Creative MuVo V100 User manual

1
Congratulations ____________________
MuVo V100 is the new digital player from Creative. Read on to learn how to get started with
your new player!
To get the most out of your player, also read the comprehensive User’s Guide on your
Installation and Applications CD.
2
1
3
4
5
8
9
7
6
1. Play/Pause button
Press and hold to turn the player on
and off.
Press once to start playing tracks, and
press again to pause playback.
2. Headphone jack
3. Microphone
4. LCD
5. Battery module
6. USB connector
7. Volume Decrease button
8. Volume Increase button
9. Scroller
For information on using the Scroller, see
“Using the Scroller” on page 2.
MuVo V100 _(PagerN)_Multi CLE.book Page 1 Friday, May 26, 2006 2:14 PM

2
Using the Scroller ___________________
We use the term “Scroll Select” to mean the following actions:
Getting Started _____________________
Step 1: Set up software
1. Turn on your computer.
You must log in as an administrator in Microsoft®Windows®before you can set up the
software. For more information, refer to your operating system’s online Help.
2. Insert the Installation CD into your CD-ROM/DVD-ROM drive. Your CD should start
automatically. If it does not, follow the steps below:
i. Double-click the My Computer icon.
Alternatively, click Start → My Computer.
ii. Right-click the CD-ROM/DVD-ROM drive icon, and then click AutoPlay.
3. Follow the instructions on the screen and when prompted, restart your computer.
4. When your computer restarts, follow the product registration instructions on the screen.
TIP You can use the Scroller to move between tracks, or turn and hold the Scroller to
move within a track.
WARNING DO NOT connect your player to your computer before setting up the software.
NOTE You will require an Internet connection to register your product.
1. Turn the Scroller. 2. Highlight the menu
option you want.
3. Press the Scroller.
MuVo V100 _(PagerN)_Multi CLE.book Page 2 Friday, May 26, 2006 2:14 PM

3
5. When prompted, connect your player to your computer’s USB port. Do not press the
buttons on your player while connecting it to your computer.
Step 2: Turn on player
Your player comes preloaded with some music to get you started immediately.
1. If your player is connected to your computer, make sure it is disconnected properly from
your computer. For more information, see “Disconnect player” on page 5.
2. Insert a AAA alkaline battery into your player.
3. Press and hold the Play/Pause button until your player turns on.
4. Connect your earphones and press the Volume buttons to adjust the volume.
1 2 3
+
-
AAA battery
+
-
AAA battery
(+)
+
-
AAA battery
( )
-
MuVo V100 _(PagerN)_Multi CLE.book Page 3 Friday, May 26, 2006 2:14 PM

4
5. When you turn on your player for the first time, the menu will be in English. To change the
language:
i. Press the Scroller. The main menu appears.
ii. Scroll Select the Settings option.
iii. Scroll Select the Language option, and then Scroll Select the language that you want.
6. After you have finished using your player, press and hold the Play/Pause button until
the Power off message disappears.
Step 3: Rip and copy music
Rip music from your CD collection to your player, or copy audio files (such as music you have
purchased online) from your computer.
To rip music from your CD collection
1. Make sure your player is connected to your computer as shown on page 3.
2. Double-click the My Computer icon on your desktop.
Alternatively, click Start → My Computer.
3. Double-click the MuVo V100 Media Explorer icon.
4. Click the Rip Audio CDs icon.
5. Follow the instructions on the screen.
Album information is automatically retrieved if you are connected to the Internet, and have
registered with a music information provider.
TIP For more information on using the Scroller, see “Using the Scroller” on page 2.
MuVo V100 _(PagerN)_Multi CLE.book Page 4 Friday, May 26, 2006 2:14 PM

5
To copy audio or data files from your computer
1. Follow steps 1 to 3 in “To rip music from your CD collection” on page 4.
2. Click the Browse Data icon.
3. Copy files using the drag-and-drop or copy-and-paste method.
Step 4: Disconnect player
When disconnecting your player from your computer, always use the Windows Eject or
Safely Remove Hardware icon on the Taskbar. If not, your player may not function normally.
Follow these steps below to safely disconnect your player.
To safely disconnect your player in Windows XP Professional x64 Edition, Windows
XP or Windows 2000
Click the Safely Remove Hardware icon on the Taskbar, click Safely remove USB
Mass Storage Device, and disconnect your player when you are prompted to do so.
NOTE WMA files protected by Digital Rights Management (DRM) technology cannot be
copied to your player using Windows Explorer. You can only do so with
applications that support this technology, such as Creative MuVo V100 Media
Explorer, Creative MediaSourceTM Player/Organizer, or Windows Media®Player.
MuVo V100 _(PagerN)_Multi CLE.book Page 5 Friday, May 26, 2006 2:14 PM

6
About Lyrics Editor _________________
With Lyrics Editor and a few MP3 or WMA files, you can sing along to your favorite songs on
your digital audio player. Using Lyrics Editor, you can:
• import LRC or TXT (plain text) files
• synchronize lyrics and songs
•editlyrics.
For more information about using Lyrics Editor, refer to its online Help.
Displaying lyrics on your player
Your player can display the lyrics of songs being played.
1. Press the Scroller.
The main menu appears.
2. Scroll Select the Settings option.
3. Scroll Select Lyrics Display and select Lyrics On.
To hide the lyrics display later, repeat steps 1 to 3 and Select Lyrics Off.
4. Press the Scroller.
The main menu appears.
5. Scroll Select the Music option.
6. Scroll Select the audio track that you want to play.
The audio track is played back automatically.
MuVo V100 _(PagerN)_Multi CLE.book Page 6 Friday, May 26, 2006 2:14 PM

