CPS BlackMax Series User manual

OWNER’S MANUAL (English)
(Software Version 1.1 or Higher with CPS®Link™App)
2 Valve Series: MD50W, MD50WHE, MD50WVHE
4 Valve Series: MD100W, MD100WHE, MD100WVHE
WIRELESS SERIES
For use with free BLACKMAX® app featuring CPS®Link™
US Patent No. 9,043,161. For Android or iOS mobile devices.
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

2
Overview ...................................................................................................................................2
General Safety Instructions.......................................................................................................3
Controls and Features ........................................................................................................... 4-5
Manifold Accessories................................................................................................................6
Quick Start Instructions (For Use With BLACKMAX Mobile APP).............................................7
BLACKMAX App Home Screen............................................................................................ 8-10
Testing: Pressure or Vaccum Hold ..........................................................................................11
Data Logging...........................................................................................................................12
Help Screen.............................................................................................................................13
Quick Start Instructions (Wireless Manifold without APP) .....................................................14
Initial Operation.......................................................................................................................15
Setting To Zero Pressure.........................................................................................................16
Testing: Pressure or Vaccum Hold .................................................................................... 16-19
Programming/Setting Units ............................................................................................. 19-22
Setting APO On or Off .............................................................................................................22
Connecting to an A/C system..................................................................................................23
Recovering Refrigerant ...........................................................................................................23
Evacuating Procedure .............................................................................................................24
Charging Procedure - Low Side ..............................................................................................24
Charging Procedure - High Side..............................................................................................25
Appendix A (Specifications: Manifold) ....................................................................................25
Appendix B (Specifications: MDXVG Vacuum Gauge Accessory) ...........................................25
Appendix C (Specifications: MDXBK Charger Accessory) .......................................................26
Appendix D (Battery Selection and Replacement)...................................................................26
Appendix E (Cleaning Sensor in MDXVG Vacuum Gauge) ......................................................26
Appendix F (Limited Warranty) ...............................................................................................27
Appendix G (Refrigerants Stored in MD50W and MD100W series) ........................................27
Appendix H (Error Indicator Screens) .....................................................................................28
CONTENTS
OVERVIEW
New Wireless BLACKMAX digital manifolds can be used as conventional, stand-alone
manifolds or can also be used with a free APP allowing a mobile device (running on
iOS or Android platforms) to communicate directly with and control select functions
on these models remotely. The resulting APP provides the HVAC/R technician with the
convenience of running and monitoring a BLACKMAX digital manifold (from up to 300
feet away), while also providing additional capabilities not found in non-wireless versions
(such as comprehensive views of system measurements, graphical depictions of test
functions, data logging, and more). If your mobile device is NOT available, your wireless
manifold may be operated as a stand alone device using the yellow keypad.
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

3
Please read, follow and understand the contents of this entire manual, with special attention given
to Danger, Warning and Caution statements.
FOR USE BY PROFESSIONALLY TRAINED AND CERTIFIED OPERATORS ONLY.
MOST STATES, COUNTRIES, ETC., MAY REQUIRE THE USER TO BE LICENSED.
PLEASE CHECK WITH YOUR LOCAL GOVERNMENT AGENCY.
DANGER: EXPLOSION/RUPTURE RISK!!! Use extreme caution when working with
flammable refrigerants. DO NOT use manifold with unregulated nitrogen,
carbon dioxide or other very high pressure gasses. NEVER USE MANIFOLD
WITH OXYGEN. Unregulated gasses can cause components in a refrigeration
system to rupture. Severe Injury or Death can occur.
DANGER: ELECTRICAL SHOCK HAZARD: Always disconnect power source when servicing
equipment.
WARNING: DO NOT APPLY MORE THAN 900 PSI TO ANY PORT ON MANIFOLD.
FOLLOW ALL EQUIPMENT MANUFACTURER’S TEST PROCEDURES WHEN
SERVICING THOSE SPECIFIC TYPES OF EQUIPMENT.
WARNING: Remove all hoses with care as they may contain liquid refrigerant under pressure.
Contact with refrigerant may cause frostbite or other related injuries. Wear proper
personal protective equipment such as safety goggles and gloves. When disconnecting
any hose, please use extreme caution.
WARNING: Avoid breathing refrigerant vapors and lubricant vapor or mist. Breathing high
concentration levels may cause heart arrhythmia, loss of consciousness, or even cause
suffocation. Exposure may irritate eyes, nose, throat and skin. Please read manufacturer’s
Material Safety Data Sheet for further safety information on refrigerants and lubricants.
NOTE: It may be unlawful to discharge or exhaust refrigerants into the
atmosphere. CPS strongly recommends the practice of recovery or
recycling. Check your local government agencies for refrigerant handling
regulations.
GENERAL SAFETY INSTRUCTIONS
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

