Covidien Kendall SCD 700 Series Manual

Instruction Guide for Cleaning, Testing, and Packaging
Kendall SCD™ 700 Sequential Compression System
Controller and Tubing Set

1
TABLE OF CONTENTS
Section 1 – Instructions for UNUSED Units 2
ConfirmKitMaterials 2
Apply DME Label to Kendall SCD™ 700 Controller 2
PackagingInstructions 3
Section 2 – Instructions for Customer Returned Units 5
ReferenceDocuments 5
EquipmentList 5
Preparation 5
TubingSet: 7
VisualInspection 7
Cleaning 7
LeakTest 7
Kendall SCD™ 700 Controller: 9
VisualInspection 9
Cleaning 10
General Function Test 10
Re-Packaging Procedure: 11
KitMaterials 11
PackagingInstructions 11
Attachment A – Instructions for Returning Damaged Controllers 13

2
Section 1 – Instructions for UNUSED Units
CONFIRM KIT MATERIALS
Verify that all the following materials are available:
Part Description Quantity Part # Vendor Contact Info
New Kendall SCD™ 700 compression system 1 H29525 Covidien 1-800-962-9888
www.covidien.com
Return Label 1 N/A N/A N/A
Twist Ties, Blue Plastic 1 F150023 Covidien 1-800-962-9888
www.covidien.com
Kendall SCD™ 700 controller QuickStart Guide 1 1066981 Covidien 1-800-962-9888
www.covidien.com
Kendall SCD™ 700 controller Printed IFU 1 1066980 Covidien 1-800-962-9888
www.covidien.com
APPLY DME LABEL TO KENDALL SCD™ 700 CONTROLLER
Remove home controller from the packaging and take out of the polybag and AIR-PAQ™*
inflatable packaging.
Create a label that provides the DME supplier contact information. At a minimum, the information
should contain the following:
Company name
Company address
Company telephone number
Apply DME supplier contact information label on the front of the controller, approximately
centered in the area indicated by the box in the sketch below (on the front of the controller, below
the control panel):
Place home controller back into the polybag and AIR-PAQ™* inflatable packaging.
Place the printed IFU into the shipping box.
PLACE LABEL WITHIN THE BOXED AREA

3
Section 1 – Instructions for UNUSED Units (continued)
PACKAGING INSTRUCTIONS
Re-package the home controller in the polybag and AIR-PAQ™* inflatable packaging. Place the
tubing sets into the original package the way it was received (see picture below).
Place the QuickStart Guide on top of the AIR-PAQTM*inflatable packaging as shown below:
AIR-PAQTM*
INFLATABLE
PACKAGING
TUBING SET
TUBING SET

4
Section 1 – Instructions for UNUSED Units (continued)
PACKAGING INSTRUCTIONS (continued)
Seal the top of the box and confirm all labels are visible on the outside of the shipping box as
shown below:
oSerial label on the top of the shipping box;
oShipping label on the front wrapping on the left side;
oReturn label to the right of the shipper label and beneath the serial label.
SERIAL
LABEL
SHIPPING
LABEL RETURN
LABEL

5
Section 2 – Instructions for Customer Returned Units
REFERENCE DOCUMENTS
Kendall SCD™ 700 system Operation and Service Manual
EQUIPMENT LIST
Regulated air source (i.e. compressor or factory air)
Tubing set Leak Test Fixture (provided by Covidien)
Known good tubing set
PREPARATION
TUBING SET LEAK TEST FIXTURE SETUP:
NOTE: This is to be performed upon receipt of the fixture, to confirm acceptable fixture
functionality.
oConfirm the tubing set Leak Test Fixture’s certification from the fixture manufacturer.
oConfirm pressure gauge is calibrated. If not, send out for re-calibration.
oConduct the leak test with the known good tubing set as follows:
Ensure that the Leak Test Fixture (see sketch below) is connected to a regulated
air source. The input air should be at pressure between 3 psi and 4 psi.
Connect the tubing set to the connectors on the test fixture. See pictures below.
CONNECT TO AIR

6
Section 2 – Instructions for Customer Returned Units (continued)
PREPARATION (continued)
TUBING SET LEAK TEST (continued):
Turn ball valve to open position, so that the knob position is in-line with valve
body (see picture below).
Adjust the input air pressure so that a pressure of between 125mmHg (2.4 psi)
and 135mmHg (2.6 psi) is indicated on the fixture’s pressure gauge, and allow to
hold for approximately 2 seconds.
Close ball valve, so that the knob position is perpendicular to valve body (see
picture below). Activate the stopwatch.
Wait 15 seconds and observe the pressure gauge. Because the test was
conducted with known good tubing set, the pressure should not fall below
89mmHg (1.72 psi). If pressure falls below 89mmHg, contact your sales rep for
replacement tubing set Leak Test Fixture.

