Courtyard Creations TCS26SH User manual

TCS26SH
Step 1:
Place the table top (#1) onto a non-abrasive surface,
such as a carpet, with its underside facing upwards.
Fasten the legs (#2) to the underside of the table top
(#1) rim by using bolts (#5) . Keep the
bolts loose. See Figure 1.
PARTS LIST
1
1
4
4
12
1
1
TCS27SH-CS05-1
TCS27SH-CS04-1
62TCS27HVY101
13C??1B29008001
17C40A0705001YX
17KAC3101----Y3
17KAA0101----Y4
TABLE TOP
LEG
CENTER
CONNECTOR
TILE
HEX.KEY WRENCH 4MM
HEX.KEY WRENCH 10MM
BOLT M6*15
FIGURE 1
PART
NO. MATERIAL CODE PART Q’TY
1
2
3
4
5
6
7
ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
INTENDED FOR RESIDENTIAL USE ONLY.
Note:
The tiles are easy to be broken, be careful when you
remove them. Do not throw the residual tiles away,
retain them for future use.
Attention:
Make sure that each bolt needed for all steps matches
the corresponding figure to ensure proper assembly.
5
2
22
2
1
COURTYARD CREATIONS INC.
Use the correct bolts as indicated. Do not tighten any of the bolts until the table is completely
assembled.
Do not sit or stand on this table.
Do not discard of any of the packaging until you have checked that you have all of the parts and
fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by
children. Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
Quote the following FQC NO. when contacting the service center.
!
!
!
!
!
!
PAGE 1 OF 2
SERVICE CENTER TOLL FREE NO.
TEL: [phone]
FAX: [phone]
#5 BOLT M6*15
15

#5 BOLT M6*15
15
FIGURE 3
FIGURE 4
Step 3:
Turn the table to its upright position. Place the tiles
(#4) onto the table top (#1) carefully.
See Figure 3 and Figure 4.
Note:
1. If any EVA foams on the table top (#1) are missing,
there are extra EVA foams in the hardware kit.
See Illustration A.
2. To repair any scratches on the frame, use the
touch-up paint (#11) provided.
Step 2:
Fasten the center connectors (#3) to the middle of
the legs (#2) by using bolts (#5). Make sure that all
of the bolts have been tightened completely .
See Figure 2.
Cleaning and Maintenance
• W ash frame parts with mild soap and water, rinse
thor oughly, and dry completely. Do not use bleach, acid,
or other solvents on the frame parts.
• Inspect and tighten all bolts and fasteners on a regular
basis to ensure the proper performance and safety of
your table .
• When moving the table, lift. Do not drag this table.
• We recommend the use of furniture covers when not
in use.
• In order to prolong the life and beauty of your table, we
recommend that it be stored in a dry and protected
area during off season periods.
A
4
1
FIGURE 2
5
5
2
2
2
3
2
PAGE 2 OF 2
The store where you made your purchase
does not stock parts for this item.
If you need parts,
whether they are missing or damaged,
STOP!
Missing A Part?
No Need To Go Back To
The Store
Call us between 9:00 AM and 4:30 PM
Eastern Time Monday through Friday
For further assistance,
please visit us at
[email protected]
Call Toll Free:
TEL: [phone]
FAX: [phone]
READ THESE INSTRUCTIONS COMPLETELY BEFORE STARTING ASSEMBLY
SEPARATE AND IDENTIFY ALL PARTS, MAKING SURE THAT YOU
HAVE ALL OF THEPARTSLISTED.
IF YOU DO NOTLOCATE ALL OF THE PARTS LISTED, INSPECT THE
PACKING MATERIAL FOR SMALL PARTSTHAT MAYHAVEBECOME
SEPARATED DURING SHIPMENT.
IF YOU EXPERIENCEANY DIFFICULTY DURING ASSEMBLYOR IF ANY
PARTS ARE MISSING OR DAMAGED,CALL THE HELP LINE AT
1-877-539-7436 BEFORERETURNING THIS ITEM TO THE STORE.
PROVIDE THEFOLLOWING INFORMATION WHEN CALLING:
1-MODEL NUMBER OF THEPRODUCT.
2-PARTNUMBER AND MATERIAL CODE OF THE PARTFROM THE PARTS
LIST.
MOST PROBLEMS CAN BERESOLVED WITHOUT RETURNING THIS
PRODUCT TO THERETAILER.
Warranty
•This product is covered by Courtyard Creations Inc. One–year limited warranty.
•Proof of purchase (dated register receipt) is required for warranty claims.
•It remains the customer’s responsibility for freight and packing charges to and from over service center.
