CREE LIGHTING IG Series User manual

IG Series
Wireless LED Parking Luminaire
Junction Box and Pendant Mount
1 of 4 LPN00305X0012A0_A
INSTALLATION INSTRUCTIONS
INSTRUCTIONS D’INSTALLATION
NOTE:
• During installation and maintenance handle
the luminaire only by the housing NOT by the
lens.
TO INSTALL:
12
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed
including the following:
READ AND FOLLOW ALL SAFETY
INSTRUCTIONS
1. DANGER- Risk of shock- Disconnect power before installation.
DANGER – Risque de choc – Couper l’alimentation avant l’installation.
2. This luminaire must be installed in accordance with the NEC or your local electrical
code.
If you are not familiar with these codes and requirements, consult a qualied
electrician.
Ce produit doit être installé conformément à NEC ou votre code électrique local.
Si vous n’êtes pas familier avec ces codes et ces exigences, veuillez contacter un
électricien qualié.
3. USE MIN. 90°C SUPPLY CONDUCTORS for 120-277V luminaires and USE MIN
75°C SUPPLY CONDUCTORS for the 347V luminaires.
LES FILS D’ALIMENTATION 90°C MIN pour 120-277V et LES FILS
D’ALIMENTATION 75°C MIN pour 347V .
4. DO NOT lift luminaire by the power leads.
5. DO NOT carry or lift luminaire by Splice Inspection Tether or wireform. Splice
Inspection Tether and wireform are only for supporting luminaire while making
wiring connections.
SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE
Mounting Plate
Mounting
Plate Tab
Mounting Plate
JUNCTION BOX MOUNTING
NOTE: “J” Input Power Designator comes with
Splice Inspection Tether only. “A” Input Power
Designator comes with a Splice Inspection
Tether or wireform.
STEP 1:
WITH SPLICE INSPECTION TETHER
Locate the Splice Inspection Tether on
the luminaire and attach the cable to the
designated screw hole on the mounting plate
using the provided screws. See Figure 1.
STEP 2:
WITH SPLICE INSPECTION TETHER
NOTE: Ensure to install mounting plate to
junction box using the two screws slots on the
mounting plate that are diagonal to the Splice
Inspection Tether. See Figure 1.
NOTE: Two people may be needed for
installing to junction box, one to hold the
luminaire and another to install the mounting
plate to the junction box.
Attach mounting plate to customer supplied
junction box with the tabs on the Mounting
Plate directed parallel to vehicle traffic as
shown in Figure 2. Torque to 20 in-lbs. See
Figure 2 and 3.
STEP 3:
Make wiring connections per “Electrical
Connections” section.
3
Mounting Plate
Splice Inspection
Tether
Splice Inspection
Tether
Splice Inspection Tether
Screw Hole
Use these 2 slots for
mounting to junction box.

2 of 4 LPN00305X0012A0_A
5
Pendant Mounting
Plate
Pendant Kit
(Supplied by
Customer)
Water Shield
Luminaire
4
(4) Luminaire Slots
(4) Tabs
Mounting
Plate
View of Underneath
Luminaire
(4) Mounting
Plate Tabs
Luminaire
Slots
(2) Screws
STEP 4:
After wiring connections have been made, tuck
all wires into junction box ensuring that no
wires are pinched.
STEP 5:
Attach luminaire to the Mounting Plate by
pressing up on the luminaire until the slots
on the luminaire engage with the tabs on
the Mounting Plate and rotate until tabs lock
securely. To secure install a minimum of (2)
supplied screws across from each other into
the mounting plate tabs on the underside of
the luminaire. See Figure 4.
NOTE: May require extra pressure on luminaire
to engage tabs into slots. Only apply pressure
on housing body NOT on the luminaire lens.
NOTE: If the mounting plate tabs become
deformed during installation, slightly reopen
the tabs back up using a screwdriver to ensure
proper install of luminaire.
STEP 6:
Lightly pull on the luminaire to verify luminaire
is securely mounted.
FIXTURE SERVICING AND
MAINTENANCE
STEP 1:
If supply wiring splices need to be inspected
or if luminaire needs to be removed, fully
loosen the (2) screws and rotate luminaire to
disengage from Mounting Plate.
STEP 2:
To re-install luminaire, when finished with
servicing or maintenance follow Step 2-6 in
“Junction Box Mounting” section above.
PENDANT MOUNTING (OPTIONAL)
NOTE: Customer supplied 3/4" IP Pendant
Kit and wire leads may be necessary for
pendant mounting. For existing rigid pendant
installations, perform Step 2 through 8 only.
Not recommended for use with a hang straight
pendant. Cree Lighting does not provide a
counterbalance system.
STEP 1:
Feed wire leads through customer supplied
pendant kit. See Figure 5. Make sure leads are
at least 6 in longer than customer supplied
pendant stem.
STEP 2:
WITH SPLICE INSPECTION TETHER ( A or J
Input Power Designator)
Locate the Splice Inspection Tether on
the luminaire and attach the cable to the
designated screw hole on the Pendant
Mounting Plate using the provided screws. See
Figure 1 and 2.
STEP 3:
WITH SPLICE INSPECTION TETHER ( A or J
Input Power Designator)
NOTE: Two people may be needed for installing
to customer supplied pendant kit, one to
hold the luminaire and another to install the
Pendant Mounting Plate to the customer
supplied pendant kit.
Attach Pendant Mounting Plate to customer
supplied pendant kit. See Figure 5.
STEP 4:
Feed wire leads through the Water Shield.
NOTE: Water Shield will be held in place by
the Pendant Mounting Plate. No fasteners are
necessary.
STEP 5:
Make wiring connections to customer supplied
wire leads per “Electrical Connections”
section.
Splice Inspection
Tether

