CrestronABVR-1
Adagio®BalancedVideoReceiver
Operations Guide

Adagio®Balanced Video Receiver Crestron ABVR-1
Contents
Adagio®Balanced Video Receiver: ABVR-1 1
Introduction ...............................................................................................................................1
Features and Functions................................................................................................1
Applications.................................................................................................................2
Specifications ..............................................................................................................2
Physical Description....................................................................................................3
Industry Compliance ...................................................................................................7
Setup..........................................................................................................................................8
CAT5 Wiring...............................................................................................................8
Installation...................................................................................................................8
Hardware Hookup .......................................................................................................8
Problem Solving ......................................................................................................................11
Troubleshooting.........................................................................................................11
Reference Documents................................................................................................12
Further Inquiries........................................................................................................12
Future Updates ..........................................................................................................12
Return and Warranty Policies..................................................................................................13
Merchandise Returns / Repair Service ......................................................................13
CRESTRON Limited Warranty.................................................................................13
All brand names, product names and trademarks are the property of their respective owners.
©2009 Crestron Electronics, Inc.
i •Contents Operations Guide – DOC. 6792A

Crestron ABVR-1 Adagio®Balanced Video Receiver
Adagio®Balanced Video
Receiver: ABVR-1
Introduction
The ABVR-1 is an active balanced-to-unbalanced video converter
designed to enable the connection of any Crestron Home®CAT5
balanced video source to a conventional RCA input. Connected at the
input of an Adagio Media System or CNX-PVID8 Video Distribution
Switcher, the ABVR-1 allows a CEN-IDOCV Interface for Apple®
iPod®, CEN-ISERVER Crestron iServer™ Network Audio Server,
CEN-IDOCV-DSW Wall Mount Interface for Apple iPod or other
Crestron Home CAT5 balanced video source to be installed up to 500
feet (152 m) from the central equipment location.
Features and Functions
•Converts Category 5 (CAT5) balanced video to RCA
unbalanced video (Component (YPbPr), S-video (Y/C), or
composite video
•Small compact size
Operations Guide – DOC. 6792A Adagio®Balanced Video Receiver: ABVR-1 •1

Adagio®Balanced Video Receiver Crestron ABVR-1
Applications
The following diagram shows an ABVR-1 and an ABAR-1 in a
residential application.
ABVR-1 and ABAR-1 in a Residential Application
Specifications
Specifications for the ABVR-1 are listed in the following table.
ABVR-1 Specifications
SPECIFICATION DETAILS
Signal Types Component (YPbPr), S-video (Y/C), or
composite video; digital audio*
Video/HDTV Formats 480i (NTSC), 576i (PAL), 480p, 576p,
720p, 1080i*
Digital Audio Format S/PDIF coaxial*
Power Requirements 3 Watts (0.13 Amps) @ 24 Volts DC
May be powered by Cresnet or
dedicated power supply (not
included)
Environmental
Temperature
Humidity
Heat Dissipation
41° to 104°F (5° to 40°C)
10% to 90% RH (non-condensing)
10 BTU/Hr
(Continued on following page)
2 •Adagio®Balanced Video Receiver: ABVR-1 Operations Guide – DOC. 6792A

Crestron ABVR-1 Adagio®Balanced Video Receiver
ABVR-1 Specifications (Continued)
SPECIFICATION DETAILS
Enclosure Metal with label overlay, freestanding
or surface mount with (4) integral
mounting flanges
Dimensions
Height
Width
Depth
1.43 in (3.64 cm)
3.91 in (9.94 cm)
4.52 in (11.47 cm)
Weight 10 oz (284 g)
* Actual output signals dependent upon the output capabilities of the CH source
device.
Physical Description
This section provides information on the connections, controls and
indicators available on your ABVR-1.
ABVR-1 Physical View
Operations Guide – DOC. 6792A Adagio®Balanced Video Receiver: ABVR-1 •3

Adagio®Balanced Video Receiver Crestron ABVR-1
ABVR-1 Overall Dimensions
3.50 in
(8.89 cm)
3.50 in
(8.89 cm)
4.52 in
(11.47 cm)
1.43 in
(3.64 cm)
3.91 in
(9.94 cm)
Connectors, Controls & Indicators
# CONNECTORS1,
CONTROLS &
INDICATORS
DESCRIPTION
1 24VDC
(1) 2-pin 3.5 mm detachable
terminal block
24 Volt DC power input (power
supply not included)
(Continued on following page)
4 •Adagio®Balanced Video Receiver: ABVR-1 Operations Guide – DOC. 6792A