7
Section 2 – Instructions for Customer Returned Units (continued)
TUBING SET
VISUAL INSPECTION
Inspect the tubing sets for missing, broken or cracked components. If any components are
missing, broken or cracked, discard the tubing set.
Inspect the tubing set for condensation in the tubing. If condensation is present in the tubing,
discard the tubing set.
Inspect the printing on the tubing set connectors. If any connectors contain incomplete
characters, discard the tubing set.
CLEANING
Clean the customer returned tube set as per the Kendall SCD™ 700 system Operation and
Service Manual.
All visible extraneous markings or materials should be removed by the cleaning step. If
extraneous markings or materials are not removed, discard the tubing set.
LEAK TEST
Inspect the Leak Test Fixture to ensure that it is in working order and that the pressure gauge
has a valid calibration date.
Ensure that the Leak Test Fixture is connected to a regulated air source. The input air should
be at pressure between 3 psi and 4 psi. See sketch below.
Connect the Tubing Set to the connectors on the test fixture. See pictures below.
CONNECT TO AIR

8
Section 2 – Instructions for Customer Returned Units (continued)
TUBING SET (continued)
LEAK TEST (continued)
Turn ball valve to open position, so that the knob position is in-line with valve body (see
picture below).
Adjust the input air pressure so that a pressure of between 125mmHg (2.4 psi) and
135mmHg (2.6 psi) is indicated on the fixture’s pressure gauge, and allow to hold for
approximately 2 seconds.
Close ball valve, so that the knob position is perpendicular to valve body (see picture below).
Activate the stopwatch.
Wait 15 seconds and observe pressure gauge. Pressure should not fall below 89mmHg
(1.72 psi). If pressure falls below 89mmHg, the tubing set has a leak. Discard the tubing set.
NOTE: If tubing set inspection and cleaning is not completed as per the steps above,
discard the tubing sets and provide new tubing sets in the package.

9
Section 2 – Instructions for Customer Returned Units (continued)
KENDALL SCD™ 700 SYSTEM CONTROLLER
VISUAL INSPECTION
Inspect the DME supplier contact information label. If the DME supplier contact information
label is torn, ripped or illegible, replace with a new label (see sketch below):
Inspect the power cord for damage. If power cord is frayed or damaged, send the controller
to the Covidien service center for repair (Reference Attachment A).
Inspect the controller for marks, scuffs and scratches especially on the control panel (see
below).
Minor surface scratches or scuffs are acceptable. If any marks are present that obscure or
interfere with the display of the icons or the clear membrane on the control panel, send the
controller to the Covidien service center for repair (Attachment A).
Inspect the controller for missing, broken or cracked components. If any components are
missing, broken or cracked, send the controller to the Covidien service center for repair
(Attachment A).
Inspect the controller for the presence of the serial label on the bottom of the device. It the
serial label is not present, or if it is illegible or damaged, send the controller to the Covidien
service center for repair (Attachment A).
PLACE LABEL WITHIN THE BOXED AREA
CONTROL PANEL

10
Section 2 – Instructions for Customer Returned Units (continued)
KENDALL SCD™ 700 CONTROLLER (continued)
CLEANING
Unplug the controller from Mains voltage before cleaning.
Clean the customer returned Kendall SCD™ 700 controller as per the Kendall SCD™ 700
system Operation and Service Manual.
GENERAL FUNCTION TEST
With no tubing set connected to the SCD™ 700 controller, connect the controller to AC
power. Verify that the power source light (power on indicator) turns on. Note: Controller
must be connected to AC power to enter test mode.
See front panel display below:
Enter “Test Access Mode”, and conduct the general function test (test mode T2) as per the
Kendall SCD™ 700 system Operation and Service Manual.
Verify battery status:
oTurn off the controller.
oDisconnect the controller from AC Power, and activate again.
oConfirm that battery charge level is at least 2/3 (i.e. 2 or 3 green battery status
indicators).
oIf battery charge level is less than 2/3, connect the controller to AC power, and leave
connected to AC power until battery reaches at least 2/3 level.
If operation of the SCD™ 700 controller is not correct as per the above tests, send the
controller to the Covidien service center for repair (Attachment A).