4
CONTROLS AND FEATURES - BLACKMAX WIRELESS DIGITAL MANIFOLD
1. [ON/OFF] - Press and hold to turn On or Off
2. [SET] - For entering programed values
3. [REF] (Refrigerant) - Scrolls through 5 pre-selected “favorite” or commonly used
refrigerants
4. [MODE] - Programming (change English vs. Metric units; Turn Auto-Power OFF)
5. [SH/SC] (Superheat, Subcool)- Controls display of Superheat/ Subcool, Saturation
temperatures, and Delta T.
6. [TEST] - Press to obtain either “Pressure Hold” or “Vacuum Hold” tests.
7. [CLR] (Clear)- Sets pressure to zero point . Also ends any test in process.
8. [BACKLIGHT] - Press once to turn light On or Off
9. HIGH SIDE VALVE- Controls flow to right side ¼” SAE male port
10. REFRIGERANT VALVE (MD100 Series Only)- Controls flow through RIGHT MIDDLE
¼” SAE Male Port.
11. SIGHTGLASS- Monitor refrigerant flow
12. VACUUM VALVE (MD100 Series Only)- Controls flow through LEFT MIDDLE 3/8”
SAE PORT.
13. LOW SIDE VALVE- Controls flow to LEFT SIDE ¼” SAE Port.
14. CENTER PORT (MD50W Series Only)- A ¼” SAE Male “T” port used as common
connection to vacuum pump, recovery unit or refrigerant supply tank. The addition
of a ¼” SAE Male “T” fitting with valve core allows for a dual hook up between
vacuum pump and refrigerant supply tank.
15. 9V DC Charger Port - Connection for Accessory MDXBK
16. Vacuum Gauge Accessory Port - Connection for accessory MDXVG
17. Thermistor Sensors - Ideal for taking Superheat and Subcool true temperatures on
round pipes, at any angle
18. Swivel Hook - Heavy Duty 360°
19. Battery Compartment - Uses 4 AA batteries
20. Hose Hangers - For securing ends of unused hoses
21. Connection Points- For (2) thermistor sensors
22. Storage Posts - For thermistor sensors
23. SAE Connection Ports - For SAE Hoses
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

5
CONTROLS AND FEATURES - BLACKMAX WIRELESS DIGITAL MANIFOLD
4 Valve Manifold
(Front)
6.) Test
7.) Clear
8.) Backlight
9.) High Side Valve
10.) Refrigerant
Valve
11.) Sightglass12.) Vacuum
Valve
13.) Low
Side
Valve
1.) On/Off
2.) Set
3.) Refrigerant
4.) Mode
5.) Superheat/ Subcool
21.) Connection Points For
Thermistor Sensors
18.) Swivel Hook
19.) Battery Compartment
20.) Hose Hangers
15.) 9V DC
Charger Port
16.) Vacuum Gauge
Accessory Port
22.) SAE Hose Connection Ports
22.) Storage Posts
4 Valve Manifold
(Back)
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

6
ACCESSORIES
Optional MDXSC Soft Case
• Padded sides
• Rear storage pocket with zipper
• Protective skirt with drawstring
• Holds 7” tablet, instruction
manual, thermistor sensors, etc.
Vacuum Gauge
Accessory
(only available
with MDXVG Kit)
AVT45 Brass
Tee Connector
(Included with
MDXVG Kit)
MDXCP Thermistor Sensor with 6 Ft.
lead for taking Superheat and Subcool
true temperatures on pipes
Vacuum Gauge Accessory Kit MDXVG
U.S. Plug 5 Ft. CordUK/Ireland/
Singapore/
Hong Kong
Plug
Euro Plug
Australia/New
Zealand/China Plug
Universal Charger MDXBK
4 (AA)
Rechargeable
NiMH Batteries
Thermistor Sensor MDXCP Soft Case MDXSC
Included (2)
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

