CPS FlexOM-PP User manual

Quick Guide for FlexOM-PP-Meter
10/17/2021
Revision 2
Environment
Operating Temperature Range
Relative Humidity
Max. Operating Altitude
Dimensions (W * H * D)
Weight
Mechanical
Protection Degree
Installation Options
-40℃ ~ 60℃ (-40℉~ 140℉)
4% ~ 85%
4,000 m (13,123 ft.)
350 * 550 * 190 mm
19 kg
IP65
Wall Mounting, Pole Mounting
NEMA4 enclosure
Breaker, 3P 600V
Include component
Transformer, 600/480/240/208V Primary, 110V Secondary
AC-DC Power supply, 85~264 VAC input, 12V output, 40W
Gateway built-in 4G module, optional data plan

Page 1
System Diagram of FlexOM-PP-Meter
Ground Terminals
Flex Gateway
Ethernet
FOMlink
A+ B- GVin G
A+ B- G
AUX Port
Antenna
Opt. Meter
CT3 CT2 CT1
VN
VC
VB
VA
A+ B- G
RS485
Surge
A+ B-
A+ B-
Cable Gland1
Gland2
Gland3 Gland4
Gland5
Gland6
Gland7
Inverter
ID: 1
Inverter
ID: 32
Weather
Sensor
Connect to 3rd party data logger
Gateway can connect up to 32 devices through RS485 interface.
Don’t use the Modbus ID 165 (A5H/0XA5).
It is reserved for broadcast commands of CPS inverters.
Transformer
600 480 240 208
0
1100
Power
Supply
NL
V+ V-
Breaker
L1 L2 L3
LA LB LC

Page 2
Antenna Cable
Gateway with enclosure
FlexOM-PP-Meter
is equipped with a NEMA4 enclosure
Gateway is its core component.
Mount the gateway to the DIN rail with clip.
Then fix the antenna in a suitable position
outside the chassis.

Page 3
FlexOM-PP-Meter pole mounting
Long rod bolt M8
Nut M8
Front U-rail
Rear U-rail
Chassis hook
Chassis hanging hole

Page 4
FlexOM-PP-Meter wall mounting
Drilling holes in the wall
Front U-rail
Expansion screw sleeve
Self-tapping screw
Wrench
Use a wrench to adjust the hook screw to
fasten the chassis to the bracket.
Chassis hook
Chassis hook
The back of the chassis hook

Page 5
Ethernet Port
Connector of
4G Antenna
SIM Card Slot
Key Interfaces
Caution:
FlexOM SIM can only be used in FlexOM gateway. By default, FlexOM gateway supports
customers' unrestricted use of the existing and future remote O&M functions of CPS portal.
SO DATA PLAN CONSUMPTION STATISTICS ARE NOT PROVIDED.
At the same time, FlexOM gateway does not guarantee the 3rd party SIM card. The user
needs to manually enter the APN.
FlexOM hardware warranty is valid by default within the validity period of our data plan.
1) Pull to open the slot
2) Open the cover of slot.
Place the chip of the SIM card facing down, with
the notch facing the corresponding position of the
card slot seat, and put it into the card slot.
3) Pull to close the slot

Page 6
Internet interface : Ethernet
If the gateway is connected to the Internet using Ethernet
instead of 4G.
Open the LAN firewall ports before commissiong !
The following ports must be opened both ways (incoming and
outgoing communications):
TCP 1884 with destination IP 47.254.52.209
(mqtt.chintpowersystems.com)
Internet interface : 4G
FlexOM SIM card supports AT&T + T-mobile at the same time.
After the gateway is powered on and works normally, it will select and
connect to the provider network with the strongest or most stable signal.
If you need to purchase FlexOM SIM, please contact CPS US sales staff
for detailed information.
Scan the QR-code to complete APP download and
installation by using the mobile phones that can
access the Internet.
Or search for “CPS Connect Pro” in Apple Store
and Google Play.

Page 7
FOMlink Port
AUX Port
Module Socket
RS485 Port B
Terminating Resistance
Switch
RS485 Port A
Internal installation option
External installation option
A
A+ B- G
Vin GND A+ B- G
Interfaces on FlexOM Main Board
B
Terminating Resistance
Switch
Default
1
ON
Caution:
If the length of the cable connecting to RS485 port or AUX port of
the gateway is over 1000 meters, the Switch button must be set to ON.
Power Switch
POWER ON
Caution:
Before configuring the gateway,
pay attention to set the power switch to ON.

