Cree EDGE XPS Transportation Series User manual

CREE EDGE™
XPS Transportation Series
Tunnel Mount
1 of 2 CI367X04R1
INSTALLATION INSTRUCTIONS
TO INSTALL:
MOUNTING - DIRECT MOUNT
STEP 1:
Remove the (4) nuts securing the retained Mounting Bracket Bolts to
the top of the mounting bracket. Remove the top piece of the mounting
bracket assembly from the fixture. See Figure 1.
STEP 2:
Align the mounting bracket removed in Step 2 on an appropriate
mounting surface. Using customer supplied 3/8” minimum mounting
bolts, secure the luminaire to the mounting surface. See Figure 2.
STEP 3:
Once the mounting bracket is secured to the mounting surface, re-
secure the luminaire using the nuts and screws removed in Step 2 to
180 in./lbs..
STEP 4:
Connect leads of supplied extension cordset to electrical supply per
the Electrical Connections section on the back page.
10.0
6.0
1Mounting Bracket
Bolts (4)
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be
followed including the following:
READ AND FOLLOW ALL SAFETY
INSTRUCTIONS
1. DANGER- Risk of shock- Disconnect power before installation.
DANGER – Risque de choc – Couper l’alimentation avant l’installation.
2. This luminaire must be installed in accordance with the NEC or your local
electrical code. If you are not familiar with these codes and requirements,
consult a qualied electrician.
Ce produit doit être installé conformément à NEC ou votre code électrique
local. Si vous n’êtes pas familier avec ces codes et ces exigences, veuillez
contacter un électricien qualié.
3. Damage to luminaire will result when improper voltage is applied. Verify
luminaire is suitable for supply voltage by checking electrical label on luminaire.
SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE
Mounting Holes For Customer
Supplied 3/8" Mounting Bolts
2

2 of 2 CI367X04R1
lighting.cree.com
© 2019 Cree, Inc. All rights reserved. For informational purposes only. Content is subject to change.
See http://lighting.cree.com/warranty for warranty and specifications. Cree®and the Cree Logo are registered trademarks, and
the Cree EdgeTM is a trademark of Cree, Inc.
ELECTRICAL CONNECTIONS
STEP 1:
Connect the leads of the supplied extension cordset to the
electrical supply using customer supplied 90°C minimum rated
wire connectors and suitable fittings :
a. Connect the black cordset lead to the voltage supply.
b. Connect the white cordset lead to the neutral supply.
c. Connect the green or green/yellow ground lead to
the green wire.
STEP 2:
Connect cordset to luminaire using supplied threaded adapter
and tighten rings securely. See Figure 1.
LINE-BLACK
GROUND-GREEN
NEUTRAL-WHITE
SUPPLY WIRING
THREADED
ADAPTER
EXTENSION
CORDSET
LUMINAIRE
