710001Y4
BOTTOM SUPPORT
BOTTOM SUPPORT
LONG SIDE BEAM
SIDE SUPPORT
SHORT SIDE BEAM
SLING BRACE
CANOPY CROSS BRACE A
U-SHAPED CANOPY BRACE B
FRONT/REAR CANOPY BRACE
MAGAZINE BAG
CANOPY
PILLOW
SUSPENSION CHAIN
BOLT M6*30
WASHER d6.5*D13*1.0
BOLT CAP
HEX.KEY WRENCH 4MM
SLING BRACE CAP
SUSPENSION HOOK
CHAIN CONNECTOR
Instructions:Please identify all parts prior to assembly.
FIGURE 1
3
3
221
1
3
3
Fabric Hammock With Canopy
Step 1:
Insert bottom supports (#2) into bottom supports (#1)
for both sides. Then insert the side supports (#3) into
the assembled bottom supports. See Figure 1.
Note:
Make sure the spring buttom should come completely
through the holes.
Use the correct bolts as indicated. Do not tighten any of the bolts until is completely assembled.
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by children. Children should
always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
Quote the following FQC NO. when contacting the service center.
SERVICE CENTER TOLL FREE NO.
TEL: [phone]
FAX: [phone]
!
!
!
!
!

PAGE 2 OF 3
FIGURE 2
FIGURE 4 FIGURE 5
16
16 16 16
13
78
16
5
12
10
12
4
FIGURE 3
4
10
33
33
16 16
15 15 17
11
14
14
14
14
6
6
5
Step 2:
Insert the long side beams (#4) through the sleeve of
magazine bag (#10), then insert the long side beam
(#4) and the short side beam (#5) into the both of the
side supports (#3). See Figure 2.
Note:
Make sure that the suspension chains (#17) are properly
connected without any twists or tangles.
Step 3:
Attach the chain connectors (#15) and suspension hooks
(#16) with suspension chains (#17), then insert the sling
brace (#6) through one side of skin (#11) sleeve and
chain connector assembly.
Attach the other chain connector (15) and suspension
hooks (#16) only, then insert the sling brace through
the other side of the skin (#11) sleeve and chain
connectors. Cover sling braces with sling brace caps
(#14). See Figure 3.
Step 4:
Hook the entire fabric sling-assembly into the holes of
the side beams (#4 and #5) with the suspension hooks
(#16). Make sure all hooks pass completely through the
side beams until you see the hook end at the bottom
hole of the side beam for a solid assembly. Tie the pillow
(#12) to the chain connectors (#15) at the higher end of
the hammock. See Figure 4.
Step 5:
Insert the canopy cross brace A (#7) and U-shaped
canopy brace B (#8) into the sleeves of the canopy
(#13). See Figure 5.
Note:
Before each use, inspect the hammock to ensure that
all parts are in good order and are properly assembled.
Carefully examine the frame to ensure that all of the parts
(including welds) are sound (free of excessive rust or
cracks).
15

FIGURE 6
FIGURE 8
FIGURE 7
Step 6:
Insert the front/rear canopy braces (#9) into the sleeves
of the canopy (#13). See Figure 6.
Step 7:
Attach the front/rear canopy brace (#9) to the U-shaped
canopy brace B (#8). Then fasten the canopy cross brace
A(#7) and front/rear canopy brace (#9) by using bolt (#18)
and washer (#19) for both sides. Make sure that all of the
bolts have been tightened completely and cover them with
bolt caps (#20). See Figure 7.
Step 8:
Insert the front/rear canopy braces (#9) into the short side
beam (#5). See Figure 8.
The store where you made your purchase
does not stock parts for this item.
If you need parts,
whether they are missing or damaged,
STOP!
MissingAPart?
No Need To Go Back To
The Store
Call us between 9:00 AM and 4:30 PM
Eastern Time Monday through Friday
Call Toll Free:
TEL: [phone]
FAX: [phone]
READ THESE INSTRUCTIONS COMPLETELY BEFORE STARTING ASSEMBLY
SEPARATE AND IDENTIFY ALL PARTS, MAKING SURE THAT YOU
HAVE ALL OF THEPARTSLISTED.
IF YOU DO NOTLOCATE ALL OF THE PARTS LISTED, INSPECT THE
PACKING MATERIAL FOR SMALL PARTSTHAT MAYHAVEBECOME
SEPARATED DURING SHIPMENT.
IF YOU EXPERIENCEANY DIFFICULTYDURING ASSEMBLYOR IF ANY
PARTS ARE MISSING OR DAMAGED,CALL THE HELP LINE AT
1-877-539-7436 BEFORERETURNING THIS ITEM TO THESTORE.
PROVIDE THEFOLLOWING INFORMATION WHEN CALLING:
1-MODEL NUMBER OF THEPRODUCT.
2-PARTNUMBER AND MATERIAL CODE OF THE PARTFROM THE PARTS
LIST.
MOST PROBLEMSCAN BERESOLVED WITHOUT RETURNING THIS
PRODUCT TO THERETAILER.
PAGE 3 OF 3
9713
9
9
9
19
18
20
9
7
8
88
8
Cleaning and Maintenance
• Wash frame parts with mild soap and water, rinse
thoroughly, and dry completely. Do not use bleach,
acid, or other solvents on the frame parts.
• The pillow and fabric may be washed on the surface
only by using mild soap and water or commercial foaming
upholstery cleaner if necessary. If washed, rinse well
and hang to dry. Do not machine wash or dry.
• We recommend the use of furniture covers to protect
your hammock when not in use.
• Inspect and tighten all parts on a regular basis to ensure
the proper performance and safety of your hammock.
• In order to prolong the life and beauty of your hammock,
we recommend that it be stored in a dry and protected
area during off season periods.