Page 8
A
Installation Option
Internal in Wire-Box of the Inverter
Inverter Inverter
Inverter
Wire Box
RS485
3rd Party Server
HTTPS/2nd MQTT
CPS Server
Primary MQTT
FOMlink + CPS Connect Pro APP
Router
When the inverters are monitored via the gateway, a unique RS-485 address for each
inverter can be set up through the LCD interface.
Up to 32 inverters can be connected in the daisy chain network, and different FlexOM
packages have different specific number restrictions.

Page 9
The Communication Board of Inverter
Inverter’s RS485 Port
1
Inverter Wire-Box
Remove the (3) screws that attach
the inverter communication board in
the Wire-Box using a #2 Phillips bit.
2Replace the screws with the (3)
standoffs included in the gateway kit.
Install the gateway by carefully align-
ing the 6-PIN connector in the upper
left-hand corner of the communication
board.
Install the (3) screws into the stand-
offs to secure the gateway in place.
Install the 3 screws and torque to 7
in-lbs using a #2 Phillips bit.
6-PIN Connector
6-PIN Header
3

Page 10
Ethernet Port
Connect the 3rd party Datalogger to the AUX port in the bottom left-hand corner
of the gateway using the 3-Pin Connector provided in the gateway kit.
Connect the RS485 inverter daisy chain to the inverter communication board using
the 5-Pin Connector provided in the gateway kit.
NOTE: The 5-Pin Connector is installed on the port on the bottom of the inverter
communication board (behind the gateway) .
The RJ45 LAN cable is inserted into
the Ethernet port of the gateway.
The LAN cable must be able to access
the Internet without port filtering behind
the firewall.
5
A+ B- G
Vin GND A+ B- G
RS485 of 3rd Party Data Logger
RS485 Inverter Daisy Chain
4
Optional wire
Optional wire
A + / B - / G
A + / B - / G

Page 11
6a
6b
6c
6d
6e
7
8
POWER ON Before closing the cover of
inverter wire-box, check again
that the gateway’s power
switch is set to on.
Pass the cable through the
disassembled cable gland
parts in sequence, then tighten
the cable glands again.
Screw one end of the antenna
cable into the cable connector
of the gateway.
Screw the other end of the antenna cable into the antenna.

Page 12
The gateway may be installed in an enclosure as shown.
The gateway enclosure includes a DIN rail mounting clip for installation in a
NEMA4 communication box (FlexOM Suite) .
Open the gateway enclosure and Install the (4) screws into the standoffs to
secure the gateway in place.
Installation Option
External in a NEMA4 enclosure
B
93 mm
90 mm
37 mm

Page 13
System Diagram for RS485 Pass-through
CPS
Portal
RS485 Cable
3rd Party Data Logger
/ SCADA
The RS485 interface of the third-party controller is connected to the AUX interface of the
gateway, which is equivalent to a direct transmission connection with a daisy chain.
Inverter or ESS
RS485 Cable
3rd Party
Portal

Page 14
System Diagram for Modbus/TCP Pass-through
CPS
Portal
Ethernet Cable
3rd Party Data Logger
/ SCADA
The gateway can be used as a modbus/TCP server, connect to a third-party SCADA
system, and forward various commands to the daisy chain.
Inverter or ESS
RS485 Cable
3rd Party
Portal

Page 15
System diagram of mixed connection of different hardware brands
CPS
Portal
RS485 Cable
3rd Party Data Logger
/ SCADA
The gateway allows users to connect different brands and models of hardware in the same
daisy chain via RS485. The connected hardware needs to be pre-compatible with FlexOM.
If the user's hardware is not yet compatible, CPS US will complete the compatibility free of
charge.
Inverter or ESS
RS485 Cable
Model A Model B
Meter Weather
Sensor
EV Charger

Page 16
Use Cases for System Design
By default, the gateway is connected to the
inverter through the RS485 interface.
Certain models provide multiple RS485
interface.
The RS485 interface of the third-party
controller is connected to the AUX interface
of the gateway, which is equivalent to a
direct transmission connection with a daisy
chain.
The gateway can be used as a Modbus/TCP server, connect
to a third-party SCADA system, and forward various
commands to the daisy chain.
RS485 RS485
DC-PLC
BLE
TCP/IP AUX
Ethernet 4G
Inverter
3rd Party
Controller
+ SCADA
3rd Party
Server
3rd Party
Controller
+ SCADA
APP
Inverter
RSD
CPS
Portal
3rd Party
Server
Modbus/TCP MQTT
HTTP POST /
extra MQTT
RS485
TTL / RS232 / 485
option
Open API
option
8
5
The gateway sends raw data unidirectionally
to a third-party server via HTTPS/ extra
MQTT.
1
3
The APP connects to the gateway
through BLE 4.2 for on-site
configuration and diagnosis.
7
4
6
INV
/ ESS
CPS
portal
3rd party
server
RSD
/ Panel level monitoring
On-site configuration
and diagnosis
MQTT Open API
HTTP POST / extra MQTT
2
3
46
5
2
Modbus/TCP via Ethernet port
AUX port for RS485 pass-thru
3rd party data logger
/ SCADA
7
8
Portal provides the flexibilities of
remote O&M.
Third-party servers can use the
open API of portal to develop their
own business systems.