3 of 4 LPN00305X0012A0_A
6View of Underneath
Luminaire
(4) Pendant
Mounting
Plate Tabs
Luminaire
Slots
(2) Screws
(4) Luminaire Slots
(4) Tabs
Pendant Mounting
Plate
STEP 6:
After wiring connections have been made,
tuck all wires into the water shield ensuring
that no wires are pinched.
NOTE: Ensure that splices are contained
within Water Shield for future splice
inspections.
STEP 7:
Attach luminaire to the Pendant Mounting
Plate by engaging the tabs on the Pendant
Mounting Plate with the slots on the
luminaire. Rotate until tabs lock securely. See
Figure 6.
NOTE: May require extra pressure on
Pendant Mounting Plate to engage luminaire
tabs into slots.
STEP 8:
Install a minimum of (2) supplied screws
into the pendant mounting plate tabs on the
underside of the luminaire. See Figure 6.
STEP 9:
Cut off any excess length of leads from the
top of the customer supplied pendant kit.
STEP 10:
Make wiring connections to customer
supplied junction box per “Electrical
Connections” section.
STEP 11:
Using customer supplied hardware, attach
pendant kit and luminaire to customer
supplied junction box.
SYSTEM COMMISSIONING AND
CUSTOMIZING
System commissioning is required for the
fixtures to be recognized on the Simply SNAP
network. Contact Cree Lighting at 800-236-
6800 for more details about commissioning
and customization.
EMERGENCY LIGHTING CONTROLS
If luminaire is provided with 2 ELCD leads
in the junction box and Emergency Lighting
bypass control is needed, please contact
Cree Lighting at 800-236-6800 for detailed
instructions.
LED LUMINAIRE MAINTENANCE
CLEANING INSTRUCTIONS:
Regular cleaning of the light LED luminaire is
required to keep the LED luminaire operating
optimal optical performance.
• Cleaning intervals to be no more than
twelve months for IESNA Clean category
environments and more frequently for
dirtier conditions.
• Care should be taken as to not damage
the lens and/or the interior reflective
surface as these components are critical
for optimal performance.
• Do not use any type of cleaners or stiff
brushes on the LED luminaire. Use water
with mild detergent and soft cloth.
FCC NOTICE
CAUTION: Changes or modifications not
expressly approved could void your authority
to use this equipment.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
This equipment has been tested and found
to comply with the limits for a Class A
digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference when the equipment is
operated in a commercial environment. This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with the instruction
manual, may cause harmful interference
to radio communications. Operation of this
equipment in a residential area is likely to
cause harmful interference in which case
the user will be required to correct the
interference at his own expense.
CAN ICES-005 (A)/NMB-005 (A)
The following statement applies to all part
numbers ending in -ENC:
RF EXPOSURE NOTICE
To comply with the FCC/IC RF exposure
compliance requirements, this device and its
antenna must not be co-located or operating
to conjunction with any other antenna or
transmitter. This equipment should be
installed and operated with minium distance
5cm between the radiator & your body. No
other antenna is authorized for use with this
product.

4 of 4 LPN00305X0012A0_A
www.creelighting.com
© 2019 Cree Lighting, A company of IDEAL INDUSTRIES. All rights reserved. For informational purposes only. Content
is subject to change. See www.creelighting.com/warranty for warranty and specifications. Cree®and the Cree logo are
registered trademarks of Cree, Inc.
ELECTRICAL CONNECTIONS
STEP 1:
NOTE: USE MIN. 90°C SUPPLY CONDUCTORS for 120-277V
luminaires and USE MIN 75°C SUPPLY CONDUCTORS for the
347V luminaires.
Make the following Electrical Connections for products rated
120V, 277V, or 347V (Line-Neutral), or rated 208V, or 240V
(Line-Line):
a. For products rated 120V, 277V or 347V, connect the Black
lead from the luminaire to the LINE supply wiring inside
the junction box or for products rated 208V, or 240V,
connect to the HOT 1 supply wiring.
b. For products rated 120V, 277V or 347V, connect the White
lead from the luminaire to the NEUTRAL supply wiring
inside the junction box or for products rated 208V, or
240V, connect to the HOT 2 supply wiring.
c. Connect the Green or Green/Yellow lead from the
luminaire to the GROUND supply wiring inside the
junction box.
STEP 2:
The Blue/White low-voltage wires are used to override the
luminaire to full output. They may be connected to third-party
equipment to provide an override signal to the luminaire. Do not
wire the Blue/White wires to high-voltage. The wires should be
capped if not being used.
• SHORT: Luminaire overrides to full output
• OPEN: Luminaire operates normally
LINE
OR HOT 1
GREEN
LINE-BLACK
GROUND-GREEN
NEUTRAL-WHITE
NEUTRAL
OR HOT 2
SUPPLY WIRING
LUMINAIRE
BLUE W/WHITE
BLUE W/WHITE