7
More Information___________________
User’s Guide
Read the User’s Guide found on your Installation and Applications CD to learn about your player’s
many features. Go to d:\manual\<language>\manual.chm
(replace d:\ with the drive letter of your CD-ROM/DVD-ROM drive, and <language> with a language that
your User’s Guide is available in)
Creative Knowledge Base
Resolve and troubleshoot technical queries at Creative's 24-hour self-help Knowledge Base.
Go to www.creative.com, select your region and then select Support.
Product Registration
Registering your product ensures you receive the most appropriate service and product support
available. You can register your product during installation or at www.creative.com/register.
Please note that your warranty rights are not dependent on product registration.
Customer Support Services and Warranty
You can find Customer Support Services, Warranty and other information in the CD.
(replace d:\ with the drive letter of your CD-ROM/DVD-ROM drive, <region> with the region that you
are in, and <language> with the language that your document is in)
Customer Support Services d:\support\<region>\<language>\support.chm
Warranty d:\warranty\<region>\<language>\warranty.chm
Please keep your Proof of Purchase for the duration of the
warranty period.
MuVo V100 _(PagerN)_Multi CLE.book Page 7 Friday, May 26, 2006 2:14 PM

8
Safety Advice _______________________
Refer to the following information to use your player safely, and to reduce the chance of electric
shock, short-circuiting, damage, fire, hearing impairment or other hazards.
Do not dismantle or attempt to repair your player, battery or power adapter.
Refer all servicing to Creative or authorized repair agents.
Do not expose your player or battery to temperatures outside the range of 0°C to
45°C (32°F to 113°F).
Do not pierce, crush or set fire to your player or battery.
Keep your player or battery away from strong magnetic objects.
Do not subject your player to excessive force or impact.
Do not expose your player or battery to water or moisture.
If your player is moisture-resistant (see product packaging for details), take care not to
immerse your player in water or expose it to rain.
Do not listen to audio at high volume for prolonged periods of time.
For players with removable batteries
• The battery must be recycled or disposed of properly. Contact local agencies for recycling
and disposal information.
• Do not allow metal objects to touch the terminals of your battery.
• If there is leakage, an offensive odor, discoloration or deformation during charging or use,
remove the battery and do not use it again. Clean your hands well before touching food or
sensitive areas, for example, your eyes.
NOTE Improper handling may void the warranty for your player.
For more information, read the warranty available with your product.
MuVo V100 _(PagerN)_Multi CLE.book Page 8 Friday, May 26, 2006 2:14 PM

9
WARNING As with any digital media-based storage device, data should be backed up regularly.
We strongly recommend that you observe the usage precautions laid out in this
booklet, and also back up the data in your player regularly. In no event will Creative
be liable for any indirect, incidental, special or consequential damages to any
persons caused by Creative's negligence, or for any lost profits, lost savings, loss of
use, lost revenues or lost data arising from or relating to this device, even if
Creative has been advised of the possibility of such damages. In no event will
Creative’s liability or damages to you or any other person ever exceed the amount
paid by you for the device, regardless of the form of the claim. Some countries/
states do not allow the limitation or exclusion of liability for incidental or
consequential damages, so the above limitation or exclusion may not apply to you.
Copyright © 2006 Creative Technology Ltd. All rights reserved. The Creative logo, MuVo and Creative MediaSource are
trademarks or registered trademarks of Creative Technology Ltd. in the United States and/or other countries. Microsoft,
Windows and the Windows logo are registered trademarks of Microsoft Corporation. All other products are trademarks
or registered trademarks of their respective owners and are hereby recognized as such.
The use of the WEEE Symbol indicates that this product may not be treated as
household waste. By ensuring this product is disposed of correctly, you will help
protect the environment. For more detailed information about the recycling of this
product, please contact your local authority, your household waste disposal service
provider or the shop where you purchased the product.
MuVo V100 _(PagerN)_Multi CLE.book Page 9 Friday, May 26, 2006 2:14 PM

10
Félicitations ________________________
MuVo V100 est le tout nouveau lecteur numérique de Creative. Lisez la suite pour savoir
comment utiliser votre nouveau lecteur.
Pour tirer le meilleur parti de votre lecteur, lisez également le Guide d’utilisateur situé sur le CD
d’installation et des applications.
2
1
3
4
5
8
9
7
6
1. Bouton Lecture/Pause
Appuyez sur ce bouton et maintenez-le
enfoncé pour allumer et éteindre le
lecteur.
Appuyez une fois pour lancer la lecture
des pistes et appuyez de nouveau pour
mettre la lecture sur pause.
2. Prise du casque
3. Microphone
4. Ecran LCD
5. Module de pile
6. Connecteur USB
7. Bouton de diminution du volume
8. Bouton d’augmentation du volume
9. Molette
Pour obtenir plus d’informations sur
l’utilisation de la molette, reportez-vous à
la section « Utilisation de la molette » à la
page 11.
MuVo V100 _(PagerN)_Multi CLE.book Page 10 Friday, May 26, 2006 2:14 PM