Page 17
Setup the gateway
When the APP starts, make sure the
phone can access the Internet.
APP will automatically enter the main
panel after data synchronization.
Click “Flex Gateway” under the “Installa-
tion” tab.
Ensure the D2XH cable and FOMlink are
connected to the gateway.
The APP will list the BLE name of FOM-
link, starting with “CPLK-”, and the SN of
FOMlink is the BLE name.
CPS Connect
Synchronizing data
20%
V 1.0.6
Installation OM Service
Flex Gateway Dongle Gateway
No-LCD Inverter Rename FOMlink
Scan Devices
APP Settings
Connect to WiFi mode
Refresh
CPLK-000AA77
way
nverter
R
e
n
a
m
e
F
O
Mlink

Page 18
-> Show Status :
Status :
Internet :
INV Baud Rate :
Modbus Range :
APN :
IMEI :
ICCID :
Secondary MQTT :
-> Show Status :
Status :
Internet :
INV Baud Rate :
Modbus Range :
APN :
IMEI :
ICCID :
Secondary MQTT :
2021-09-16 10:22:02 GMT -6
Powering On
Ethernet + 4G
9600 N8 1
1 - 32
-
-
-
-
2021-09-16 10:25:02 GMT -6
Detecting SIM Card
Ethernet + 4G
9600 N8 1
1 - 32
-
86682200000077
-
-
Quit CPLK-000001211 Next
Scan Daisy Chain
Send Log
Modbus ID Range
Inverter Baud Rate
Fullscreen
More
Internet Settings
Show Status
<- Show Status :
Model :
SN :
Hardware :
MAC :
Firmware :
Status :
Time Zone :
Server :
IP Address :
INV Baud Rate :
2021-09-16 10:21:32 GMT -6
FG4C
408800000000022
2.2.2251
00:00:5E:11:13:C0
3.0035
Offline
GMT -6
mqtt.chintpowersystems 1884
DHCP enabled
9600 N8 1
Quit CPLK-000001211 Next
Scan Daisy Chain
Send Log
Modbus ID Range
Inverter Baud Rate
Fullscreen
More
Internet Settings
Show Status
Important : Click “Show Status” to
display the current configuration
parameters of the gateway.
The gateway connects to the Internet
through 4G by default.
In this case, it is assumed that the SIM
card is inserted into the gateway.
If there is no SIM card in the gateway, the
APP will display "Detecting SIM card", and
then the gateway keeps restarting the 4G
module and displays "Powering on".
When the gateway is connected to the
Ethernet to access the Internet.
Click "Internet Settings" to change how
the gateway connects to the Internet.

Page 19
Back Internet Settings Save
Only the enabled interface will be used as a channel
to connect to the Internet.
Ethernet
4G Cellular
DHCP
Back Internet Settings Save
Only the enabled interface will be used as a channel
to connect to the Internet.
Ethernet
4G Cellular
DHCP
-> Show Status :
Status :
Internet :
INV Baud Rate :
Modbus Range :
APN :
IMEI :
ICCID :
Secondary MQTT :
HTTPS Push :
2020-03-16 10:30:16 GMT -6
Online
Ethernet + 4G
9600 N8 1
1 - 32
AT&T
123135531341433
89898977866767756565645
Disable
Disable
Quit CPLK-000001211 Next
Scan Daisy Chain
Send Log
Modbus ID Range
Inverter Baud Rate
Fullscreen
More
Internet Settings
Show Status
Click “4G Cellular” or “Ethernet” to enable
this connection method.
When returning to the previous screen,
click “OK” to save the settings.
Click “Show Status” to check the connec-
tion status.
Before the status becomes “Online”, click
“Next” will only display “Gateway unable to
access Internet”.
When the gateway status becomes
“Online”, the gateway will automatically
create related objects on the portal, and
the administrator can remotely set the
required parameters.
You can also click “Next” to modify the site
and gateway name on site.