7
Press “>” to go to Home
Screen
1. Download and install the FREE APP for your wireless BLACKMAX Digital Manifold;
• For iOS mobile devices - Navigate to the iTunes APP Store and
download the free BLACKMAX Wireless Digital Manifold APP.
• For Android mobile devices - Navigate to Google Play and
download the BLACKMAX Wireless Digital Manifold APP.
2. Install 4 AA Alkaline (included) or rechargeable batteries in back of manifold.
3. Press and hold [ON/OFF](green button) to turn manifold ON.
4. Open the “BLACKMAX CPS Link” icon from your mobile device.
5. The application will appear on your mobile device screen in landscape mode.
6. Select one BLACKMAX Wireless Digital Manifold to operate.
7. Review and adhere to all safety instructions.
8. Connect the BLACKMAX manifold to an AC system. (see pages 24-26)
9. You are now ready to work.
Indicates
wireless
manifold
has been
detected
If you plan to use the wireless manifold without the free app, go to page 14 for quick start
instructions - manifold only.
QUICK START INSTRUCTIONS (For Use With BLACKMAX Mobile APP)
Scroll Up/
Down to
refresh the
scanning
process
Or Swipe LEFT
here to open
Side Screen
(Help Or Exit)
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

8
Touch
Settings Icon
Left Swipe
From Right
Side Of Screen
And Touch
Settings
Side Menu
BLACKMAX APP HOME SCREEN
Analog Scale
Digital Scale
Current Refrigerant
Home
Screen SettingsData
Logging
Vacuum
Hold
Presure
Hold
Working
Temperature(s)
CHANGE OR CONFIRM SETTINGS
High SideLow Side
Touch arrows
to toggle between
Home Screens
(View 1
Or View 2)
View 1
View 2
OR
Touch icons here to
select any of these
functions
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

9
Open manifold to atmosphere
before each use especially if
manifold has been dropped
or pressurized beyond 800
psig (55 Bar).
!
BLACKMAX APP SETTINGS SCREEN
Select One
Change Language
Zero Offset
Target Superheat
Change Units
Settings
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

10
CHANGE OR CONFIRM REFRIGERANTS
Move screen Up/Down then select a new
active refrigerant. Note: Refrigerant selected will
become the default (but not affect FAVORITE FIVE.
Changing FAVORITE FIVE refrigerants permanently
must be done using the manifold. See page 21 for
more information)
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

11
1. Touch “Start” or “Stop” at any time.
2. Default duration = 5 minutes (Max time = 100 mins)
3. You may navigate to other screens while this test runs
Pressure Hold Test
Normally, systems with vacuum levels within 250-500 microns are deemed a good seal and
are ready for charging.
1. Connect BLACKMAX #MDXVG Vacuum Gauge Accessory to Digital Manifold & initiate
vacuum to enable test. (Note: See Appendix E for cleaning the sensor).
2. Touch “Start” or “Stop” at any time.
3. Default duration = 5 minutes (Max time = 100 mins)
4. You may navigate to other screens while this test runs
Vacuum Hold Test
TESTING: Pressure Hold or Vacuum Hold
gray line is
starting point
gray line is
starting point
Final graph will show initial, current and final
pressures.
Final graph will show initial, current and final vacuum.
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

12
DATA LOGGING
Touch
icon to
download
a file
Mobile Device Logs
1. Shows logs stored in the mobile device’s local storage.
2. For Geolocation, Delete, View or Export logs, touch icons.
New Log Tab
1. For starting new data logging in the
Manifold
2. Select frequency in which the
manifold will record values
3. View maximum time remaining
4. Start/Stop logging at any time
(or let system run until no more
Manifold memory).
All stored files have
option of showing
Geolocation, Delete,
View Or Export
Logs stored in
mobile device
Manifold Logs
1. Shows logs stored in manifold
2. Can only erase entire memory
3. Download any file to mobile device
Maximum
time
remaining
Touch
to select
interval
time
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