Crestron ABVR-1 Adagio®Balanced Video Receiver
Connectors, Controls & Indicators (Continued)
# CONNECTORS1,
CONTROLS &
INDICATORS
DESCRIPTION
2 VIDEO IN2
PIN
1PIN
8
(1) 8-pin RJ-45 female,
shielded
CAT5 balanced video input port
Input Impedance: 100 ohms per
pair
Connect to any “CH” CAT5
video output port
Maximum Cable Length: 500 ft
(152 m)3
3 VIDEO ADJUST (1) rotary potentiometer for
adjustment of CAT5 video input
compensation
4 PWR LED (1) green LED, indicates 24
Volts DC power supplied from
Cresnet or power supply
5 VIDEO OUT (3) RCA female comprising (1)
component/S-video/composite
video output4
Output Impedance: 75 ohms
Output Level: 1 Vp-p nominal
6 SPDIF
(1) RCA female comprising (1)
coaxial digital audio output4
Output Impedance: 75 ohms
Output Level: 0.5 Vp-p nominal
1. Interface connector for the 24VDC port is provided with the unit.
Operations Guide – DOC. 6792A Adagio®Balanced Video Receiver: ABVR-1 •5

Adagio®Balanced Video Receiver Crestron ABVR-1
2. This eight-pin RJ-45 port provides connectivity to a device with a CH input port
or a Crestron device with a CAT5 video input. This port provides component or
composite balanced output over CAT5 wiring. Refer to the following table for
connector pinouts.
RJ-45 PIN
NUMBER WIRE COLORS (568B) COMPOSITE COMPONENT
1 WHITE/ORANGE + Composite + Y
2 ORANGE - Composite - Y
3 WHITE/GREEN N/A + Pb
4 BLUE N/A + Pr
5 WHITE/BLUE N/A - Pr
6 GREEN N/A - Pb
7 WHITE/BROWN + SPDIF + SPDIF
8 BROWN - SPDIF - SPDIF
3. Maximum cable length for CAT5 video is 500 feet (152 m) using CresCAT®IM
or quality CAT5e cable.
4. Actual output signals dependent upon the output capabilities of the CH source
device.
6 •Adagio®Balanced Video Receiver: ABVR-1 Operations Guide – DOC. 6792A

Crestron ABVR-1 Adagio®Balanced Video Receiver
Industry Compliance
As of the date of manufacture, the ABVR-1 has been tested and found to
comply with specifications for CE marking and standards per EMC and
Radiocommunications Compliance Labelling.
Federal Communications Commission (FCC) Compliance Statement
This device complies with part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference and (2) this device must accept any interference received,
including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the
manufacturer responsible for compliance could void the user’s authority
to operate the equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and if not installed
and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Operations Guide – DOC. 6792A Adagio®Balanced Video Receiver: ABVR-1 •7

Adagio®Balanced Video Receiver Crestron ABVR-1
Setup
CAT5 Wiring
Category 5 (CAT5) wiring is a twisted pair cable designed for Ethernet
networks. These networks operate at speeds of up to 100 Megabits per
second (Mbps) using the 100BASE-T standard. Crestron takes advantage
of this specification for a variety of audio and video applications.
Crestron recommends using CresCAT-IM (or D) wire for transmitting
video signals from the CH port.
When using a Crestron wiring solution, the CresCAT-IM (or D) wire can
carry video signals up to 500 feet (152 meters) (observe distance
limitations based upon power consumption for the device in use).
For more information, refer to the latest version of the Crestron CAT5
Wiring Reference Guide (Doc. 6137), which is available for download
from the Crestron website (www.crestron.com/manuals).
Installation
The ABVR-1 can be mounted in a rack or to any surface using the
integral mounting flanges. Mounting hardware is not provided.
Hardware Hookup
Connect the
Device Make the necessary connections as called out in the illustration that
follows this paragraph. Apply power after all connections have been
made.
When making connections to the ABVR-1, use Crestron power supplies
for Crestron equipment.
8 •Adagio®Balanced Video Receiver: ABVR-1 Operations Guide – DOC. 6792A