11
Section 2 – Instructions for Customer Returned Units (continued)
KENDALL SCD™ 700 CONTROLLER (continued)
RE-PACKAGING PROCEDURE
KIT MATERIALS
oVerify that all materials are available, referencing the batch record.
oList of materials required to re-package the kit is as follows:
Part Description Quantity Part # Vendor Contact Info
Kendall SCD™ 700 system corrugate case 1 1029053 Covidien 1-800-962-9888
www.covidien.com
Kendall SCD™ 700 system tubing sets (for
replacements) 2 9528 Covidien 1-800-962-9888
www.covidien.com
Kendall SCD™ 700 system hospital DME shipping
label 1 1077455 Covidien 1-800-962-9888 www.covidien.com
Return Label 1 N/A N/A N/A
Chip Board - AIR-PAQTM* Protector 1 1059428 Covidien 1-800-962-9888
www.covidien.com
Kendall SCD™ 700 system AIR-PAQTM* inflatable
packaging 1 1031823 Covidien 1-800-962-9888 www.covidien.com
Polybag for Kendall SCD™ 700 controller 1 1033373 Covidien 1-800-962-9888
www.covidien.com
Polybag for tubing set 2 F123450 Covidien 1-800-962-9888
www.covidien.com
Twist Ties, Blue Plastic 1 F150023 Covidien 1-800-962-9888
www.covidien.com
Kendall SCD™ 700 controller QuickStart Guide 1 1066981 Covidien 1-800-962-9888
www.covidien.com
Kendall SCD™ 700 controller Printed IFU 1 1066980 Covidien 1-800-962-9888
www.covidien.com
PACKAGING INSTRUCTIONS
oUsing regulated air source set at 9-10 psi of pressure; inflate the AIR-PAQTM* inflatable
packaging. If an air source is not available to inflate AIR-PAQ™* inflatable packaging,
you should not ship the device. Hand delivery of the kit is recommended in this situation.
oTape the bottom surface of the shipping box.
oPlace the Chip Board in the box on the bottom surface. Place the Printed IFU in the
shipping box on top of the Chip Board.
oPlace the AIR-PAQ™* inflatable packaging into the shipping box on top of the printed
IFU. Place a tubing set on either side of the AIR-PAQTM* inflatable packaging as shown
below.
AIR-PAQTM*
INFLATABLE
PACKAGING
TUBING SET
TUBING SET

12
Section 2 – Instructions for Customer Returned Units (continued)
KENDALL SCD™ 700 CONTROLLER (continued)
RE-PACKAGING PROCEDURE (continued)
PACKAGING INSTRUCTIONS (continued)
oVerify that the DME supplier contact information label is on the Kendall SCD™ 700
controller. Place the controller into the polybag and use a twist tie to secure.
oPlace the Kendall SCD™ 700 controller in the AIR-PAQ™* inflatable packaging, and
close the AIR-PAQ™* inflatable packaging.
oPlace the QuickStart Guide on top of the AIR-PAQ™* inflatable packaging as shown
below:
oSeal the top of the box and assemble the following labels on the outside of the shipping
box as shown below:
Pre-printed shipping label on the front wrapping on the left side;
Return label to the right of the shipper label.
PRE-PRINTED
SHIPPING
LABEL
RETURN
LABEL

13
ATTACHMENT A: Instructions for Returning Damaged Controllers
To obtain service on your Covidien Kendall SCD™ 700 controller, you must contact the service
department and request a Return Material Authorization Number (RMA).
Please contact the service department by:
1. Phone- 1-800-962-9888 opt 1/opt 1
2. Email: [email protected]
3. CovidienConnect: https://www.covidienconnect.com/
Please have the following available when contacting the service department:
Account Bill To
Account Ship To
Device Serial Number
Reason for service/return
Contact information for Estimate approval if applicable: (Name, Phone Number & Email address)
Repackage the Kendall SCD™ 700 controller carefully in its original box. List the RMA number on the
shipping label or exterior of the box.
Equipment returned without RMA number will not be serviced!
Mail Device to:
Covidien
5290 Longbow Drive
Building 4 Service Dock
Boulder, Co 80301
COVIDIEN, COVIDIEN with logo, and Covidien logo are U.S. and internationally registered trademarks of Covidien AG.
™* Trademark of its respective owner. Other brands are trademarks of a Covidien company.
Covidien llc, 15 Hampshire Street, Mansfield, MA 02048 USA.
www.covidien.com
© 2014 Covidien
14MAN0014 07/14