13
HELP SCREEN
Manifold Manual
Download a pdf version
of this manual (from
APP HELP
Select for general description of any
item;
1. General
2. Home
3. Pressure Hold
4. Vacuum Hold
5. Data Logging
6. Settings
7. Side Menu
Video
Watch instructional videos
on how to use this app
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

14
1. Install 4 AA Alkaline (included) or rechargeable batteries into back of manifold.
2. Press and hold [ON/OFF](green button) to turn manifold ON.
3. WELCOME SCREEN appears briefly (displays current version of software).
4. “LOC” and “SEL” will appear on the display.
5. Intermittently press [CLR] to scroll among regions:
• AUSTRALIA (Australia, Asian Pacific)
• EUROPE (All of continental Europe, plus Great Britain, Russia)
• USA (Includes USA, Canada, Caribbean, Central or South America)
6. Press [SET] to select desired region.
7. To change the region selected:
A. Press and hold [SET], then [ON/OFF]until display appears, then release BOTH keys.
B. This will take you back to step 5 above. Select another region.
8. The next screen will be the “MAIN” screen [FIG.1] showing default status for the following:
• Battery charge status/APO (On or Off)
• High and low side working pressures
• High and low side temperatures
• Current working refrigerant
QUICK START INSTRUCTIONS (WIRELESS DIGITAL MANIFOLD)
If your mobile device is NOT available, Wireless BLACKMAX Digital Manifolds may also
be operated as stand-alone devices. Simply follow these instructions.
T LOW
°F
T HIGH
°F
R
Psig Psig
APO
Battery Level
Indicator,
(and APO Status)
Current
Working
Refrigerant
High and Low
Side Working
Pressures
High and Low
Side Working
Temperatures
Main Screen
FIG.1
OPERATING THE WIRELESS MANIFOLD WITHOUT THE APP
9. Review and adhere to all safety instructions.
10. Connect MD50W or MD100W series to an AC system.
11. You are now ready to work.
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

15
T LOW
°F
T HIGH
°F
R
Psig Psig
APO
Refrigerants
Main Screen
FIG.1
INITIAL OPERATION
3. Note: In this mode, and to prevent errors, refrigerant cannot be changed using [REF]
key. Press [CLR] to return to the Main Screen [FIG.1] from this view.
4. To View Superheat (SH) and Sub-cool (SC) Temperatures- Press [SH/SC] again.
1. To Select A Refrigerant Other Than the One Shown- From Main Screen [FIG.1], press
[REF] to scroll through a list of 5 common factory programmed refrigerants.
Note: To change default refrigerants, go to page 20.
Note: Thermistor sensors must be connected to get a T Low and / or T High temperature reading.
2. To View Vapor (VSAT) and Liquid (LSAT) Saturation Temperatures, press [SH/SC]
Saturation Temperature Screen
VSAT
°F
LSAT
°F
R
Psig Psig
APO
VSAT LSAT
FIG.2
SH
°F
SC
°F
R
Psig Psig
APO
Super Heat, Sub Cool Screen
Sub
Cool
Super
Heat
FIG.3
5. Note: In this mode, and to
prevent errors, refrigerant
cannot be changed using the
[REF] key. Press [CLR] to return
to Main Screen [FIG.1] from
this view.
Thermistor Sensors - The
enclosed clamps can be used to
take temperatures of pipes or
other round surfaces within its
jaw range (1/8” to 1-1/8”). This greatly improves the calculation of Superheat and Subcool
temperatures, as the sensor is virtually isolated from ambient conditions, allowing
sensors to read true pipe temperatures while attached.
Blue Red
Operation - Plug one lead into the LEFT
(Blue) socket and one lead into the RIGHT
(Red) socket. Apply Thermistor Sensors to
system tubing and read the resulting display
temperatures.
6. To Display Difference Between High and
Low Side Temperatures- Press [SH/SC]
again. Press [CLR] to return to Main Screen
[FIG.1].
7. To turn manifold OFF, press and hold the
[ON/OFF] until the screen shows “OFF”.
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

