CREE LIGHTING VG Series User manual

VG Series
LED Parking Luminaire
Junction Box Mount (JB)
1 of 2 LPN00100X0001A0_B
INSTALLATION INSTRUCTIONS
INSTRUCTIONS D’INSTALLATION
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed including
the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. To reduce the risk of electrical shock, turn off power supply before installation or
servicing.
DANGER – Risque de choc – Couper l’alimentation avant l’installation.
2. This luminaire must be installed in accordance with the NEC or your local electrical code.
If you are not familiar with these codes and requirements, consult a qualied electrician.
Ce produit doit être installé conformément à NEC ou votre code électrique local. Si vous
n’êtes pas familier avec ces codes et ces exigences, veuillez contacter un électricien
qualié.
3. DO NOT lift luminaire by the power leads.
4. DO NOT carry or lift luminaire by wireform. Wireform is only for supporting luminaire while
making wiring connections.
SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE
TO INSTALL:
LUMINAIRE INSTALLATION
STEP 1:
Using customer supplied hardware,
attach mounting plate to customer
supplied junction box with the arrow
on the underside of the Mounting
Plate directed parallel to vehicle
traffic. See Figure 1 and 2.
STEP 2:
Peel back and remove adhesive
backing on 3/16” thick gasket,
provided in hardware bag, and attach
it centered to underside of Mounting
Plate covering all slots and screw
heads. See Figure 1.
STEP 3:
For hands-free wiring locate the
wireform on luminaire and remove
tape. Attach it to the hook on the
Mounting Plate. See Figure 3.
STEP 4:
Make wiring connections per
“Electrical Connections” section.
STEP 5:
After wiring connections have been
made no need to remove wireform
from hook. DO NOT let the luminaire
hang by the power leads.
STEP 6:
Bring luminaire up to Mounting Plate,
rotate luminaire until the arrow on the
inside of the Mounting Plate points to
the recessed area nearest to the latch
on the luminaire. See Figure 4.
1
3
Mounting Plate
4
Wireform
Latch
Mounting
Plate Hook
Mounting Plate
Mounting Plate
Arrow
Latch
Underside View of
Mounting Plate
3/16” Thick Gasket
2
Arrow On Mounting Plate
Pointing Parrallel To
Traffic

2 of 2 LPN00100X0001A0_B
www.creelighting.com
© 2019 Cree Lighting, A company of IDEAL INDUSTRIES. All rights reserved. For informational purposes only. Content
is subject to change. See www.creelighting.com/warranty for warranty and specifications. Cree®and the Cree logo are
registered trademarks of Cree, Inc.
STEP 7:
Attach luminaire to the Mounting Plate by pressing up on
the luminaire until the slots on the Mounting Plate engage
with the clips on the luminaire and rotate until latch locks
securely. See Figure 5.
NOTE: May require extra pressure on luminaire to engage
clips into Mounting Plate slots.
NOTE: If the Mounting Plate slots become deformed during
installation, slightly reopen the slots back up using a
screwdriver to ensure proper install of luminaire.
STEP 8:
Lightly pull on the luminaire to verify luminaire is securely
mounted.
FIXTURE SERVICING AND MAINTENANCE
STEP 1:
If supply wiring splices need to be inspected or if luminaire
needs to be removed, fully loosen the tamperproof screw
and slide out the latch. Then, rotate luminaire to disengage
from Mounting Plate. See Figure 5.
STEP 2:
To re-install luminaire, when finished with servicing or
maintenance, engage and tighten the latch’s tamperproof
screw and follow Step 1-7 in “Luminaire Installation”
section above.
5
ELECTRICAL CONNECTIONS
STEP 1:
Make the following Electrical Connections :
a. For 120/277/347V connect the black fixture lead to the
voltage supply position of the junction box (Hot 1 for
208/240/480V wiring).
b. For 120/277/347V Connect the white fixture lead to the
neutral supply position of the junction box (Hot 2 for
208/240/480V wiring).
c. Connect the green or green/yellow ground lead to the green
wire position of the junction box.
d. If Dimming is an option; connect the violet dimming positive
lead to the supply dimming positive lead.
e. If Dimming is an option; connect the grey dimming negative
lead to the supply dimming negative lead.
Slots
Luminaire
Clips
Slots
Mounting
Plate
Tamerproof
screw
