Creality Ender-5 User manual

Ender-5 Pro Printer
Guide Book
◆This guide book is for standard Ender-5 Pro.
◆Please plug the power cord into a three-hole power jack.
◆Detailed instructions for use are available in the TF card.
V.2.3
To be the Chief Evangelist
To make Top-quality 3D printer

Contents
1.Introduction....................................1
2.General List.....................................2
3.Assembly Step.......................................3
4.Cable Connection............................8
5.Screen Information........................10
6.Loading Filament...........................11
7.Bed Levelling.....................................12
8.Software Inst al lat io n.. ....... ....... . ......13
9. Pr epari ng t o Print .. ............ .. ... .. ... .. 14
10.Trouble shooting..........................15
Preface
Dear consumers,
Thank you for choosing our products. For the best experience, please read the instructions before operating the Printer.
Our 3D team will always be ready to give you the best service. Please contact us via the phone number or e-mail address
provided at the end when you encounter any problem with the Printer.
For a better experience in using our product, you may learn how to use the Printer in the following ways:
1. View the accompanied instructions and videos in the TF card.
2. Visit our official website www.creality.com You will find relevant software/hardware information, contact details and
operation and maintenance instructions on the website.

Notes
1. Do not use the printer any way other than described herein in order to avoid personal injury or
property damage.
2. Do not place the printer near any heat source or flammable or explosive objects. We suggest placing it
in a well-ventilated, low-dust environment.
3. Do not expose the printer to violent vibration or any unstable environment, as this may cause poor
print quality.
4. Before using experimental or exotic filaments, we suggest using standard filaments such as ABS or PLA
to calibrate and test the machine.
5. Do not use any other power cable except the one supplied. Always use a grounded three-prong power
outlet.
6. Do not touch the nozzle or printing surface during operation as they may be hot. Keep hands away
from machine while in use to avoid burns or personal injury.
7. Do not wear gloves or loose clothing when operating the printer. Such cloths may become tangled in
the printers moving parts leading to burns, possible bodily injury, or printer damage.
8. When cleaning debris from the printer hotend, always use the provided tools. Do not touch the nozzle
directly when heated. This can cause personal injury.
9. Clean the printer frequently. Always turn the power off when cleaning, and wipe with a dry cloth to
remove dust, adhered printing plastics or any other material off the frame, guide rails, or wheels . Use
glass cleaner or isopropyl alcohol to clean the print surface before every print for consistent results.
10. Children under 10 years of age should not use the printer without supervision.

3
1
2
14
12
6
11
10
15
85 7
4
13
16
1.Hot Bed
2.Levelling screw
3.Power supply
4.Switch
5.SD Slot and USB Port
6.Display
7.Z Stepper
8.Foot pad
9.Spool Holder
10.Extrusion mechanism
11.X Stepper
12.Nozzle Assembly
13.Y Stepper
14.Z Limit Switch
15.Y Limit Switch
16.X Limit Switch
9
A、Introduction
3
1
2
14
12
6
11
10
15
85 7
4
13
16
9
14
12 15
13
16
1

G:Bottom Frame
F:Hot Bed
D:Extruder kit
E:Filament Holder
H:Display Screen
C:2040 Profile 4Pcs
A:Top Frame
B：Z-axis Frame
No. Image Name Qty
1 Wrench & Screw
driver 1set
2 TF Card & Reader 1set
3 Spatula 1
4 Pliers 1
5 0.4mm
Nozzle Cleaner 1
6 Power Cable 1
7 Filament(200)g 1
8 Spare Parts 1set
B、General List
Tool List
2
M4X8 M4 T-nut M5X25
M5X30
M5X8 M5 T-nut
M4X10
2pcs
2p
c s
6
4pcs
pcs
16pcs
M4X8
2pcs
M4 T-nut
2

M5X25
8pcs
Place the profile hole of the
side upon, install the profile, but
not mess with the direction.
4pcs
Bottom Frame
2040 Profile
C、Assembly Step
3

Note: Tighten the four
screws on the top, then tight
the side screws.
8pcs
M5X25
4

4pcs
M5X30
Note: Align the
bottom profile ,then
tighten the screws.
Z-axis Frame
5

6pcs
M4X10
Hot Bed
6

M4X8
2pcs 2pcs
M4X8
2pcs
M4 T-nut M4 T-nut
2pcs
M5X8
2pcs
M5 T-nut
M4X8
M4X8
7