16
1. It is recommended the manifold be opened to
the atmosphere before every working session.
If display reads other than zero in the selected
pressure units, zero can be re-set by pressing
and holding [CLR] at main screen. The Pressure
Zero Screen [FIG.4] appears and will then
return user to Main Screen [FIG.1], where
both Pressure Displays should now read zero.
This operation should be performed especially
if manifold has been dropped or pressurized
beyond 800 PSIG (55 bar) full scale.
SETTING TO ZERO PRESSURE
Pressure Zero Screen
APO
FIG.4
PRESSURE HOLD TEST
A pressure hold test should be used to determine if a large leak exists (not to determine
if no leak or small leaks exist). Electronic Leak Detectors are the only instrument to
determine leak rates less than 1 oz./year. In practice there should be no pressure hold
detected if the system is deemed leak proof enough to add refrigerant. Large leaks
should be found before adding refrigerant. Low cost tracer gas mixtures such as 95%
N2 and 5% H2 are popular and can be sensed by a CPS E_MOS leak detector.
1. At Main Screen [FIG.1] press [TEST]. The Test Pressure Set Screen will appear
[FIG.5]. [Note: The MDXVG Vacuum Gauge accessory should not be plugged in
at this time].
2. Press [SET] to advance to Test Time (Pressure) Set Screen [FIG.6].
Test Pressure Set Screen
APO
FIG.5
hh:mm
APO
Test Time Pressure Set Screen
Adjust Test
Duration In 5
Minute Increments
FIG.6
PRESSURE HOLD OR VACUUM HOLD TESTING
The BLACKMAX MD100W and MD50W series manifold can perform Pressure Hold
and Vacuum Hold tests. Test pressures and durations are fully settable by the user.
Any test can be aborted at any time by pressing [CLR].
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

17
PRESSURE HOLD TEST (CONTINUED)
3. Use [UP/DOWN ARROWS] to adjust test duration in 5 minute increments to
desired setting (Note: Minimum time is pre-set at 5 minutes. Maximum time is
95 minutes).
4. Press [SET] to store Test Duration. Display will advance to Pressure Set Screen [FIG.8].
hh:mm
Psig
Pressure Set Screen
Input Test
Pressure
FIG.7
Psig Psig
APO
Start Vs. Final Pressures
FIG.8
Original Set
System Pressure
Value
Final System
Pressure
Value
5. Connect manifold Low and High Side Service hoses to the system to be tested.
Pressurize the system. Regulated Nitrogen or Nitrogen/Hydrogen trace gas is
recommended.
6. The pressure in the system will be displayed in the UPPER LEFT.
7. Press [SET] to start test. Starting test pressure is indicated in upper left display
[FIG.7]. Current system pressure is shown in upper right display. Timer (lower left
display) decrements and when at zero, a bell will sound indicating test completion
and Start Vs. Final Pressures will be displayed [FIG.8] to determine if system
leaks.
VACUUM HOLD TEST
Normally, systems with vacuum levels within 250-500 microns are deemed as having a
good seal and are ready for charging. As with any recharged system, a good electronic leak
detector should be used to test for leaks after the charge has been completed. MD50W
or MD100W manifold series will function as accurate vacrometers when used with the
MDXVG Remote Vacuum Accessory (page 6).
1. Plug the MDXVG Vacuum Accessory into the upper right side of the manifold [FIG.9].
2. The Vacuum Display Screen [FIG.10] appears.
MDXVG Vacuum Gauge Accessory Connection
Connection port
FIG.9
Vacuum Display Screen
Vac
mic
FIG.10
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

18
VACUUM HOLD TEST
FIG.11
4. In this mode, the manifold will show current vacuum
in the system. The display begins to show vacuum
levels at 25000 microns or less and is accurate to
+/- 10 microns. Continue to run vacuum pump until
the desired vacuum level is reached. Once reached,
proceed to Vacuum Hold Test.
5. Vacuum Hold Test - To perform this test, press
[CLR] to go to the Main Screen [FIG.1] Vacuum
Gauge Accessory should still be plugged into
manifold.
6. At Main Screen [FIG.1] press [TEST]. The Test
Vacuum Set Screen appears [FIG.12]
7. Press [SET] to advance to Vacuum Hold Test –
Time Set Screen [FIG.13].
8. Use [UP/DOWN ARROWS] to adjust test
duration in 5 minutes increments (minimum
time is pre-programmed at 5 minutes).
A) Press [SET] to store Vacuum Test duration
time. Vacuum Hold Test Screen [FIG.14]
will now be displayed.
APO
Vac
FIG.12
Test Vacuum Set Screen
hh:mm
Vac
APO
Vacuum Hold Test Time Set Screen
FIG.13
Set test
duration (adjust
in 5 minute
increments
NOTE: The Vacuum Reading in the upper Left display is still active. The Reading in the
upper Right display is not active unit steps 2 and 3 are completed.
3. Assemble the BLACKMAX
MDXVG vacuum gauge
accessory to the Suction
Port on an AC system as
shown [FIG.11].
Suction
port Discharge
port
Suction
port Discharge
port
AVT45 Brass
Tee Connector
Vacuum Gauge
Accessory
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

19
VACUUM HOLD TEST
hh:mm
Psig
Vacuum Display Screen
B) Continue to Evacuate the system to the desired level which is indicated in the
upper left display once the desired vacuum level is reached:
a. On the MD100W, close the vacuum valve
b. On the MD50W, close the High and Low side valves.
C) Press [SET] to start test. Starting test vacuum level is indicated in upper left
display [FIG.15]. Current system vacuum level is shown in upper right of
display and timer is shown in lower left. The timer decrements and when zero, a
bells sounds and test ends. At end of test, Start vs. Final Vacuum levels will be
displayed to enable determination of any vacuum loss over a set period of time.
Inactive
Current Vacuum
Level
Leak test
duration
FIG.14
D) Press [CLR] to return to Main Screen [FIG.1].
NOTE: If it is required to rerun the vacuum pump after STEP 3, disconnect and reconnect the
MDXVG to reset it in the vacrometer mode.
Vacuum Display Screen
Current System
Vacuum Level
Desired Test
Level
Timer counts
backwards
FIG.15
PROGRAMMING/SETTING UNITS
According to your geographic location, MD50W and MD100W manifold series are fac-
tory programmed with 5 common refrigerants in those regions (see chart below), and
units of measure (Temperature, Pressure and Vacuum) for specific regions. See chart on
next page for details. Any of these units can be changed via the Program Mode.
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

20
PROGRAMMING/SETTING UNITS
PRE-PROGRAMMED REFRIGERANTS and UNITS OF MEASURE
USA AUSTRALIA EUROPE
R-134a R-134a R-134a
R-22 R-22 R-404A
R-404A R-404A R-744 (CO2)
R-407A R-744 (CO2) R-410A
R-410A R-410A R-407c
PSIG, F, Micron kPA, C, Micron Bar, C, Micron
The recommended way to change refrigerants involves making a new list of 5
refrigerants, and change all five of them in the same session. Example: If only R-22
needs to be changed to R-1234yf (and if using USA defaults), program the following
items: R-410A, R-1234yf, R-404A, R-134a and R-407A.
1. At Main Screen [FIG.1] press and hold [MODE] until “PrO” (Program) Screen
[FIG.16] appears. “PrO” will blink.
2. Press and hold [SET] to enter the Refrigerant Selection Screen [FIG.17].
R
APO
Program Screen
Refrigerant Selection Screen
R11 is initial
default
refrigerant
Counter
APO
FIG.16 FIG.17
3. The Initial Refrigerant (blinking in upper right) should be R-11 and Counter (Lower
Right) should start at 000.
4. Use [UP/DOWN ARROWS] to scroll through 93 refrigerants. Press and hold either
arrow to scroll through refrigerants progressively faster. Release to stop scrolling.
Last refrigerant displayed will blink.
There are 2 major options. In each, a blinking symbol represents a choice the user can
make by pressing [SET].
1. PrO (Programming)
a. Change Refrigerants: Change any or all of 5 common refrigerants accessible at
Main Screen.
b. Change Temperature Units: Change °F or °C.
c. Change Pressure Units: Change Psig, kPa, Mpa, bar and KgCm2 pressure units.
d. Change Vacuum Units: Change Microns vs. Hg vacuum units.
2. APO (Set Automatic Power OFF) - Manifolds come factory pre-set to ON.
Pre-Programmed Refrigerants
The following 5 common refrigerants have been programmed for easy access from the
Main Screen using the [REF] key:
PROGRAMMING/SETTING REFRIGERANTS
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30
